MULTIBAND P25

AIRBORNE TRANSCEIVER

MODEL TDFM-600/6000

Installation and

Operating Instructions

Til Document No.

01RE293

Rev. C

August 2002

Technisonic Industries Limited

240 Traders Blvd, Mississauga, Ontario L4Z 1W7

Tel:(905)890-2113 Fax:(905)890-5338

www.til.ca

CAUTION

This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves when handling printed

circuit boards.

WARNING: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference and (2) this device must accept any interference received, including

interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provided reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Warning:

Changes or modifications not expressly approved by Technisonic Industries could void

the users authority to operate the equipment.

WARRANTY INFORMATION

The Model TDFM-600/6000 Transceiver is under warranty for one year from date of purchase. Failed units caused by

defective parts, or workmanship should be returned to:

Technisonic Industries Limited Technisonic Industries Limited

240 Traders Boulevard 3840 E. Robinson Road, Suite 214

Mississauga, Amherst,

Ontario L4Z 1W4 New York 14228

Tel: (905) 890-2113 Fax: (905) 890-5338 Tel: (716) 691-0669

WARNING For compliance with FCC RF Exposure Requirements, the mobile

transmitter antenna installation shall comply with the following two

conditions:

1. The transmitter antenna gain shall not exceed 3 Bi

2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation

distance of 70 cm meters or more between the transmitter antenna of this device and persons during

operation.

TABLE OF CONTENTS

Paragraph Title Page

SECTION 1 GENERAL DESCRIPTION

1.1 Introduction ................................................................................................1-1

1.2 Description .................................................................................................1-1

1.3 Technical Summary......................................................................................1-1

SECTION 2 OPERATING INSTRUCTIONS

2.1 General ......................................................................................................2-1

2.14 Radio Service Software.................................................................................2-4

SECTION 3 INSTALLATION INSTRUCTIONS

3.1 General ......................................................................................................3-1

3.2 Equipment Packing Log.................................................................................3-1

3.3 Transceiver Installation.................................................................................3-1

3.4 Installation Kit - Contents..............................................................................3-1

3.5 Pin Locations and Connections ......................................................................3-2

3.6 Wiring Instructions.......................................................................................3-3

3.17 Post Installation Tests ..................................................................................3-7

LIST OF TABLES

Table No. Title Page

3-1 25-pin D Connections...................................................................................3-2

LIST OF ILLUSTRATIONS

Figure No. Title Page

3-1 Outline Drawing...........................................................................................3-1

3-2 Wiring Connections and notes .......................................................................3-5

1-1

SECTION 1

GENERAL DESCRIPTION

1.1 INTRODUCTION

This publication provides operating and installation information on the TDFM-600/6000 airborne transceiver.

(The exact model number depends on which and how many RF modules are installed.)

1.2 DESCRIPTION

The TDFM-600/6000 series of transceivers are airborne multiband radios capable of conventional FM, P25,

SmartNet and SMART ZONE trunking systems. RF modules are available in VHF, UHFLO, UHFHI and 800 MHz

bands. The bands are numbered 1,4,5 and 8 respectively.

The following are typical model examples:

TDFM-655 -Two UHF high band modules

TDFM-688 -Two 800 MHz modules

TDFM-6148 -One VHF, UHF low and 800 MHz module

TDFM-6158 -One VHF, UHF high and 800 MHz module

1.3 TECHNICAL CHARACTERISTICS

Specification Characteristic

Model Designation: TDFM-600/6000

Physical Dimensions: Approx. 8" X 3" X 5.75"

Weight: 3 Lbs (1.2 kg)

Operating Temperature Range: -45°C to +60°C

Power Requirement:

Voltage: 28.0 Vdc, ±15%

Current: 165mA minimum

5A maximum

RF Output Power: 1 or 5 Watts

Frequency Range - VHF Module: 136 to 178 MHz

UHF LO Module: 403 to 470 MHz

UHF HI Module: 450 to 512 MHz

800 Module: 806 to 870 MHz

Audio Output Power (including sidetone): 500 mW into 600 ohms

Microphone Inputs: Carbon or Equivalent

Panel Back Lighting: 28 VDC or 5VAC

(specified when ordered)

