USER’S MANUAL

Revision 1.0

SUpERSERvER®

2028BT-HTR+, 2028BT-HNR+,

2028BT-HNC0R+

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Manual Revision 1.0

Release Date: March 16, 2017

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

PrefacePreface

Preface

About this Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SuperServer. Installation and

maintenance should be performed by experienced technicians only.

Please refer to the server specications page on our Web site for updates on

supported memory, processors and operating systems (www.supermicro.com).

This manual may be periodically updated without notice. Please check the

Supermicro Web site for possible updates to the manual revision level.

Warnings

Special attention should be given to the following symbols used in this manual.

Warning! Indicates high voltage may be encountered when performing

a procedure.

Warning! Indicates important information given to prevent equipment/

property damage or personal injury.

SuperServer 2028BT-Hxxx User Manual

Contents

Chapter 1 Introduction

1-1 Overview ........................................................................................................ 1-1

1-2 Motherboard Features..................................................................................... 1-2

Processors ...................................................................................................... 1-2

Memory ........................................................................................................... 1-2

Serial ATA........................................................................................................ 1-2

PCI Expansion Slots ...................................................................................... 1-2

Rear I/O Ports................................................................................................. 1-2

SIOM Network Slot ......................................................................................... 1-2

System Block Diagram.................................................................................... 1-3

1-3 Chassis Features .......................................................................................... 1-4

System Power................................................................................................. 1-4

Drives .............................................................................................................. 1-4

PCI Expansion Slots ....................................................................................... 1-4

Front Control Panels....................................................................................... 1-4

Cooling System............................................................................................... 1-4

1-4 Contacting Supermicro.................................................................................... 1-5

Chapter 2 Rack Installation

2-1 Unpacking the System .................................................................................... 2-1

2-2 Preparing for Setup......................................................................................... 2-1

Choosing a Setup Location............................................................................. 2-1

2-3 Warnings and Precautions.............................................................................. 2-2

Rack Precautions............................................................................................ 2-2

General Server Precautions............................................................................ 2-2

Rack Mounting Considerations ....................................................................... 2-3

Ambient Operating Temperature ................................................................ 2-3

Sufcient Airow......................................................................................... 2-3

Circuit Overloading..................................................................................... 2-3

Reliable Ground ......................................................................................... 2-3

2-4 Rack Mounting Instructions............................................................................. 2-4

Overview of the Rack Rails ............................................................................ 2-4

Adjusting the Rails .......................................................................................... 2-4

Installing the Rails on a Rack ......................................................................... 2-5

Chassis Installation ......................................................................................... 2-6

Preface

Chapter 3 System Interface

3-1 Overview ......................................................................................................... 3-1

3-2 Control Panel Buttons ..................................................................................... 3-2

Power .............................................................................................................. 3-2

UID .................................................................................................................. 3-2

3-3 Control Panel LEDs ........................................................................................ 3-2

NIC .................................................................................................................. 3-2

Information LED .............................................................................................. 3-3

Overheating..................................................................................................... 3-3

3-4 Drive Carrier LEDs.......................................................................................... 3-4

3-5 Power Supply LEDs ........................................................................................ 3-4

Chapter 4 Advanced Motherboard Setup

4-1 Handling the Motherboard .............................................................................. 4-1

Precautions ..................................................................................................... 4-1

Unpacking ....................................................................................................... 4-1

4-2 Installing the Processor and Heatsink ............................................................ 4-2

Installing an LGA 2011 Processor................................................................... 4-2

Removing the Heatsink .................................................................................. 4-6

4-3 I/O Ports.......................................................................................................... 4-7

Motherboard I/O Ports .................................................................................... 4-7

SIOM Network Connections............................................................................ 4-7

Dedicated IPMI LAN Ethernet Port................................................................. 4-7

Unit Identier Buttons/LED Indicators............................................................. 4-7

4-4 Installing Memory............................................................................................ 4-8

Memory Support.............................................................................................. 4-9

Processor and Memory Module Population Conguration ........................ 4-9

Memory Support for E4-2600 (v3/v4)-based Motherboards .................... 4-10

4-5 Motherboard Details.......................................................................................4-11

Motherboard Quick Reference...................................................................... 4-12

