AQUABOOST

MAB & MARB Variable Speed Booster Sets

Installation, Operation & Maintenance

Instructions

Please leave this instruction booklet with the owner as it contains important warranty,

maintenance and safety information.

Read this manual carefully before commencing installation.

This manual covers the following products:

MAB Variable Speed Booster Sets

MARB Variable Speed Booster Sets

Please note images are representative only and may not portray

your model

CONTENTS

1PRODUCT OVERVIEW............................................................................................3

2WARNINGS .............................................................................................................4

3ELECTRICAL SECTION............................................................................................6

4INSTALLATION ....................................................................................................... 8

5PRIMING .................................................................................................................11

6MAINTAINANCE & SERVICE ................................................................................. 12

7PRODUCT WARRANTY TERMS & CONDITIONS .................................................. 13

8DECLARATION OF CONFORMITY ........................................................................ 16

PRODUCT OVERVIEW

1.1 Product Description

The Booster sets are designed and built to ensure a constant pressure, specifically

suitable for domestic applications and small or medium systems for civil,

agricultural or industrial uses. Booster sets strengths and benefit: constant

pressure, low noise operation, low running costs, low water consumption,

protection against dry running. It’s recommended to use the sets with pressure

vessel.

1.2 Application

Cold water pressure and flow boosting in a range of domestic, commercial and

industrial applications.

1.3 Storage

If this product is not to be installed immediately on receipt, ensure that it is stored

in a dry, frost and vibration free location in its original packaging.

1.4 Environment Protection

Your appliance contains valuable materials which can be recovered or recycled.

At the end of the products’ useful life, please leave it at an appropriate local civic

waste collection point.

WARNINGS

•

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

The motor casing can become very hot under normal

operating conditions. Care must be taken to ensure it

cannot be touched during operation.

•

The electrical installation must be carried out in accordance

with the current national electrical regulations.

•

The electrical installation must be installed by a qualified

person.

Do not run the pump dry.

System pressure must not exceed 10 bar.

Before starting work on the electrical supply ensure

power supply is isolated.

DO NOT allow the supply cord to contact hot surfaces,

inluding the motor shell, pump body or pupework. The

cord should be safely routed and secured by cable clips.

This appliance must be earthed via the supply cord,

whih must be correctly connected to the earth point

loacted in the terminal box

Please read installation details carefully as they are intended to ensure

this product provides long, trouble free service. Failure to install the unit

in accordance with the installation instructions will lead to invalidation of

the warranty.

2.1 SPECIAL WARNING REGARDING FREQUENCY CONVERTER

The FREQUENCY CONVERTER should NEVER be opened or tampered with and

guards that come with it should never be removed.

The frequency converter must be installed, adjusted and maintained by qualified

personnel who understand the risks involved.

The booster set is designed to start automatically. Make hydraulic connections and

to prime the pumps before making any electrical connections.

The connection of the control panels must be performed by a qualified electrician

in accordance with the present electrical standards.

The booster set and control panels must be connected to an efficient earthing

system in accordance with the electrical standards of the country in which it is

installed.

The connection of the earth must be performed first.

The connection of the alarms can distribute power even when the frequency

converter is turned off. Ensure that there is no residual voltage on the terminals of

the alarms. All the power terminals and other terminals must be inaccessible after

installation is completed.

The maximum output frequency must not exceed the design frequency of the

pump being controlled. Operating at a frequency higher than the allowable

frequency can cause higher current absorption and damage to the device.

If it is necessary to remove the frequency converter, remove only the covers

required in order to disconnect the electrical cables. Take care not to damage the

electronic cards.

Failure to comply with the safety regulations not only causes risk to personal

safety and damage to the equipment, but also invalidates every right to assistance

under warranty.

ELECTRICAL SECTION

3.1 Warning!

The drive controller contains dangerous voltages and controls potentially

dangerous rotating mechanical parts. The installation, commissioning and

maintenance of this equipment should be performed only by qualified personnel

who are familiar with the operation. The installation, commissioning and

maintenance of this equipment should be performed only by qualified personnel

who are familiar with the operation.

