Summit FF410WH Bedienungsanleitung

Compact Refrigerator

Réfrigeratuer Compact

Refigerador Compacto

User Manual

FF410WH/FF430BL

Guide de l’Utilisateur

FF410WH/FF430BL

Manual del Usuario

FF410WH/FF430BL

SAFETY PRECAUTIONS

Read all of the instructions before using this appliance. When using this

appliance, always exercise basic safety precautions, including

the following:

1) Use this appliance only for its intended purpose as described in this use

and care guide.

2) This refrigerator must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in

the installation section.

3) Never unplug your refrigerator by pulling on the power cord. Always

grasp the plug firmly and pull straight out from the outlet.

4) Repair or replace immediately, all electric service cords that have

become frayed or otherwise damaged. Do not use a cord that shows

cracks or abrasion damage along its length, the plug or the

connector end.

5) Unplug your refrigerator before cleaning or before making any repairs.

Note: If for any reason this product requires service, we strongly

recommend that a certified technician performs the service.

6) Do not use any electrical device or any sharp instrument in defrosting

your refrigerator.

7) If your old refrigerator is not being used, we recommend that you

remove the doors and leave the shelves in place. This will reduce the

possibility of danger to children.

8) After your refrigerator is in operation, do not touch the cold surfaces

in the freezer compartment, particularly when hands are damp or wet.

Skin may adhere to these extremely cold surfaces.

9) Do not refreeze foods, which have been thawed completely. The United

States Department of Agriculture in Home and Garden Bulletin No. 69

reads: “…You may safely refreeze frozen foods that have thawed if

they still contain ice crystals or if they are still cold-below 40˚F.

“…Thawed ground meats, poultry, or fish that have any off-odor or

off-color should not be refrozen and should not be eaten. Thawed ice

cream should be discarded. If the odor or color of any food is poor or

questionable, discard it. The food may be dangerous to eat.

“…Even partial thawing and re-freezing reduce the eating quality of

foods, particularly fruits, vegetables, and prepared foods. The eating

quality of red meats is affected less than that of many other foods. Use

refrozen foods as soon as possible, to save as much of its eating quality

as you can.”

English

Thank you for using our Summit

product. This easy-to-use manual

will guide you in getting the best

use of your refrigerator.

Remember to record the model and

serial number. They are on a label

in the rear of the refrigerator.

Model number

Serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain

warranty service.

10) This refrigerator should not be recessed or built-in an enclosed cabinet.

It is designed for freestanding installation only.

11) Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

For Future Reference Please

DANGER

Risk of child entrapment. Before you throw away your old

refrigerator or freezer, take off the doors. Leave the shelves

in place so that children may not easily climb inside.

English

Table Of Contents

PAGE

Safety Precautions......................................................................1

Parts And Features .....................................................................4

Installing Your Refrigerator.......................................................5

Unpacking Your Refrigerator .............................................................5

Leveling Your Refrigerator .................................................................5

Proper Air Circulation.......................................................................5

Electrical Requirements .....................................................................6

Door Alignment ...............................................................................7

Door Reversal..................................................................................8

Refrigerator Features And Use..................................................... 10

General Features ...........................................................................10

Refrigerator Interior Shelves.............................................................10

Dispense-A-Can™ ..........................................................................11

Defrosting .....................................................................................11

Food Storage Information ...............................................................12

Normal Operating Sounds..............................................................12

Proper Refrigerator Care and Cleaning .................................13

Cleaning and Maintenance.............................................................13

Power Interruptions.........................................................................13

Vacation and Moving Care.............................................................13

Troubleshooting ........................................................................14

Warranty Information..............................................................15

English

1. Freezer Compartment

2. Ice Cube Tray

3. Drip Tray

4. Adjustable Temperature Control

5. Slide-Out Shelves

6. Retainer Bar

7. Adjustable Front Leveling Leg

(not shown)

8. “Dispense-A-Can™” Can Storage

9. Fixed Door Shelf

English

Parts And Features

1. Remove all packaging material. This includes the foam base and all

adhesive tape holding the refrigerator accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed materials

before powering on the refrigerator.

