INSTRUCTIONS FOR USE AND CARE + RECIPES P.2

INSTRUCTIONS POUR L’USAGE ET L’ENTRETIEN + RECETTES P.20

ELECTRIC PRESSURE COOKER

AUTOCUISEUR ÉLECTRIQUE

Pressure release valve

(steam vent)

Float valve

Lid

Lid handle

Non-stick inner

cooking pot

Outer pot

Base

Digital control panel

Heating plate

Detachable power cord

Steaming tray

Measuring cup

Serving spoon

Anti-blocking nut

Sealing ring

Float valve

silicone gasket

OPERATING AND SAFETY INSTRUCTIONS

Item no. Voltage (V) Wattage (W) Frequency (Hz)

024600 120 1200 60

IMPORTANT SAFEGUARDS

READ THE INSTRUCTIONS BEFORE USE

WARNING: To reduce the risk of ﬁre, electrical shock, serious personal injury and/or

property damage:

1. To protect against electric shock, do not immerse power cord, plug or product in

water or any other liquid.

2. Do not touch hot surfaces. Use protective oven mitts or gloves to avoid burns or

serious personal injury. Always use lid handle or side handles.

3. Keep the product out of the reach of children and pets. This product is not intended

for use by children. Close adult supervision is necessary when any appliance is used

near children.

4. This appliance cooks under pressure. Ensure the minimum quantity of food and liquid

is at least 1/5 full. Do not ﬁll the appliance over 4/5 full. Refer to markings inside the

cooking pot. Do not overﬁll the appliance as it may clog the pressure release valve

and develop excess pressure.

5. Before operating, ensure the sealing ring and pressure release valve are properly

installed. Ensure the lid is tightly closed before operating.

6. Always check, pressure release valve, anti-blocking nut, ﬂoat valve for clogging before use.

7. Allow the appliance to completely cool down and make sure internal pressure

is released before opening the lid. If the lid is difﬁcult to turn, it is an indication

that the appliance is still pressurized. DO NOT force it open as it may cause

serious injuries

8. DO NOT use the appliance to pressure fry with oil. This may cause serious injuries.

9. Unplug from electrical outlet before cleaning or when not in use. Allow the unit to

cool down completely before assembling, disassembling, relocating.

10. Do not operate the product if it has a damaged power cord or plug, or after the

appliance malfunctions or has been damaged in any manner. Do not attempt to

examine or repair this product yourself. Please call the customer service number

provided in this user manual.

11. Do not leave the product unattended while it is in use. DO NOT move the appliance

while in use.

12. Do not touch, cover or obstruct the pressure release valve as it is extremely hot and

may cause scalding.

13. Use extreme caution when opening the lid and releasing steam manually as hot

steam will escape and may cause scalding. Use protective oven mitts or gloves to

avoid burns or serious personal injury. Always use utensils to handle hot food.

14. The cooking pot is designed for use with this appliance only. It must never be used

on a stovetop, range top, hot gas or electric burner or in a heated oven. It may warp

and result in injuries. To avoid serious injuries, always cook inside the removable

cooking pot.

15. Always make sure the outside of the cooking pot is dry prior to use. If the pot

is returned to the appliance when wet, it may damage or cause the product to

malfunction.

16. Do not plug or unplug the product into/from the electrical outlet with a wet hand.

17. Use the product in a well-ventilated area. DO NOT operate the appliance directly

under kitchen cabinets.

18. Do not use attachments not recommended or sold by the product manufacturer. The

use of accessory attachments not recommended by the appliance manufacturer may

cause injuries.

19. This product is intended for indoor, non-commercial use. Do not use outdoors or for

anything other than its intended use. This appliance is intended for countertop use

only .

20. Do not let the cord hang over edge of a table or counter or touch hot surfaces, as

you may trip and fall or cause the hot contents of the appliance to spill and possibly

cause burns or injuries

21. Do not place the product on or near a hot gas or electric burner, or in heated oven as

it may cause this appliance to melt.

