INSTALLATION INSTRUCTIONS

UNDERCOUNTER REFRIGERATION

SUB-ZERO®is a registered trademark of Sub-Zero Freezer Company, Inc.

As you follow these instructions, you will

notice WARNING and CAUTION symbols.

This blocked information is important for the

safe and efficient installation of Sub-Zero

equipment. There are two types of potential

hazards that may occur during installation.

Another footnote we would like to identify is

IMPORTANT NOTE: This highlights informa-

tion that is especially relevant to a problem-

free installation.

signals a situation where minor injury or

product damage may occur if you do not

follow instructions.

states a hazard that may cause serious

injuryor death if precautions arenot

followed.

UNDERCOUNTER

INSTALLATION

The importance of the installation of the

Sub-Zero Undercounter unit cannot be

overemphasized. Installation should be done

by a qualified installer.

Before you begin the installation process,

it is recommended that you read this entire

Installation Instructions book. There are key

details that you should take special care to

observe during the installation. By reading

these instructions carefully, you will make the

installation process easier, problem-free and,

most importantly, safe.

Any questions or problems about the

installation should be directed to your

Sub-Zero dealer or the Sub-Zero Customer

Service Department at 800-222-7820. You can

also visit our website at subzero.com.

CONTENTS

Installation Recommendations 3

Installation Instructions 4

Door Panel Installation 7

Installation Checklist 10

Service Information 11

Features and specifications indicated herein and

on the website are subject to change at any time

without notice. Check our website, subzero.com,

for the most up-to-date specifications.

INSTALLATION

RECOMMENDATIONS

SITE PREPARATION

Make sure that the finished rough opening

where the Undercounter unit is to be installed

is properly prepared. Refer to the Installation

Specifications illustration for rough opening

dimensions, door swing clearance and location

of electrical and plumbing (Model UC-24C).

IMPORTANT NOTE:

To operate properly, the

door must open a minimum of 90˚. Use a

minimum 2" (51) filler in corner installations to

assure a 90˚ door opening. Allow enough clear-

ance in front of the unit for full door swing.

IMPORTANT NOTE:

Make sure the floor under

the unit is level with the surrounding finished

floor.

TOOLS AND MATERIALS REQUIRED

The following is a list of tools and materials

that should be available for proper installation.

Appliance dolly able to support130 lbs

(59 kg)

Level—2' (.6 m) and 4' (1.2 m)

recommended

Phillips and slotted screwdriver sets

Wrench set and allen wrench set

Crescent wrenches

Various sized pliers

5/16"hex bolt nut driver

Drill and assorted drill bits

4' (1.2 m) of 1/4"copper tubing and saddle

valve for the water line—part #4200880

(Model UC-24C)

Copper tubing cutter (Model UC-24C)

Masonite, plywood, 1/8"pressed fiberboard,

cardboard or other suitable material to

protect finished flooring

Dimensions in parentheses are in

millimeters unless otherwise specified.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

237/8"

(606)

90˚

145˚

MAXIMUM

DOOR SWING

44" (1118)

DOOR CLEARANCE

26" (660)

DOOR CLEARANCE

253/8"

(644)

253/8"

(645)

INSTALLATION SPECIFICATIONS

NOTE: Door swing clearances are based on stainless

steel door and handle dimensions.

341/2"

(876)

ROUGH

OPENING

HEIGHT

341/4"

(870)

MINIMUM

HEIGHT

REQUIRED

24" (610)

ROUGH OPENING

WIDTH

151/2"

(394)

LOCATE ELECTRICAL

AND WATER LINE

(MODEL UC24C ONLY)

WITHIN SHADED AREA

3" (76)

2" (51)

FRONT VIEW

ANTI-TIP BRACKET

24"

(610)

ROUGH

OPENING

DEPTH

LOCATE WATER LINE

(MODEL UC24C ONLY)

WITHIN SHADED AREA

151/2"

(394)

1/2"(13)

2" (51)

TOP VIEW

NOTE: Water line is required for Model UC-24C only.

ELECTRICAL REQUIREMENTS

A115 V AC, 60 Hz, 15 amp circuit breaker and

electrical supply are required. A separate

circuit, servicing only this appliance, is

required.

