Digifobpro User Instructions Page - 8
Downloading the Vehicle
You must rst place a valid Company card in Slot 1 or Slot 2 of your Vehicle Unit
(VU). Attach the VU cable supplied and the VU Download menu will
automatically appear. Refer to your vehicle’s achograph instructions for
details on where the download connection is located or see Page 5 for helpful
hints.
Use the UP and DOWN arrows to select options and the LEF and RIGH
buttons to turn ON and OFF options or to increment the values. Select the
Download ICON and press OK.
he minimum requirement for a standard download consists of;
Activity: Since Last (VU) — Events and Faults: Yes — Speed Data: No —
echnical Data: No.
Using the digifobpro menu you can download ‘ALL data’, a set number of days
or ’Since last’ which will download from the last time recorded by your
digifobpro.
Since Last (VU) downloads from the date recorded by the Vehicle Unit based on
any device that downloaded it (not including Control or Workshop cards). his
is the default for all achosys devices. here are further download options that
can be set using the digiconnect software (see page 14 onwards).
Vehicle Unit Menu
Choose the Vehicle you wish to analyse from the list. You can sort Vehicles by
time or A-Z, Z-A by using the Left and Right arrows.
Vehicle Functions
N.B. See page 21 for more information on Events and Faults.
Activity data - OK to drill
down, UP / DOWN to scroll
Speed data, LEF / RIGH to
zoom, UP / DOWN to scroll
Information on the
downloaded le
Events and Faults, OK to drill
down (page 7 for icons )
Calibration data Speed graph shown for 4hz
Data (see page 13)
Delete File - use cautiously.
Digifobpro User Instructions Page - 9
SRE DDS and VDO Counter
Your digifobpro has a unique and extremely useful new feature. By
connecting your digifobpro to any Digital achograph and placing the
digifobro in this mode you can view your current driving totals in real time.
Please note that whilst Digital achograph have been around since 2006 more
comprehensive real time data provided by the achograph was not available
until around 2012. Despite this there are benets for all users adopting this
technology.
achosys also manufacture a range of Bluetooth devices to which the
digifobpro can connect to provide a Wireless solution. Please have a look at
our digiDL-EX and digiblu products at achosys.com for more information.
See Page 13 to see how to pair Bluetooth devices.
VDO Counter Compatability
he table below shows which versions support full Counter functionality and
whether updates or activation cards may be required.
* Upgrade of the release is possible via workshop
** Must be activated with an Update Card
*** Can only be activated via the workshop
he VDO Counter Update Card comes in two types Single or Multi Use.
he part numbers are:-
Single: A2C59516603 Multi Use: A2C59516604
Stoneridge DDS Compatibility
here are currently two models that support DDS, the Exakt Duo and Exakt
Duo². hese models are software revision R7.4 and R7.5 respectively.
1.2a 1.3 1.4 2.0 2.0a 2.1
2.1
active
VDO
Counter
*
***
**
