Targus Ultra-Mini Wireless
Optical Mouse Presenter
USER’S GUIDE
Making Your Mobile Life Easier.®
Making Your Mobile Life Easier.®
Visit our Web site at: www.targus.com
Features and specifications are subject to change without notice.
©2003 Targus Group International and Targus, Inc..
400-0140-001A
3
TARGUS ULTRA-MINI
WIRELESS OPTICAL
MOUSE PRESENTER
Introduction
Congratulations on your purchase of a Targus Ultra-Mini
Wirelss Optical Mouse Presenter. This 2.4GHz Mouse
Presenter is an ideal solution when giving a presentation
or when travelling. It provides multi-functions as wireless
optical mouse, presenter and laser pointer up to 50 feet
(15 m).
This user’s guide describes how to:
› connect the charger base/receiver to your computer
› install default software drivers
› set up the wireless link and use the mouse presenter
In addition to this user’s guide this package contains:
› Wireless Optical Mouse Presenter
› USB charger base/receiver
› 2 AAA rechargeable batteries
› Carrying pouch
4
Targus Ultra-Mini Wireless Optical Mouse Presenter
System Requirements
To use the Mouse Presenter, your computer must meet the
following hardware requirements and run one of the
operating systems listed below.
Hardware
›PCwithaPentium
®processor or equivalent
› USB v1.1 or higher interface
Operating System
›Windows
®98/Me/2000/XP
NOTE: The third button and the scrolling wheel only
work with the operating systems listed above. If you
use the Mouse Presenter with a different operating
system, it will lose its enhanced features and will
function as a standard, two-button mouse.
5
Targus Ultra-Mini Wireless Optical Mouse Presenter
Connecting the Charger Base/
Receiver and Installing the
Default Driver
To connect the charger base/receiver:
1 Turn off your computer.
2 Plug the USB connector into an available USB port on
your computer.
3 Turn on your computer.
Your computer’s operating system identifies the receiver
and begins installing the default driver. Follow any on-
screen procedures to complete the default driver
installation.
4 NOTE: If you are running Windows®98/Me operating
system, you may be prompted to insert the installation
CD-ROM that came with your computer.
You must now install batteries and synchronize the mouse
presenter with the charger base/receiver. See
“Synchronizing” on page 7
6
Targus Ultra-Mini Wireless Optical Mouse Presenter
Installing the Batteries
1 Remove the battery cover from the top of the mouse
presenter by pressing the battery cover hinge located on
the bottom of the mouse presenter and sliding it off.
2 Insert the supplied batteries, making sure that the
positive (+) and negative (-) ends of each battery match
the polarity indicators inside the battery housing.
WARNINGS: When replacing the batteries, you must
use rechargeable batteries only.
Avoid mixing new and used batteries in a device.
3 Slide the battery cover back into position until it “clicks”
firmly into place.
4 For best results, you should charge the mouse presenter
on the charger base/receiver at least 12 hours before
using it.
NOTE: To continuously charge the mouse presenter
your computer must be on and awake. For best
results, turn off your computer's power management
feature while charging the mouse.
7
Targus Ultra-Mini Wireless Optical Mouse Presenter
Synchronizing
After your computer detects the USB charger base/receiver
and the driver software is installed, you must synchronize
the mouse presenter with the charger base/receiver
BEFORE you can use the mouse presenter. To do this:
1 Press and release the connect button on the bottom of
the mouse presenter.
2 Press and release the connect button on the bottom of
the charger base/receiver.
This link must be established within a few seconds or
the steps will need to be repeated.
You are now ready to use the Mouse Presenter.
CAUTION: Removing the batteries will require you to
synchronize the mouse presenter with the receiver again.
8
Targus Ultra-Mini Wireless Optical Mouse Presenter
Using the Mouse Presenter
Functionality
The Mouse Presenter provides 3 working modes:
•PresenterMode
In Presenter Mode the device will work as a Wireless
Presenter and provide the functionalities as follows:
Left button: Page up
Right button: Page down
Middle button/Scrolling wheel: Laser Pointer
Function key 1: Escape
Function key 2: Internet
Function key 3: Alt+Tab
9
Targus Ultra-Mini Wireless Optical Mouse Presenter
•MouseMode
In Mouse Mode the device will work as a Wireless Optical
Mouse and provide functionalities as follows:
• Power-Off Mode
note: the internet function key does not work under
the Windows 98 operating system.
Left button: Mouse left button
Right button: Mouse right button
Middle button/Scrolling wheel: Scrolling
Function key 1: Escape
Function key 2: Internet
Function key 3: Alt+Tab
10
Targus Ultra-Mini Wireless Optical Mouse Presenter
Power Management
To power the mouse presenter on and off, slide the on/off
switch at the bottom of the mouse presenter to the desired
position.
To save battery power, turn off the mouse presenter while
traveling or when you’re not using it.
CAUTION: Removing the batteries will require you to
synchronize it with the receiver again the next time you
turn it back on. See “Synchronizing” on page 7
Operating Hints
For optimal performance and RF reception:
› Avoid using the Mouse Presenter on a metal surface.
Metals, such as iron, aluminum or copper, shield the
radio frequency transmission and may slow down the
mouse presenter’s response time or cause the mouse
presenter to fail temporarily.
› The Mouse Presenter will enter a suspend mode at the
same time your computer does. Click a button on the
mouse presenter to activate it.
› If your computer has a metal case that contains alumi-
num or magnesium, use the Mouse Presenter to the
side. The display panel may interfere with the radio fre-
quency signal if you use the mouse presenter directly in
front of the computer.
› Never use the Mouse Presenter on a glass or mirrored
surface as these surfaces will cause the mouse pre-
senter to fail temporarily.
› To maximize battery life, use the Mouse Presenter on a
white, or light colored surface. Dark surfaces cause the
