Sun-Tech ST940 Bedienungsanleitung

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

1 of 28

Personal / Asset Tracker

ST940

User Manual

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

2 of 28

Table of Contents

1. Introduction....................................................................................................................................................3

2. Features..........................................................................................................................................................5

2-1. GSM/GPRS specification .....................................................................................................................6

2-2. GPS specification.................................................................................................................................7

2-3. Available operation / Features.............................................................................................................8

3. Accessories.................................................................................................................................................... 9

4. Install SIM card...............................................................................................................................................9

5. Charging battery ..........................................................................................................................................10

6. Appearance ..................................................................................................................................................11

7. Operation......................................................................................................................................................11

8. Commands ...................................................................................................................................................13

9. Reports.........................................................................................................................................................25

Revision History...............................................................................................................................................28

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

3 of 28

Disclaimer

We, at Suntech, announce that this document and all other related products (i.e. device, firmware, and software) have

been developed by the company, Suntech International Ltd., which is hereinafter referred to as “Suntech”. The

information in this manual is believed to be accurate and reliable at the time of releasing. We, at Suntech, also

assume no responsibility for any damage or loss resulting from the use of this manual, and expressly disclaim any

liability or damages for loss of data, loss of use, and property damage of any kind, direct, incidental or consequential,

in regard to or arising out of the performance or form of the materials presented herein or in any software program(s)

that may accompany this document. When this document is released, it is most compatible with a specified firmware

version. Now that the functionalities of the devices are being developed and improved continuously from time to time

by Suntech, any alteration on the protocol, the firmware functions, the hardware specifications of the product is subject

to change without prior notice.

We, at Suntech, notify that Suntech holds all parts of intellectual rights applicable in the copyright laws in all the

countries. The information contained in this document cannot be reproduced in any form without prior written consent

made by Suntech. Any software programs that might accompany this document can be used only in accordance with

any license agreement(s) between the purchaser and Suntech.

Document Amendments

When it comes to the firmware version column with specific firmware number, any amendment(s) on the comments

column should be made on this relevant firmware version (and the versions thereafter). Before applying any changes

made in this protocol, you are required to make sure that you have upgraded the firmware suitable for the specified

version.

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

4 of 28

1. Introduction

ST940: Personal / Asset Tracking Device

The ST940 is a waterproof (IP65 compliant) hard-cased ultra-mini tracking device for various usages such as asset

tracker and personal trackers.

Without any efforts for connecting wires, the ST940 works autonomously with its built-in battery. If users want to track

an object with the ST940, all they have to do is just simply put it into the box or the carry bag where the object is

contained. And then, users can track the locations of such an object and receive an alert if the object enters or leaves

a pre-defined zone.

This non-wiring device is so small that it can be hidden after being placed. So, the waterproof ST940 is suitable for

covert tracking even in rainy weather conditions. The ST940 is ideal for tracking various objects such as people,

vehicles (especially small vehicles or motorcycles), boats and valuable fixed/moving assets like expensive

merchandises, computers, smart phones, electronic products, machinery and so on.

In addition to 3-axis acceleration sensor, the ST940 has various functionalities such as low-power consumption

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

5 of 28

algorithms and motion checking.

*In case the ST940 is placed inside a metal container, it may not work.

- Position of the IMEI label

the center of the back cover.

2. Key Features

New technology and the latest GPS Chipset

GSM Quad band support 850/900/1800/1900 Mhz band width

SMS/GPRS communications

Report when the battery is in a low status

Periodic reporting in real time

Built-in motion detector for alarming

Waterproof in compliance with IP65

Baby’s palm-sized versatile mini tracker

Fixed asset tracking in real time with Standby Current with less than 8uA.

RF Exposure

This device complies with FCC/CE RF exposure guidelines set forth for an uncontrolled environment.

For body worn operation, this device has been tested and meets the RF exposure guidelines for use with

an accessory that contains no metal and the positions the handset a minimum of 0.5 cm from the body.

Use of other enhancements may not ensure compliance with RF exposure guidelines.

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

6 of 28

2-1. GSM/GPRS Specifications

Item

Description

Battery

Rechargeable 3.7V, Li-ion Battery- 1500mAh

Motion Detection

Built-in 3-axis Acceleration sensor

Standby time

Deep Sleep

Sleep on network

*with 1,500mA/h Li-ion battery

less than 8uA

Report once a day: 400days

3 minute reporting: 99 hours

5 minute reporting: 139 hours

10 minute reporting: 200 hours

30 minute reporting: 284 hours

* only at a good GPS and GPRS signals

Frequency/ Sensitivity

GSM 850 / EGSM 900MHz -104dBm

DCS1800 / PCS1900MHz -102dBm

Temperature Range

-20°C ~ +55°C

*Caution !

Please pay a careful attention that the vehicle shall NOT be left

under direct sunlight for long time in hot weather. There is a risk of

battery explosion at hot temperature.

