StarTech.com PEXESAT32 Bedienungsanleitung

PCI Express Serial ATA

Adapter Card

2-Port SATA 6Gbps PCI Express

eSATA Controller Card

PEXESAT32

PEXSAT32

Instruction Manual

2-Port SATA 6Gbps PCI Express

SATA Controller Card

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

PEXESAT32 View........................................................................2

PEXSAT32 View ..........................................................................2

Installation....................................................................... 3

Hardware Installation...................................................................3

Driver Installation.........................................................................4

Verifying Installation.....................................................................5

Speciﬁcations.................................................................. 6

Technical Support........................................................... 7

Warranty Information...................................................... 7

Introduction

The StarTech.com 2-Port PCI Express 6Gbps eSATA or SATA

Controller Cards offers simple connectivity between a host computer

system and eSATA or SATA revision 3.0 devices. A cost-effective

solution for connecting high RPM hard drives and Solid State Drives

(SSD), which in turn allows for easier data backups and archiving.

With full support for SATA revision 3.0 hard drives and data transfer

speeds of up to 6 Gbps, as well as backwards support for SATA

revision 2.0 devices, the adapter card features a native PCI Express

single chip design that provides enhanced compatibility, reliability and

performance.

Packaging Contents

1 x PEXESAT32 controller card•

1 x PEXSATA32 controller card

1 x Low Proﬁle bracket•

1 x Driver Installation CD•

1 x Instruction Manual•

System Requirements

PCI Express enabled computer system with available slot•

Microsoft• ®Windows®XP/Server 2003/Vista/Server 2008 R2/7

(32/64-bit), or Linux®

eSATA

connector

LED header

connector

PEXESAT32 View

PEXSAT32 View

LED header

connector

SATA

connector

Installation

WARNING! PCI Express cards, like all computer equipment, can be

severely damaged by static electricity. Be sure that you are properly

grounded before opening your computer case or touching your PCI

Express card. StarTech.com recommends that you wear an anti-static

strap when installing any computer component. If an anti-static strap

is unavailable, discharge yourself of any static electricity build-up by

touching a large grounded metal surface (such as the computer case)

for several seconds. Also be careful to handle the PCI Express card by

its edges and not the gold connectors.

Hardware Installation

Turn your computer off and any peripherals connected to the1.

computer (i.e. Printers, external hard drives, etc.). Unplug the power

cable from the rear of the power supply on the back of the computer.

Remove the cover from the computer case. See documentation for2.

your computer system for details.

Locate an open PCI Express slot and remove the metal cover plate3.

on the rear of the computer case (Refer to documentation for your

computer system for details.). Note that this card will work in PCI

Express slots of additional lanes (i.e. x4, x8 or x16 slots).

OPTIONAL: if installing the card into a low proﬁle system, remove the

full height bracket on the card and replace with the included low proﬁle

bracket.

Insert the card into the open PCI Express slot and fasten the bracket4.

to the rear of the case.

OPTIONAL: if connecting external LED indicators to the card, connect

the 2x4-pin header on the card to the LEDs.

Place the cover back onto the computer case.5.

Insert the power cable into the socket on the power supply and6.

reconnect all other connectors removed in Step 1.

Driver Installation

Windows XP/Server 2003/Vista/Server 2008 R2

After installing the card into the computer system, boot up the1.

computer.

Once logged into Windows, the Hardware/Driver installation wizard2.

should appear. Insert the Driver Installation CD into the CD/DVD

drive when prompted.

Windows should automatically start to search the CD for the3.

appropriate drivers. This may take several minutes.

Once Windows has located the drivers and installed them, the card4.

should be ready for use.

Windows 7

No driver installation is required for Windows 7, as the controller card is

natively supported, so the drivers are already installed.

Verifying Installation

Windows XP/Server 2003/Vista/Server 2008 R2/7

From the main desktop, right-click on “My Computer” (“Computer”

in Vista or later), then select “Manage”. In the new Computer

Management window, select Device Manager from the left window

panel.

Under the “SCSI and RAID Controllers” category (“Storage Controllers”

in Vista or later), should be a “Marvell 91xx” device. Right-click on the

device and select “Properties” to make sure it is installed and working

correctly.

For Windows 7, if using the native drivers, the card will instead be listed

under the “IDE ATA/ATAPI Controller” category as a “Standard AHCI”

device.

Specications

Bus Interface

PCI Express rev 2.0

(x1 connector)

SATA rev 3.0

Connectors 2 x 7-pin eSATA (PEXESAT32)

2 x 7-pin SATA (PEXSAT32)

Chipset ID Marvell 9128

Maximum Data Transfer Rate SATA: 6Gbps

RAID Support 0, 1, JBOD (single)

Operating Temperature 5°C ~ 50°C (41°F ~ 122°F)

Storage Temperature -25°C ~ 70°C (-13°F ~ 158°F)

Humidity 15~90% RH

Compatible Operating

Systems

Windows XP/Server 2003/Vista/

Server 2008 R2/7 (32/64-bit),

Linux

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.
