StarTech.com CB555WG Handbuch

802.11g Wireless Cardbus Adapter

CB555WG

Instruction Guide

The Professionals’ Source For Hard-to-Find Computer Parts

880022..1111ggWWIIRREELLEESSSSLLAANN

CCAARRDDBBUUSSAADDAAPPTTEERR

* Actual product may vary from photo

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Federal Communications Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled

environment. In order to avoid the possibility of exceeding the FCC radio frequency

exposure limits, human proximity to the antenna shall not be less than 2.5cm (1 inch)

during normal operation.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE

EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment

and telecommunication terminal Equipment and the mutual recognition of their

conformity (R&TTE).

EU Countries Intended for Use

The ETSI version of this device is intended for home and office use in Austria, Belgium,

Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the

Netherlands, Portugal, Spain, Sweden, and the United Kingdom.

The ETSI version of this device is also authorized for use in EFTA member states:

Iceland, Liechtenstein, Norway, and Switzerland.

EU Countries Not intended for use

None.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Using the Configuration Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Profile Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

WPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Appendix A: Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Introduction

Thank you for purchasing a StarTech.com 54 Mbits/sec 802.11g wireless cardbus adapter.

Based on the IEEE 802.11g wireless standard, the CB555WG instantly provides your

notebook computer with wireless LAN (WLAN) access. The adapter comes with both

WPA and WEP protection to keep your wireless network secure and works with 802.11b

wireless devices to ensure compatibility with your network. The card requires no

external power source and uses low levels of power to help preserve your notebook

battery life.

Features

•Provides your laptop computer with wireless LAN access

•Offers high data transfer rate up to 54 Mbits/sec

•Uses low levels of power to preserve notebook battery life

•Compatible with IEEE 802.11g and 802.11b devices

•Uses enhanced WPA (Windows XP only) and 64/128 bit WEP data encryption for

high level of security

•Complies with draft of IEEE 802.11e EDCF and HCF polling for multimedia over

WLAN applications

•Supports 32-bit Cardbus specifications

•Supports Windows Plug and Play installation

•Uses automatic fallback data rate to increases data security and reliability

Before You Begin

System Requirements

•An IBM (or compatible) computer running Windows XP/2000/Me/98SE

•An open Cardbus slot

Package Contents

•1x wireless Cardbus adapter

•1x driver/utility disk

Installation

Note: Depending on your OS and the configuration of your system, the instructions

below may not be identical to what you see on your screen.

Note: You must install the software BEFORE you plug the adapter into your notebook.

1. Insert your driver/utility disk into the disk drive and run the setup.exe file.

2. Click Next.

3. Review the License Agreement Select and select “I accept...”, then click Next.

4. On the “Ready to Install the Program” screen, click Install.

5. Windows will install the driver and utility of the card automatically. Click Finish to

complete the installation.

Note: Windows XP users may see the Windows Logo Testing warning. This is normal.

This message is generated by any driver not written or tested by Microsoft. The driver

has not passed because it has never been tested by Microsoft. You can safely install this

driver on Windows XP.

6. When installation has been completed, insert the adapter into your notebook’s

cardbus slot.

7. The system will automatically detect the card as a new device and display the

“Found New Hardware Wizard” dialog box. Follow the installation wizard to

complete the device setup.

Using the Configuration Utility

After completing the installation, a new icon will be displayed in the system tray at

the bottom of the screen. The icon appears as a bar diagram, with different colors and

levels representing different levels of connection. When the adapter is not associated

with other wireless stations or an access point, the icon will appear as an empty (blank)

bar diagram. Once the adapter is associated, the bar diagram will appear in different

colors depending on the signal strength. There are three colors that represent signal

strength: Green (signal strength from 100%-50%), Yellow (50%-25%), or Red (below 25%).

You can open the Configuration Utility by clicking on the icon. If you right-click the icon,

you can access the following options:

•Connect: Brings up a profile list. If you want to connect to one of the networks

immediately, click the network.

•Radio: Select “On” to enable the card, select “Off” to disable the card temporarily.

•Open: Click “Open” to maximum the screen of the Configuration Utility tool.

•Minimize: Click “Minimize” to minimize the screen of the Configuration Utility tool.

•Exit: Click “Exit” to close the Configuration Utility tool.

Status

The Status screen lets you view information about the network you are connected to.

Parameter Description

Profile Displays the profile name of the network.

SSID Displays the SSID of the wireless network the

adapter is connecting to (up to 32 printable ASCII

characters).

Link Status Displays the status of the connection: Scanning,

Connected, or Disconnected.