The power supply cord has a 3-prong ground-

ing plug, which must be plugged into a mating

3-prong grounding-type wall receptacle. Follow

the National Electrical Code and local codes

and ordinances when installing the receptacle.

For location of the electrical supply, refer to the

Installation Specifications illustration on page 3.

IMPORTANT NOTE:

The electrical outlet must

be placed so the grounding prong is to the right

of the thinner blades. The outlet must be flush

with the back wall.

The Model UC-24RO is designed and safe for

use in outdoor applications. When installed

outdoors, a ground fault circuit interrupter

(GFCI) is required to reduce the risk of electrical

shock. A GFCI is not recommended for use with

other Undercounter models and may cause

interruption of operation.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

Do not use an extension cord or two-

prong adapter. Electrical ground is

required on this appliance.

PLUMBING REQUIREMENTS

Model UC-24C comes with an automatic ice

maker. The illustration on page 3 shows the

precise placement of the water line. When

routing through the side walls, you must place

the water line within 1/2"(13) of the floor and

as close as possible to the back wall. A

minimum of 26" (660) of copper tubing is

required for the water line.

Connect the 1/4"water line from the ice maker

water valve to the house water supply. Use an

easily accessible shut-off valve between the

water supply and the unit. This shut-off valve

should not be installed behind the unit. Do not

use self-piercing valves. A saddle valve kit

(part #4200880) is available from your

Sub-Zero dealer.

Aline filter is required when water conditions

have a high sediment content. The ice maker

operates on water pressure of 20 psi (1.4 bar)

to 100 psi (6.9 bar).

Areverse osmosis system can be used,

provided there is a consistent water pressure

of 20 psi (1.4 bar) to 100 psi (6.9 bar) supplied

to the water valve at all times.

IMPORTANT NOTE:

In some cases a reverse

osmosis water filter system may not be able

to maintain the minimum water pressure

consistently.

OPTIONAL

COMPONENTS

Optional installa-

tion components

are available

through your

Sub-Zero dealer.

For questions

relative to the

installation, call

Sub-Zeroat

800-222-7820.

Dimensions in parentheses are in

millimeters unless otherwise specified.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

UNPACKING AND MOVING

Uncrate the unit and remove its wood base.

Remove all packing materials and tape.

IMPORTANT NOTE:

Do not discard the

kickplate, anti-tip bracket, hardware and the

shipping bolts that hold the wood to the

bottom of the unit (leveling legs). These items

will be needed for the installation.

Roller-assembly wine shelves should be

removed to reduce weight and prevent them

from rolling (Models UC-24B and UC-24C). To

remove, pull the shelf out to its full extension,

gently and evenly lift up on both sides of the

front of the shelf and remove. Reverse the

procedure to reinstall the shelf.

Use an appliance dolly to move the Under-

counter unit. Position the dolly at the back of

the unit to prevent damage to finished

surfaces.

Before moving the Undercounter unit into

position, protect any finished flooring

with appropriate materials and secure the

door closed.

POSITION THE UNIT

IMPORTANT NOTE:

If the Undercounter unit

has been laid on its back or side, you must

allow the unit to stand upright for a minimum

of 24 hours before connecting power.

Plug the power supply cord into the 15 amp

grounded electrical outlet. With power applied

tothe appliance, check for lighting and cooling

before going any further. Once you are satis-

fied that the unit is operating properly, shut off

power to the electrical outlet at the circuit

breaker and proceed.

Pre-level the unit beforesliding it into position.

Leveling cannot be completed with the unit

pushed back in the installation opening.

The Undercounter unit provides the best

access to its contents when the front surface of

the door panel extends out from surrounding

cabinets approximately 1/4"(6).

IMPORTANT NOTE:

The floor under the

Undercounter unit must be at the same level

as the surrounding finished floor to allow for

removal of the unit for servicing.

Shut off the power to the electrical outlet.

ANTI-TIP BRACKET

INSTALLATION

An anti-tip bracket and hardware is provided

with the Undercounter unit. The anti-tip

bracket must be installed on a solid base to

prevent tipover in case several loaded wine

shelves are extended at the same time.