Do you have particular caution if the automatic restart is activated? To avoid injury

by possibly unintentional restart of the drive controller after a power failure, turn

off the automatic restart in case of doubt. When repairing or servicing this

equipment, make sure that the system cannot be switched on by others again!

The frequency controller has DC link capacitors, which carry hazardous voltage

even after the mains supply is switched off.

Therefore, always wait after switching off the mains voltage for at least 5 minutes

before working on the machine or turn on the unit again. It is important to ensure

that no live parts are touched when power is applied or the intermediate circuit

capacitors are charged.

Do not work on the wiring and check any signals when power is applied. The

Inverter - Regulator has a leakage current. Ground the frequency controller on the

connections provided.

3.2 Caution!

All frequency controllers are tested for dielectric strength and insulation

resistance. Before the insulation measurement in the pump station, for example

within the scope of the inspection frequency controller must be disconnected! It is

strongly recommended that all electrical equipment conforms to the National

Electrical Codes and local regulations.

Factors such as high temperatures, high humidity as well as dust, dirt and

corrosive gases.

The installation should be a well-ventilated, not exposed to direct sunlight place.

Put them no mains voltage to the transducer terminals or to the control terminals.

Enter the operating signals Hand/0/Auto via the selector switch on or about the

driving of external contacts and not by switching on and off of a line or motor

contactor. Only qualified personnel should perform installation, alignment and

maintenance.

The manufacturer reserves the right to alter the technical data in order to make

improvements or update information.

The manufacturer cannot release you from the obligation to comply with the latest

safety standards the user.

3.3 Notice!

The technical data and descriptions in this guide are correct to the best

knowledge and belief. Technical improvements have been continuously carried

out - that's why the manufacturer reserves the right, without prior notice to carry

out such changes. The manufacturer cannot be held liable for errors in the manual.

Warranty is within the incorporated statutory warranty period and applies only to

the product itself and not for any consequential loss or damage or costs

associated with the occurrence of a Warranty claim arise at other plants or plant

parts. The operator shall, in each case to ensure that a failure or defect in the

product cannot lead to further damage.

3.4 Caution Danger to life!

Incorrect installation and incorrect electrical connection can be life-threatening.

Electricity hazards must be ruled out.

•Installation and electrical connection may only be performed by qualiﬁed

personnel and in accordance with the applicable regulations (e.g. IEC, VDE,

etc.)!

•The type of current and voltage must comply with the data on the rating

plate.

•Comply with the regulations of the local power supply company!

•Comply with the accident prevention regulations!

•Never pull on the power cord

•Do not bend the cord

•Do not place any objects on the cord

•When the pump is used in systems with temperatures above 90°C, a

connection cable that is suitably resistant to high temperature must be used

•There is a risk of sharp and jaged edges during assembly.

•Never transport by holding the power cord.

•There is a risk of injury from dropping the pump.

INSTALLATION

When requesting information or spare parts from our Sales Department, quote

the exact identification code of the model together with the manufacture

number.

This manual, along with any other manuals and other documents which are

delivered with the booster set, is an integral part of the operating instructions.

This manual aims to provide information and instructions essential to adequately

perform all activities related to the use of the product purchased. This manual, and

documentation, are intended to be viewed by all persons involved in the life cycle

of the booster set and therefore must be accessible to the user.

Compliance with all safety requirements is an obligation of the customer.

The following instructions and requirements relate to the standard operations; for

instructions, situations and events that are not covered in the present manual or

sales documents, contact our assistance service.

The installation must be designed and carried out only by qualified technicians;

Errors in the installation or use can cause serious damage to the equipment, the

user system and the people involved.

Do not make any action, maintenance, repairs or modifications that you do not

have specific knowledge or received detailed instructions. If doubts remain, after

consultation with the following paragraphs, surveyed Fluid Water Solutions Ltd. All

operations must be carried out while respecting the safety rules.