Network Type Displays the mode the device is operating in. There

are two sorts of network types: Infrastructure and

Ad Hoc.

Channel Displays the radio channel used by the device.

Tx Rate Displays the transmission rate of the network.

Status, continued

From the Status screen, you can also click on the Configuration button to configure the

network you are connecting to. See Profile Configuration on page 8 for details.

Parameter Description

Signal Strength Displays the signal strength. The higher the

percentage, the better the signal. This indicator can

help you find the best position for your wireless

devices.

Link Quality Displays the quality of the link. The higher the

percentage, the better the quality.

Network Address The Network Address section shows information

about your network: whether DHCP is enabled, and

the adapter’s MAC address, IP address, Gateway

Address, Subnet Mask address, and DNS server

address.

Site Survey

The Site Survey screen gives you information on all your available networks.

Parameter Description

Available Networks This list shows you available networks, along

with information about them. You can see the

network’s link quality, network name, network

mode, security settings, etc. Use this information to

decide which network to connect to.

Rescan Button Click Rescan to get the latest information of all the

wireless networks nearby.

Profiles This Profiles list shows all the profiles (up to 32

sets) with their current configurations. To change

the connection, double-click on the profile you

want to connect to. You can also Add, Delete, and

Edit profiles from this screen.

For more information on creating and editing

profiles, see Profile Configuration on page 8.

Profile Configuration

You can make it quick and easy to connect to your wireless networks by setting each

network up with a profile. You can set up a profile for each wireless network you

frequently use. You can configure your profiles by clicking on the Configuration button

from the Status screen or by selecting New or Edit from the Site Survey screen.

General

Parameter Description

Profile Name Assign a recognizable profile name for the wireless

network.

Network Type Choose the type of network this profile uses:

Infrastructure – Choose Infrastructure if the

network uses an Access Point for communication.

Ad-Hoc – Choose Ad Hoc if the network is

another wireless station that will communicate

directly with the CB555WG.

SSID Enter the SSID (up to 32 printable ASCII characters)

of the wireless network.

Channel (This setting is only available in Ad Hoc mode.)

Choose the channel the network communicates on.

Desired Rate Select a desired data transfer rate from the list.

When Automatic is selected, the device will choose

the most suitable transmission rate automatically.

The higher the data rate you designate, the shorter

distance is allowed between the card and the other

wireless stations. (When in Ad Hoc mode, the

maximum rate will be 11 Mbits/sec. See Appendix

Afor information on improving this performance.)

Inhaltsverzeichnis

Andere StarTech.com Adapter Handbücher

StarTech.com

StarTech.com USB32DP24K60 Bedienungsanleitung

StarTech.com

StarTech.com USBBT2EDR4 Bedienungsanleitung

StarTech.com

StarTech.com CF2USAT18E Bedienungsanleitung

StarTech.com

StarTech.com USB31GEHD Bedienungsanleitung

StarTech.com

StarTech.com HD2DPVGADVI Bedienungsanleitung

StarTech.com

StarTech.com ITB20D3250 Bedienungsanleitung

StarTech.com

StarTech.com MHD2HDF11 Bedienungsanleitung

StarTech.com

StarTech.com DKT31CHPDL Bedienungsanleitung

StarTech.com

StarTech.com GAME511WB Handbuch

StarTech.com

StarTech.com ICUSBAUDIO Bedienungsanleitung

StarTech.com

StarTech.com PAX2235-WIFI-6E-CARD Bedienungsanleitung

StarTech.com

StarTech.com USB150WN1X1 Bedienungsanleitung

StarTech.com

StarTech.com US1GC30SFP Bedienungsanleitung

StarTech.com

StarTech.com DVI2HD Bedienungsanleitung

StarTech.com

StarTech.com S322SAT3R Bedienungsanleitung

StarTech.com

StarTech.com ICUSB232 Bedienungsanleitung

StarTech.com

StarTech.com ICUSB2328 Bedienungsanleitung

StarTech.com

StarTech.com DVI2DPA Bedienungsanleitung

StarTech.com

StarTech.com ICUSB232PRO Bedienungsanleitung

StarTech.com

StarTech.com EC1000S Bedienungsanleitung

StarTech.com

StarTech.com ICUSB2321F Bedienungsanleitung

StarTech.com

StarTech.com PCI EXPRESS SERIAL ADAPTER PEX4S952 Bedienungsanleitung

StarTech.com

StarTech.com PEX10GSFP Bedienungsanleitung

StarTech.com

StarTech.com USB32HD4 Bedienungsanleitung

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

NETGEAR

NETGEAR A6100 Bedienungsanleitung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung
