Sur-Gard System Five Bedienungsanleitung

SG-System 5 v1.1

Operating Manual

NOTE: This manual contains information regarding product use and function, in addition to manufacturer liability and

restrictions pertaining to it. The entire manual should be read carefully.

1.0 Table of Contents

- 2 -

1.0 Table of Contents

1.0 Table of Contents 2

2.0 Introduction 7

2.1 SG-System 5 overview 8

2.1.1 CPM redundancy 8

2.1.2 Diagrams 8

2.1.3 Description 10

2.1.4 Specifications 10

2.2 System features 10

2.2.1 SG-System 5 10

2.2.2 Visual Verification 11

2.3 Approvals 11

2.3.1 Industry approvals 11

2.3.2 UL864 programming requirements 12

2.3.3 Printers 13

Serial printer 13

TCP/IP printer 13

SG-System 5 Console software system requirements 13

2.3.4 UL Manual mode 13

2.3.5 SG-System 5 power limited circuit separation 13

3.0 Receiver Setup and Operation 15

3.1 SG-System 5 quick install guide 16

3.1.1 Receiver installation 18

3.1.2 SG-CPM5 LEDs 20

4.0 Hardware Descriptions and Specifications 21

4.1 SG-MLRF5 22

4.1.1 SG-MP5 midplane 22

4.1.2 SG-S5CFANTR – SG-CPM5 fan tray 22

4.1.3 SG-MLRF5-RM – Mounting rails 23

4.2 SG-CPM5 - Central processing module 23

4.2.1 SG-CPM5 I/O terminal pin-outs 24

4.2.1.1 UPS AC Failure – Pin 1 24

4.2.1.2 UPS DC Failure – Pin 3 24

4.2.1.3 Remote ACK – Pin 4 24

4.2.1.4 Buzzer Follow Output – Pin 7 24

4.2.1.5 Trouble Status Output – Pin 9 24

4.2.1.6 Network Status Output – Pin 11 25

4.2.2 SG-CPM5 Setup 25

4.2.2.1 Connecting the SG-CPM5 Fan Cable 25

4.2.2.2 Y-Cable 25

4.2.2.3 RTC Battery 25

4.2.2.4 EMMC Memory 25

4.2.2.5 DDR3 Memory 26

4.2.3 SG-CPM5BATT - RTC battery 26

4.2.4 SG-S5SERCAB - Y-cable 27

4.2.4.1 Maximum connected cable length 28

4.2.5 SG-CPM5 fan tray replacement 28

4.2.6 UPS setup 29

4.3 SG-DRL5-IP - IP line card 30

4.3.1 SG-DRL5-IP configurations 31

SG-DRL5-IP STD 31

SG-DRL5-IPF 31

SG-DRL5-IPE 31

4.3.2 SG-DRL5-IP LED status indicators 31

4.3.2.1 Network fault 32

4.3.2.2 Invalid report condition 32

4.3.2.3 SG-CPM5 absent 32

4.3.2.4 Ethernet interface 32

4.3.2.5 Supervised receiver database 32

4.3.2.6 Profiles 33

4.3.2.7 Rules for account table exceeded messages 33

1.0 Table of Contents

- 3 -

4.3.3 SG-DRL-IP setup 33

4.3.3.1 Line card fan tray installation 33

4.3.3.2 Paddle card installation 34

4.3.3.3 EMMC memory 34

4.3.3.4 DDR3 memory 35

4.3.3.5 SD card 35

4.4 SG-DRL5-IP PAD – SG-DRL5-IP paddle card 36

4.5 SG-S5LFANTR - Line card fan tray 36

4.6 SG-DRL5/DRL5E/DRL5-2L - Line card 37

4.7 SG-DRL5-PAD - Paddle card 37

4.8 SG-DRL5-ADPT - Adapter card 38

4.9 SG-DRL4-2L upgrade to System 5 39

Converting SG-DRL4-2L line cards to SG-DRL5-2L line cards 39

4.10 Installing SG-DRL5 PSTN cards in a SG-System 5 40

4.11 SG-PSU5 250W and 600W power supply 41

4.11.1 SG-PSU5-600/SG-PSU5-250 installation 42

4.11.2 Power management 42

4.12 SG-UIB5 - User interface 42

4.12.1 SG-UIB5 LCD replacement 43

4.13 SG-SYS5MEM4 - Expandable EMMC 44

4.14 DDR3 RAM 45

4.15 SD card 45

5.0 Operation 46

5.1 Basic operation 47

5.1.1 Connectivity 47

5.1.2 SG-System 5 Console software 47

5.1.2.1 Visual verification 47

5.1.2.1.1 Connectivity 47

5.1.2.1.2 Functionality 47

5.1.2.1.3 Header file 47

5.1.2.1.4 Unique ID 47

5.1.2.1.5 Automation and printer messages 47

