StarTech.com ST121HDBTPW Bedienungsanleitung

Manual Revision: 01/29/2019

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST121HDBTPW

HDMI® over Cat 5/6 Extender – 330ft

(100m)

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

About LED indicators............................................................................................................................... 3

Installation ..............................................................................................4

Hardware Installation .............................................................................................................................. 4

Specications..........................................................................................6

Technical Support ..................................................................................7

Warranty Information............................................................................7

Instruction Manual

Product Diagram

Front View

Rear View

HDMI®

in port

HDMI®

out port

Status

(Power)

LED

Status

(Power)

LED

Receiver

Transmitter

Power

Jack

Link (RJ-45

Connector)

Optional

Grounding

Bolt

Power

Jack

Link (RJ-45

Connector)

Optional

Grounding

Bolt

Instruction Manual

Introduction

Packaging Contents

• 1x HDMI extender

• 1x HDMI receiver

• 4x mounting brackets

• 2x foot pad set

• 1x universal power adapter (NA / EU / UK / AU)

• 2x grounding wires

• 1x 4ft (1m) Cat5e Cable

• 2x screw sets

• 1x instruction manual

System Requirements

• HDMI® enabled video source device (i.e. computer, Blu-ray Player)

• HDMI enabled display device (i.e. television, projector)

• Available AC electrical outlet for either the transmitter or receiver

• 2x HDMI cable (for video source to transmitter, and receiver to display)

Instruction Manual

About LED indicators

Both the transmitter and receiver feature LED indicators located on the top of the units.

For more information about what the LEDs signify, consult the table below.

Device LED behavior Signicance

Transmitter

Green LED is illuminated Device is receiving power

Blue LED is illuminated Link is established

Flashing blue and green LED No video source or

monitor connected

Receiver

Red LED is illuminated Device is receiving power

Blue LED is illuminated Link is established

Flashing blue and red LED No video source or

monitor connected

Instruction Manual

Installation

1. Determine where the local video source (i.e. computer, Blu-ray Player) will be

located and set up the device.

2. Determine where the remote display will be located and place/ mount the

display appropriately.

NOTE: This HDMI® extender kit features Power over cable, allowing both the

transmitter and receiver to be powered from a single power source that connects

to either the transmitter or receiver unit. Please ensure that unit you’ve chosen to

power is situated near an available AC electrical outlet. Make sure all devices are

turned o before beginning installation.

Before you begin Hardware Installation ensure both transmitter and receiver are

properly grounded.

Hardware Installation

1. Install transmitter unit

a) Position the transmitter unit near the video source (i.e. Computer, Blu-ray Player).

b) Connect an HDMI® cable from the video source device (i.e. computer, Blu-ray

Player) to the HDMI® in port on the transmitter unit.

c) (Optional) If you’ve chosen to connect the power adapter to the transmitter unit,

connect the power adapter from the power adapter port to an available wall outlet.

2. Install RJ45 terminated Cat5e/6 Ethernet Cable

a) Connect an RJ45 terminated Cat5e/6 Ethernet cable (not included) to the RJ45

connector on the transmitter unit.

NOTE: If you are using surface cabling, ensure you have enough Category 5e

unshielded twisted pair (UTP) network cabling to connect the Host Unit to the

Remote Unit’s location, and that each end is terminated with a RJ45 connector. The

cabling should not go through any networking equipment (i.e. router, switch).

If you are using premises cabling, ensure that the Category 5 unshielded twisted

pair (UTP) network cabling between the Host Unit and the Remote Unit has been

properly terminated in a wall outlet in each location and there is a patch cable long

enough to connect the Remote Unit and the Host Unit to their respective outlets.

The cabling should not go through any networking equipment (i.e. router, switch).

b) Connect the other end of the Cat5e/6 cable run to the RJ45 connector on the

receiver unit.

Instruction Manual

3. Install receiver unit

a) Position the receiver unit near the video display (i.e. television, projector).

b) Connect the video source to the HDMI® out port on the receiver unit using an

HDMI® cable.

c) (Optional) If you’ve chosen to connect the power adapter to the receiver unit,

connect the power adapter from the power adapter port to an available wall outlet.

4. (Optional) Install the grounding wires.

Note: Installation of the grounding wires is optional but recommended in

environments with high levels of electromagnetic interference (EMI), or

frequent electrical surges.

Transmitter

a) Using a Phillips type screw driver (sold separately) remove the optional grounding

bolt from the Transmitter Unit.

b) Attach the loop of one of the grounding wires to the shaft of the grounding bolt

that was removed.

c) Using the Phillips type screw driver (sold separately)drive the grounding bolt back

into the hole it was removed from, on the Transmitter Unit.

d) Attach the other end of the grounding wire (that’s not connected to the

Transmitter Unit) to an earth ground connection.

Receiver

a) Using a Phillips type screw driver (sold separately) remove the optional grounding

bolt from the Receiver Unit.

b) Attach the loop of one of the grounding wires to the shaft of the grounding bolt

that was removed.

c) Using the Phillips type screw driver (sold separately)drive the grounding bolt back

into the hole it was removed from, on the Receiver Unit.

d) Attach the other end of the grounding wire (that’s not connected to the Receiver

Unit) to a proper earth-ground connection.

4. Your source video image will now appear on the remote video display.

Instruction Manual

Specications

Local Unit Connectors 1x HDMI® (19 pin) Female

1x RJ-45 Female

Remote Unit Connectors 1x HDMI® (19 pin) Female

1x RJ-45 Female

Maximum Data Transfer Rate HDMI® - 3.4Gbps

Max Distance 100 m / 330 ft

Maximum Digital Resolutions 4k @ 60Hz, 48-bit

Wide Screen Supported Yes

Audio Specications Supports Dolby® TrueHD, DTS-HD MA

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