4-6 Connector Denitions.................................................................................... 4-13

Power & Front Control Panel Connector (JF1)............................................. 4-13

Rear Input/Output Connectors ...................................................................... 4-13

Other Connectors.......................................................................................... 4-14

4-7 Jumper Settings ............................................................................................ 4-15

4-8 Onboard Indicators........................................................................................ 4-18

4-9 PCIe Slots and SATA .................................................................................... 4-19

4-10 Installing Software......................................................................................... 4-20

SuperDoctor®5 ............................................................................................. 4-21

4-11 Onboard Battery............................................................................................ 4-22

SuperServer 2028BT-Hxxx User Manual

Chapter 5 Chassis Setup and Maintenance

5-1 Overview ......................................................................................................... 5-1

5-2 Removing Power from the System ................................................................. 5-2

5-3 Accessing the System..................................................................................... 5-3

Removing a Computing Node Drawer............................................................ 5-3

Removing the Chassis Cover ......................................................................... 5-4

5-4 Storage Drives ................................................................................................ 5-5

Installing and Removing Drives ...................................................................... 5-5

5-5 Installing the Expansion Cards ....................................................................... 5-8

SIOM Card ...................................................................................................... 5-9

5-7 System Fans ................................................................................................. 5-10

5-8 Air Shrouds ................................................................................................... 5-12

Installing the Air Shroud................................................................................ 5-12

5-9 Power Supply ............................................................................................... 5-13

Chapter 6 BIOS

6-1 Introduction...................................................................................................... 6-1

Starting BIOS Setup Utility.............................................................................. 6-1

6-2 Main Setup...................................................................................................... 6-2

6-3 Advanced Setup Congurations...................................................................... 6-3

6-4 Event Logs .................................................................................................... 6-31

6-5 IPMI Settings................................................................................................. 6-33

6-6 Security Settings ........................................................................................... 6-35

6-7 Boot Settings................................................................................................. 6-38

6-8 Save & Exit ................................................................................................... 6-40

Appendix A BIOS Error Beep Codes

Appendix B Standardized Warning Statements for AC Systems

Appendix C System Specications

Appendix D UEFI BIOS Recovery Instructions

Chapter 1

Introduction

1-1 Overview

The SuperServer 2028BT-Hxxx is a high-end solution comprised of two main

subsystems: the SC217BHQ+-R2K22BP 2U chassis and X10DRT-B+ dual

processor motherboards. This is a Twin2chassis with four independent hot-

pluggable computing nodes. It includes twenty-four 2.5" storage drives. The system

is equipped with dual 2200 watt high-efciency 80Plus Titanium level (96%+)

redundant power supplies, power-efcient motherboards and optimized cooling

subsystems. It is the best choice for HPC, datacenter and cost-effective blade-type

applications.

Refer to the Supermicro web site for information on operating systems that have

been certied for use with the system (www.supermicro.com).

2028BT-Hxxx Models

System Drive Type 1U Backplanes (4) 2U Midplane (1)

2028BT-HTR+ SATA BPN-ADP-6SATA3-1UB BPN-SAS3-217BHQ

2028BT-HNR+ NVMe BPN-ADP-6NVME3-1UB BPN-NVME3-217BHQ

2028BT-HNC0R+ SAS/NVMe hybrid BPN-ADP-6S3008N4-1UBL BPN-SAS3-217BHQ-N4

In addition to the above components, the server includes:

• Four 8-cm system cooling fans (FAN-0162L4)

• Four air shrouds (MCP-310-21706-0B)

• Four passive CPU heatsinks (SNK-P0047PSM),

Four passive CPU heatsinks (SNK-P0057PS)

• One rackmount rail kit (MCP-290-00144-0N)

Note: For your system to work properly, please follow the links below to download

all necessary drivers/utilities and the user’s manual for your server.

• Supermicro product manuals: http://www.supermicro.com/support/manuals/

• Product drivers and utilities: ftp://ftp.supermicro.com

• Product safety info:

http://www.supermicro.com/about/policies/safety_information.cfm

For support, email [email protected].

Chapter 1: Introduction

1-1

1-2

SuperServer 2028BT-Hxxx

1-2 Motherboard Features

The SuperStorage server 2028BT-Hxxx is built around the X10DRT-B+, a dual

processor motherboard based on the Intel PCH C612 chipset. Below are the main

features. (See Figure 1-1 for a block diagram of the chipset.)