5.1.2.1.6 ACK 47

5.1.2.1.7 NACK from the console or automation software 47

5.1.2.1.8 NACK from the receiver 48

5.1.2.1.9 No response from the console software 48

5.1.2.1.10 No response from the receiver 48

SG-DRL5-IP – Visual verification 48

SG-CPM5 - SG visual commands 48

5.1.2.2 Advanced output protocol specification 48

5.2 Printer 48

5.2.1 Introduction 48

5.2.2 TCP/IP 48

5.2.3 Serial 49

5.3 AHS table management 49

5.4 Automation 50

5.4.1 Automation input/output 50

5.4.2 Automation compatibility 50

5.4.3 Automation protocols 50

5.4.4 Acknowledgment of the signal 50

5.4.5 COM responses 50

5.4.6 Automation absent 50

5.4.7 SIA internal status output 51

5.4.8 Line card addressing 51

5.5 Operation - LCD user interface 51

5.5.1 Bootup 51

5.5.2 Calibration 52

5.5.3 Home screen 53

5.5.3.1 Status banner 53

5.5.3.2 Type - unit IP 53

5.5.3.3 Active mode 53

5.5.3.3.1 SG-TCP 53

5.5.3.3.2 SG- SERIAL 53

5.5.3.3.3 SG-ALL 54

1.0 Table of Contents

- 4 -

5.5.3.4 Standby mode 54

5.5.3.5 Manual mode 54

5.5.3.6 System trouble 54

5.5.3.6.1 No troubles 54

5.5.3.6.2 Troubles 54

5.5.3.6.3 Trouble screen 55

5.5.3.7 Line Card banner 55

5.5.3.7.1 Numbering 55

5.5.3.7.2 Icons 55

5.5.3.7.3 Status color 55

SG-DRL5-IP 55

SG-DRL5/DRL5E/DRL5-2L 56

5.5.3.8 IPs 56

5.5.3.8.1 Automation IP 56

5.5.3.8.2 Logging IP 56

5.5.3.8.3 Console IP 56

5.5.3.8.4 Printer IP 57

5.5.3.8.5 Visual IP 57

5.5.3.9 Time and date 57

5.5.3.10 Active user 57

5.5.3.11 User defined message 57

5.5.3.12 ACK button 57

5.5.3.13 Menu button 57

5.5.3.14 Home button 57

5.5.4 Logging In 58

5.5.4.1 Login/Options 58

5.5.4.2 Username 58

5.5.4.3 Password 58

5.5.4.4 Default username and password 58

5.5.4.5 Keyboard 58

5.5.4.6 Valid username and password 59

5.5.4.7 Invalid username and password 59

5.5.5 Hardware Diagnostics 60

5.5.5.1 Fan Speed tab 60

5.5.5.2 Temperatures tab 60

5.5.5.3 Power Consumption screen 61

5.5.6 Admin Menu screen 61

5.5.7 Admin access versus user access 61

5.5.7.1 CPM Options 62

5.5.7.2 View Options 62

5.5.7.3 Change SG-CPM5 options 63

5.5.7.4 Full Keyboard options 63

5.5.7.5 Numeric Keyboard options 64

5.5.7.6 Selectable options 64

5.5.7.7 Cold Boot SG-CPM5 65

5.5.7.8 Set Date Time 65

5.5.7.9 System Info 66

5.5.7.10 Brightness/Tone 66

5.5.7.11 Reset SG-CPM5 67

5.5.7.12 SG-CPM5 decommission 67

5.5.7.13 More options 68

5.5.7.14 Debug Mode 68

5.5.7.15 Visual Display Test 69

5.5.8 User menu 69

5.5.8.1 View Options 69

6.0 Options 71

6.1 SG-CPM5 options 72

6.1.1 SG-CPM5 options: [0XX] - IP options 72

6.1.2 SG-CPM5 Options: [1XX] - User Name/Password Options 72

6.1.3 SG-CPM5 Options: [2XX] - System Options 73

6.1.4 SG-CPM5 Options: [3XX] - LCD Options 74

6.1.5 SG-CPM5 Options: [4XX] - Automation Options 74

6.1.6 SG-CPM5 Options: [5XX] - Printer Options 82

6.1.7 SG-CPM5 Options: [6XX] and [7XX] - Troubles 83

1.0 Table of Contents

- 5 -

6.2 SG-DLR5-IP Options 86

6.2.1 SG-DRL5-IP Options: [1XX] - System Hardware 86

6.2.2 SG-DRL5-IP Options: [2XX] - Signaling Options 88

6.2.3 SG-DRL5-IP Options: [3XX] - System Troubles 89

6.2.4 SG-DRL5-IP Options: [4XX] - System Options 90

Option Values 97

Format ID List 97

6.2.5 Profile Options 98

6.2.5.1 Dynamic Profile Options 98

