Stardom SR4-WBS3 Bedienungsanleitung

SR4-WBS3

User Manual

»STARDOM Safe Capsule Series User Manual .....................

»STARDOM Safe Capsule Serie Bedienungsanleitung ...........

»Série STARDOM Safe Capsule Manuel de l’utilisateur .........

»Manual de usuario de STARDOM Safe Capsule Serie ..........

»STARDOM Safe Capsule .......................

»STARDOM Safe Capsule シリーズユーザーマニュアル................

»STARDOM Safe Capsule....................

SOHORAID SR4 User Manual

» SOHORAID SR4 Series User Manual ............................................................3

» SOHORAID SR4 Serie Bedienungsanleitung .................................................9

» Série SOHORAID SR4 Manuel de l’utilisateur ..............................................15

» Manual de usuario de SOHORAID SR4 Series .............................................21

» SOHORAID SR4 系列產品使用說明 ..............................................................27

» SOHORAID SR4 シリーズユーザーマニュアル ............................................33

» SOHORAID SR4 시리즈 사용 설명서 ............................................................39

» SOHORAID SR4 系列产品使用说明 ..............................................................45

Thank you for purchasing STARDOM products. This manual will introduce the SOHORAID SR4 Series.

Before using your SOHORAID SR4, please read this manual thoroughly. Although all information

contained in this user manual has been carefully verified before publishing, however, the actual product

specification will be based on the time of delivery from STARDOM. Any updates to the product

specifications or relevant information may be found on www.stardom.com.tw. Products are subject to

change without prior notifications.

If you have any questions regarding the products of STARDOM, or you would like to know the latest

product information, user manual update, or firmware update, please contact your local supplier or visit

www.stardom.com.tw for further information.

1. Package Contents and Product Views

2. Environmental Requirements

3. Hardware Requirements and Precautions

4. Hardware Installation

5. Description of Front Panel Operation and LCD Information

6. Replacement of Malfunctioning Drive and Data Rebuild Instructions

7. System Temperature Overheat and Fan Failure Management

8. Visual Status Indicator Definitions

9. Frequently Asked Questions

Open the package and you should find the following:

SR4-WBS3

SR4-WBS3ｘ1 ( with removable drive tray enclosed x 4 )

Firewire 800 (1394b) Cable ｘ1

e-SATA Cable ｘ1

USB 3.0 Cable ｘ1

AC Power Cable ｘ1

Accessories Kit

User Manual

Please make sure that the contents listed above are not damaged or missing. If you should find damages

or missing contents, please contact your supplier immediately.

Introduction

Table of Contents

1. Package Contents and Product Views

SOHORAID SR4 User Manual

Front and Rear View

A. Hard drive status indicator B. Removable drive tray C. Key access opening

D. LCM display E. UP button F. DOWN button

G. ENTER button H. ESC button I. Power indicator

J. Alarm indicator K. USB3.0 interface connection

L. e-SATA interface connection M. FireWire 800 (1394b) interface connection

N. Mute button O. Power Switch P. Power socket

Q. Cooling fan R. Anti-theft cord slot

Drive Position

Drive position (1) Drive position (2) Drive position (3) Drive position (4)

Storage Mode Definition

Independent mode ( JBOD ) : Four discrete storage capacities.

Speed mode ( Raid 0 ) : One big independent data storage with without data protection.

Safe mode ( Raid 1 ) : One independent data storage with data protection.

The secondary FireWire 800 (1394b) connection on the SR4-WBS3 is provided to connect and extend to

another FireWire 800 (1394b) device.

Operating Temperature : 0 ∼40 ℃(32 ~ 104 ℉)

Storage Temperature : -10 ∼70 ℃(14 ~ 158 ℉)

Line Voltage : 100 ∼240V AC

2. Operating Information

SOHORAID SR4 User Manual

1. Only one interface connection may be used at once per computer system.

2. RAID volume formation utilizes the capacity of whichever hard drive has the smallest and then

multiply that capacity by three for RAID 5, four for RAID 0, to form a large volume, therefore, it is

recommended to only install hard drives of the same brand and specification for all drive position prior

to use. Moreover, when you need to replace with a new hard drive, please be sure to purchase one

with the same specification, capacity and brand. If these conditions can’t be met, select one that’s at

least 20 GB greater in capacity.

3. The actual storage capacity of SR4-WBS3 recognized by the system may differ from the total capacity

stated on the hard drives once the drives have been formatted.

4. When connected to the computer system, it’s prohibited to remove, insert or swap the hard drive

while data transfer is being performed.

