mPulse® Series
User Manual
2
Congratulations! You are now the owner of an mPulse™ sauna.
With Sunlighten infrared heat, you are empowered to improve your quality of
life. Just follow our assembly instructions and sauna protocol to begin your
wellness journey with the very best in infrared therapy.
WARNING:
Do not use this sauna to treat any health problems without consulting your physician.
Sunlighten, Inc. does not provide medical advice, education or treatment. Our information
should not be relied on in making decisions about your health. Always consult your physician for
medical advice.
3
TABLE OF CONTENTS
PRE-INSTALLATION
Specications 4
Pre-installation Information 5
INSTALLATION GUIDE
Parts List 7
Assembly Instructions 8
OPERATING INSTRUCTIONS
Android Control Panel Guide 16
Initial Set-Up 16
Sauna Settings 17
Health Programs 21
Scheduling Sauna Sessions 23
MediaApps 24
Warm Up Time & Usage Guidelines 26
Sauna Protocol 27
Health & Safety 28
FREQUENTLY ASKED QUESTIONS 29
TROUBLESHOOTING 32
WARRANTY 34
4
MPULSE SERIES SPECIFICATIONS
aSPIRE
Dimensions
(Width x Depth x Height)
43.6inx41.6inx78.6in
110.7 cm × 105.6 cm × 199.6 cm
Power 120v;1800wattsmax(1440wattscontinuous);15a
DEDICATED 120V 15A CIRCUIT & OUTLET REQUIRED. SEE IMAGE 1 FOR REFERENCE
bELIEVE
Dimensions
(Width x Depth x Height)
51.7inx47.6inx78.6in
131.3 cm × 120.9 cm × 199.6 cm
Power 120v;2400wattsmax(1920wattscontinuous);20a
DEDICATED 120V 20A CIRCUIT & OUTLET REQUIRED. SEE IMAGE 2 FOR REFERENCE
cONQUER
Dimensions
(Width x Depth x Height)
70.6inx47.6inx78.6in
179.3 cm × 120.9 cm × 199.6 cm
Power 240v;3840wattsmax(3072wattscontinuous);20a
DEDICATED 240V 20A CIRCUIT & OUTLET REQUIRED. SEE IMAGE 3 FOR REFERENCE
dISCOVER
Dimensions
(Width x Depth x Height)
70.6 in x 70.6 in x 78.6 in
179.3 cm × 179.3 cm × 199.6 cm
Power 240v;3840wattsmax(3072wattscontinuous);20a
DEDICATED 240V 20A CIRCUIT & OUTLET REQUIRED. SEE IMAGE 4 FOR REFERENCE
eMPOWER
Dimensions
(Width x Depth x Height)
85.6 in x 70.6 in x 78.6 in
217.4cm×179.3cm×199.6cm
Power 240v;3840wattsmax(3072wattscontinuous);20a
DEDICATED 240V 20A CIRCUIT & OUTLET REQUIRED. SEE IMAGE 5 FOR REFERENCE
2
5-20R
USA/CANADA
1
5-15R
USA/CANADA
4
6-20R
USA/CANADA
5
6-20R
USA/CANADA
3
6-20R
USA/CANADA
5
INTERNATIONAL ELECTRICAL SPECIFICATIONS
Region Voltage/Ampe Exterior Power Cord
Europe Aspire: 230V-7.5A
Believe: 230V-10A
Conquer: 230V-15A
Discover: 230V-18A
Empower: 230V-20A
Aspire: H07RN-F,250V-16A,Plug type: MT-32 or NS-13
Believe: H07RN-F,250V-16A,Plug type: MT-32 or NS-13
Conquer: H07RN-F,250V-16A,Plug type: MT-32 or NS-13
Discover: H07RN-F,250V-20A,No Plug
Empower: H07RN-F,250V-20A,No Plug
Singapore Aspire: 230V-7.5A
Believe: 230V-10A
Conquer: 230V-15A
Discover: 230V-18A
Empower: 230V-20A
Aspire: H07RN-F,250V-16A,Plug type: NS-17
Believe: H07RN-F,250V-16A,Plug type: NS-17
Conquer: H07RN-F,250V-16A,Plug type: NS-17
Discover: H07RN-F,250V-20A,Don’t have Plug
Empower: H07RN-F,250V-20A,Don’t have Plug
Australia Aspire: 240V-7.5A
Believe: 240V-10A
Conquer: 240V-15A
Discover: 240V-18A
Empower: 240V-20A
Aspire: H07RN-F,250V-16A,Plug type: XR-351
Believe: H07RN-F,250V-16A,Plug type: XR-351
Conquer: H07RN-F,250V-16A,Plug type: XR-351
Discover: H07RN-F,250V-20A,Don’t have Plug
Empower: H07RN-F,250V-20A,Don’t have Plug
1. Have a certied electrician install a dedicated outlet for sauna. Not
doing so will void warranty.