22. Always place the product on a ﬂat, stable surface – it is not recommended to use the

appliance on temperature sensitive surfaces.

23. Always attach plug to appliance ﬁrst, then plug cord into wall outlet. To disconnect,

turn any control to ''off'', then remove plug from wall outlet. Connect the power plug

to an easily accessible outlet so the appliance can be unplugged immediately in the

event of an emergency.

24. Do not use the appliance with a programmer or timing device that switches it on

automatically. The use of such devices is dangerous and can cause a ﬁre risk.

25. While in use, provide adequate space above and around the appliance for air

circulation. Do not operate this appliance while it is near or touching curtains, wall

coverings, dish towels, clothing or other ﬂammable materials.

26. If this appliance begins to malfunction during operation, immediately unplug the cord

from the outlet. Do not attempt to repair or use a malfunctioning appliance.

27. Extreme caution must be used when moving an apliance containing hot oil or other

hot liquids.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

GROUNDED PLUG: As a safety feature, this appliance is equipped with a grounded plug,

which will only ﬁt into a three-prong outlet. Do not attempt to defeat this safety feature.

Improper connection of the grounding conductor may result in the risk of electric shock.

Consult a qualiﬁed electrician if you are in doubt as to whether the outlet is properly grounded.

SPECIAL INSTRUCTIONS: A short power supply cord used to reduce the risk resulting

from it being grabbed by children, becoming entangled in, or tripping over a longer cord.

DO NOT alter the plug. DO NOT attempt to defeat the safety purpose of the grounded plug.

1. Automatic temperature control: Appliance will automatically stop heating, if the

cooking pot is missing / empty or operating without enough liquids.

2. Automatic pressure control: If the internal pressure exceeds maximum pressure

value, the appliance will automatically start releasing pressure through the pressure

release valve.

3. Extreme pressure protection: If the automatic temperature and pressure control

safety devices become invalid and the pressure inside the pot reaches maximum value, the

appliance will automatically start releasing pressure from the lid.

4. Anti-blocking steam vent device: A specially designed cover avoids food particles

from blocking the pressure release valve (under the lid) while in operation and ensure

steam exhausts smoothly during the cooking process.

5. Overheat safety device: The appliance will automatically disconnect if

excessivetemperature is build up inside the cooking pot.

6. Special safety lid mechanism: The appliance is equipped with a locking lid mechanism

that prevents the appliance from operating if lid is not properly locked. Locking mechanism

also prevent the lid from opening when appliance is pressurized.

7. Extreme pressure control: The appliance will automatically disconnect if it reaches

extreme pressure level.

BUILT-IN SAFETY MECHANISMS

BEFORE FIRST USE

READ THE INSTRUCTIONS BEFORE USE

A. Remove all packaging material. Dispose of packaging.

B. Open the lid using the lid handle (Fig 1).

C. Remove the inner cooking pot (Fig 2), the pressure release valve (Fig 3), the sealing ring

(Fig 4) and wash in hot soapy water with all other accessories. Dry thoroughly.

WARNING: Do not immerse body, electrical cord or plug in water or any other liquid.

D. Rinse the lid with hot water and dry thoroughly.

E. Wipe body with a damp cloth and dry thoroughly.

F. Reassemble the appliance (Fig 5).

NOTE: ALWAYS ensure the sealing ring is properly reinstalled under the lid and the

pressure release valve is back in the outlet.

NOTE: During ﬁrst use of the appliance, smoke or light vapors may occur from the appli-

ance because of the initial warming process of the materials. This is normal and will quickly

disappear.

FIG 1 How to open the lid

Rotate the lid counter clockwise and lift upward.

FIG 2 How to remove / replace the cooking

pot inside the base

Lift the inner cooking pot from the outer pot to wash or ﬁll with food.

Insert the cooking pot back inside the appliance and rotate left and

right to make sure it is in contact with the heating plate. Always

ensure the outside of the cooking pot is dry before replacing inside

the appliance.

