StarTech.com 8STUSB2001EXTV Bedienungsanleitung

Manual Revision: 09/21/2016

For the latest information, technical specications, and support for

this product, please visit www.startech.com/USB2001EXTV.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida pe r l’uso - it.startech.com

USB2001EXTV

1-Port USB 2.0-Over-Cat5-or-Cat6 Extender Kit

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Introduction............................................................................................1

Packaging contents.................................................................................................................................. 1

System requirements............................................................................................................................... 1

Product diagram ....................................................................................2

Front view .................................................................................................................................................... 2

Rear view...................................................................................................................................................... 2

Installing the extender..........................................................................3

Install the extender................................................................................................................................... 3

Technical support...................................................................................4

Warranty information............................................................................4

Instruction manual

Introduction

This 1-port USB 2.0 extender lets you connect a USB peripheral device up to 50 m (165

ft.) away from your host computer. Now you can place your USB 2.0 device exactly

where you need it, and you can overcome the 16 ft. USB cable length limitation to

create a more exible and ecient workspace.

Packaging contents

• 1 x USB 2.0 extender local unit

• 1 x USB 2.0 extender remote unit

• 1 x USB 2.0 cable

• 1 x RJ45 cable

• 8 x rubber feet

• 1 x universal power adapter (NA/JP, UK, EU, ANZ)

• 1 x quick-start guide

System requirements

• A host computer with an available USB-A port (USB Type-A)

• An AC electrical outlet

• Terminated RJ45 Cat5e or better Ethernet cable

Operating system requirements are subject to change. For the latest requirements,

please visit www.startech.com/USB2001EXTV.

Instruction manual

Product diagram

Front view

Rear view

LED

USB Micro-B host port

RJ45 port

USB-A port

RJ45 port

DC power input

LED

Instruction manual

Installing the extender

The USB2001EXTV features both a local and a remote extender unit. The local extender

connects to your host computer system, while the remote extender connects with

your remote USB device. Both devices are then connected together using standard

Cat5e cable.

The provided power adapter must be connected to the remote unit in order for the

extender to function properly. Follow the instructions below to install the extender.

Install the extender

1. Connect the USB 2.0 cable (included) to the local unit’s host port and to the host

computer’s USB-A port.

2. Connect a Cat5e Ethernet cable to the local unit’s RJ45 port and to the remote unit’s

RJ45 port.

3. Connect your USB peripheral device to the remote unit’s USB-A port.

4. Select the appropriate power cord for your region (NA/JP, UK, EU, or ANZ) and

connect it to the power adapter.

5. Connect the power adapter to an AC electrical outlet and to the remote unit’s DC

power input port.

Notes:

• Do not route the Ethernet cable through any networking equipment (for example, a

router, or a switch).

• Ensure that your Ethernet cable is long enough to connect the local unit to the remote unit

(maximum extension distance is 50 m, or 165 ft.).

• If your host computer enters Sleep, Standby, Hibernate, or Power Save mode, the

USB extension functionality may fail upon wake up. To ensure proper operation,

don’t allow your host computer to enter these modes. Consult your computer’s

documentation to ensure these modes are not enabled, and for instructions on how

to disable any enabled modes.

Instruction manual

Technical support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship

for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