5. It’s prohibited to change the positioning of the drives once the initial installation has been completed

as the changes made to the drive positions may destroy the RAID formation.

6. If you discover that hard drive failure is taking place, go to Section 6 “Replacement of Malfunctioning

Drive and Data Rebuild Instructions” and follow the steps accordingly.

7. Whenever turning off or unplugging the SR4-WBS3 from your computer system becomes necessary,

always remember to safely remove it from your operating system first.

8. In RAID 5 mode, the system allows one single hard drive failure. If multiple drive failures occur at

once, it’s likely that all data stored in the system have been destroyed or lost. In RAID 0 mode, if one

hard drive failure occurs, then all data maybe destroyed or lost. If this happens, we recommend you

to consult with a professional hard drive data recovery specialist to see if your data may be

recoverable.

9. It is highly recommended for users to back up important data contained within the SR4-WBS3 unit on

a regular basis or whenever the user feels necessary to a remote or a separate storage device.

Stardom will not be responsible for any lost of data caused during the use of the unit or the recovery

of the data lost.

Please follow the instructions below to complete the hardware installation.

Step 1 Open the package and take out the product making sure that all the enclosed contents are not

damaged or missing. Should you find damages or missing contents, please contact your supplier

immediately.

Step 2 Place the system on a stable surface. Ensure that it is well ventilated without blockage to the vent

and kept away from areas near water and damage prone areas.

Step 3 Use the key included in the accessory kit and inserted into the key access opening to eject the

removable drive tray latch and extract the removable drive tray.

3. Hardware Requirements and Precautions

4. Hardware Installation

SOHORAID SR4 User Manual

Step 4 Mount your hard drives onto the removable drive tray and secure it with the screws included in the

accessory kit to avoid any damage to the hard drive due to accidental movements.

Step 5 When the hard drive installation has been completed, insert the hard drive tray into the system

horizontally and secure the latch into place.

Step 6 Connect the AC power cable to the SR4-WBS3, and then plug the AC power to the wall socket.

Boot-up the unit.

Step 7 Set the storage mode using the LCD and buttons on the front (please refer to section 5 for front

panel and LCD information).

Step 8 Connect the cable to the PC and the SR4-WBS3 port.

Step 9 After boot-up, your operating system will automatically detect the storage capacity of your hard

drives. Please follow the operating system instructions to configure and format your drives. The

formatted drives can be configured for the RAID setup.

Level 0

Level 1

Level 2

Level 3

Level 4

EXTERNAL 4

BAY

HARDWARE

RAID

Quick Setup

Create One RAID

RAID 0 / RAID 5

Select Disk

EXTERNAL 4

BAY

HARDWARE

RAID

Quick Setup

Delete All RAID

EXTERNAL 4

BAY

HARDWARE

RAID

Disk Manager

Identify Disk

Disk 1

Check Disk LED

EXTERNAL 4

BAY

HARDWARE

RAID

Disk Manager

Identify Disk

Disk 2

Check Disk LED

EXTERNAL 4

BAY

HARDWARE

RAID

Disk Manager

Identify Disk

Disk 3

Check Disk LED

EXTERNAL 4

BAY

HARDWARE

RAID

Disk Manager

Identify Disk

Disk 4

Check Disk LED

EXTERNAL 4

BAY

HARDWARE

RAID

Disk Manager

Show Disk Info

< Disk Info >

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Identify RAID

Select RAID

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Create RAID

RAID 0 / RAID 5

Select Disk

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Delete RAID

Select RAID

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

RAID Info

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Change RAID Pwd

< Password > for RAID setup

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Rebuilding Priority

Highest/High/Medium/Low/Lowest

EXTERNAL 4

BAY

HARDWARE

RAID

RAID Manager

Standby Timer

< 99999min >

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

System Info

Firmware Version

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Change Password

< Password > for System Info

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Logout From Menu

< Y or N >

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Alarm Control

Mute the Buzzer

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Hardware Monitor

Voltage Monitor

< 3.3V / 5V / 12V >

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Hardware Monitor

Temp. Monitor

< Temp. >

EXTERNAL 4

BAY

HARDWARE

RAID

System

Manager

Hardware Monitor

FAN Monitor

<Fan Speed/Fan

Level>

5. Description of Front Panel Operation and LCD Information

SOHORAID SR4 User Manual

When a front hard drive indicator has lit up red and the audio alarm sounds, this could mean the indicated

hard drive may be malfunctioning. If this occurs, you may press the mute button at the rear of the system

to shut off the audio alarm and power off the system immediately if in the allowed operational state, and

then re-power on the system to double check and see if in fact the indicated hard drive has

malfunctioned. If the problem persists, please turn off the system and follow the directions below :

Step 1 Remove the drive tray containing the malfunctioned hard drive and disassemble the hard drive

from drive tray.

