Summit CT67 Series Bedienungsanleitung

FELIX STORCH, INC.

SUMMIT APPLIANCE DIVISION®

INSTRUCTION MANUAL FOR:

CT-67

CT-67A

CT-67B

CT-67SS

CT-67SSTB

Thank you for purchasing this appliance and for putting your trust in our company. It’s

designed to refrigerate and/or freeze your fresh foods, while adding elegance to your

home or office.

REFRIGERATOR-FREEZER

Before Putting Into Use

These instructions are intended for the user. They describe the appliance and the

correct and safe way to use it. The instruction manual was prepared for various

types/models of refrigerators. Therefore you may find in it descriptions of some

accessories and functions that your appliance may not have.

Before connecting the appliance to the power supply, leave it standing for about 2

hours, which will reduce a possibility of malfunctions in the cooling system due

to transport handling.

Clean the appliance thoroughly; especially in the interior (See Cleaning the

Appliance).

In case the interior accessories are not correctly placed, rearrange them as

necessary.

Mounting Instructions

Integrated appliances are equipped with instructions for mounting the appliance into

the kitchen unit.

The appliance should be mounted by qualified technicians and instructions are for

their use only.

We Care for the Environment

Our appliances are distributed in packaging made of environmental friendly

material which could safely be recycled, disposed of or destroyed without any

effects on the environment whatsoever.

Our instruction manuals are printed either on recycled paper or chlorine free

bleached paper.

Tips for Energy Savings

Try not to open the door too often, especially when the weather is hot and

humid. Once you open the door try to close it as soon as possible.

Every now and then check if the appliance is sufficiently ventilated

(adequate air circulation behind the appliance).

Set thermostat from higher to lower settings as soon as possible

(depending on how loaded the appliance is, ambient temperature etc...).

The coils on the rear of the refrigerator should be cleaned and free of dust

or any impurities.

Ice and frost layer increase energy consumption, so do clean the appliance

as soon as the layer is 1/8” thick.

Always consider instructions stated in sections Positioning and Energy

Saving Tips, otherwise the energy consumption is substantially higher.

Instructions for Use

Important

If you bought this appliance to replace an old one equipped with a lock

that cannot be opened from the inside (lock, bolt), make sure that the lock

is broken. This will make it impossible for children to lock themselves

inside the appliance and suffocate.

The appliance must be correctly connected to the power supply.

If the food has a strange smell or color throw it away because it is very

likely that it is spoiled and therefore dangerous to eat.

Disconnect the appliance from the power supply before repairing it (only a

qualified technician should repair it), cleaning it and before replacing the

light bulb.

Use only enclosed tools or tools recommended by the manufacturer.

For the sake of environmental protection be careful not to damage the rear

wall of the appliance (the condenser unit or the tubes when moving the

refrigerator) or any part of the refrigerating system inside the appliance.

Use only enclosed tools or tools recommended by the manufacturer.

The refrigerating system of the appliance is filled with refrigerant and oil,

so when the appliance is damaged handle it with care and dispose of it in

compliance with the environmental protection precautions

Before throwing away your old refrigerator or freezer please remove the

doors and leave the shelves in place so that children may not easily climb

inside.

. DANGER: Risk of child entrapment.

The rating plate is inside the appliance or outside on the rear wall.

Disposing of the Worn Out Appliance

When your appliance finally wears out, dispose of it. If the appliance has

a lock, break it to prevent eventual accidents (danger of children getting

locked inside the appliance).

The refrigerating system of the appliance is filled with refrigerant and

insulating substances which should be separately treated and processed,

you should call your nearest authorized service agent or specialized

servicing center if they cannot be contacted call your local authorities or

your distributor to remove the refrigerator. Be careful not to damage the

tubes on the rear wall of the appliance (danger of pollution).

Instructions for Use

Placing and Installation

Choosing the Right Place

Place the appliance in a dry and regularly ventilated room. Allowed ambient

temperature depends on the model (class) of the appliance and is stated on the

rating plate of the appliance.

Class Ambient Temperature

SN (sub-normal) from + 56°F to + 90°F

N (normal) from + 62°F to + 90°F

ST (sub-tropical) from + 64°F to +100°F

T (tropical) from + 64°F to +120°F

The appliance may be exposed to lower or higher temperatures but only for a

shorter period of time and the temperature should never be lower than 41°F.

Never place the appliance near heat emitting devices (e.g. cooker, radiator, water

heater or similar devices) and do not expose it to direct sunlight.

Placing the Self-Standing Appliance

It is important to make sure the appliance is leveled evenly to prevent falling.

Two spacers attached to the appliance must be fitted onto the upper edge of the

condenser, thus preventing the appliance from being installed too close to the

wall. Spacers are manufactured for all-purpose functions depending on the

distance of the condenser from the wall. Therefore turn spacers correspondingly

and adjust them accordingly to the appliance.

Connection to Power Supply

Connect the appliance with the cable and plug to the power supply socket outlet

with a ground terminal (safety socket).

