Targus Wireless Laser Rechargable Notebook Mouse Bedienungsanleitung

USER GUIDE

Wireless Laser

Rechargeable

Notebook

Mouse

CAUTION

LASER RADIATION. DO NOT STARE INTO

THE BEAM OR VIEW DIRECTLY WITH

OPTICAL INSTRUMENTS. CLASS I LASER

PRODUCT.

NEVER POINT A LASER BEAM INTO A

PERSON’S EYES OR VIEW A LASER BEAM

DIRECTLY, AS PROLONGED EXPOSURE CAN

BE HAZARDOUS TO THE EYES.

MOMENTARY EXPOSURE FROM A LASER

POINTER, SUCH AS AN INADVERTENT

SWEEP OF THE LIGHT ACROSS A PERSON'S

EYES, MAY CAUSE TEMPORARY FLASH

BLINDNESS SIMILAR TO THE EFFECT OF A

CAMERA FLASH BULB. ALTHOUGH THIS

CONDITION IS TEMPORARY, IT CAN

BECOME MORE DANGEROUS IF THE

EXPOSED PERSON IS ENGAGED IN A

VISION-CRITICAL ACTIVITY SUCH AS

DRIVING.

Introduction

Congratulations on your purchase of the Targus

wireless laser rechargeable notebook mouse . This

ergonomically designed mouse uses a radio frequency

(RF) link that enables you to use the mouse anywhere

within 1 m of its receiver. No line-of-sight between the

mouse and its receiver is required.

In addition to this user’s guide this package contains:

System Requirements

Hardware

• PC

• USB interface

Operating System

• Windows®98/2000/Me/XP

• Mouse

• USB receiver

• 2 AAA rechargeable

batteries

• USB extension cable

• USB charge cable

• Carrying pouch

TARGUS

WIRELESS LASER

RECHARGEABLE

NOTEBOOK MOUSE

• Mac

• Mac: OS 10.x and above

• Windows Vista™

Wireless Laser Rechargeable Notebook Mouse

NOTE: THE THIRD BUTTON AND THE SCROLLING WHEEL ONLY WORK WITH THE

OPERATING SYSTEMS LISTED ABOVE. IF YOU USE THE MOUSE WITH A

DIFFERENT OPERATING SYSTEM,IT WILL LOSE ITS ENHANCED FEATURES AND

FUNCTION AS A STANDARD,TWO-BUTTON MOUSE.

Connecting the Mouse

Receiver

To connect the mouse receiver:

1 Plug the USB receiver into an available USB port on

your computer.

2 Your computer’s operating system identifies the

receiver and begins installing the default driver.

Follow any on-screen procedures to complete the

default driver installation.

Using the Mouse

Installing the Batteries

1 If the mouse is on, slide the on/off switch on the

bottom of the mouse to the “off” position.

2 Remove the battery cover from the top of the mouse

by pressing the battery cover hinge located on the

bottom of the mouse and sliding it off.

Wireless Laser Rechargeable Notebook Mouse

NOTE: THE BATTERY COVER IS ALSO THE TOP COVER OF THE MOUSE.

3 Insert the supplied batteries, making sure that the

positive (+) and negative (-) ends of each battery

match the polarity indicators inside the battery

housing.

WARNING: WHEN REPLACING THE BATTERIES,USE ONLY HEAVY-DUTY NIMH

BATTERIES. RECHARGING ALKALINE BATTERIES MAY DAMAGE THE MOUSE.

AVOID MIXING NEW AND USED BATTERIES IN A DEVICE.

4 Slide the battery cover back into position until it

“clicks” firmly into place.

5 Turn on the mouse by sliding the on/off switch on the

bottom of the mouse to the “on” position.

The optical sensor, located on the bottom of the

mouse, illuminates.

laser

OPEN

off

Battery cover

release button

Operating Notes for Wireless Mice with

Recharging Feature via USB Cable

1. Charge the mouse for at least 8 hours before using it. And please

make sure only rechargeable batteries (the ones that come with your

product) are used.