Step 2 Mount the new hard drive onto the tray and insert it back to the empty drive position of the SR4,

then push the latch into place making sure it is secured and locked.

Step 3 In RAID 5 mode, when you turn the system on, the hard drive status indicator of the replacement

drive will interchangeably blink red and purple to inform that the data is being rebuilt to the

replacement drive. During data rebuild, you may operate the SR4-WBS3 as normal. When the

indicator stops, the data rebuild process has been completed.

If the alarm indicator has lit up red and the audio alarm sounds, this could mean that either a system fan

has stopped operating entirely or the system temperature has exceeded over the default temperature of

60°C. When this occurs, you may press the mute button at the rear of the system to shut off the audio

alarm and power off the system immediately if in the allowed operational state to let the system cool.

Check and see if the overall operation environment is well ventilated and make sure there are no

blockages to the enclosed fan and then re-power on the system to continue use. If the problem persists,

please turn off the system and contact your supplier or the STARDOM tech support for further assistance.

States

Front LED

buzzer

States

Power LED

Alarm LED

HDD LED

buzzer

Power on

Blue

------

Blue flash -> Blue

1 long when

booting finished

No disk

Blue

------

Disk Fail

Blue

------

Red

------

RAID Fail

Blue

------

Red

4 short

Disk Idle

Blue

------

Blue

------

Format

Blue

------

Blue flash

------

Access

Blue

------

Blue flash

------

Fan Fail

Blue

Red

Blue

4 short

Over Temp

Blue

Red

Blue

4 short

Rebuilding

Blue

------

Source: Blue flash

Target: Blue and Purple light on alternatively

------

6. Replacement of Malfunctioning Drive and Data Rebuild Instructions

7. System Temperature Overheat and Fan Failure Management

8. Visual Status Indicator Definitions

SOHORAID SR4 User Manual

Q1. Which drive format should I choose to format the hard drives in the SR4-WBS3?

A : It depends on the computer system you most often use. See the below suggestions:

1. Use NTFS format for Windows 2000/XP/Vista/Windows 7 system

2. Use HFS+ (Mac OS Extended) format for a Mac OS X system

3. Choose FAT32 format if you’ll use the SR4 in both Windows and Mac environments (the maximum

size of one single file may not exceed 4 GB).

Q2. Why can’t my SR4-WBS3 reach the transfer performance speed of 200 MB/s via e-SATA

interface as stated on your website?

A : 1. Please first check if your PCI-E SATA host adapter would only support PCI-E (1X).

This type of host adapters cannot reach the transfer performance speed beyond 135MB/s.

2. It is recommended to purchase STARDOM SJ20-x8 (PCI-E 8X) host adapter to enhance the

transfer speed performance via e-SATA.

3. The SR4-WBS3 will need to be set to the RAID 0 mode also.

9. Frequently Asked Questions

SOHORAID SR4 User Manual

Vielen Dank für den Kauf eines STARDOM Produkts. Dieses Bedienungsanleitung beschreibt das

STARDOM SOHORAID SR4 Produkt. Bevor Sie dieses Produkt benutzen, lesen Sie diese Anleitung bitte

sorgfältig durch. Obwohl alle Informationen in dieser Anleitung vor der Veröffentlichung sorgfältig

überprüft wurden, beziehen sich die tatsächlichen Produktspezifikationen auf die Zeit der Auslieferung

durch STARDOM. Aktualisierungen der Produktspezifikationen können auf der Webseite

www.stardom.com.tw gefunden werden. Änderungen der Produkte ohne vorherige Nachricht vorbehalten.

Wenn Sie Fragen zu den Produkten von STARDOM haben, oder mehr über die aktuellsten

Produktinformationen, Aktualisierungen der Bedienungsanleitung oder Firmwareupdates erfahren

möchten, kontaktieren Sie bitte Ihren Händler vor Ort oder besuchen Sie www.stardom.com.tw für weitere

Informationen.

