Targus AMB01US Bedienungsanleitung
BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY
"LUETOOTH
-INIÖ-OUSE
).34!,,Ö'5)$%
-AKINGÖ9OURÖ-OBILEÖ,IFEÖ%ASIER
Ë
-AKINGÖ9OURÖ-OBILEÖ,IFEÖ%ASIER
Ë
6ISITÖOURÖ7EBÖSITEÖATÖWWWTARGUSCOM
&EATURESÖANDÖSPECIFICATIONSÖAREÖSUBJECTÖTOÖCHANGEÖWITHOUTÖNOTICE
¬
ÖÖÖ4ARGUSÖ'ROUPÖ)NTERNATIONALÖANDÖ4ARGUSÖ)NC
-"53ÖÖ"
3
TARGUS BLUETOOTH MINI
MOUSE WITH BLUETOOTH
ADAPTER
Introduction
Congratulations on your purchase of a Targus Bluetooth
Mouse. The Bluetooth software included offers service to
other Bluetooth devices from your computer, such as: PIM
Synchronization, PIM Item Transfers, File Transfers, Network
Access, Dial-up Networking and Bluetooth Serial Port.
This user’s guide describes how to connect the mouse
adapter to your computer, install default software drivers
and set up the radio link.
In addition to this user’s guide this package contains:
• Targus Bluetooth Mini Mouse
• Bluetooth USB Adapter
• USB Extension cable
•CD-ROM
• 2 AAA batteries
• Carrying Pouch
4
Targus Bluetooth Mini Mouse with Bluetooth Adapter
System Requirements
To use the mouse, your computer must meet the following
requirements:
Hardware
•PCwithaPentium
®processor or equivalent
•USBinterface
Operating System
•Windows
®2000 or XP
Installing the Software
CAUTION: Do not plug in the USB
adapter until prompted by the software.
1 Insert the software CD-ROM into your computer’s
CD-ROM drive.
The “InstallShield Wizard” screen appears.
If setup does not begin automatically, click Start, Run,
then enter D:\Setup.exe (where D: is the path of your disc
drive) and then click OK.
2ClickNext.
3 The ‘License Agreement’ screen appears.
4 Click ‘I accept the terms in the License Agreement’.
5ClickNext.
Follow the on-screen instructions.
The following screen will appear to prompt you to plug in
the USB adapter.
5
Targus Bluetooth Mini Mouse with Bluetooth Adapter
6 Plug the USB adapter into an available USB slot on your
computer.
7 Click OK.
The new hardware will be found and the installation will
finish.
8 You will be prompted to Restart your computer to
complete the installation.
NOTE: For a complete user’s guide, please refer to the
manual located on the CD-ROM included in this
package.
6
Targus Bluetooth Mini Mouse with Bluetooth Adapter
Using the Bluetooth Mouse
Installing the Batteries
1 Remove the battery cover from the top of the mouse by
pressing the release latch on the bottom of the mouse.
Top of Mouse Bottom of mouse
2 Insert the supplied batteries, making sure that the
positive (+) and negative (-) ends of each battery match
the polarity indicators inside the battery housing.
WARNINGS: When replacing the batteries, you may use
alkaline or other heavy-duty NiMH batteries. Never
use an alkaline with a NiMH battery in a device.
Avoid mixing new and used batteries in a device.
3 Snap the battery cover back into position.
4 Turn on the mouse by sliding the on/off switch on the
bottom of the mouse to the “on” position.
Battery cover
On/Off switch
Release latch
7
Targus Bluetooth Mini Mouse with Bluetooth Adapter
Initial Configuration
Before you can begin using Bluetooth on your computer
and with other Bluetooth devices, you must perform some
initial setup.
NOTE: For a complete user’s guide with detailed
instructions on configuring Bluetooth devices, please
refer to the manual located on the CD-ROM included
in this package.
Accessing the Bluetooth
Configuration Panel
The Bluetooth Configuration Panel provides access to
settings for Bluetooth services, client applications,
hardware, security, discovery, accessibility, default paths,
event notification and other Bluetooth related items.
Open the configuration panel one of two ways:
Optical sensor
On/Off switch
Pairing
button
On
Off
8
Targus Bluetooth Mini Mouse with Bluetooth Adapter
• From the Windows Control Panel, select Bluetooth
Configuration; or
• In the Windows System Tray, right-click the Bluetooth
icon, and select Advanced Configuration from the
shortcut menu.
The following screen will appear:
The Configuration Wizard will take you through the initial
setup of your computer and configure a basic Bluetooth
environment.
9
Targus Bluetooth Mini Mouse with Bluetooth Adapter
You can select the locations you want the Bluetooth icon to
appear.
10
Targus Bluetooth Mini Mouse with Bluetooth Adapter
Next you will need to select a name for your computer and
indicate what type it is:
