StarTech.com USB3DOCKH2DP Bedienungsanleitung

Manual Revision: 06/02/2015

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the latest information, technical specications, and support for

this product, please visit www.startech.com/USB3DOCKH2DP

USB3DOCKH2DP

Triple video docking station for laptops

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging contents.................................................................................................................................. 1

System requirements............................................................................................................................... 1

Product diagram ....................................................................................2

Front view .................................................................................................................................................... 2

Rear view...................................................................................................................................................... 2

About USB 3.0 and USB 3.1 Gen 1 .......................................................3

About installation ..................................................................................3

Install the driver......................................................................................................................................... 3

Install the hardware.................................................................................................................................. 3

About the docking station ports .........................................................4

Charge a device ......................................................................................4

Charge an iPad with a 30-pin dock connector ............................................................................... 4

Congure a display device....................................................................4

Use DisplayLink to congure a display device ............................................................................... 4

About the display options ....................................................................5

Use Mac OS to congure a display device ....................................................................................... 6

Use Mac OS to change the display mode......................................................................................... 6

Use Mac OS to change the primary display..................................................................................... 6

Supported video resolutions ...............................................................7

Technical support...................................................................................8

Warranty information............................................................................8

Instruction Manual

Introduction

Packaging contents

• 1x triple video laptop docking station

• 1x USB 3.0 host cable

• 1x universal power adapter (NA/EU/UK/AU)

• 1x instruction manual

System requirements

• USB-enabled host computer system with an available USB 3.0 port

• Available AC electrical outlet

• DisplayPort™ and HDMI® enabled display(s) with cables as desired (for additional

external displays)

• Windows® 7 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

• Windows 8.1 (32-bit and 64-bit)

• Mac OS®10.8 and later (tested up to 10.10)

Note: If you connect the docking station to a USB 2.0 host port or if you use a USB 2.0

host connection cable, performance may be limited.

Operating system requirements are subject to change. For the latest requirements,

please visit www.startech.com/USB3DOCKH2DP

Instruction Manual

Product diagram

Front view

Rear view

3.5mm TRRS headset port

(audio and microphone)

USB 3.0 fast-charge and

sync port

Power

switch

USB 3.0

ports

HDMI

port

RJ45

port

Microphone

input

Audio

output

Security

lock port

DisplayPort 1 DisplayPort 2

USB 3.0

host port

DC input

port

Instruction Manual

About installation

Depending on the version of operating system that you’re currently running and

whether your network connection is active, the docking station might install

automatically or download the proper drivers when the dock is connected to an

available USB port on the host system.

If you receive a prompt to automatically install the driver, complete the on-screen

instructions to complete the installation.

Install the driver

1. On your computer, use a web browser to navigate to http://www.startech.com/

USB3DOCKH2DP.

2. Click the Support tab.

3. Click the driver le and complete the on-screen instructions to download the le.

4. Browse to the location of the driver le that you downloaded and do one of the

following:

If the operating system that you’re using is a version of Windows, run the

DisplayLink “exe” install le.

If the operating system that you’re using is a version of Mac OS, run the

DisplayLink “dmg” install le.

5. Follow any on-screen instructions to complete the driver installation process.

Note: You may be asked to restart your host laptop(s) to complete the installation.

Install the hardware

1. Select the appropriate regional clip for your region and connect the power adapter

to an AC electrical outlet.

2. Connect the power adapter to the DC input on the docking station.

3. Attach the provided USB 3.0 cable to the USB 3.0 port on the docking station and

then to an available USB 3.0 port on the host laptop.

5. Connect your DisplayPort and/or HDMI displays to the corresponding ports on the

docking station.

6. As necessary, connect any other devices to the docking station, including an RJ45

network connection, USB peripherals, a headset, speakers, or microphones.

About USB 3.0 and USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard oers speeds up to 5

Gbps.

Instruction Manual

About the docking station ports

The four USB ports located at the back of the docking station are standard USB 3.0

throughput ports. When the docking station is connected to a host laptop, these ports

provide a trickle charge to a selection of devices.

The side USB 3.0 port is compliant with Battery Charging Specication Revision 1.2 (BC

1.2), which means that you can use the port to connect and charge a device faster than

a traditional standard USB 3.0 port.

This side USB 3.0 port can fast-charge a connected device, even when the docking

station isn’t connected to a host laptop. When the docking station is connected to a

host laptop, the side USB 3.0 port functions as a Charging Downstream Port (CDP),

which has simultaneous charge and sync capabilities.

Charge a device

If you’re only using the side USB 3.0 port to charge a device, a connection to a host

laptop isn’t required.

• To charge a device, connect a device to the USB 3.0 port located on the side of the

docking station.

Note: The side USB 3.0 port can only fast-charge connected devices that comply to

USB Battery Charging Specication Revision 1.2.

Charge an iPad with a 30-pin dock connector

The following steps only apply to an iPad with a 30-pin connector. An iPad that uses

a Lightning connector can be charged using the USB port located on the side of the

docking station.

1. Make sure that the host laptops are not connected to the docking station.

2. Connect the iPad to the USB 3.0 port located on the side of the docking station.

Note: If you connect a host laptop to the docking station while you’re charging a rst-

generation iPad, the iPad will switch to data sync mode and stop charging. To switch

back to charging mode, disconnect the host laptop and the iPad from the docking

station. Then connect the iPad to the docking station again.

Congure a display device

Use DisplayLink to congure a display device

1. Connect a display device (monitor, projector, and so on) to the docking station.

2. If necessary, to display all of the available icons, click the Show hidden icons arrow

Instruction Manual

on the toolbar.

3. Click the DisplayLink icon.

4. Click StarTech USB3DOCKH2DP.

5. In the drop-down list, click a congurable option.

Each display is congured independently from all of the connected displays.

Note: If you’re using a computer that’s running Windows 7 or Windows 8, you can also

adjust a display device on the Display Settings screen.

About the display options

The following information describes the display congurations available using the

DisplayLink utility.

Extend

Select this option to display an extension of your active Windows desktop on the

display that’s connected to the docking station. When you select this option, you can

view more applications or documents at the same time. The display is extended in the

direction it was the last time that the display was in Extend mode.

For more control, click Extend To and select one of the options. This puts the display

into Extend mode, and places the display to the right or left, above, or below the

primary display.

Mirror

Select this option to display a duplication of the primary display on the display that’s

connected to the docking station. The resolution, color depth, and refresh rate of the

primary display are replicated on the connected display.

Note: When the connected monitor uses a dierent specication than the primary

display, the system’s primary graphics adapter scales all of the settings to a lower

specication to maintain a uniform aspect ratio.

Extend To

Select this option to specify the physical location of the display that’s connected to the

docking station in relation to the system’s primary monitor.

Screen Resolution

Select this option to change the resolution on the display that’s connected to the

docking station.

Screen Rotation

Select this option to change the orientation in which the screen is viewed. The two

most common orientation types are portrait and landscape.

Instruction Manual

Set as Main Monitor

Select this option to specify the display that’s connected to the docking station as the

primary display. The primary display shows all of the system notications, and takes

priority with applications.

O

Select this option to disable the display that’s connected to the docking station.

Use Mac OS to congure a display device

If you’re using a computer that’s running a version of Mac OS, you can adjust a display

device in the Displays section of the Mac System Preferences menu.

Use Mac OS to change the display mode

By default, the docking station will be set up as an extended display.

• Do one of the following:

• To change the display to Mirror mode, on the Arrangement screen on a

display, select the Mirror Display check box.

• To change the display to Extend mode, on the Arrangement screen on a

display, clear the Mirror Display check box.

• To use Extended and Mirror modes simultaneously, clear the Mirror Display

check box. On the Arrangement screen, press and hold Cmd + Alt, and then

drag and drop the display that you want to mirror over the primary display

(indicated with a white bar). Repeat this step for all of the displays that you

want to mirror.

Use Mac OS to change the primary display

Changing the primary display aects where new windows appear.

• To change which of the connected displays is the primary display, on the current

primary display, click the white menu bar and drag it to the display that you wish to

make the primary one.

