StarTech.com DKT30CSDHPD Bedienungsanleitung

Manual Revision: 06/13/2017

For the latest information, technical specications, and support for

this product, please visit www.startech.com/DKT30CSDHPD

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

DKT30CSDHPD

USB-C Multiport Adapter with SD Card Reader -

Power Delivery - 4K HDMI - GbE - 2 x USB 3.0 Ports

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Product diagram ....................................................................................1

Front view .................................................................................................................................................... 1

Side view ...................................................................................................................................................... 1

Packaging contents.................................................................................................................................. 2

Requirements ............................................................................................................................................. 2

About USB 3.0 and USB 3.1 Gen 1 .......................................................3

About USB-C ...........................................................................................3

About the adapter’s USB-C port ..........................................................3

About DP Alt Mode (DisplayPort alternative mode) ........................3

About USB Power Delivery 2.0 .............................................................3

Install the adapter..................................................................................4

Connect the adapter................................................................................................................................ 4

Power the adapter .................................................................................................................................... 4

You can power the adapter by one of the following methods................................................. 4

Install the drivers....................................................................................................................................... 4

SD card reader ........................................................................................6

SD card installation................................................................................................................................... 6

SD card removal......................................................................................................................................... 6

Supported Card Types............................................................................................................................. 6

Technical support...................................................................................7

Warranty information............................................................................7

Product diagram

Instruction manual

USB 3.0

ports

(5Gbps)

USB-C port

(DC power

input only)

SD™ card

reader slot

HDMI

output

port

Gigabit RJ45

port

USB-C™

host port

Instruction manual

Packaging contents

• 1 x USB-C multiport adapter

• 1 x quick-start guide

Requirements

• A host laptop with an available USB-C port (to ensure full adapter functionality, the

host USB-C port must support USB Power Delivery 2.0 and DP alt mode)

• Optional: USB-C power adapter (for example, your laptop’s USB-C based power

adapter)

• Optional: An AC electrical outlet

• An HDMI equipped display with cables (for an additional external display)

• A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also

known as 4K x 2K)

• A DisplayPort 1.2 equipped video card is required to support 4K resolution

• Any of the following operating systems:

o Windows® 10 (32-bit or 64-bit)

o Windows 8.1 (32-bit or 64-bit)

o Windows 7 (32-bit or 64-bit)

o macOS 10.12 (32-bit or 64-bit)

o macOS 10.11 (32-bit or 64-bit)

o ChromeOS®

Notes:

• Not all USB-C ports support the full functionality of the USB Type-C™standard.

Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP Alt Mode.

• The adapter can connect to a host laptop’s USB-C port that doesn’t support USB

Power Delivery 2.0. However, in this conguration if a power adapter is connected to

the multiport adapter, it will not pass power through to your host laptop.

• Video output capabilities are dependent on the video card and hardware

specications of your connected host laptop.

Requirements are subject to change. For the latest requirements, please visit

www.StarTech.com/DKT30CSDHPD.

Instruction manual

Introduction

About USB 3.0 and USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard oers speeds up

to 5Gbps. Any mention of USB 3.0 in this manual or on the StarTech.com website for

DKT30CHPD refers to the 5Gbps USB 3.1 Gen 1 standard.

About USB-C

Not all USB-C ports support the full functionality of the USB Type-C standard. Some

ports might only provide data transfers, and might not support video or USB Power

Delivery 2.0. For this adapter to operate properly, check to ensure that your host laptop

supports DP Alt Mode and USB Power Delivery 2.0.

If your laptop supports DP Alt Mode, but not USB Power Delivery, then the multiport

adapter will be powered by your laptop’s host USB-C port.

Thunderbolt™ 3 technology also uses the USB-C connector, so you can connect the

adapter to a Thunderbolt 3 port. The adapter will connect to the Thunderbolt 3 port at

the USB speed of 5Gbps.

USB Power Delivery 2.0 is a specication that allows power (up to 100 watts) to be sent

over a USB-C or Thunderbolt™ 3 cable that supports the specication.

The adapter supports USB Power Delivery 2.0, delivering up to 60 watts of power

through the USB-C or Thunderbolt 3 port on your laptop.

About the adapter’s USB-C port

When connected to a compatible host USB-C port, the adapter itself supports data

throughput (up to 5Gbps), as well as DP Alt Mode (video over USB-C), and USB Power

Delivery 2.0 (maximum 60 watts).

However, the adapter’s USB-C female port only supports USB Power Delivery 2.0. This

port cannot be used for data or video throughput. You can only connect a USB-C

power adapter to the USB-C female port.

About DP Alt Mode (DisplayPort Alternate Mode)

DP Alt Mode is a specication that allows a video signal to transfer over USB-C.

Instruction Manual

Install the adapter

• The adapter is natively supported when connected to a compatible operating

system (see Requirements for supported operating systems). It automatically

detects and installs the required drivers when connected to a USB-C port on your

host laptop.

Connect the adapter

1. Connect your external HDMI monitor to the adapter’s HDMI port.

2. Connect your peripherals to the adapter (for example, a USB device such as a

keyboard, or an RJ45 network device).

3. Connect the adapter’s built-in USB-C cable to a USB-C port on your host laptop.

Power the adapter

You can power the adapter by one of the following methods.

• Without USB Power Delivery 2.0 using your computer’s bus power: The adapter

is powered by your host laptop’s USB-C port and does not require a separate power

adapter and will not charge your laptop.

• With USB Power Delivery 2.0 using your laptop’s USB-C power adapter

(Recommended to ensure sucient power): The adapter is powered using your

laptop’s power adapter (if your laptop is powered by a USB-C power adapter).

