StarTech.com ICUSB232IS Systemhandbuch

1 Port Industrial USB to RS232 Serial Adapter with 5KV Isolation and 15KV ESD Protection

StarTech ID: ICUSB232IS

The ICUSB232IS Industrial USB to Serial Adapter lets you add an optically isolated RS232 serial port with ESD

protection through a USB port and offers a durable DIN Rail-mountable design.

Ideal for industrial environments, the USB serial adapter features an integrated 5KV optical isolation circuit and

15KV ESD protection, to protect costly and often sensitive control equipment against electrical damage. An

extended operating temperature range (-309/25/2013eg;C to 759/25/2013eg;C) also helps to ensure performance

in harsh environments.

For fast communication with serial peripherals, the adapter features an integrated FTDI chipset, supporting baud

rates up to 921Kbps. The adapter also features COM retention that automatically retains COM Port assignments,

even through a reboot.

The ICUSB232IS serial adapter is compatible with Windows®, Windows CE, Mac OS and Linux which makes it

easy to integrate into mixed environments.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Connect, monitor and control industrial/automotive sensors and other sensitive equipment

Connect and program LED and Digital signage boards with serial communication ports

Connect a satellite receiver, serial modem, or PDU

Features

USB to Straight-Through RS232 Serial Adapter

Integrated 5000Vrms Optical Isolation Circuits

15KV ESD protection

High speed 921.6 Kbps baud rate

Industrial DIN rail mountable design

Integrated FTDI USB UART Chip

USB Powered

Technical Specifications

Warranty 2 Years

Bus Type USB 2.0

Chipset ID FTDI - FT232RL

Port Style Cable Adapter

Ports 1

External Ports 1 - DB-9 (9 pin; D-Sub) Male

External Ports 1 - USB Mini-B (5 pin) Female

Flow Control None, Xon/Xoff, RTS/CTS

Isolation 5KV

Max Baud Rate 921.6 Kbps

Serial Protocol RS-232

Surge Protection 15KV ESD

Data Bits 7, 8

FIFO 256 Bytes

Parity None, Odd, Even, Mark, Space

Stop Bits 1, 2

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), CE(4.2, 5.2)

Windows® Server 2008 R2, 2003(32/64)

Mac OS 10.x (Tested up to 10.9)

Linux 2.6.x - 3.9.x

Cable Length 1 m [3.3 ft]

Color Black

Enclosure Type Plastic

Product Height 22 mm [0.9 in]

Product Length 42 mm [1.7 in]

Product Weight 25 g [0.9 oz]

Product Width 93 mm [3.7 in]

LED Indicators 2 - Tx / Rx Activity

Power Adapter Included USB-Powered

Humidity 5~95% RH (Non-Condensing)

Operating Temperature -30°C to 75°C (-22°F to 167°F)

Storage Temperature -40°C to 85°C (-40°F to 185°F)

System and Cable Requirements Available USB Port

Shipping (Package) Weight 195 g [6.9 oz]

Included in Package 1 - USB to Serial Adapter

Included in Package 1 - DIN Rail Bracket

Included in Package 1 - 1m (3ft) USB Cable

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual
