Write Model & Serial Nos. here:

Model No. ________________

Serial No. _________________

ALL-REFRIGERATORS

Models CM405

CM411L

CM421BL

Owner's Manual

BEFORE USE, PLEASE READ AND FOLLOW

ALL SAFETY RULES AND OPERATING INSTRUCTIONS

FELIX STORCH, INC.

770 Garrison Avenue

Bronx, NY 10474

www.medicalrefrigerators.com

FF511L

(ACCUCOLD) *

FF521BL (ACCUCOLD) *

SCR450L (ACCUCOLD) *

SCR500BL (SUMMIT COMMERCIAL)

IMPORTANT SAFEGUARDS

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance.

Always read and obey all safety messages.

This is the Safety Alert Symbol. This symbol alerts you to potential

hazards that can kill or injure you and others. All safety messages will

follow the Safety Alert Symbol and either the words DANGER or

WARNING.

DANGER means that failure to heed this

safety statement may result in severe

personal injury or death.

WARNING means that failure to heed

this safety statement may result in

extensive product damage, serious

personal injury, or death.

Safety messages will alert you to what the potential hazard is, tell you how to reduce the chance

of injury, and let you know what can happen if the instructions are not followed.

Before the refrigerator is used, it must be properly positioned and installed

as described in this manual, so read the manual carefully. To reduce the

risk of fire, electrical shock or injury when using the refrigerator, follow

basic precautions, including the following:

•Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,

and do not use an extension cord.

•It is recommended that a separate circuit, serving only your refrigerator, be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

•Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or

explosion. And do not store or use gasoline or other flammable vapors and liquids in the

vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

•Before proceeding with cleaning and maintenance operations, make sure the power line of the

unit is disconnected.

•Do not connect or disconnect the electric plug when your hands are wet.

•Unplug the refrigerator or disconnect the power before cleaning or servicing. Failure to do so

can result in electrical shock or death.

•Do not attempt to repair or replace any part of your refrigerator unless it is specifically

recommended in this material. All other servicing should be referred to a qualified technician.

•This unit is not designed to operate in enclosed spaces. When placing your unit, make

sure you allow adequate airflow on all sides.

•Use two or more people to move and install the refrigerator. Failure to do so can result in back

or other injury.

•To ensure proper ventilation for your refrigerator, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below

90°F (32°C). This unit must be installed in an area protected from the elements, such as wind,

rain, water spray or drips.

•The refrigerator should not be located next to ovens, grills or other sources of high heat.

•The refrigerator must be installed with all electrical connections in accordance with state and

local codes. A standard electrical supply (115V AC only, 60 Hz), properly grounded in

accordance with the National Electrical Code and local codes and ordinances, is required.

•Do not kink or pinch the power supply cord of the refrigerator.

•The fuse (or circuit breaker) size should be 15 amperes.

•It is important for the refrigerator to be leveled in order to work properly. You may need to

make several adjustments to level it.

•Never allow children to operate, play with or crawl inside the refrigerator.

•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

•Do not use this apparatus for other than its intended purpose.

Risk of child entrapment

Child entrapment and suffocation are not problems of the past. Junked or abandoned

refrigerators are still dangerous, even if they will “just sit in the garage a few days.”

•Before you throw away your old refrigerator: Take off the doors. Leave the

shelves in place so that children may not easily climb inside.

•Never allow children to operate, play with, or crawl inside the refrigerator.

- SAVE THESE INSTRUCTIONS -

Table of Contents

Important Safeguards .......................................................................................................1 - 2

Location of Parts ...................................................................................................................3

Technical Information ............................................................................................................4

Installation Instructions .....................................................................................................4 - 6

Before Using Your Refrigerator ..................................................................................4

Installing the Refrigerator ......................................................................................4 - 5

Electrical Connection / Extension Cord ......................................................................5

Reversing the Door Swing / Door Handle Installation..................................................6

Operating Your Refrigerator ..................................................................................................7

Setting the Temperature Control / Light Switch / Automatic Defrost System ..............7

Care and Maintenance .....................................................................................................8 - 9

Cleaning the Refrigerator / Power Failure / Vacation Time / Moving the Unit ............8

Energy-Saving Tips ...................................................................................................9

Troubleshooting ..................................................................................................................10

Limited Warranty .................................................................................................................11

Location of Parts

Temperature

control knob

Door

(solid door

for FF511L

& FF521BL;

glass door for

SCR450L &

SCR500BL)

Crisper cover

Crisper

(FF511L and

FF521BL only)

Leveling legs

Shelves

(Wire for FF511L

& SCR450L;

glass for FF521BL

& SCR500BL)

Light switch

(behind

thermostat

housing)

MODELS FF511L, FF521BL & SCR450L ARE DESIGNED FOR MEDICAL OR PHARMACEUTICAL USE ONLY.

NONE, INCUDING MODEL SCR500BL, ARE INTENDED FOR USE AS HOUSEHOLD REFRIGERATORS.