Connecting your laptop’s power adapter

1. Connect the adapter’s built-in USB-C cable to a USB-C port on your host laptop.

2. Connect the USB-C connector on your laptop’s power adapter to the USB-C female

port on the adapter.

3. The power adapter will power the multiport adapter and pass power through to

your host laptop.

Disconnecting your laptop’s power adapter

Caution! It is important to follow the below disconnection steps whenever you

disconnect power from the multiport adapter. If you disconnect the power adapter

while you’re transferring les to or from an attached storage device, the transfer

will stop, causing possible le corruption. Disconnecting the power adapter during

operation can also cause the multiport adapter to lose functionality.

1. Fully complete all data transfers over USB and to or from the SD card.

2. Disconnect the adapter from the host laptop.

3. Disconnect your laptop’s power adapter from the adapter.

Instruction Manual

4. Disconnect the HDMI connector, eject SD card and disconnect any USB peripherals

as required.

Note: Your laptop might have specic charging requirements. For example, if your

laptop requires exactly 60W of power and an adapter consumes some of the

60W, your laptop might not recognize that it is getting enough power. For more

information about Power Delivery, refer to the manufacturer of your hardware.

Install the drivers

When the adapter is powered and connected to your host laptop, the required drivers

install automatically. If the drivers don’t automatically install, follow the below steps to

complete the driver installation manually:

1. If the Found New Hardware dialog box appears on your screen, close the dialog

box or click Cancel.

2. Download the latest drivers. Use a web browser and navigate to

www.StarTech.com/DKT30CSDHPD.

3. Click the Support tab.

4. Download the driver.

5. When the download is complete, extract the contents of the compressed le that

you downloaded.

6. Double-click the appropriate driver for the version of operating system that you’re

running and follow the on-screen instructions to complete the installation.

Note: If you are prompted to restart your computer, do so to complete the installation.

Instruction Manual

SD card reader

SD card installation

1. Gently insert your memory card into the SD card reader, with the label side facing

upward.

Note: The card does not need to be forced into place.

2. Your computer system will automatically detect the card and install the required

driver software.

3. To access the content on the SD memory card, follow the instructions specic to the

OS that you’re running.

SD card removal

Windows

1. On your desktop, click the Safely Remove Hardware icon.

2. In the list that appears, click the card reader.

3. When a message appears saying that it’s safe to do so, remove the card from your

multiport adapter.

Caution! If you remove the card before it’s safe to do so, you could experience lost or

corrupted data on your memory card.

macOS

1. Close any open windows that list the contents of the card reader/writer.

2. On your desktop, click and drag the USB storage icon to the trash can icon.

3. Wait ten seconds and then remove the card reader/writer.

Caution! If you remove the card reader/writer before it is safe to do so, you could

experience lost or corrupted data on your memory card.

Supported card types

• Secure Digital (SDSC™) card, Secure Digital eXtended Capacity

(SDXC™) card, and Secure Digital High Capacity (SDHC™) card, Mini

Secure Digital (MiniSD™) card (MiniSD to SD adapter required).

Instruction manual

Technical support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.StarTech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.StarTech.com/downloads

Warranty information

This product is backed by a three-year warranty.

StarTech.com warrants its products against defects in materials and workmanship

for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Inhaltsverzeichnis

Andere StarTech.com Adapter Handbücher

StarTech.com

StarTech.com PEXM2SAT32N1 Bedienungsanleitung

StarTech.com

StarTech.com USBBT1EDR4 Bedienungsanleitung

StarTech.com

StarTech.com USB3SSATAIDE Bedienungsanleitung

StarTech.com

StarTech.com MDP2DPDVHD Bedienungsanleitung

StarTech.com

StarTech.com DKT31CDHPD3 Bedienungsanleitung

StarTech.com

StarTech.com Thunderbolt TB3DKM2DPL Bedienungsanleitung

StarTech.com

StarTech.com USB32HD2 Bedienungsanleitung

StarTech.com

StarTech.com DKT30CHVSDPD Bedienungsanleitung

StarTech.com

StarTech.com 104B-USBC-MULTIPORT Bedienungsanleitung

StarTech.com

StarTech.com CF2X2IDE25 Bedienungsanleitung

StarTech.com

StarTech.com USBBT1EDR2 Bedienungsanleitung

StarTech.com

StarTech.com CB1S485 Bedienungsanleitung

StarTech.com

StarTech.com MDP2VGDVHD Bedienungsanleitung

StarTech.com

StarTech.com USB2VGAPRO2 Bedienungsanleitung

StarTech.com

StarTech.com MSAT2SAT3 Bedienungsanleitung

StarTech.com

StarTech.com MDP2VGDVHDW Bedienungsanleitung

StarTech.com

StarTech.com 120B-USBC-MULTIPORT Bedienungsanleitung

StarTech.com

StarTech.com 117B-USBC-MULTIPORT Bedienungsanleitung

StarTech.com

StarTech.com EC1S232U Bedienungsanleitung

StarTech.com

StarTech.com MDVIHDMIMF Bedienungsanleitung

StarTech.com

StarTech.com USB433ACD1X1 Bedienungsanleitung

StarTech.com

StarTech.com TB3ESATU31 Bedienungsanleitung

StarTech.com

StarTech.com MHD2VGA Bedienungsanleitung

StarTech.com

StarTech.com USB31000S Systemhandbuch

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

NETGEAR

NETGEAR A6100 Bedienungsanleitung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung
