SUTO A554 2301 Handbuch
English
Instruction and operation manual
Measuring chamber A554 2301
Dear Customer,
Thank you for choosing our product.
The operating instructions must be read in full and carefully observed
before starting up the device. The manufacturer cannot be held liable
for any damage which occurs as a result of non-observance or non-
compliance with this manual.
Should the device be tampered with in any manner other than a
procedure which is described and specified in the manual, the warranty
is cancelled and the manufacturer is e empt from liability.
The device is destined e clusively for the described application.
SUTO offers no guarantee for the suitability for any other purpose.
SUTO is also not liable for consequential damage resulting from the
delivery, capability or use of this device.
2 Measuring chamber A554 2301
1. Safety instructions
Table of contents
1. Safety instructions.......................................................................4
2. Application.................................................................................6
3. Features.....................................................................................6
4. Technical Data............................................................................6
5. Dimensional drawing....................................................................7
6. Installation ................................................................................8
6.1 Installation Requirements........................................................8
6.2 Installation Procedure ............................................................8
7. Maintenance...............................................................................8
8. Disposal or waste........................................................................8
9. Warranty....................................................................................9
Measuring chamber A554 2301 3
1. Safety instructions
1. Safety instructions
lease check if this instruction manual accords to the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which have to be
observed before and during installation, operation and
maintenance. Therefore this instruction manual has to be read carefully
by the technician as well as by the responsible user / qualified
personnel.
This instruction manual has to be available at the operation site of the
device at any time. In case of any obscurities or questions, regarding
this manual or the product, please contact the manufacturer.
WARNING!
Compressed air!
Any contact with quickly escaping air or bursting
parts of the compressed air system can lead to
serious injuries or even death!
•Do not e ceed the ma imum permitted pressure range (see
chamber label).
•Only use pressure tight installation material.
•Avoid that persons get hit escaping air or bursting parts of the
instrument.
•The system must be pressureless during maintenance work.
WARNING!
ermitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding this parameters can lead to
malfunctions and may lead to damage on the
instrument or the system.
•Do not e ceed the permitted operating parameters.
•Make sure the product is operated in its permitted limitations.
•Do not e ceed or undercut the permitted storage and operation
temperature and pressure.
•The product should be maintained frequently, at least annually.
4 Measuring chamber A554 2301
1. Safety instructions
General safety instructions
•It is not allowed to use the product in e plosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
•Always use spanner to mount the product properly.
ATTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and
frequently maintained, otherwise it may lead to
wrong measurement values, which can lead to
wrong results.
Storage and transportation
•Make sure that the transportation temperature of the device is
between -30°C ... 70°C.
•For transportation it is recommended to use the packaging which
comes with the device.
•Please make sure that the storage temperature of the device is
between -10°C ... 50°C.
•Avoid direct UV and solar radiation during storage.
•For the storage the humidity has to be <90%, no condensation.
Measuring chamber A554 2301 5
2. Application
2. Application
The measuring chamber is used in applications with pressurized air in
combination with a SUTO dew point sensor. It ensures that the sampling
air flows around the sensor element thus providing a fast response time
to dew point changes. It must be used within the permissible operating
parameters. These parameters can be found in the technical data
section.
The measuring chamber is not developed to be used in e plosive areas.
For the use in e plosive areas please contact the manufacturer.
The measuring chamber is mainly used in compressed air systems in
industrial environment.
3. Features
•Easy mountable at a surface through 4 mounting holes
•sample air connection through 1/4” compression fitting
•Inlet valve to isolate the chamber from compressed air supply
•Needle valve to adjust the purge flow
•Outlet pigtail tube to avoid back diffusion
•Convenient to all the dew point sensors of the manufacturer.
•Sensor is mounted to the 1/2” G-type thread connection.
4. Technical Data
Measuring medium Air, gas (non corrosive gas, non e plosive)
Operating temperature -20°C ... 50°C
Humidity of the meas.
medium
< 90%, no condensation
Operating pressure up to 1.5 MPa
Housing material Stainless steel
Inlet connection 1/4” compression fitting
Dimensions See dimensional drawing on the ne t page
Weight 850g
6 Measuring chamber A554 2301
6. Installation
6. Installation
Please make sure that all components listed below are included in your
package.
Qty Description Item No.
1 Measuring chamber A554 2301
1 Instruction manual No P/N
6.1 Installation Requirements
The dew point sensor is mounted to the chamber through the 1/2” G-
type thread connection. The compressed air/gas is supplied through a
OD 1/4” tube to the inlet fitting.
6.2 Installation rocedure
The following steps e plain the procedure of an appropriate installation.
Installation of measuring chamber
1. Mount the chamber on a surface through the 4 mounting holes.
2. Screw the dew point sensor onto the 1/2” G-type thread
connection. Make sure that the sealing-ring is fitted on the sensor!
3. Connect the compressed air/gas supply through a OD 1/4” tube to
the inlet fitting
4. Mount the outlet pictail tube to the outlet fitting
5. Close the outlet needle valve and then open the inlet valve
6. Open up the outlet needle valve so that a flow can be felt at the
end of the outlet pigtail tube. The higher the flow the faster the
response time, but the more air/gas is lost.
7. Maintenance
To clean the measuring chamber it is recommended to use distilled
water or isopropyl alcohol only.
8. Disposal or waste
The device, the accessories and its packings must be disposed
according to your local statutory requirements. The dispose can also be
8 Measuring chamber A554 2301
8. Disposal or waste
carried by the manufacturer of the product, for this please contact the
manufacturer.
9. Warranty
SUTO provides a warranty for this product of 24 months covering the
material and workmanship under the stated operating conditions from
the date of delivery. Please report any findings immediately and within
the warranty time. If faults occurring during the warranty time SUTO
will repair or replace the defective unit, without charge for labour and
material costs but there is a charge for other service such as transport
and packing costs.
E cluded from this warranty is:
•Damage caused by:
◦Improper use and non-adherence to the instruction manual.
◦Use of unsuitable accessories.
◦E ternal influences (e.g. damage caused by vibration, damage
during transportation, e cess heat or moisture).
The warranty is cancelled:
•If the user opens the measurement instrument without a direct
request written in this instruction manual.
•If repairs or modifications are undertaken by third parties or
unauthorised persons.
•If the serial number has been changed, damaged or removed.
Other claims, especially those for damage occurring outside the
instrument are not included unless responsibility is legally binding.
Warranty repairs do not e tend the period of warranty.
Measuring chamber A554 2301 9