Remember that you respect the regulations in force in the country of

installation: if different rules are in force on the same topic, you should always

consider the more stringent requirements.

Our products have been manufactured in accordance with the applicable safety

standards in force for which it is recommended the use of all devices or notices in

order that the use does not cause injury to persons or damage to belongings.

Our products were designed for the specific use intended, THEREFORE ANY

OTHER USE THAT IS DIFFERENT AND NOT IN ACCORDANCE WITH WHAT

INDICATED, EXEMPTS STRUART TURNER LTD FROM RISKS that may occur.

The modification of both mechanical and electrical parts of the machine is strictly

prohibited. The non-compliance exempts Stuart Turner Ltd from any responsibility.

The responsibility of any operation that has not been authorised in writing shall fall

upon the executor, inasmuch that they become the manufacturer.

READ THE INSTRUCTION MANUALS OF EVERY PUMPS, MOTORS, CONTROL

PANELS AND OTHERWISE OF ALL COMPONENTS. FOLLOW THE PROVISIONS OF

THE SAFETY AND PERFORM THE PLANNED MAINTENANCE RECOMMENDED IN THE

INSTRUCTION MANUALS!

•

The set must be fitted in a well ventilated place, protected from

unfavourable weather conditions.

•

When handling the set, lift it by the base.

•

Do not lift the set by the delivery manifold: risk of damage to the

glued pipe work which may cause leaks when installed.

•

Position the set in such a way that any maintenance jobs can be

carried out without difficulty.

•

Ensure that the system pipes are independently supported and do

not weigh down on the set manifolds so as to avoid deformation or

breaking of any of its components.

It is also advisable to insert vibration-damping couplings on the system manifolds.

Make the intake section following all the precautions necessary to keep load losses

to a minimum and to avoid the formation of air pockets, for example:

•

Position the set as close as possible to the power supply source.

•

Consider a suction pipe diameter never smaller than that of the

manifold.

•

Lay the suction pipe horizontally or sloping slightly upwards towards

the set.

•

Avoid using elbows or couplings that cause sudden changes in

direction. If necessary, use bends with a wide radius.

Installation must be performed by skilled and authorised installers. During

installation, apply all safety behaviours issued by the competent bodies and

suggested by common sense. Install the unit in a dry well-ventilated place. Rest

the unit on a flat, regular and solid surface (rubber feet) or disassemble the rubber

feet and fix the unit to the base using the relevant screws. Vibrations must not

occur during functioning. The unit can only be installed in the horizontal position.

In the applications with positive suction head, the suction pipe must not be

smaller than that of the intake manifold. In the applications with negative suction

head, in particular cases there may be the necessity to replace the intake manifold

with an individual supply for each pump, in order to prevent preferential flows to

one or several pumps. Generally, in negative suction head applications, the intake

pipes must be as short and straight as possible, they must have a diameter greater

than or equal to the diameter of the pump intake (or the manifold if present). They

must also be supplied with foot-valve and have a slight slope to the pumps, to

prevent the formation of air pockets. Functioning with leaks in intake can damage

the unit pumps. Fix carefully the piping in order not to transmit stress of any type

to the pump. Fasten the piping to the respective manifolds, without excessive

force so as not to cause damage. Booster sets can be shifted in different ways

depending on the configuration of the machine and equipment available to the

installer.

The units are delivered ready for power supply connection, which must be carried

out by a skilled, authorised installer, in compliance with the Standards in force in

the country of installation. During installation, apply all safety behaviours

suggested by law and common sense. Make sure that the electric power supply

network is protected by ground connections in compliance with Standards. Check

the correspondence between the plate data and line nominal values. Before

making the connections, make sure that the ends of the line wires are not live.

Make the connection when you are sure of the existence of an efficient ground

circuit. The ground wire must be longer than the phase wires and must be the first

to be connected during assembly and the last to be disconnected during

disassembly. The installation of a differential switch is recommended.

