StarTech.com VGA2TV2WAY2 Bedienungsanleitung
Video Converter with Scaler
2-Way High Resolution HDTV/
VGA Video Converter
with Scaler
VGA2TV2WAY2
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.
i
Table of Contents
Introduction..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Side 1 View..................................................................................2
Side 2 View..................................................................................2
Installation....................................................................... 3
Hardware Installation...................................................................3
Driver Installation.........................................................................3
How to Use ...................................................................... 4
On Screen Display.......................................................................4
OSD Menu...................................................................................5
Support Resolutions....................................................... 6
Specifications.................................................................. 7
Technical Support........................................................... 8
Warranty Information...................................................... 8
1
Introduction
The StarTech.com 2-Way VGA to Component (HDTV) or Component
(HDTV) to VGA video Converter / Scaler combines the features of a
video scaler and a format converter, to provide a cost-effective way to
display VGA (PC) or component YPbPr (HDTV) feeds.
Packaging Contents
1 x VGA2TV2WAY2 video converter•
1 x 3ft. VGA to YPbPr component video cable•
1 x Power Adapter•
1 x Instruction Manual•
System Requirements
VGA or component (YPbPr) video source•
VGA or component (YPbPr) display device•
2
Side 1 View
Side 2 View
VGA or Component*
input connector
Video Pass-
through output
connector
*requires use of VGA to component breakout cable
*requires use of VGA to component breakout cable
VGA or Component*
output connector
DC Power
connector
Configuration
buttons
3
Installation
WARNING: The default output signal from the video converter/
scaler is 1024 x 768 (XGA) at 60 Hz. Not all display devices have the
capability to display this resolution, so it is advisable to consult the
documentation for your display before attempting installation. If your
display does not support this resolution, you may not be able to access
the menu features through the on-screen display (OSD).
Hardware Installation
Make sure all devices and components are powered off.1.
Connect the VGA/Component video source into the “PC/HD IN”2.
connector on the video converter. If using a VGA source, then a
standard male/male cable should suffice. If using a component
source, use the included VGA to Component breakout cable.
Plug the power adapter into the video converter. The Power LED3.
should light up steady.
Connect the “PC/HD Output” on the converter to the display device.4.
If connecting a display with VGA inputs, a standard male/male VGA
cable should suffice. If connecting a display with component inputs,
use the included VGA to Component breakout cable.
Power on the display device.5.
Power on the video converter.6.
Power on the video source.7.
Driver Installation
No driver or software installation is required, as the video converter is
an external device, not visible to the video source or display device.
4
How to Use
On-Screen Display
The video converter/scaler has a built in On-Screen Display (OSD)
that can be accessed via the push buttons on the unit itself. The OSD
allows for manual configuration of the video converter/scaler. Press the
“Menu” button to activate the OSD and the + and - buttons to navigate
the menu. Press the “Menu” button to confirm selections.
NOTE: The OSD will only activate if an active video source is
connected to the video converter/scaler. If a video source is not
connected or not turned on, the OSD will not be visible.
The OSD allows for adjustments to the output picture, such as
brightness, contact, color and output resolution. These options should
allow for an optimal video image to be displayed on the display device.
If the wrong output resolution is selected, or incompatible with the
type of display device being used, the output resolution can be reset
to either XGA or 480p modes by pressing the “Menu” and + or “Menu”
and - buttons simultaneously. XGA mode should be used for any
display device that would normally be connected directly to a computer
system (i.e. computer monitor), while 480p should be used for a display
device that would normally be connected to cable/satellite TV.
480p reset
XGA reset
5
OSD Menu
1st Level Menu 2nd Level Menu Adjustment
Contrast N/A 0~100
Brightness N/A 0~100
Fine Tune
Hue 0~100
Saturation 0~100
Sharpness 0~100
Exit Return to 1st Level Menu
Color
Red 0~100
Green 0~100
Blue 0~100
Exit Return to 1st Level Menu
Size N/A Full, Overscan, Underscan,
Letterbox, Panscan
Output N/A
Native, VGA, SVGA, XGA,
SXGA, UXGA, WXGA, WSXGA,
WUXGA, 480i, 480p, 720p@50Hz,
720p@60Hz, 1080i@50Hz,
1080i@60Hz, 1080p@60Hz,
1080p@50Hz 576i, 576p,
OSD
HPosition 0~100 OSD Horizontal Position
VPosition 0~100 OSD Vertical Position
Timer 0~100sec. OSD time-out
Background 0~100 OSD transparency
Exit Return to 1st Level Menu
Information N/A Source, Input, Output, Version
Exit N/A Exit OSD Menu
6
Support Resolutions
Input/Output Resolution PC/HD Input PC/HD Output
480i/576i NTSC/PAL NTSC/PAL
480p/576p NTSC/PAL NTSC/PAL
720p 50/60Hz 50/60Hz
1080i 25/30Hz 25/30Hz
1080p 50/60Hz 50/60Hz
VGA (640x480) 60/72/75/85Hz 60Hz
SVGA (800x600) 56/60/72/75/85Hz 60Hz
XGA (1024x768) 60/70/75/85Hz 60Hz
SXGA (1280x1024) 60/75/85 60Hz
UXGA (1600x1200) 60Hz 60Hz
WXGA (1280x800) 60Hz 60Hz
WSXGA (1680x1050) 60Hz 60Hz
WUXGA (1920x1200) 60Hz 60Hz
7
Specications
Compatible Video Formats VGA (RGBHV),
Component (YPbPr)
Connectors 3 x DE-15 VGA female
1 x DC Power
LEDs 1 x Power
Maximum Video Resolution 1920x1200 / 1080p
On Screen Display Yes
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature 0°C to 60°C (32°F to 140°F)
Humidity 0~60% RH
Power Adapter 5VDC, 2.6A, center positive
Dimensions 157.0mm x 102.0mm x 25.0mm
Weight 332g