1. Packungsinhalt und Produktansichten

2. Betriebsbedingungen

3. Hardwarevoraussetzungen und Vorsichtsmaßnahmen

4. Hardwareinstallation

5. Description of Front Panel Operation and LCD Information

6. Austausch eines defekten Laufwerks und Anweisungen zur Datenwiederherstellung

7. Verhalten bei Systemüberhitzung und Lüfterausfall

8. Beschreibung der visuellen Statusanzeige

9. Oft gestellte Fragen

Öffnen Sie das Paket und Sie sollten die folgenden Dinge vorfinden:

SR4-WBS3

SR4-WBS3 x 1 (mit integriertem Wechselrahmen x 4)

FireWire 800 (1394b) Kabel x 1

eSATA Kabel x 1

USB 3.0 Kabel x 1

Stromkabel x 1

Zubehörset

SR4-WBS3 Bedienungsanleitung

Bitte stellen Sie sicher, dass die oben aufgelisteten Inhalte nicht beschädigt sind oder fehlen.

Falls Schäden oder fehlende Inhalte festgestellt werden, kontaktieren Sie bitte umgehend Ihren Händler.

Über diese Anleitung

Inhaltsverzeichnis

1. Packungsinhalt und Produktansichten

SOHORAID SR4 User Manual

Vorder- und Rückansichten

A. Festplatten-Statusanzeige B. Wechselrahmen

C. Schlüsselzugangsöffnung D. LCD Anzeige

E. UP Taste F. DOWN Taste G. ENTER Taste H. ESC Taste

I. Netzanzeige J. Alarmanzeige

K. USB 3.0 Anschluss L. e-SATA Anschluss M. FireWire 800 (1394b) Anschlüsse

N. Stummtaste O. Netzschalter P. Netzbuchse Q. Kühllüfter

R. Steckplatz für Kensingtonschloss

Laufwerkposition

Laufwerkposition 1 Laufwerkposition 2

Laufwerkposition 3 Laufwerkposition 4

Speichermodus Beschreibung

Unabhängiger Modus ( JBOD ): Vier unabhängige Speicherkapazitäten.

Sicherheitsmodus (RAID 5): Großer Laufwerksspeicher mit Datenschutz.

Geschwindigkeitsmodus (RAID 0): Großer Laufwerksspeicher mit hohem Durchsatz, aber ohne

Datenschutz.

Der sekundäre FireWire 800 (1394b) Anschluss des SR4-WBS3 wird zum Anschluss anderer FireWire

800 (1394b) Geräte verwendet.

Betriebstemperatur : 0 ~ 40 ℃(32 ~ 104 ℉)

Lagertemperatur : -10 ~ 70 ℃(14 ~ 158 ℉)

Spannung : 100 ~ 240V AC

2. Betriebsbedingungen

SOHORAID SR4 User Manual

Andere Handbücher für SR4-WBS3

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Stardom Lagerung Handbücher

Stardom

Stardom SA2TB3 Bedienungsanleitung

Stardom

Stardom DR2-B31 Bedienungsanleitung

Stardom

Stardom SOHORAID MR2-B31BP Series Bedienungsanleitung

Stardom

Stardom SOHORAID SR3MSB-B31 Bedienungsanleitung

Stardom

Stardom SOHORAID ST4-TL3+ Bedienungsanleitung

Stardom

Stardom SOHORAID MR2-B31BP Series Bedienungsanleitung

Stardom

Stardom SOHORAID ST2-B31+ Bedienungsanleitung

Stardom

Stardom SOHORAID ST2-TB3 Bedienungsanleitung

Stardom

Stardom SOHORAID ST2-B31+ Bedienungsanleitung

Stardom

Stardom sohoraid ST2-B31 Bedienungsanleitung

Stardom

Stardom SOHORAID SR4-B31A Bedienungsanleitung

Stardom

Stardom iTANK MT1-B31BP Bedienungsanleitung

Stardom

Stardom SOHORAID DR2-TB3 Bedienungsanleitung

Stardom

Stardom SOHORAID SR4-SB3PLUS Bedienungsanleitung

Stardom

Stardom SOHORAID DR2-TB3 Bedienungsanleitung

Stardom

Stardom SR2611 Series Bedienungsanleitung

Stardom

Stardom SOHORAID DR5-WBS3 Bedienungsanleitung

Stardom

Stardom itank i310 Bedienungsanleitung

Stardom

Stardom SR2-B31 Bedienungsanleitung

Stardom

Stardom SOHOTANK US2-B32 Bedienungsanleitung

Stardom

Stardom SOHORAID DR8-TB3 Bedienungsanleitung

Stardom

Stardom SA2TB3 Bedienungsanleitung

Stardom

Stardom ST4-B31 Bedienungsanleitung

Stardom

Stardom Sohoraid SR4 Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