7.0 SG-DRL5/DRL5E/DRL5-2L PSTN Line Cards 99

7.1 Introduction 100

7.2 Profiles introduction 100

7.3 SG-DRL5 system options 102

7.4 SG-DRL5 static options: 00 - 2F 103

Option Values 104

7.5 SG-DRL5 dynamic options: 130/230 - 13F/23F 110

Appendix A: DEC-HEX-BIN Conversion Chart 133

Appendix B: ASCII Character Chart 134

Appendix C: TCP/IP Ports 135

SG-CPM5 TCP/IP ports 135

Appendix D: Events and Messages 136

SG-CPM5 messages 136

SG-DRL5-IP messages 140

SG-DRL PSTN messages 143

LCD and console trouble list 144

Appendix E: Glossary 146

Warning Please Read Carefully 151

Limited Warranty 151

GENERAL DESCRIPTION of the EQUIPMENT and CLASSIFICATION 151

EULA 152

FCC Compliance Statement 153

Important Information 153

Innovation, Science and Economic Development Canada 153

Trademark 155

1.0 Table of Contents

- 6 -

2.0 Introduction

In this chapter...

2.1 SG-System 5 overview 8

2.1.1 CPM redundancy 8

2.1.2 Diagrams 8

2.1.3 Description 10

2.1.4 Specifications 10

2.2 System features 10

2.2.1 SG-System 5 10

2.2.2 Visual Verification 11

2.3 Approvals 11

2.3.1 Industry approvals 11

2.3.2 UL864 programming requirements 12

2.3.3 Printers 13

2.3.4 UL Manual mode 13

2.3.5 SG-System 5 power limited circuit separation 13

2.0 Introduction

- 8 -

2.1 SG-System 5 overview

The SG-System 5 is a multi-platform receiver intended for remote monitoring of commercial fire and burglary systems. The SG-System 5 can monitor

up to 24 communication line cards (SG-DRL5-IP or SG-DRL5/DRL5E/DRL5-2L) to receive and process alarm data in up to 64 pre-programmed pro-

files per line card. The SG-System 5's real-time clock date stamps all received alarm signals which are then transmitted to a central station computer via

TCP/IP or RS-232 port; transmitted directly to a printer using the serial printer port and/or TCP/IP; and viewed on the LCD of the front panel while the

receiver is in the manual state. Options can be programmed using a PC with SG-System 5 Console or locally using the touchscreen LCD.

2.1.1 CPM redundancy

The SG-System 5 can be used in a redundant configuration using two SG-CPM5s, where the primary SG-CPM5 backs up to the secondary SG-CPM5

and vice versa. Under normal conditions, the primary SG-CPM5 is active and outputs all signals to the printer and automation, while the secondary SG-

CPM5 is in standby. If the primary fails, the secondary SG-CPM5 automatically switches to active within 30 seconds and starts outputting signals to

the printer and automation. During the switchover from standby to active, signal reception is not affected because the line cards are still able to receive

signals. The output to printer and automation is delayed by the length of time required to switch from standby to active.

2.1.2 Diagrams

FIGURE 2-1: SG-System 5 front with door closed

3 4 5

1 2

1. Thumb screws to hold faceplate closed

2. Line card status indicators (top LED is watchdog, middle LED is status

and bottom LED is network)

3. SG-CPM5 Status LEDs (from left to right: Console, Trouble, Network,

Watchdog, Automation)

4. Quick HOME button

5. 7-inch resistive touch LCD screen

2.0 Introduction

- 9 -

FIGURE 2-2: SG-System 5 front with door open

FIGURE 2-3: SG-System 5 back

NOTE: Employ only 26 AWG wires for the Telco connections.