Processors

The motherboard supports single or dual Intel E5-2600 v3/v4 Series processors

in socket R3 (LGA 2011). Refer to the motherboard description pages on the

Supermicro website for a complete listing of supported processors (www.

supermicro.com).

Memory

The motherboard has 24 DIMM slots that can support 3 TB of Load Reduced

(LRDIMM 3DS), 1.5 TB LRDIMM, or 768 GB Registered (RDIMM) ECC DDR4-

2400/2133/1866/1600 memory. See Chapter 4 for details.

Serial ATA

A SATA controller is integrated into the chipset to provide six SATA 3.0 (6/Gbps)

ports), which support RAID 0, 1, 5 and 10.

PCI Expansion Slots

The system supports two PCIe x16 expansion cards in each node (eight total) by

means of a riser card.

Rear I/O Ports

The I/O ports include a VGA port, two USB 3.0 ports and a dedicated IPMI LAN

(Ethernet) port.

SIOM Network Slot

The motherboard provides a PCI-E x16 slot for a Super I/O module (SIOM)

networking card. Several SIOM congurations are available.

1-3

Chapter 1: Introduction

Figure 1-1. Intel PCH C612 Chipset:

System Block Diagram

Note: This is a general block diagram. Please see Chapter 4 for details.

SPI

LAN3

RGRMII

Debug Card

FRONT PANEL

SYSTEM POWER

CTRL

FAN SPEED

PCI-E X1 G2

USB 2.0

PCH

6.0 Gb/S

USB 2.0

LPC

SXB1

RTL8211F-CG

RJ45

SPI

Temp Sensor

EMC1402-1 *2 at diff SMBUS

TPM HEADER

USB 3.0

USB

AST2400

BMC

RMII/NCSI

VGA

BMC Boot Flash

DDR3

5 PHASE

145W

DDR4

VR12.5

#2-1

DDR4

#1-4

#1-3

#1-2

#1-1

QPI

9.6G

DMI2

PCI-E X16 G3

#1-5

#1-6

DMI2DMI2

QPI

9.6G

5 PHASE

145W

VR12.5

SIOM

PCI-E X16 G3

SLOT2

SXB1

PCI-E X16 mini PCI-E G3

PCI-E X8 G3

PCI-E X16 G3

#1#3#2

#1-7

#1-8

#2-2

#2-3

#2-4

#2-5

#2-6

#2-7

#2-8

SXB2

BIOS

SPI

MUX

CPU2

CPU1

#1-9

#1-10

#1-11

#1-12

#2-9

#2-10

#2-11

#2-12

PCI-E X4 G3

Slot1_1

S-SATA3

6.0 Gb/S

Onboard SATA-DOM

S-SATA

6.0 Gb/S

I-SATA

S-SATAPort0, 1, 2

Port0-5

Port 3

PCI-E X4 G3

JF2

#2 #3

System Block Diagram

1-4

SuperServer 2028BT-Hxxx

1-3 Chassis Features

The SC217BHQ+-R2K22BP chassis houses four separate computing nodes, each

containing its own motherboard.

System Power

The system features dual redundant 2200 W power supplies consisting of two

hot-plug power modules. They have 80 Plus certication at Titanium Level (96%)

high-efciency. The system will continue to operate if one module fails or is replaced.

Drives

The chassis includes twenty-four hot-swap 2.5" storage drives, so each node

supports six drives. Drive types vary with model, as noted on page 1-1.

PCI Expansion Slots

The system allows eight low prole, externally accessable PCI-E cards, two in

each node.

Front Control Panels

Each node has a control panel on the front of the chassis that provides system

monitoring and power control. Status LEDs indicate system power, drive activity,

network activity, UID, and overheat and fan failure.

Cooling System

The chassis uses four system fans powered from the motherboards through the

backplane. The two fans on each side are controlled by the two motherboards on

that side, so that when one of the motherboard nodes is removed, the second

motherboard will continue to control both fans. Fan speed can be determined by

system temperature through IPMI.

Each node uses an air shroud to channel air where needed. Each power supply

module also includes a cooling fan.