The anti-tip bracket should be attached to the

wall behind the unit with the bracket flange

located immediately above the top of the unit.

Refer to the illustration below.

Asmaller metal ‘countertop’ bracket is also

provided with the Undercounter unit, for instal-

lations that need to be modified to provide a

secure surface for attaching the bracket. This

bracket will securethe front of the unit to the

underside of the countertop, above the unit.

Refer to the illustration below.

If it is not possible to use the countertop

bracket, wedge shims along the sides and top

of the unit.

LEVEL THE UNIT

Using an adjustable wrench or pliers, turn

each of the four leveling legs clockwise to raise

the unit and counterclockwise to lower the

unit. For the location of the leveling legs, refer

to the illustration below.

KICKPLATE INSTALLATION

Once the unit is leveled, the kickplate can be

installed. Use the two #10 x 1/2"stainless steel

screws that areprovided with the kickplate.

Refer to the illustration below.

IMPORTANT NOTE:

The kickplate must be

removed for servicing. The floor cannot inter-

ferewith removal. The louvered section of the

kickplate must not be covered so as to prevent

air circulation.

Turn power back on to the electrical outlet.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

1/4"(6)

Anti-Tip

Bracket

Leveling Legs

Kickplate

Location of leveling legs Kickplate installation

To reduce the possibility of the unit

tipping forward, the front leveling legs

must be in contact with the floor.

To prevent the unit from tipping forward

and provide a stable installation, the unit

must be secured in place with the anti-tip

bracket.

Countertop

Bracket

Countertop bracket

installation

Anti-tip bracket installation

Dimensions in parentheses are in

millimeters unless otherwise specified.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

DOOR PANEL INSTALLATION

MODELS UC-24R AND UC-24C

Models UC-24R and UC-24C can be fitted with

acustom overlay or stainless steel door front

panel. A classic stainless steel door panel with

tubular handle is available as a sales acces-

sory. Installation of the stainless steel panel

will be required.

For the overlay application, a decorative door

panel and handle hardware must be provided.

You can match your handle hardware with

surrounding cabinetry or use a Sub-Zero

accessory handle. Handles must be attached

directly to the overlay panel.

The overlay application requires a decorative

door panel 233/4"(603) by 301/16"(764). The

overlay panel must be a minimum of 5/8"(16)

thick and has a weight limit of 20 lbs (9 kg).

Installation of the overlay door panel for

Models UC-24R and UC-24C is outlined on the

following pages.

OUTDOOR MODEL UC-24RO

Model UC-24RO is shipped from the factory

with the classic stainless steel door panel and

tubular handle in place. No panel installation is

required.

IMPORTANT NOTE:

Model UC-24RO must be

built into cabinetryand cannot be used in a

free-standing application.

GLASS DOOR MODEL UC-24B

The classic stainless steel Model UC-24B/S is

shipped from the factory with the classic stain-

less steel door panel and tubular handle in

place. No panel installation is required.

For the overlay Model UC-24B/O, a decorative

frame door panel must be provided to

surround the glass. The door panel must be

233/4"(603) by 301/16"(764) with rails and stiles

aminimum of 21/4"(57) wide. The overlay

panel must be a minimum of 5/8"(16) thick and

has a weight limit of 10 lbs (5 kg). Installation

of the overlay door panel for Model UC-24B/O

is outlined on the following pages.

You may also use your own handle hardware

to match surrounding cabinetry. If you do not

use the pre-drilled holes on the door of the

unit, you will need to attach the handle directly

to the overlay panel.

IMPORTANT NOTE:

For installations at or

above 5,000' (1524 m) in altitude, a special

high altitude glass door unit must be ordered.

Asolid panel must not be installed on a

glass door unit, as this may cause

moisture to form behind the panel.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

The screw holes inside the door are hidden

under a cover flap on the door gasket. It is

necessary to lift the flap to insert the screws.

Use as many screws as necessary to hold the

door panel in place properly.