Instruction Manual

Video Output

Max DisplayPort

Resolution –

Port 1

Max DisplayPort

Resolution –

Port 2

Max HDMI

Resolution

DisplayPort 1 Only

(Single Display)

3840x2160p (4K)

2560x1600p

2560x1440p

N/A N/A

DisplayPort 2 Only

(Single Display) N/A 2560x1600p N/A

HDMI Only (Single

Display) N/A N/A 2560x1440p

DisplayPort 1

and HDMI (Two

Displays)

3840x2160p (4K) N/A 2560x1440p

DisplayPort 2

and HDMI (Two

Displays)

N/A 2048x1152p 2048x1152p

DisplayPort 1 and

DisplayPort 2 (Two

Displays)

3840x2160p (4K) 2560x1600p N/A

All Displays

(DisplayPort 1,

DisplayPort 2,

HDMI)

3840x2160p (4K) 2048x1152p 2048x1152p

Supported video resolutions

The docking station supports approximately 4K video resolutions on DisplayPort 1

video output.

4K (3840x2160) resolutions can be achieved if the connected DisplayPort display oers

4K support.

See the video resolution chart below for specic congurations and supported

resolutions:

Note: Depending on the conguration and the supported resolutions of your

connected monitors, the docking station may support video resolutions lower than

those specied above.

Inhaltsverzeichnis

Andere StarTech.com Dockingstation Handbücher

StarTech.com

StarTech.com SATADOCK22UE Bedienungsanleitung

StarTech.com

StarTech.com SATDOCKU3SP Bedienungsanleitung

StarTech.com

StarTech.com DKWG30DPHPD Bedienungsanleitung

StarTech.com

StarTech.com SATADOCKU2 Bedienungsanleitung

StarTech.com

StarTech.com InfoSafe SATDOCKU2GB Bedienungsanleitung

StarTech.com

StarTech.com DKT31CHDVCM Bedienungsanleitung

StarTech.com

StarTech.com SATADOCKU2 Bedienungsanleitung

StarTech.com

StarTech.com SDOCKU313E Bedienungsanleitung

StarTech.com

StarTech.com TB3DK2DPPD Bedienungsanleitung

StarTech.com

StarTech.com TB3DKM2DP Bedienungsanleitung

StarTech.com

StarTech.com SATDOCKCRH Bedienungsanleitung

StarTech.com

StarTech.com DK30CHPH Bedienungsanleitung

StarTech.com

StarTech.com SATDOCKU3S Bedienungsanleitung

StarTech.com

StarTech.com SDOCK2ERU33 Bedienungsanleitung

StarTech.com

StarTech.com DK30BACDD Bedienungsanleitung

StarTech.com

StarTech.com USB3DDOCKFT Bedienungsanleitung

StarTech.com

StarTech.com 129N-USBC-KVM-DOCK Bedienungsanleitung

StarTech.com

StarTech.com SATDOCK4U3 Bedienungsanleitung

StarTech.com

StarTech.com USB3SMDOCK4K Bedienungsanleitung

StarTech.com

StarTech.com SATDOCK25U Bedienungsanleitung

StarTech.com

StarTech.com SATDOCK22U3S Bedienungsanleitung

StarTech.com

StarTech.com DKT31CHDVCM Bedienungsanleitung

StarTech.com

StarTech.com Thunderbolt TB3CDOCKDP Bedienungsanleitung

StarTech.com

StarTech.com SDOCK2U33HFB Bedienungsanleitung

Beliebte Dockingstation Handbücher anderer Marken

Sony

Sony Dream Machine XDR-DS12iP Bedienungsanleitung

Acer

Acer USB Type-C Dock II Bedienungsanleitung

ATEN

ATEN UC-2000 Bedienungsanleitung

Xcellon

Xcellon HDD-202 Bedienungsanleitung

Dok

Dok CR09 Bedienungsanleitung

Philips

Philips BTM630/12 Bedienungsanleitung

IOGear

IOGear Travel Pro GUD3C09 Bedienungsanleitung

RKI

RKI SDM-E2 Bedienungsanleitung

iHome

iHome iP15 Bedienungsanleitung

VITURE ONE

VITURE ONE MOBILE DOCK Bedienungsanleitung

Lindy

Lindy 42984 Bedienungsanleitung

CipherLab

CipherLab 8001 Bedienungsanleitung

Pyle

Pyle PIPDSP2 Bedienungsanleitung

Avol

Avol AS2350 Bedienungsanleitung

Datalogic

Datalogic JoyaTouch Bedienungsanleitung

Philips

Philips DC190/79 Bedienungsanleitung

Targus

Targus DOCK315EUZ Bedienungsanleitung

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Bedienungsanleitung