User Interface

Power Button, SOS Button,

Charger Adaptor, Charger & Setting Cable

AT Command

GSM 07.07 , 07.05

LED Indicator

GPRS, GPS, Charging status

GPRS

Multi-slot Class 12

Support all 4 coding schemes

(CS-1, CS-2, CS-3 and CS-4)

‘SyncTrack’for PC

Mini USB cable

Dimensions

50.5(W) x 75(L) x 22.5(T) mm

55.9(W) x 88.3(L) x 35.6(T) mm (with cradle)

Weight

88g,

200g (with cradle)

Approval

CE, FCC, RoHS

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

7 of 28

2-2. GPS Specifications

Item

Description

Receiver Type

56-channel U-blox7 engine

GPS & QZSS L1 C/A, GLONASS L1OF,

Galileo* E1B/L1, Compass* ready

SBAS: WAAS, EGNOS, MSAS

Update Rate

10Hz

Accuracy1)

Position 2.5m CEP

SBAS 2.0m CEP

Acquisition2)

TCXO

Cold starts 26s

1s ( AssistNow Autonomous)

Aided start<1s

Hot start<1s

Sensitivity3)

Tracking -162dBm

Reacquisition -160dBm

Cold start -148dBm

Back-up Supply

Voltage range : 2.5V to 3.6V

Antenna type

Patch Antenna

Operating Temperature

-20 ~+ 55℃

*1) All SV @ –130 dBm

*2) It depends on aiding data connection speed and latency

*3) The 3 figures were measured with a good active antenna.

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

8 of 28

2-3. Operational Features

Item

Description

Configuration

either by SMS or PC

Parameter Change

either by SMS or GPRS

Command /Control

either by SMS or GPRS

Reporting

either by GPRS or SMS (as a back-up)

GPRS Communication

TCP, SMS, (UDP is optionally available.)

GPRS Connection

either always connected or upon needed

Basic Data reported

NMEA location, Speed, Course, GPS signal status, Message No.,

Accumulated moving (travelling) distance

Data Storage

up to 2,000 locations in case of transmission failure or cost issue

Reporting

Cyclic location reporting with interval adjustable making possible only

when command comes

Back-up Reporting

possible (Dual IP reporting or Backup SMS reporting)

Power down

Sleep on network (less than 2.8mA)

Deep sleep on no network (less than 8uA):

How to upgrade

Firmware

by OTA (Over The Air ) or pc tool.

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

9 of 28

3. Accessories

The ST940 has two accessories:

Wall Charger, and

USB Cable (for charging and setting)

4. How to insert SIM card by step

There are 5 steps in inserting a SIM card onto the ST940 as shown below in the pictures.

Step 1.: Please, unscrew SIM cover. Step 2.: Please, insert SIM #1.

Step 3: Please, insert SIM #2. Step 4.: Please, insert SIM #3

Step 5.: Please, make an assembly with the SIM cover.

Doc. Title

ST940 User Manual (STGPS)

Concerning:

Rev.

Date

Page of Pages

Features and how to configure ST940

1.0

14-10-27

10 of 28

5. Charging battery

1. Open the cover to the multifunction jack on the side of the device.

2. Plug the small end of the travel adapter into the device.

3. Plug the large end of the travel adapter into a power outlet.

4. When charging is finished, unplug the travel adapter from the power outlet.

5. Remove the travel adapter from the device.

It is highly recommended that the rechargeable battery should be charged

completely before using the device. Connect the ST940 to its charger cable

supplied by Suntech and charge it for 5 hours.

< Charging Status indicated on the battery LED >

Red blinking twice: under 10% of the full capacitance

Red blinking: under 30% of the full capacitance

Orange blinking: 30% to 80%

Green blinking: Almost Full

Green lighting: Completed charging in full

As soon as the charger is connected with the device which has been turned off, the GPS LED will be turned on and

continue

The battery does not charge properly or sometimes your device turns itself off while charging

• Disconnect the device from the charger, remove and reinstall the battery, and try charging again.

• If the battery no longer charges completely, dispose of the old battery properly and replace it with a new

battery.

When an error occurs while the battery is being charged. The red LED and the green LED blink by turns. In this case,

please disconnect the charger cable and try to do charging again by reconnecting the cable. If this error occurs

continuously, please replace the battery or contact Suntech.

Andere Handbücher für ST940

Inhaltsverzeichnis

Andere Sun-Tech GPS Handbücher

Sun-Tech

Sun-Tech ST4500 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4340LC Bedienungsanleitung

Sun-Tech

Sun-Tech ST3940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST310U Bedienungsanleitung

Sun-Tech

Sun-Tech ST3500 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940B Bedienungsanleitung

Sun-Tech

Sun-Tech ST4300 Bedienungsanleitung

Sun-Tech

Sun-Tech ST940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST3340 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4310P Bedienungsanleitung

Sun-Tech

Sun-Tech ST4310 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940B Bedienungsanleitung

Sun-Tech

Sun-Tech ST4315 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST690 Bedienungsanleitung

Sun-Tech

Sun-Tech ST310U Bedienungsanleitung

Sun-Tech

Sun-Tech ST3300 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4950 Bedienungsanleitung

Sun-Tech

Sun-Tech ST3940 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4340 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4290L Bedienungsanleitung

Sun-Tech

Sun-Tech ST500 Bedienungsanleitung

Sun-Tech

Sun-Tech ST410 Bedienungsanleitung

Sun-Tech

Sun-Tech ST4940B Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