Technical Information

Models: FF511L (white with solid door)

FF521BL (black with solid door)

SCR450L (white with glass door)

SCR500BL (black with glass door)

Capacity: 4.1 cubic feet

Electrical Input: 115V AC / 60Hz / 1.4A / 100W

Refrigerant: R134a, 1.75 oz

Installation: Free-standing

Unit Weight: 57 lbs

Unit Dimensions: 19.5"W x 21.5"D x 33.3"H*

*For models with suffix ADA, height is modified to 32” for use under lower counters

Installation Instructions

Before Using Your Refrigerator:

•Remove the exterior and interior packing.

•Check to be sure you have all of the following parts:

3 shelves

1 crisper drawer with glass cover (models FF511L & FF521BL only)

1 handle with screws and handle seal

2 keys

•Before connecting the unit to the power source, let it stand for approximately 2

hours. This will reduce the possibility of a malfunction in the cooling system

from handling during transportation.

•Clean the interior surface with lukewarm water using a soft cloth.

Installing the Refrigerator:

•This appliance is designed to be free-standing only, and should not be

recessed or built in.

•Place your unit on a floor that is strong enough to support the unit when it is

fully loaded. To level your unit, adjust the leveling legs at the bottom.

•Allow 5 inches of space between the back and sides of the unit, which will

allow the proper air circulation to cool the compressor and condenser.

•Locate the unit away from direct sunlight and sources of heat (stove, heater,

radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources

may increase electrical consumption. Extremely cold ambient temperatures

may also affect the unit's performance.

NOTE: THESE REFRIGERATORS ARE DESIGNED FOR MEDICAL OR PHARMACEUTICAL USE ONLY AND

ARE NOT INTENDED FOR USE AS HOUSEHOLD REFRIGERATORS.

Improper use of the grounded plug can result in the risk of electrical shock. If the power

cord is damaged, have it replaced by an authorized service center.

•Avoid locating the unit in moist areas.

•Plug the unit into an exclusive, properly installed and grounded wall outlet. Do

not under any circumstances cut or remove the third (ground) prong from the

power cord. Any questions concerning power and/or grounding should be

directed toward a certified electrician or authorized service center.

•After plugging the appliance into a wall outlet, allow the unit to cool down for 2

to 3 hours before placing items to be stored inside.

Electrical Connection:

This unit should be properly grounded for your safety. The power cord of this unit

is equipped with a three-prong plug which mates with a standard three-prong wall

outlet to minimize the possibility of electrical shock.

Do not under any circumstances cut or remove the third ground prong from the

power cord supplied. For personal safety, this appliance must be properly

grounded.

This unit requires a standard 115-volt AC/60Hz electrical outlet with three-prong

ground. Have the wall outlet and circuit checked by a qualified electrician to

make sure the outlet is properly grounded. When a standard 2-prong wall outlet

is encountered, it is your responsibility and obligation to have it replaced with a

properly grounded 3-prong wall outlet.

To prevent accidental injury, the cord should be secured behind the unit and not

left exposed or dangling.

The unit should always be plugged into its own individual electrical outlet which

has a voltage rating that matches the rating label on the appliance. This provides

the best performance and also prevents overloading house wiring circuits that

could cause a fire hazard from overheated wires. Never unplug the unit by pulling

on the power cord. Always grip the plug firmly and pull straight out from the

receptacle. Repair or replace immediately any power cord that has become

frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion

damage along its length or at either end. When moving the unit, be careful not to

damage the power cord.

Extension Cord:

Do not use an extension cord with this appliance. If the power cord is too short,

have a qualified electrician or service technician install an outlet near the

appliance.

Reversing the Door Swing:

Figure 1 (Default position) Figure 2 (After door reversal)

1. Upper hinge cover 6. Screws

2. Screws 7. Hole cover

3. Upper hinge 8. Cabinet

4. Door 9. Pin cap

5. Lower door hinge

This refrigerator can be opened from either the right side or the left. By default, the door

hinge is on the right side. If you prefer it on the left, please follow these instructions:

NOTE: All of the parts that are removed must be kept for the reinstallation of the door.

1. Remove the three screws (6) holding lower door hinge (5). Keep hinge for later use.

2. Remove the door from the upper hinge (3), and keep the padded surface upward to

prevent scratching.

3. Remove the upper hinge cover (1), remove the two screws (2), remove the upper

hinge (3) and keep it for later use.

4. Remove the hole cover (7) and transfer it to the same location on the opposite side.

5. Insert the lower door hinge (5) into the left side, fixing the hinge into place by

tightening all the screws (6).

6. Remove the pin cap (9) from the left side of the upper door frame and then transfer it

to the same location on the opposite side.

7. Set the door on the lower door hinge (5), keep the door level, then fix the upper hinge

(3) to the body (8) by the screws (2).

8. Put on the upper hinge cover (1).

Door Handle Installation:

The door has two screw holes on each side, allowing you to install a handle (included).

To do so, align the handle with the screw holes on the side you prefer. Fix the handle in

place with the included screws, then cover the screw heads with the handle seal

(included).

