State Water Heaters PE) Anwendungshandbuch

COMMERCIAL WATER HEATERS

REPLACEMENT PARTS LIST

STATE WATER HEATERS

500 Lindahl Parkway, Ashland City, TN 37015

Phone: 800-821-2017 • Fax: 800-644-9306

www.statewaterheaters.com

PRINTED IN U.S.A. 0903 195314-000

MODELS: SBS75 75 (NE, PE)

SBS100 75 (NE, PE)

GAS

3/4" T&P RELIEF VALVE

AUTOMATIC, SELF-CLOSING TYPES

PART PRESS A = TEMP

NUMBER RELIEF

76527-3 150 LBS. 2 1/8" 210°

NATURAL BURNER ASSEMBLY

21 4

PROPANE BURNER ASSEMBLY

SBS 75 & 100SBS 75 & 100

SBS 75 & 100

SBS 75 & 100SBS 75 & 100

SBS 75 & 100

SBS 75 & 100SBS 75 & 100

SBS 75 & 100

SBS 75 & 100SBS 75 & 100

SBS 75 & 100

SBS 75 & 100SBS 75 & 100

SBS 75 & 100

Item Qty. Description SBS75 75 (NE) SBS75 75 (PE) SBS100 75 (NE) SBS100 75 (PE)

STATE WATER HEATERS

500 Lindahl Parkway, Ashland City, TN 37015

Phone: 800-821-2017 • Fax: 800-644-9306

www.statewaterheaters.com

1 1 Pipe Nipple .............................. 194139 ................. 194139 .................. 194139 ....................194139

2 1 Burner Tube .............................. 194561 ................. 181784 .................. 194561-1 ..................181784

3 1 Burner ...................................... 194549 ................. 41157-8 .................. 194549 ................... 41157-8

4 1 Thermocouple ........................... 194621 ................. 35489-2 .................. 194621 ................... 35489-2

5 1 Pilot ....................................... 194550-2 ............... 160228-1 ................ 194550-2 ................ 160228-1

6 1 Draft Hood .................................39072 ................... 39072 ..................... 39072 ..................... 39072

7 3 Draft Hood Brace ...................... 194309 ................. 194309 ................... 194309 ....................194309

8 1 Inlet Tube ................................. 194891 ................. 194891 .................. 194891-1 ................ 194891-1

9 4 Flue Baffle Assembly ................ 194332 ................. 194332 ................... 194332 ....................194332

10 1 Anode Rod ............................ 183463-39 ............. 183463-39 .............. 183463-48 .............. 183463-48

11 1 Cleanout Cover ..........................99037 ................... 99037 ..................... 99037 ..................... 99037

12 1 Cleanout Gasket ....................... 99038 ................... 99038 ..................... 99038 ..................... 99038

13 1 Cleanout Screw ....................... 69852-1 ................. 69852-1 .................. 69852-1 .................. 69852-1

14 1 Inner Door .................................. 39923 ................... 39923 ..................... 39923 ..................... 39923

15 1 Outer Door ............................... 39112-1 ................. 39112-1 .................. 39112-1 .................. 39112-1

16 1 Thermostat ............................... 190015 ................. 191855 ................... 190015 ....................191855

17 1 T & P Relief Valve .................... 76527-3 ................. 76527-3 .................. 76527-3 .................. 76527-3

18 1 Drain Valve .............................. 26273-7 ................. 26273-7 .................. 26273-7 .................. 26273-7

19 1 Flue Reducer ............................. 35405 ................... 35405 ..................... 35405 ..................... 35405

20 1 Front Cover ............................... 181260 ................. 181260 ................... 181260 ....................181260

21 1 Pilot Tube ................................. 194552 ................. 160190 ................... 194552 ....................160190

22 1 Orifice .................................... 181508-21 ............. 181778-38 .............. 181508-19 .............. 181778-38

23 1 Fitting Breakaway ...................... 32365 ................... 32365 ..................... 32365 ..................... 32365

24 1 Manual ..................................... 195313 ................. 195313 ................... 195313 ....................195313

* Not Illustrated