2.0 Introduction

- 10 -

2.1.3 Description

The basic configuration consists of one 19-inch rack mounted chassis comprising the following:

lSG-MLRF5 - Metal rack of the SG-System 5 with SG-MP5

lSG-PSU5-600 - 600W power supply unit provides power to all system modules

lSG-PSU5-250 - 250W power supply unit provides power to all system modules

lSG-CPM5 - Central processing module controls all communication to and from receiver modules and printers

lSG-UIB5 - Touch screen user interface

lSG-DRL5-IP - Internet protocol line card

lSG-DRL5-IP PAD - Paddle card for SG-DRL5-IP provides network connection

lSG-MLRF5-RM - Rack mount rails

lSG-S5LFANTR - Line card fan tray

lSG-S5CFANTR - SG-CPM5 fan tray

lSG-S5SERCAB - Y cable for serial connection to the SG-CPM5 for automation/printer

lSG-SYS5MEM4 - Removable EMMC memory

lSG-SYS5DDR31 - DDR3 RAM 1GB

lSG-CPM5BATT - SG-CPM5 real time clock battery

lSG-DRL5 - Single line PSTN card

lSG-DRL5E - Single line PSTN card with backup channel and 2-way audio bridge

lSG-DRL5-2L - Dual line PSTN card

lSG-DRL5PAD - Paddle card for SG-DRL5/DRL5E/DRL5-2L PSTN cards

lSG-ADPT5 - Adapter card for SG-DRL5/DRL5E/DRL5-2L PSTN cards

2.1.4 Specifications

Depth: 27.5 in. (69.85 cm)

Width: 19 in. (48.26 cm)

Height: 7 in. (17.78 cm)

Required rack space: 4U

Dimensions

SG-System 5 UL Electrical:

Input voltage: 100-240 VAC, 50/60Hz.

Input current 600W: 8A max (RMS) @ 100VAC

Input current 250W: 3A max (RMS) @ 100VAC

Backup power supply: External UPS (not supplied)

In a two SG-CPM5 configuration, a redundant SG-PSU5 can be inserted in the second slot. In the event of a SG-PSU5 failure, the redundant SG-

PSU5 automatically assumes operation. These modules are hot swappable (can be removed and replaced while the system is in operation) if a working,

redundant SG-PSU5 is installed. Both PSU units used in the system must have the same power rating.

Environmental:

Temperature: 0-49°C (32 - 120°F)

Humidity: 93%RH, non-condensing

Accounts:

ULC Line Security Levels: A1-A4 (active channels) or P1-P3 (passive channels)

Printers (UL/ULC Listed Installations):

Serial: Seiko DPU-414

DACT Compatible communication formats (ULC Passive channels): SIA, CID

Encryption: AES 128 bit

2.2 System features

2.2.1 SG-System 5

lReduced size of 4U in height for improved receiver room logistics management

lCMS access to visual verification files through SG-System 5 Console

lUpgradeable through the SG-System 5 Console

lEnhanced hardware diagnostics via SG-System 5 Console

lStatic IP for programming of network protocols

lReal time system status via intuitive user touchscreen interface

lSupports visual verification features for DSC PowerSeries Neo

lMonitor up to 1,474,560 IP communicators (Cellular or Ethernet) with up to 24 IP line cards

Inhaltsverzeichnis

Andere Sur-Gard Empfänger Handbücher

Sur-Gard

Sur-Gard System III Bedienungsanleitung

Sur-Gard

Sur-Gard MLR2E Bedienungsanleitung

Sur-Gard

Sur-Gard SG-MLR2000 Bedienungsanleitung

Sur-Gard

Sur-Gard SG-System III Bedienungsanleitung

Sur-Gard

Sur-Gard MLR2000 Bedienungsanleitung

Sur-Gard

Sur-Gard SG Security Communications MLR2-DG Bedienungsanleitung

Sur-Gard

Sur-Gard SG System II Bedienungsanleitung

Sur-Gard

Sur-Gard System I Bedienungsanleitung

Sur-Gard

Sur-Gard SG-System IV Bedienungsanleitung

Sur-Gard

Sur-Gard SG-MLR2-E Bedienungsanleitung

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