2. Your computer needs to stay powered on for the mouse to charge.

Follow these steps to prevent your computer from going in to

Standby or Hibernate:

a) Click “Start”

b) Click “Control Panel”

c) Click “Performance and Maintenance” (Skip in Classic View)

d) Click “Power Options”

e) Make sure “System Standby:” and “System Hibernates:” under “Plugged

in” are set to “Never”

3. If you use your notebook computer’s LCD monitor, please do not

close the lid. (Please ignore this step if you use an external monitor

with your notebook lid closed.)

4. If your mouse does not respond after a period of inactivity, please

wake it up by pressing one of the buttons on the mouse or moving

the mouse around.

Wireless Laser Rechargeable Notebook Mouse

Charging the Batteries

For best results, you should charge the mouse at least 8

hours before using it. You can do this via the supplied

USB charge cable. To do this:

1 Connect the cable’s USB connector into an available

USB port on your computer

2 Connect the other end to the mouse.

NOTE: TO CONTINUOUSLY CHARGE THE MOUSE VIA THE USB CHARGE CABLE,

YOUR COMPUTER MUST BE ON AND AWAKE. FOR BEST RESULTS,TURN OFF

YOUR COMPUTER’S POWER MANAGEMENT FEATURE WHILE CHARGING THE

MOUSE.

Establishing a Communica-

tions Link

The mouse has 256 identification codes that allow the

mouse and its receiver to operate without interference

from other radio frequency devices.

After your computer detects the USB receiver and the

driver is installed, you must establish a communications

link between the mouse and its receiver BEFORE you

can use the mouse. To establish this link, you need to set

the identification code so that the mouse works properly.

To do this, follow the instructions below:

Make sure that your computer is turned on and has

detected the USB receiver before you establish a

communications link.

Wireless Laser Rechargeable Notebook Mouse

1 Press and release the link button located on the bottom

of the receiver.

Receiver

The receiver’s status light blinks when the receiver is

activated.

2 Press and release the link button, located on the

bottom of the mouse.

You are now ready to use the mouse.

Mouse Power Management

To power the mouse on and off, slide the on/off switch at

the bottom of the mouse to the desired position.

When power is on, the mouse goes into "sleep mode"

after 8 minutes of no use. To activate the mouse, move

the mouse or press any key.

To save battery power, turn off the mouse while traveling.

Status light

Wireless Laser Rechargeable Notebook Mouse

Operating Hints

For optimal performance and RF reception:

• Place the receiver at least 20cm away from all

electrical devices, such as your monitor, speakers or

external storage devices.

• If necessary, use the supplied extension cable to keep

the receiver away from the computer. Plug the receiver

into the extension cable, and the extension cable to the

computer.

• Avoid using the mouse on a metal surface. Metals,

such as iron, aluminum or copper, shield the radio

frequency transmission and may slow down the

mouse’s response time or cause the mouse to fail

temporarily.

• The mouse will enter a suspend mode at the same time

your computer does. To activate the mouse, simply

move the mouse.

• If your computer has a metal case that contains

aluminum or magnesium, use the mouse to the side.

The display panel may interfere with the radio

frequency signal if you use the mouse directly in front

of the computer.

• Never use the mouse on a glass or mirrored surface as

these surfaces will cause the mouse to fail temporarily.

• To maximize battery life, use the mouse on a white, or

light colored surface. Dark surfaces cause the mouse’s

light emitter diode (LED) light to glow brighter, which

causes the battery to discharge more rapidly.

Wireless Laser Rechargeable Notebook Mouse

Comfortable Usage

Research suggests that physical discomfort and injury to

nerves, tendons, and muscles may be related to

repetitive motion, an improperly set up work area,

incorrect body posture, and poor work habits.

To reduce the risk of injury, follow these precautions:

• Stand, stretch, and move around several times every

hour.

• Switch hands while performing tasks. Use shortcut

keys to avoid repetitive or awkward mouse

movements.

• Relax your shoulders and keep your elbows at your

sides. Adjust the keyboard’s position so that you don’t

have to stretch to reach it.

• Adjust your position so that you don’t have to bend

your wrists to type; avoid placing your wrists on a sharp

edge.

If you feel discomfort or numbness in your hands, wrists,

arms, shoulders, neck, or back while typing, consult a

qualified medical professional.

Troubleshooting

What do I do if the mouse does not work?

• Make sure that the polarity of the batteries is correct.

The positive (+) and negative (-) ends of each battery

must match the positive (+) and negative (-)

connections in the battery housing.