Before removing the inverter cover or starting interventions on

it, the system must be disconnected from the mains electricity

and you must wait 5 mins until the intermediate circuit

condensers, which can reach voltages up to 800V, have the

time to discharge via the built-in discharge resistors.

EMERGENCY STOP

An emergency stop can be performed while the inverter is

running, by turning the Hand/off/Auto switches to “0” or

turning the panel isolator off.

Before starting up, please read carefully this Manual and the instructions of MAB &

MARB Variable speed control panels.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Stuart Turner Wasserpumpe Handbücher

Stuart Turner

Stuart Turner BOOSTAMATIC 330 Bedienungsanleitung

Stuart Turner

Stuart Turner 46647 Leitfaden

Stuart Turner

Stuart Turner SHOWERMATE TP S1.5 bar Twin Leitfaden

Stuart Turner

Stuart Turner MAINSBOOST MBF Series Montage- und Bedienungsanleitung

Stuart Turner

Stuart Turner CH4-30 Betriebsanleitung

Stuart Turner

Stuart Turner CH 12-14 B Leitfaden

Stuart Turner

Stuart Turner MAINSBOOST VariQ Leitfaden

Stuart Turner

Stuart Turner Monsoon Extra 2.6 bar PS Leitfaden

Stuart Turner

Stuart Turner Monsoon Extra U1.4 bar Leitfaden

Stuart Turner

Stuart Turner 46601 Leitfaden

Stuart Turner

Stuart Turner CH 3-30 CI Leitfaden

Stuart Turner

Stuart Turner ABB V150-45-2V-1 Leitfaden

Stuart Turner

Stuart Turner STUART 46553 Leitfaden

Stuart Turner

Stuart Turner Wasteflo Montage- und Bedienungsanleitung

Stuart Turner

Stuart Turner Stuart SPU 130 Mini Leitfaden

Stuart Turner

Stuart Turner Mainboost MJ3 VM Leitfaden

Stuart Turner

Stuart Turner AQUABOOST iMatic 0304 1S-CMT/8 450 Leitfaden

Stuart Turner

Stuart Turner CH 4-30 PS Leitfaden

Stuart Turner

Stuart Turner Jet 55-45 Leitfaden

Stuart Turner

Stuart Turner Monsoon Series Leitfaden

Stuart Turner

Stuart Turner techflo qt Leitfaden

Stuart Turner

Stuart Turner FLOMATE MBF 12 Montage- und Bedienungsanleitung

Stuart Turner

Stuart Turner Supersub 460A Bedienungsanleitung

Stuart Turner

Stuart Turner iBOLT 0304 3H-CMT/24 Leitfaden

Beliebte Wasserpumpe Handbücher anderer Marken

Neptun

Neptun NPHW 5500 Bedienungsanleitung

Sensidyne

Sensidyne Gilian BDX-II Montage- und Bedienungsanleitung

Draper

Draper 47808 Bedienungsanleitung

Trolla

Trolla 12820 Bedienungsanleitung

Sunfab

Sunfab SVH Series Bedienungsanleitung

WilTec

WilTec 50740 Bedienungsanleitung

Fieldmann

Fieldmann FVC 5015 EK Bedienungsanleitung

Everbilt

Everbilt EFSUB5-122HD Bedienungsanleitung

Graco

Graco Husky 3300e Bedienungsanleitung

esotec

esotec 101018 Bedienungsanleitung

moyno

moyno 2000 CC Bedienungsanleitung

Becker

Becker BASIC VASF 2.80/1-0.AC230 Bedienungsanleitung

Sykes AmeriPumps

Sykes AmeriPumps GP100M Fehlerbehebungshandbuch

DUROMAX

DUROMAX XP WX Series Bedienungsanleitung

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Bedienungsanleitung

Franklin Electric

Franklin Electric IPS Bedienungsanleitung

Xylem

Xylem e-1532 Series Bedienungsanleitung

Milton Roy

Milton Roy PRIMEROYAL Bedienungsanleitung
