Streetwize SWOBD3 Technisches Datenblatt

Information for use

SWOBD3

PRODUCT INFO streetwize.online/SWOBD3

Produktinformation

Information du produit

Información sobre el producto

Wireless OBDII

Diagnostic Code Reader

Intention For Use

Product Elements

Thank you for purchasing this Wireless OBDII Diagnostic Code Reader

from Streetwize. This wireless OBDII reader diagnoses the root cause

behind why your vehicle’s engine light is showing.

It is suitable for all kinds of users, from professional mechanics to

home mechanics.

The wireless reader provides both generic and manufacturer speciﬁc

codes as well as live diagnostic information and current engine data

via compatible apps. It also determines the malfunction indicator

lamp status and it reviews emission readiness status. It is ideal for

all kinds of users, including professionals and home mechanics.

To operate this device, download and install an OBD II reader app

onto your devices. Then link the wireless reader to the app over your

Wi-Fi connection.

There are many free and paid apps to choose from. Take some time

to research these apps and pick an app that meets your needs. Then

download the app and follow the instructions as displayed.

While this product is primarily designed for use with smartphone/

tablet apps, you can wirelessly retrieve diagnostic information directly

to your PC/Mac via suitable software.

Before using this product, we advise that you read through all the

information in this document. Please keep this document for

future reference.

1. Wireless OBDII Diagnostic Code Reader

2. CD with PC software

3. User manual

Using This Product With Your

Smartphone/Tablet

Please note: You do not need to be connected to your personal Wi-Fi

network. This wireless OBDII reader transmits it’s own Wi-Fi signal that

you will need to connect to.

• First, locate your vehicle’s OBDII port (please refer to your

vehicle’s handbook).

• Make sure your vehicle is switched off.

• Insert the wireless OBDII reader into your vehicle’s OBDII port.

• Enable the Wi-Fi on your smartphone/tablet.

• Switch on your vehicle to power up the reader.

• On your smartphone/tablet, open up its Wi-Fi connection settings,

search for WiFi_OBDII and connect to it.

Suitable Apps

This wireless OBDII reader is compatible with a number of FREE and PAID

apps that are available on both iOS and Android (smartphone/tablet).

For optimum performance, we recommend you use one of the following apps*.

• Car Scanner (Free)

• Auto Doctor (Free)

• Four Stroke (Free)

• InCarDoc (Free)

• Torque (Paid)

Each of these apps has its own set of features. We advise that you take some

time to research these apps before deciding which one you want to go with.

*As of November 2021.

This wireless OBDII reader is compatible with a number of FREE and PAID

apps that are available on both iOS and Android (smartphone/tablet).

For optimum performance, we recommend you use one of the following apps*.

• Car Scanner (Free)

• Auto Doctor (Free)

• Four Stroke (Free)

• InCarDoc (Free)

• Torque (Paid)

Each of these apps has its own set of features. We advise that you take some

time to research these apps before deciding which one you want to go with.

*As of November 2021.

Using his Product With Your PC/Mac

Multi-Protocal Support

As mentioned in the Intention For Use section, you can use this wireless

OBDII reader with a desktop application for either Windows or Mac.

This product comes with a mini CD featuring a number of Windows

software applications for communicating with the wireless OBDII reader.

The provided applications are:

• Easy OBDII

• OBD2 Spy

• Scan Master ELM

• wORB Crazy

• Scan Tool (Net113Win)

All of these software products come with their own set of features, which

you can read in full in the documentation provided on the CD.

It is advised that you use the Scan Tool (Net113Win) as it is free to use.

The other applications require that you purchase a license.

Alternatively, you can use a number of suitable software products for

both Windows and Mac that you can purchase.

As for compatibility please check with your car dealer if your car OBD II port is

using one of protocols below:

• SAE J1850 PWM (41.6Kbaud)

• SAE J1850 VPW (10.4Kbaud)

• ISO9141-2(5 baud init, 10.4Kbaud)

• ISO14230-4 KWP (5 baud init, 10.4 Kbaud)

• ISO14230-4 KWP (fast init, 10.4 Kbaud)

• ISO15765-4 CAN (11bit ID, 500 Kbaud)

• ISO15765-4 CAN (29bit ID, 500 Kbaud)

• ISO15765-4 CAN (11bit ID, 250 Kbaud)

• ISO15765-4 CAN (29bit ID, 250 Kbaud)

Troubleshooting

The adaptor does not

connect to my device

The adapter is not

reading any OBDII

codes in my app.

The adaptor will not

read my ABS, SRS,

StabiliTrack, scheduled

maintenance or any

other lights

• Please ensure your Wi-Fi is enabled

on your device.

• Restart the device and re-install the

software on your chosen device.

• If after restart, the device is still not

reading codes, please check if your

vehicle is OBDII compliant.

(See Multi-Protocol Support).

• This wireless reader is designed for

reading OBDII codes only (emission

system) in 99.9% of vehicles. To

read other codes, you will need a

more specialised tool that is usually

speciﬁc to these vehicles.

Technical Speciﬁcations

Supplier Code

Product Name

Connectivity Method

Supported OS platform

Operating Voltage

Operating Temperature

Operating Humidity

SWOBD3

Streetwize Wireless OBDII Diagnostic

Code Reader

Wi-Fi

Android/iOS/Windows/Mac

9V to 16V

-40°C to 85°C

<60%

Streetwize, Ashburton Road West,

Trafford Park, Manchester, M17 1RY

www.streetwizeaccessories.com

EU Regd. Address:

Ace Supply Co (Europe) Ltd. D02 A098, Republic of Ireland

For Product Support:

E: suppor[email protected]

T: +44 (0)161 447 8597

For Trade Enquiries:

E: [email protected]

T: +44 (0)161 447 8580

Technical Support

If you require any technical support for your product within the

warranty period, please contact us on:

suppor[email protected]

and provide the product name and supplier code (see Technical

Speciﬁcations) along with the technical query and proof of purchase.