2. Remember your sauna should be assembled by 2 or more people.
3. Do not place plumbing or plumbing xtures in the sauna.
4. Keep all liquids away from the heating panels and electronics.
5. Install sauna on a level surface.
6. Install sauna in an area that is dry and protected from the weather.
7. Keep ammable objects and corrosive chemical substances away from
the sauna.
8. Installation of the sauna in an area below standard room temperature
can increase warm up time
PRE-INSTALLATION
6
PRE-INSTALLATION
UNPACK YOUR SAUNA
Refer to the parts list on the next page as you unpack your sauna to ensure you
have all of the parts for installation. We make every effort to ensure that your
sauna arrives safely. Double check to ensure that all pieces arrived undamaged
in transit. If damaged, please call Sunlighten Customer Service immediately
at 913.754.0831 x7 or your local Sunlighten representative. Photos of any
damage are required to process any replacement request. Please do not
discard any loose parts or fabric.
Unpackyoursaunainalargeareafreeofobstructions.Layboxesatontheground
and undo any bands or tape. Once unpacking is complete, proceed to installation
instructions.
RECORD SAUNA SERIAL NUMBER: #
(Locatedonthebacksideoftheoorpanel)
INSTALLATION GUIDE
NOTE: Beware of the glass door
(packed between foam boards and
wrapped with paper and shrink
wrap). Keep wrapped and lean
against a wall, in an area free of
obstructions until ready to install to
prevent shattering.
7
Front Panel
Back Panel
Le Panel Right Panel
Floor Panel (base)
PARTS LIST
QUANTITY PART
1 Front panel
1 Back panel
1 Left side panel
1 Right side panel
1 Roof panel
1 Floor panel (base)
1Tempered Glass door (2 doors for dISCOVER)
4Door hinge gaskets
1 Bench panel (2 for dISCOVER, 3 for eMPOWER)
1Doorhandlew/2screws,4plasticwashers,2roundwashers,
(double for dISCOVER)
4C clips
1 Main power cord
5 Furniture feet - large (10 for eMPOWER)
2 Furniture feet - small
Important Note: Eucalyptus models have a solid wood oor; no oor heater
included.
8
SAUNA ASSEMBLY
The following pictures are for your reference. The dISCOVER and eMPOWER
models have additional steps. Please review before assembling your sauna.
1. INSTALLING THE FEET
Install screw through wooden feet into designated holes on the bottom of the
oorpanel. The small feet go towards the back of the sauna (back side has the
power box).
2. PLACING THE FLOOR PANEL
Placeoorpanelonasmoothatsurface.Ventopeningandstickersindicate
back side of sauna base. Before proceeding, double check that the base
locationisinitsnalposition.Makesurethebaseisleveltoavoidanyparts
becoming misaligned (shims can be placed under furniture feet if surface is
not level). Leave enough room around your sauna to plug in the power cord
(located on back left side) and for any maintenance once it is assembled.
Remove power control covers before proceeding to next step. After connections
are made and sauna powers on properly, screw covers back in place.
* Eucalyptus models have a solid wood oor; no oor heater included.
* Make a note of the serial number for keypad setup and future use - see page 6.
Power Control Cover
WARNING:
Heater grate must be installed prior to
steppingontheoor.
9
3. PLACE THE BACK PANEL
Begin by removing the small wooden wiring covers at the bottom of each panel
before you assemble the wall panels.
(A) Place the back panel into the groove in base. Center its location with the
raisedareaoninterioroor.Onepersonshouldholdthewallwhiletheother
person continues to the next step.
4. CONNECTING THE RIGHT SIDE PANEL
While the rear panel is being held in position, place the right panel into the
grooved base and gently raise into position. The magnet system and wooden
dowels will help to pull the panels together.
(B) Place the C shaped piece of stainless steel (C clip) into the groove on top of
the panels to further hold them together. Once the C clip is installed correctly,
you can let go of the panels.
B
NOTE: You may want to remove the heater covers prior to installing wall panels to keep
them from falling out as the walls are being moved. REMEMBER THE CORRECT
LOCATION TO REATTACH.
A
10
Pay careful attention to the power
cords, making sure they are safely out
of the way.
(C) Place C clips into grooves on top
panels to secure the walls together.
C
5. CONNECTING THE FRONT PANEL
Place the front panel into the groove on the front of the base. DO NOT lift by
the thin horizontal pieces that become the top and bottom of the door frame.
D
6. CONNECT THE LEFT SIDE PANEL
Place the left panel into the grooved base at a slight angle and gradually
bring to vertical position until magnets click into place - making sure you
do not hold on to glass when doing so.
(D) Once wall is in place, place
C clips into the two remaining
grooves on the panels’ top
corners.