• Your refrigerator has two leveling legs which are located in the front

bottom corners of your refrigerator. After properly placing your

refrigerator in its final position, you can level your refrigerator.

• Leveling legs can be adjusted by turning them clockwise to raise

your refrigerator or by turning them counterclockwise to lower your

refrigerator. The refrigerator door will close easier when the leveling

legs are extended.

• To assure your refrigerator works at the maximum efficiency it was

designed for, you should install it in a location where there is proper

air circulation, plumbing and electrical connections.

• The following are recommended clearances around the refrigerator:

Sides……………3/4" (19mm)

Top....................2" (50mm)

Back..................2" (50mm)

Installing Your Refrigerator

Unpacking Your Refrigerator

Proper Air Circulation

Leveling Your Refrigerator

English

Electrical Requirement

• Make sure there is a suitable power outlet (115 volts, 15 amps outlet)

with proper grounding to power the refrigerator.

• Avoid the use of three prong adapters or cutting off the third

grounding prong in order to accommodate a two prong outlet. This is

a dangerous practice since it provides no effective grounding for the

refrigerator and may result in shock hazard.

• Avoid the use of an extension cord because of potential safety

hazards under certain conditions. If it is necessary to use an extension

cord, use only a 3-wire extension cord that has a 3-blade grounding

plug and a 3-slot outlet that will accept the plug. The marked rating

of the extension cord must be equal to or greater than the electrical

rating of the appliance.

• Do not install your refrigerator in any location not properly insulated

or heated, e.g. garage, etc. Your refrigerator was not designed to

operate in temperature settings below 55˚ Fahrenheit.

• Select a suitable location for the refrigerator on a hard even surface

away from direct sunlight or heat source, e.g. radiators, baseboard

heaters, cooking appliances, etc. Any floor unevenness should be

corrected with the leveling legs located on the front bottom corners of

the refrigerator.

Install Limitations

English

Use of Extension Cords

1. Remove the top hinge cover.

2. Loosen the top hinge screws using a phillips head screwdriver.

3. Adjust the door or put a spacer in between and then tighten

the screws.

4. Replace the top hinge cover.

Door Alignment (see fig. # 1)

fig. # 1

English

Reversing the Door Hinge

1. Remove the top hinge cover. (see fig. # 1)

2. Using a phillips pead screwdriver, loosen and remove the screws

holding the top hinge in place. (see fig. # 1)

3. Remove the top hinge and carefully lift off the door.

4. Remove the screw hole plug from the opposite side and insert the

plug in the screw hole openings of the just removed screws.

(see fig. # 2)

5. Remove the door pin from the bracket of the lower hinge by turning

counter clockwise. Move the pin to the opposite hole and tighten.

(see fig. # 3)

6. Loosen the screws holding the lower hinge bracket and remove the

hinge. (see fig. # 3)

7. Align the holes in the lower hinge bracket to the corresponding

holes in the opposite side of the cabinet. Insert and tighten the

screws. (see fig. # 3)

8. Align the bottom hole on the left side of the door with the pin of the

lower hinge and slide into place.

fig. # 2

screw hole plugs

English

9. Align the pin of the top hinge with top hole on the left side of the

door and push into place. Replace the screws in the upper hinge

bracket but do not tighten all the way. (see fig. # 2)

10. Make sure the door closes easily but forms a tight seal. Adjust the

door as needed. Once you are satisfied with the door alignment,

completely tighten the upper door hinge screws.

11. Replace the hinge cover. (see fig. # 2)

12. If the door does not close properly, refer to the section titled

“Door Alignment”.

NOTE: As the door gets pressed-in during shipping, after reversing

the door, the gasket may have to be reset. This is done to

prevent the cool refrigerated air from escaping. If there is a

gap between the door gasket and the cbainet, set the gasket by

gently pulling it out to seal the gap.

fig. # 3

door pin

lower hinge bracket

screw hole plug

English
