3. Structure of the Maintenance Manual
The MM has been prepared in accordance with the Air Transport Association (ATA) Specification
Number 100 for Manufacturers Technical Data.
A. Division of Subject Matter
The MM is divided into 5 major sections. Each of these sections is subdivided into chapters. A list
of effective pages and the table of contents are provided at the beginning of each MM chapter.
(1) General Ch. 05 - 12
(2) Airframe Systems Ch. 20 - 37
(3) Structures Ch. 51 - 57
(4) Propeller Ch. 61
(5) Power Plant Ch. 71 - 80
Each chapter is separated by a cover sheet with the chapter number and the title.
B. The Page Numbering System
(1) The page numbering system consists of three-element numbers separated by dashes.
The first element of the division identify a system:
e.g. 27 –Flight Controls (a chapter)
The following element designate a subsystem in the system:
e.g. 27-30 Elevator (a section)
If a system consists of several subsystems, further sections are added:
e.g. 27 - 31 Elevator Trim control (a further section)
The last element permits the identification of the individual units in a system or subsystem.
However, this is used if it is necessary.
Example
27 - 10 - 00
Chapter/ Section/ Subject/
System Subsystem Unit
(here Flight- (here
Controls) Ailerons)
(2) When the chapter/system element number is followed with zeros in the section/subsystem
and subject/unit element number (28-00-00), the information is applicable to the entire
system.
:
00-00-00 Page 02
Nov 18/11
00-00-00 Page 03
7
ROTAX Part. No. 899470,
Rev. 0, December 01/2007, o r
a later Revision
Illustrated Parts Catalog ROTAX 912
A/F/S/UL/ULS/ULSFR and 914 F/UL ROTAX Aircraft Engines
8
ROTAX Part. No. 899643,
Rev. 01, February 01/2008, or
a later Revision
Operator’s Manual for ROTAX 914 Series ROTAX Aircraft Engines
9 E-118, Issue No. 33, September
18th, 2007 or a later Issue
Operation & Installation Manual,
Electrically Controlled Variable Pitch
Propeller
mt-Propeller Entwicklung
GmbH
10 Garmin p/n 190-00356-02,
latest revision 400W series Installation Manual Garmin International
11 Garmin p/n 190-00180-00,
latest revision GI-102A/GI-106A Installation Manual Garmin International
12 Garmin p/n 190-00149-01,
latest revision GMA340 Audio Panel Installation Manual Garmin International
13 Garmin p/n 190-00207-02,
latest revision
GTX 330/GTX330D Transponder
Installation Manual Garmin International
14 --- Operating Manual for Aero tow Release,
Type Tail Clutch E22 (german)
TOST GmbH,
Flugzeuggerätebau
München
Table 1 - List of Vendor Technical Publications (Continued)
Nov 18/11