“DO NOT USE AN EXTENSION CORD.”

Required nominal voltage and frequency are indicated on the rating plate.

The connection to the power supply and grounding has to be made according to

current standards and regulations. The appliance resists temporary voltage

tolerance up to -15 to 10%.

Operation Control

The appliance is controlled with the thermostat knob, placed in the right upper

part inside the appliance.

Turn the knob clockwise from STOP (0) position towards 7 and backwards.

Temperature Selection

•When the freezer operates automatically, the interior temperature is

controlled by the thermostat. Higher settings on the knob mean colder

temperatures in all compartments of the appliance. The temperature in the

interior of the appliance may even drop below 32°F. Only use higher

thermostat settings when required or recommended. The most suitable

thermostat position is in the middle, between max and min.

•Changes of the ambient temperature affects the temperature in the interior

of the appliance (choose the correct setting on the thermostat knob).

•When the knob is on the STOP (0) position the appliance does not operate

(the cooling system is switched off), yet the power supply is not

interrupted (the light will still come on if you open the door).

•Temperature in the refrigerator and in low temperature compartments also

depend on how often you open and close the door.

Instructions for Use

Use

Storing Fresh Foods

•Foods to be stored in the refrigerator should be properly packed as to

prevent mixing various moisture degrees and odors (in polyethylene bags

or sheet, aluminum foil, wax paper, covered containers or bottles).

•Never store any inflammable, volatile or explosive substances.

•Beverages with high alcohol percentage shall be stored in tightly sealed

bottles in a vertical position.

•Food should not touch the rear wall of the refrigerator.

•Some organic solutions like volatile oils in lemon and orange peel, acid in

butter etc. can cause damages when in contact with plastic surfaces or

gaskets for a long period of time.

•An unpleasant odor inside the refrigerator is a sign that something is

wrong with the food or that your refrigerator needs cleaning. Odors may

be eliminated or reduced by washing the interior of the refrigerator with a

mild solution of water and vinegar. We also recommend using activated

carbon filters to clean the air or to neutralize odors.

•If you plan on taking a long trip make sure you remove all perishable food

before you leave to prevent any odors.

Fresh Food Storage Time in the Refrigerator

Storage time (days)

Article of Food

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Butter +++++++=== = =

Eggs ++++++++++ = = = =

Fresh uncut meat ++=

Chopped meat + =

Smokedmeat ++++++++++ = = = =

Fish +=

Marinade ++++++++++ = = = =

Root ++++++++== = = = =

Cheese ++++====== = = = =

Sweets ++====

Fruit ++========

Prepareddishes ++==

Legend: + means recommended storage time

= means possible storage time

Instructions for Use

Freezing Fresh Foods

•Carefully select food you intend to freeze; the food should be of adequate

quality and suitable for freezing.

•Use correct packaging and wrap it right.

-The packaging should be air tight and shouldn’t leak; this may

cause substantial vitamin loss and dehydration of the foods.

-Foils and bags should be soft enough to tightly wrap around the

foods.

•Mark the packages with the following data: kind and amount of foods and

the date of loading.

•It is most important that the food is frozen as quickly as possible.

•We recommend that the size of the package not to be too large and to be

cooled off before loading into the freezer.

•The amount of fresh foods that can be loaded in the freezer within 24

hours is indicated on the rating plate. If the loaded amount is too large,

the quality of freezing is reduced which affects the quality of frozen foods.

Freezing Procedure

•24 hours before loading the freezer with fresh foods, set the thermostat

position between 4 and 7. Place the packages on the shelf and let them

freeze. And 24 hours after loading the packages reset the thermostat if

necessary to an operating temperature.

•The next time you want to freeze fresh foods, repeat the freezing

procedure and be careful that the packages containing fresh foods do not

touch the frozen packages.

•When freezing smaller amounts of food (up to 1 kg) there is no need to

change the thermostat setting (see Temperature Selection).

Storing Frozen Foods

Frozen foods can be stored on the bottom of the appliance or on the shelf.

Instructions for Use

Commercially Frozen Foods

The storage time and the recommended temperature for storing commercially

frozen foods are indicated on the packaging. For storing and using consider the

manufacturer’s instructions. When shopping for foods, be careful to choose only

adequately packed foods provided with complete data and stored in freezers

where the temperature is not higher than -18°C. Do not buy packages of food

covered with frost layer. This indicates that the package was thawed before at

least once. Be careful that packages don’t start to thaw; as the temperature rises it

reduces the quality of foods. Storage time (in months)

Food 1 2 3 4 5 6 7 8 9 10 11 12

Vegetable +++

Fruit + + +

Bread,Pastries +

Milk +

Ready-MadeMeals +

Beef + + +

Veal +++

Pork +++

Poultry +++

Game +++

MincedMeat +

SmokedSausages +

LeanFish +

FatFish +

Offal +

Defrosting Frozen Food

Partially thawed or defrosted foods should be used as soon as possible. Cold air

preserves the food and does not does not destroy the microorganisms which

rapidly activate after defrosting.