Operating Your Refrigerator

Setting the Temperature Control:

•Your unit has only one control for regulating the temperature in the

compartment. The temperature control is located on the upper right-hand side

of the compartment.

•

When you turn the unit on for the first time, set the control to its coldest setting,

which is

•The range of the temperature control is from the Off position to 6. After 24 to

48 hours, adjust the temperature control to the setting that best suits your

needs. The setting 3should be appropriate for most uses.

•To turn the appliance off, turn the temperature control to Off.

NOTES:

1. Turning the temperature control to Off stops the cooling cycle but does not

shut off the power to the unit.

2. If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5

minutes before restarting the unit. If you attempt to restart before this time

delay, the unit will not start.

Interior Light

The interior light is controlled by a rocker switch located behind the thermostat

(temperature control) housing. If you turn the light on, be sure to turn it off again

before closing the door.

Switch

Automatic Defrost System:

It is not necessary for you to defrost this appliance. While the compressor is

operating, ice may build up along the cold rear wall of the refrigerator

compartment (the evaporator is behind the wall). During the compressor's off-

cycle, the ice will melt, drip down, and drain through a small hole at the back of

the cabinet into a tray above the compressor where the compressor's heat

evaporates the water.

If you notice an excessive build-up of ice on the rear wall, try setting the

thermostat to a slightly warmer setting. Be sure the door gasket is well seated.

Occasionally you should check that there is no obstruction of the drain hole in the

bottom rear of the cabinet.

Care and Maintenance

Cleaning the Refrigerator:

1. Turn the temperature control to Off, unplug the unit and remove the stored

items and shelves.

2. Wash the inside surfaces with a solution of warm water and baking soda. The

solution should contain about 2 tablespoons of baking soda to a quart of

water.

3. Wash the shelves with a mild detergent solution.

4. Wash the outside cabinet with warm water and mild liquid detergent. Rinse

well and wipe dry with a clean soft cloth.

5. Wring excess water out of the sponge or cloth before cleaning the area of the

controls, or any electrical parts.

CAUTION: Failure to unplug the unit before cleaning or maintenance could result

in electrical shock or personal injury.

Power Failure:

Most power failures are corrected within a few hours and should not affect the

temperature of your unit if you minimize the number of times the door is opened.

If the power is going to be off for a longer period of time, you need to take the

proper steps to protect the contents.

Vacation Time:

Short vacations: Leave the refrigerator operating during vacations of less than

three weeks.

Long vacations: If the refrigerator will not be used for several months, remove all

contents and unplug the power cord. Clean and dry the interior thoroughly. To

prevent odor and mold growth, leave the door open slightly, blocking it open if

necessary.

Moving the Unit:

1. Remove all items stored in the refrigerator.

2. Securely tape down all loose items inside the unit.

3. Turn the leveling legs up to the base to avoid damage.

4. Tape the door shut.

5. Be sure the unit stays secure in the upright position during transportation.

Also, protect the outside of the unit with a blanket or similar covering.

Energy-Saving Tips:

•The unit should be located in the coolest area of the room, away from heat-

producing appliances and out of direct sunlight.

•Let warm items cool to room temperature before placing in the unit.

Overloading the unit forces the compressor to run longer.

•Be sure to wrap items properly and wipe containers dry before placing them in

the unit. This cuts down on frost build-up inside the unit.

•The unit's storage area should not be lined with aluminum foil, wax paper or

paper toweling. Liners interfere with cold air circulation, making the unit less

efficient.

•Organize and label stored items to reduce door openings and extended

searches. Remove as much as needed at one time, and close the door as

soon as possible.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Summit Kühlschrank Handbücher

Summit

Summit FFBF240W Bedienungsanleitung

Summit

Summit FF1425SS Bedienungsanleitung

Summit

Summit CP97 Bedienungsanleitung

Summit

Summit FF29B Bedienungsanleitung

Summit

Summit CT66 Series Bedienungsanleitung

Summit

Summit FFBF192SS Bedienungsanleitung

Summit

Summit ADRD15 Bedienungsanleitung

Summit

Summit SP6DBS2D7 Bedienungsanleitung

Summit

Summit FFRF36 Bedienungsanleitung

Summit

Summit FF19524 Bedienungsanleitung

Summit

Summit SP5DS2DBLK Bedienungsanleitung

Summit

Summit BDR190NACSSHH Leitfaden

Summit

Summit FFBF246SS Bedienungsanleitung

Summit

Summit ADRD18 Bedienungsanleitung

Summit

Summit SCR600BL-BITB Leitfaden

Summit

Summit CP171 Series Bedienungsanleitung

Summit

Summit S19L Leitfaden

Summit

Summit SP6DS2DOS SERIES Leitfaden

Summit

Summit SCR600 Series Leitfaden

Summit

Summit ALR47B Bedienungsanleitung

Summit

Summit SCR600LOS SERIES Bedienungsanleitung

Summit

Summit MB34 Bedienungsanleitung

Summit

Summit FF1325SSIM Bedienungsanleitung

Summit

Summit FF1843BCSSADA Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