IMPORTANT NOTE:

After the first three or

four mounting screws are in place, but not

completely tightened, close the door and check

your panel fit. This is the time to make small

adjustments. Once you are satisfied with the

appearance, open the door and apply the

remainder of the screws. Check all screws for

tightness.

The metal frame on the door has numerous

mounting holes on each side of the door. This

is to accommodate the Sub-Zero accessory

handles and provide for easy attachment of the

handle through the door frame.

If you choose not to use the pre-drilled handle

mounting holes, it will be necessary to fasten

the handle from the rear of the door panel

only, or drill one or more additional holes

through the metal frame of the door.

The illustration below shows how this hole

passes through the door frame. The hole

center is on the small locator groove in the

front of the frame. A 1/4"(6) diameter hole is

made in the front wall of the extrusion and a

13/32"(11) diameter hole through the rest of

the frame.

OVERLAY PANEL INSTALLATION

GLASS DOOR MODEL UC-24B/O

Inspect the door panel for the minimum 5/8"

(16) thickness, the finished inside edge and the

weight limit.

Decide if the handle will be attached through

the glass door frame or just through the deco-

rative door panel. If it is just through the door

panel, the handle must be attached first.

The decorative panel is attached using #8 x 5/8"

square drive screws passing through the door

frame from the rear, behind the gasket into the

panel. The door panel is marked for screw

locations by the use of ‘tenon centers’, which

are temporarily inserted into the 1/4"(6)

diameter holes in the front of the door frame.

Refer to the illustration below.

With the unit secured in place and the door

closed, the panel is held in the desired position

on the door and rapped by hand from the

front, putting center marks on the rear surface

of the panel. If the door panel is made of such

amaterial that pre-drilling is needed, all of the

mounting holes should be marked. If not, only

enough holes to hold the panel in place

temporarily, are necessary.

The door panel is then lowered from the door

frame, tenon centers removed, the door

opened and the screws driven into the panel

through the black tape on the door frame,

using the center marks to locate the screws.

Door

Frame

Overlay

Panel

Tenon Center

Tenon centers Door frame cross-section

1/4"(6)

Diameter

13/32"(11)

Diameter

Glass

Gasket

IMPORTANT NOTE:

For Model UC-24B, install

screws in all the mounting holes in the door

frame. The nature of the door panel with a

narrow outer rim and no connecting center

member requires the support provided by the

glass door.

After the door panel installation is complete,

apply the cover patches or plugs provided over

the holes on the inside surface of the door.

The cover patches or plugs are part of the

insulation system on the door of the

Undercounter unit. Be sure to cover all

the holes in the door that were used.

Dimensions in parentheses are in

millimeters unless otherwise specified.

UNDERCOUNTER INSTALLATION INSTRUCTIONS

The Model UC-24B glass door is made

with a sealed double-wall tempered glass

core. The drill must not contact this core

when drilling. Be sure the hole is centered

on the small groove in the front of the

door frame and the drill passes squarely

through the frame. If you are inexperi-

enced with drilling, fasten the handle from

the rear of the door panel only.

OVERLAY PANEL INSTALLATION

MODELS UC-24R AND UC-24C

Remove the two panel mounting brackets

attached to the front of the door and set aside.

Place the overlay door panel lying face down

on a protected surface to ensure that the front

is not scratched or damaged.

Position the plastic template (provided) flush

with the lower edge of the door panel. Be sure

you are following the exact location for the

right-hand (RH) or left-hand (LH) door swing.

Refer to the illustrations below for placement

of the mounting brackets.

Once you have located the proper placement

for the brackets, mark the pilot holes, remove

the template and drill pilot holes for mounting

the brackets. It is best to start with a few holes,

position the bracket, drill the remaining pilot

holes and then securethe mounting bracket

with the #8 x 1/2"screws provided.

233/4"(603)

151/16"

(382)

31/2"

(89)

35/8"

(92)

301/16"

(764)

215/8"(549)

LH DOOR SWING

7/8"

(22)

233/4"(603)

151/16"

(382)

31/2"

(89)

35/8"

(92)

215/8"(549)

RH DOOR SWING

7/8"

(22)

Exercise caution when drilling holes for

mounting hardware. This is especially

critical with inset panels.

Overlay Panel Bracket Placement

UNDERCOUNTER INSTALLATION INSTRUCTIONS

Door Panel

Bracket

Top Door Hinge

Adjustment

Screws

Adjustment

Screws

Bottom

Door Hinge

Top hinge adjustment Bottom hinge adjustmentDoor panel mounting

brackets

HINGE ADJUSTMENT

IMPORTANT NOTE:

The Undercounter unit

should be properly leveled in position before

door hinge adjustments are made.

The top and bottom cabinet hinges are held in

place with three permanent adjustment

screws. If the door needs adjustment, loosen

the adjustment screws and reposition the door.

Once in position, tighten the adjustment

screws. Refer to the illustrations below.

INSTALLATION CHECKLIST

The importance of the installation of the

Sub-Zero Undercounter unit cannot be

overemphasized. Proper installation is the

responsibility of the selling dealer or installer.

IMPORTANT NOTE:

The following checklist

should be completed by the installer to ensure

that no partof the installation has been

overlooked.

Advise the homeowner to fill out and return all

product registration forms. This will ensure

that the customer information is in our

database in the event service is required.

Any questions or problems about the installa-

tion should be directed to your Sub-Zero

dealer or the Sub-Zero Customer Service

Department at 800-222-7820. You can also visit

our website at subzero.com.

OVERLAY PANEL INSTALLATION

MODELS UC-24R AND UC-24C

Before attaching the panel to the door, remove

the outer screws from each of the two

mounting positions along the hinge side of the

door. Unscrew the two remaining screws in the

center of each mounting position just enough

that the slotted holes on the hinge side door

panel bracket will slide under the heads. These

positioning screws will support the door panel

during installation and adjustment. Refer to the

illustration below.

Install the door panel by engaging the tabbed

bracket to the handle side of the door first and

then sliding the hinge side mounting bracket

onto the positioning screws on the hinge side

of the door.The panel can be adjusted 1/4"(6)

up and down and side to side.

Once the door panel is in place and adjusted

correctly, attach the four remaining #10 x 1/2"

screws to the hinge side mounting bracket and

install the magnetic decorative caps as shown

in the illustration below.

Andere Handbücher für UC-24C

Dieses Handbuch passt für folgende Modelle

Andere Sub-Zero Kühlschrank Handbücher

Sub-Zero

Sub-Zero BI-36R Bedienungsanleitung

Sub-Zero

Sub-Zero 315W Leitfaden

Sub-Zero

Sub-Zero Sub-Zero BI series Bedienungsanleitung

Sub-Zero

Sub-Zero IC-27R Bedienungsanleitung

Sub-Zero

Sub-Zero 542 Bedienungsanleitung

Sub-Zero

Sub-Zero BI-48S Montageanleitung

Sub-Zero

Sub-Zero ICBIC-24R Bedienungsanleitung

Sub-Zero

Sub-Zero PRO3650G Bedienungsanleitung

Sub-Zero

Sub-Zero BI-36UFD Bedienungsanleitung

Sub-Zero

Sub-Zero PRO 48 Montageanleitung

Sub-Zero

Sub-Zero IC-24FI Bedienungsanleitung

Sub-Zero

Sub-Zero PRO3650GRH Bedienungsanleitung

Sub-Zero

Sub-Zero BI-30UG Bedienungsanleitung

Sub-Zero

Sub-Zero Classic Series Bedienungsanleitung

Sub-Zero

Sub-Zero ICBBI-36R Bedienungsanleitung

Sub-Zero

Sub-Zero 611G Bedienungsanleitung

Sub-Zero

Sub-Zero IT-36RID Bedienungsanleitung

Sub-Zero

Sub-Zero 650G Bedienungsanleitung

Sub-Zero

Sub-Zero BI-36S Bedienungsanleitung

Sub-Zero

Sub-Zero BI-30U Montageanleitung

Sub-Zero

Sub-Zero 601R Bedienungsanleitung

Sub-Zero

Sub-Zero IC-30RID Bedienungsanleitung

Sub-Zero

Sub-Zero 700TF Betriebsanleitung

Sub-Zero

Sub-Zero 600 Series BI-36RG Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
