Targus DEFCON CL Bedienungsanleitung
Visit our Website at www.targus.com
Features and specications subject to change without
notice.
©2006 Targus Group International, Inc. and Targus, Inc.
PA410U-10 / 410-0014-001B
USER GUIDE
notebook security
DEFCON®CL
cable lock
2
Table of Contents
Introduction ...................................................... 3
Setting the Combination................................... 4
Securing the DEFCON CL ............................... 5
Locking the DEFCON CL to your Notebook Com-
puter................................................................. 6
Using the DEFCON SecureSpacers ................ 8
Unlocking the DEFCON CL ............................. 9
DEFCON Security Base Plate ......................... 9
Specifications.................................................. 11
Technical Support ........................................... 12
Recording Your Combination.......................... 13
3
TARGUS NOTEBOOK
SECURITY
DEFCON
®
CL COMBO
CABLE LOCK
Introduction
Thank you for purchasing the Targus Notebook Security
DEFCON®CL Combo Cable Lock. The DEFCON CL
helps protect your valuable notebook computer from theft
using a resettable four-digit combination lock. The
resettable combination lock eliminates the need for keys
and enables you to change your combination periodically
for increased security.
In addition to this user’s guide, this package contains:
• DEFCON CL
• DEFCON SecureSpacers
• DEFCON Security Base Plate
WARNING: TOUSE THE DEFCON CL OR RESET THE COMBINATION YOU
MUST SET THE LOCK TO THE CURRENT COMBINATION.
4
Targus Notebook Security DEFCON® CL Combo Cable Lock
Setting the Combination
1 Locate the combination dials and windows on the
lock.
DEFCON CL
2 Using the dials, enter the current combination.
If you are setting the combination for the first time,
enter the preset combination 0000.
The combination appears in the windows.
3 Using a small flat-head screwdriver or similar object,
push in and rotate the reset screw 90 degrees
clockwise so that the screw’s groove appears
horizontal.
Unlocking the combination lock
Combination windows Reset screw
Combination dials
Locking button
5
Targus Notebook Security DEFCON® CL Combo Cable Lock
4 Using the dials, enter the new combination.
5 Rotate the reset screw 90 degrees counterclockwise,
back to its original vertical position, to save the new
combination.
Locking the combination lock
6 Record the combination in either the space provided
at the end of this guide or another secure, easy-to-find
place.
Testing the Combination
Before attaching the lock to your notebook computer:
1 Turn the dials to disguise the combination.
2 Return to the combination you set.
3 Check that the locking button depresses completely.
Securing the DEFCON CL
Select an object in the room to which you will secure your
notebook computer with the DEFCON CL. Choose a
large, heavy piece of furniture such as a table or desk, or
an immovable fixture such as a closet hanging bar.
6
Targus Notebook Security DEFCON® CL Combo Cable Lock
1 Take the looped end of the cable and wrap it around
the selected object.
NOTE: WRAP THE CABLE AROUND APART OF THE OBJECT THAT WILL DETER
AN INTRUDER FROM SLIPPING THE CABLE OFF (FOR EXAMPLE, ATABLE OR
DESK LEG WITH ACROSS BAR OR ADRAWER HANDLE).
2 Feed the lock through the looped end of the cable as
shown.
Securing the DEFCON CL to an object
Locking the DEFCON CL to
your Notebook Computer
NOTE: HOLD THE DEFCON CL WITH BOTH HANDS FOR ADDITIONAL
STABILITY WHILE INSERTING OR REMOVING THE LOCK.
1 Using the dials, enter the correct combination.
The combination appears in the windows.
7
Targus Notebook Security DEFCON® CL Combo Cable Lock
DEFCON CL
2 Press and hold the locking button to align the locking
teeth.
NOTE: FOR THE LOCKING BUTTON TO DEPRESS COMPLETELY YOU MUST
ENTER THE CORRECT COMBINATION.
3 Insert the DEFCON CL into your notebook computer’s
lock slot and release the locking button.
NOTE: DUE TO THE VARIATION IN THE SIZE OF THE SECURITY SLOTS ON
VARIOUS NOTEBOOK MODELS, YOU MAY FIND THAT THERE IS SOME SLACK
BETWEEN THE LOCK AND THE COMPUTER. THE SUPPLIED DEFCON
SECURESPACERS ARE THE BEST SOLUTION FOR OPTIMAL FIT AND SECURITY.
4 Turn the dials to conceal your combination.
Due to differences in the size of the security slots on
various notebook computers, you may find that there
is some slack between the DEFCON locking device
and the computer. The DEFCON SecureSpacers
provide optimal fit and security.
Locking button
Locking teeth
SecureSpacer
8
Targus Notebook Security DEFCON® CL Combo Cable Lock
Using the DEFCON
SecureSpacers
1 Insert your DEFCON locking device into the
computer’s lock slot.
2 Pull the DEFCON locking device away from the
computer and check whether the gap is excessive.
3 If so, try each of the SecureSpacers to determine
which one fits the gap. The SecureSpacers come in
three sizes: 1.6 mm, 0.8 mm, and 0.4 mm.
NOTE: DONOT REMOVE THE ADHESIVE STRIP FROM ANY OF THE
SECURESPACERS UNTIL YOU DECIDE WHICH ONE TO USE.
4 Once you know which SecureSpacer you are going to
use, remove the locking device from the computer.
9
Targus Notebook Security DEFCON® CL Combo Cable Lock
Then remove the adhesive strip from the back of the
SecureSpacer and attach the spacer to the DEFCON
lock.
Unlocking the DEFCON CL
WARNING: DONOT ATTEMPT TO REMOVE THE DEFCON CL WITHOUT USING
THE COMBINATION. TODO SO WILL PHYSICALLY DAMAGE YOUR NOTEBOOK
COMPUTER.
1 Using the dials, enter the correct combination.
2 The combination appears in the windows.
3 Press and hold the locking button to realign the
locking teeth.
4 Remove the DEFCON CL from your notebook
computer’s lock slot.
DEFCON Security Base
Plate
Included with your DEFCON CL Combo Cable Lock is
the Security Base Plate for the security of desktop
computers.
Using the DEFCON Security Base
Plate
1 Choose a solid location to attach the DEFCON
Security Base Plate: a piece of furniture, or metal
10
Targus Notebook Security DEFCON® CL Combo Cable Lock
cabinet. If you plan to use the two screws, you can use
the base plate as a template to pre-drill the holes.
2 Use the abrasive pad, then the alcohol wipe to
prepare the area when you will attach the DEFCON
Security Base Plate.
3 After the alcohol dries, remove the backing on the
base plate to expose the adhesive and place it on the
prepared location. If desired, secure the base with the
two screws.
NOTE: WHEN USING THE ADHESIVE BACKING, APPLY AT ROOM TEMPERATURE
-60°F (16°C), AND ALLOW IT TO BOND FOR MORE THAN 24 HOURS. NOT
RECOMMEND TO USE IN OUTDOOR OR HIGH HUMIDITY ENVIRONMENT.
BONDING TO GLASS, CERAMIC TILE, WATER-ABSORBENT MATERIALS, COPPER,
BRASS, OR PLASTICIZED VINYL WITHOUT PRIMER SURFACE ARE NOT
