StarTech.com DK30CHDPD Bedienungsanleitung

Manual Revision: 07/08/2019

User Manual

For the latest information and specications visit

www.startech.com/DK30CHDPD

www.startech.com/DK30CHDPDUE

USB-C Docking Station for Laptops

4K HDMI | Power Delivery | USB 3.0

Actual product may vary from photos

SKU#: DK30CHDPD/DK30CHDPDUE

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Product Diagram....................................................................................4

Front View.................................................................................................................................................... 4

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Front View

1Power Button

23.5 mm Headset Port

3USB-A Port Fast charge

5Gbps and Battery Charge

1.2 compatible.

123

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Rear View

1USB-A Ports (x 3)

2RJ-45 Port

3HDMI Port (Video)

4DC 20V Power Input Port

5USB-C Host Port

• Supports data, DP Alt

Mode and USB Power

Delivery.

345

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Package Contents

• Docking Station x 1

• USB-C Cable x 1

• Universal Power Adapter (NA/JP, ANZ for DK30CHDPD) or (EU,

UK for DK30CHDPDUE) x 1

• User Manual x 1

Requirements

For the latest requirements, please visit: www.StarTech.com/

DK30CHDPD or www.StarTech.com/DK30CHDPDUE

• Host laptop with a USB-C™ Port (to ensure full docking

station functionality, the host USB-C port must support USB

Power Delivery and DP Alt Mode)

Note: The docking station can still connect to a host laptop

with a USB-C port that does not support USB Power Delivery

(must still support DP Alt Mode). In this conguration, the

docking station will not provide power to your host laptop.

• An AC electrical outlet

• An HDMI® display with cables as needed

• A 4K-capable display is required to achieve 4K resolution (also

known as 4K x 2K)

• Any of the following operating systems:

• Microsoft Windows® 10, 8 / 8.1, or 7

• macOS 10.14, 10.13, 10.12, or 10.11

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Installing the Docking Station

The docking station will automatically install the required

drivers when it’s connected to your laptop’s USB-C port. If you

receive a prompt to automatically install the driver(s), follow the

on-screen instructions to complete the installation.

Powering the Docking Station

When the docking station is plugged in and powered, you

can use USB Power Delivery to power and charge your laptop

through its USB-C port.

The docking station cannot receive power from the host laptop,

therefore it must always be connected to the power adapter.

1. Select the appropriate power cord for your region and

connect it to the power adapter.

2. Connect the power adapter to an AC electrical outlet and

then to the docking station’s DC 20V power input port.

3. Connect the provided USB-C cable to a USB-C port on your

host laptop and to the USB-C host port on the docking

station. Both the docking station and your connected laptop

should now be receiving power.

Notes: By default, the docking station power button will be

powered on, as soon as the docking staiton is connected to

a power source. If the docking station has been powered o,

press the power button to turn the docking station on.

In order to power and charge your laptop, its USB-C port

must support USB Power Delivery.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Connecting Devices to the Docking Station

After completing the steps in the Power the docking station

section:

1. Connect the peripheral devices to the appropriate ports on

the docking station. Devices may include USB peripherals,

headset, and tablets.

Notes: The three available USB ports located on the back of

the docking station (USB-A) are standard USB 3.0 through-

put ports. When the docking station is connected to a host

laptop, these ports provide a standard USB 3.0 power output

to power or charge the connected devices.

The USB-A port on the front of the docking station is compli-

ant with USB Battery Charging Specication Revision 1.2

(BC1.2), you can use the port to connect and charge a device

faster than you can using a standard USB port. This front USB

port can charge a connected device, even when the docking

station isn’t connected to a laptop.

2. Connect the external display to the docking station’s HDMI

video port.

Note: Video output capabilities are dependent on the video

card and hardware specications of your connected host

laptop. Some monitors will also limit the available resolution.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Conguring the Display Device

Use your Windows or Mac operating system to adjust display

settings for your external HDMI display.

Supported Video Resolutions

The below table outlines the maximum resolutions available at

each refresh rate, for the HDMI video port.

Number

Displays

Display

Conguration

Maximum HDMI

Resolution

1 HDMI only

4096x2160 @ 24Hz

3840x2160 @ 30Hz

2560x1600 @60 Hz

1920 x 1200 @ 60Hz

Notes: Lower resolutions are also supported at each speci-

ed refresh rate.

Video output capabilities are dependent on the video card

and hardware specications of your host laptop.

2560 x 1600 resolution may not be available on certain

legacy monitors.