Partial defrosting reduces the nutritional value of foods, especially of fruits,

vegetables and ready-made meals.

Ice Making

The recommended thermostat setting for ice making is positioned between 3 and

5. Fill the ice cube tray (two thirds of it) with cold water or with any liquid

suitable for freezing and insert the tray into the low temperature compartment.

Dry the bottom of the tray so that it doesn’t stick to the bottom of the low

temperature compartment. The best method to get the ice cubes out of the tray is

to hold the tray under cold tap water for a second and turn it around and slightly

bend it.

Instructions for Use

Changing the Direction of Opening the Door

If you find the direction of opening the door on your appliance inconvenient, you

can change it. Holes on the opposite side have already been prepared at the

factory (except on stainless steel towel bar models).

•Take off the upper hinge cover and unscrew the upper and lower hinges.

•Remove the kick plate and place it in its new position.

•Unplug the holes covering the holes on the opposite side of the appliance

door.

•Place the lower hinge on the opposite side of the appliance and put the

door on.

•Fix the upper hinge and cover it.

•Unscrew the handle and replace it to the opposite side (not for handles

mounted horizontally).

•Plug the remaining holes with decorative caps.

•Check the gasket, it should not be creased and should seal well.

Changing the Direction of the Opening Door on the Low

Temperature Compartment

•Unscrew the blocking element and the hinge of the low temperature

compartment and take off the door.

•Plug the holes with the plastic caps provided.

•Turn the door 180° and replace it on the opposite side of the low

temperature compartment. Fix the hinge and the blocking element of the

door (position of holes already provided).

Instructions for Use

Maintenance and Cleaning

Automatic Defrosting of the Refrigerator

There is no need to defrost the refrigerator, because the ice depositing on the inner

back wall is defrosted automatically.

The ice is depositing on the inner back wall during the compressors operation;

later on, when the compressor is not operating, ice is defrosting and water drops,

drains and collects through the outlet in the inner back wall into the drain pan

situated above the compressor where it evaporates.

Manual Defrosting of the Low Temperature Compartment

When the frost and ice layer in the low temperature compartment is 1/8” thick,

you should clean the freezer.

•Turn the thermostat knob to the STOP (0) position and disconnect the

power supply. Empty the compartment and take care that the packages

remain frozen.

•Put a suitable vessel under the low temperature compartment to collect the

defrost water. Leave the door of the compartment open to accelerate

defrosting.

Cleaning the Appliance

Disconnect the power supply before cleaning the appliance. Do not use coarse or

Aggressive cleaning agents as you can damage the surface.

•Clean the exterior with water and detergent. Varnished surfaces are

cleaned with soft cloth and an alcohol based cleaning agent (for example

glass cleaners). You may also use alcohol (ethanol or isopropyl alcohol).

The application of abrasive and especially aggressive cleaners, such as

stainless steel cleaners, is not appropriate for the cleaning of plastic and

coated parts.

•Remove the detachable accessories in the interior of the appliance and

clean it with water and liquid detergent. Plastic parts cannot be washed in

a washing machine.

•Wash the interior of the appliance with lukewarm water, in which you add

one or two spoonfuls of vinegar.

•Every now and then wipe the condenser on the rear wall. Use a soft non-

metal brush or vacuum cleaner.

•Do not forget to clean the defrost water receptacle above the refrigerators

compressor (do not remove the receptacle). After cleaning, connect the

appliance to the power supply and reload the packages.

Instructions for Use

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Summit Kühlschrank Handbücher

Summit

Summit FF71LLF2 Bedienungsanleitung

Summit

Summit FF-1274 Series Bedienungsanleitung

Summit

Summit AL55 Bedienungsanleitung

Summit

Summit FFBF279SSX Bedienungsanleitung

Summit

Summit FF41SS-AL Bedienungsanleitung

Summit

Summit CM406W Bedienungsanleitung

Summit

Summit FFAR2L Bedienungsanleitung

Summit

Summit SWC6G Series Bedienungsanleitung

Summit

Summit SUM-603 Bedienungsanleitung

Summit

Summit FFBF285SS Bedienungsanleitung

Summit

Summit AZRF7W Bedienungsanleitung

Summit

Summit FF6ADA Series Bedienungsanleitung

Summit

Summit ALR46W Bedienungsanleitung

Summit

Summit FFBF283SS Bedienungsanleitung

Summit

Summit AL650 series Bedienungsanleitung

Summit

Summit BDR190NASSHH Leitfaden

Summit

Summit FF27BSS Bedienungsanleitung

Summit

Summit AL750LSSHH Leitfaden

Summit

Summit FF1084W Bedienungsanleitung

Summit

Summit FFBF240W Bedienungsanleitung

Summit

Summit SPRF34D Bedienungsanleitung

Summit

Summit FF882 Bedienungsanleitung

Summit

Summit CP96 Bedienungsanleitung

Summit

Summit Accucold ARS23ML Service-Handbuch

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