FIG 3 How to remove/install the pressure release valve

To remove, lift the valve upward. Insert the pressure release valve back into the outlet. It

is normal that the valve ﬁts loose it is required for pressure and temperature regulation.

Always point the valve to ‘’sealing’’ position when operating and to ‘’release’’ position

to manually release the pressure. Pressure won’t build inside the appliance if pressure

valve is not sealed properly.

FIG 4 How to remove/install the sealing ring

The sealing ring is located under the lid. Remove the sealing ring from the rack section by

section. Ensure the sealing ring is properly reinstalled back into the rack before operating

the appliance. Never operate the appliance with a damaged sealing ring.

FIG 5 How to close the lid

Place the lid on the appliance and align the symbol with the ‘’open‘’ mark on the body

and turn clockwise to align with the ‘’close’’ mark. Close the lid securely until a “click” is

heard. The appliance is equipped with a locking lid mechanism that prevents the appliance

from operating if lid is not properly locked.

Sealing position Release position

COOKING PROGRESS DISPLAY

The Starfrit electric pressure cooker is designed with a unique feature that allows you to cook

any meal with peace in mind. The digital cooking progress display helps you monitor the

cooking stages every step of the way.

HEATING: Heating will start immediately after a cooking function is selected. Heating

stage will light up and display will show rolling bars indicating that the heating stage

has started. During the heating stage the appliance will gradually reach maximum temperature.

Heating time may vary depending on food and quantity as well as external factors such as

ambient temperature.

PRESSURIZING: Pressurizing stage will light up and pressure will start to build inside the

appliance. Display will continue showing rolling bars . Pressurizing time may vary

depending on food and quantity as well as external factors such as ambient temperature (between

8-10 min). Pressure release valve will go up indicating the appliance is pressurized.

MAINTAIN PRESSURE: The appliance will switch to maintain pressure once maximum

pressure temperature is reached. Display will show total pressure cooking time (0:00). Each

cooking function has a pre-set cooking time. Cooking time displayed represents pressure

cooking time not total cooking time. Total cooking time may vary depending on food and

quantity. Pressure release valve will remain up indicating the appliance is pressurized. Do

not try to force the lid open while the appliance is in use.

PRESSURE RELEASE: The appliance will beep 5 times when pressure cooking time is over

and automatically switch to pressure release mode. The pressure release stage will light

up and the appliance will naturally start releasing internal pressure. This may take 10-15

minutes depending on food and quantity. For a quick release, carefully turn the steam

release vent to the ‘’release ‘’ position . Do not try to force the lid open allow the

appliance to cool down completely. Always use protective oven mitts.

WARM: Once the pressure inside the appliance is completely released, pressure release

valve will drop down and appliance will automatically switch to Warm mode. Warm stage

will light up and timer will start counting up by incrementing of 1 minute for up to 10

hours. Once maximum time is reached, appliance will automatically turn OFF. Use extreme

caution when opening the lid to avoid scalding.

PRESSURE COOKING TIME CHART

Cooking

function

Pre-set

Pressure

cooking time

(min)

Adjustable

cooking time

range (min)

Pressure &

temperature Warm

Rice 13 10-60 50 kPa

10 hours

Whole grain 20 10-60 60 kPa

Pasta 8 5-60 96- 98 °C

Oatmeal 25 10-60 96- 98 °C

Fish 5 5-60 50 kPa

Poultry 15 10-60 60 kPa

Beef stew 25 10-60 60 kPa

Beans/chili 30 10-60 60 kPa

Soup 20 10-60 60 kPa

Potatoes 17 10-60 60 kPa

Pilaf 25 10-60 50 kPa

Sauté 15 5-60 150-155 °C

Steam 30 5-0 50 kPa

Bake 45 10-60 120 -130 °C

Yogurt 480 Not adjustable 35-40 °C -

Cake 40 30-60 105-120 °C 10 hours

HOW TO USE

(READ THE INSTRUCTIONS BEFORE USE)

NOTE: Always use plastic, rubber, wooden, or silicone cooking utensils inside the cooking

pot to avoid scratching the cookware.

NOTE: Do not operate the appliance directly under kitchen cabinets. Provide adequate

space above and around the appliance for air circulation.

1. Place the product on a ﬂat, stable, heat-resistant surface.

2. Open the lid, take out the cooking pot and add all ingredients inside the inner cooking

pot. Refer to Fig 1.

NOTE: Ensure the minimum quantity of food and liquid is at least 1/5 full. Do not

ﬁll the appliance over 4/5 full. Refer to markings inside the cooking pot. Do not ﬁll

the appliance over 3/5 full when cooking food that expands such as grains and dried

vegetables. Refer to Fig.6

3. Place the inner cooking pot inside the appliance. Refer to Fig 2.

4. Close the lid securely until a “click” is heard. Refer to Fig 5.

NOTE: The appliance is equipped with locking lid mechanism that will prevent the

pressure from building into the appliance if the lid is not securely locked.

NOTE: Ensure the sealing ring is properly installed before operating. Do not operate

the sealing ring is damaged. Refer to Fig 4.

5. Position the pressure release valve to the ‘’sealing’’ position . Refer to Fig 3.

6. Plug the power cord into a 120V AC wall outlet. Appliance will beep and display will

show 00:00.

7. Select the desired cooking function. Light indicator will blink 5 times (standby mode)

and display will show pressure cooking time. Rolling bars will appear indicating

that the heating process has started.

NOTE: Refer to the following section for more details on each cooking functions.

Use the ‘’minutes’’ function during the standby mode to adjust cooking time (refer to

‘’Minutes’’ section).

8. Refer to the ‘’Cooking Progress Display’’ section to help you monitor every cooking stage.

9. Once cooking time is over, appliance will beep 5 times and automatically switch to

WARM mode. Let the appliance cool down completely before opening the lid. Pressure

release valve will drop down indicating that the pressure is released. For a quick

release, carefully turn the steam release vent to the ‘’release ‘’ position .

NOTE: Do not try to force the lid open as it may cause serious injuries.

10. Warm function can be used for a maximum of 10 hours after the appliance will

automatically shut off.

11. Turn off the appliance by pressing the CANCEL button and unplug from electrical outlet.

Fig.6

Inhaltsverzeichnis

Sprachen:

Andere STARFRIT Elektrischer Schnellkochtopf Handbücher

STARFRIT

STARFRIT 024604 Montageanleitung

Beliebte Elektrischer Schnellkochtopf Handbücher anderer Marken

Presto

Presto 6-Quart Stainless Steel Bedienungsanleitung

Orbegozo

Orbegozo HPL 70 Series Bedienungsanleitung

Midea

Midea MY-CS5039P Bedienungsanleitung

Prestige

Prestige 47286 Bedienungsanleitung

Maestro

Maestro MR790 Bedienungsanleitung

Rosewill

Rosewill RHPC-15001 Bedienungsanleitung

Magefesa

Magefesa mageplus Bedienungsanleitung

Espressions

Espressions EP6005 Bedienungsanleitung

Bra

Bra NEW STAR Bedienungsanleitung

GoWISE USA

GoWISE USA GW22700 Bedienungsanleitung

Paula Deen kitchen electrics

Paula Deen kitchen electrics PDPC8 Technische Daten

Aurora

Aurora AU 251 Bedienungsanleitung

Tramontina

Tramontina VANCOUVER Bedienungsanleitung

Prestige

Prestige 2025 Bedienungsanleitung

TEFAL

TEFAL Secure 5 Neo Bedienungsanleitung

Rommelsbacher

Rommelsbacher KA 1800 Bedienungsanleitung

PoongNyum

PoongNyum Stainless steel pressure cooker Bedienungsanleitung

Vitesse Home

Vitesse Home VS-512 Bedienungsanleitung