2-1

SECTION 2

OPERATING INSTRUCTIONS

2.1 GENERAL

A 2 line display and a keypad and 2 or 3 rotary knobs provide the operator control of the 2 or 3 RF modules

installed in the unit. The display is showing the activity of one RF module at a time, selected by pressing the

desired knob. The knobs have multiple functions including volume, channel, display dimmer. The microphone,

key line and headphone audio are separate for each of the two or three bands therefore switching from band

to band is performed at an audio panel such as the Technisonic A710 series. This allows for separate and

simultaneous operation on each of the bands just like having 2 or 3 separate radios.

2.2 FRONT PANEL

Refer to the diagram below:

2.3 POWER SWITCH

To switch the transceiver on, press the left most knob. The transceiver will immediately power up. The display

will show TECHNISONIC and the software version installed followed by the model number as determined by

which RF modules are installed. The display will then show the normal display for band 1. To switch off the

transceiver at any time, press and hold the left most knob for 2 seconds until the display shows OFF then

release.

2-2

2.4 KNOBS

The transceiver will have two or three knobs depending on how many RF modules are installed. The knobs are

rotary encoders which turn endlessly which means their actual position is not important. Each knob also has

a push button incorporated in it so you can press the knob as well as turn it. Pressing a different knob will cause

the display and keyboard to switch to the band associated with that knob. The knob will start out as a volume

control. Pressing the same knob again will change its function to act as the channel/talkgroup selector

depending on how that band is programmed. Pressing the same knob again changes the function of the knob

to a display dimmer control. Pressing the knob again causes the key pad function to change from function keys

to number keys. The knob in this mode acts as a volume control. Pressing the knob again brings it back to the

first mode of volume control. The current function of the knob is shown at the top right of the display. The

function of the knobs of the unselected bands are always volume control.

2.5 SOFT KEYS AND HOME

The transceiver has three soft keys which assume the function shown above them on the display. The functions

displayed depend on how the module was programmed with the radio service software (RSS)™. Functions can

be different on a channel by channel basis as well. These may include:

ZONE - Pressing this function will prompt you for a new zone number which can be entered directly or

scrolled using the UP and DN keys.

MUTE - Selecting this function will prompt you for an on or off entry using the soft keys. Tones refer

to the beeps heard when pressing buttons.

VIEW - The view function is used to view lists. Lists can include phone numbers, call lists and or page.

CHAN - Pressing CHAN will prompt you for a new channel number. This can be entered via the key pad

or by using the UP and DN buttons. Channel selection can also be programmed as one of the

rotary knob functions using the RSS™.

PWR - Selecting PWR will allow the power output of the radio to be set to high or low.

PROG - Selecting PROG allows brings you to user programmable features of the radio such as telephone

numbers. The ability for the user to program phone numbers, etc can be enabled or disabled by

the RSS™.

At any time while in one of these functions, you can escape back to the normal mode by pressing the HOME

key.

2.6 FUNCTION KEYS

Four function keys at the top of the keypad provide the same actions as the three side buttons and the top

button found on the XTS-3000 portable. They are as follows:

F1 - Top side button (purple button) on the portable.

F2 - Center side button (with one dot) on the portable.

F3 - Bottom side button (with two dots) on the portable.

F4 - Top button (orange button) on the portable.

2-3

TDFM-600/6000 Transceiver Recommended Keypad Menu Defaults:

TDFM-600/6000

ITEM

Portable

ITEM

Conventional

Operation (H35) SmartNet

Operation (H37) SMARTZONE

Operation (H38)

F1 Key Top Side

Button 1 Monitor Phone Phone

F2 Key Center Side

Button 2 Scan Scan Scan

F3 Key Bottom Side

Button 3 Talkaround/

Direct Private Call Site

Display/Search

F4 Key Orange (Top)

Button Emergency Emergency Emergency

MUP and

MDN keys 16-Position

Rotary Knob Channel Select Channel Select Channel Select

ESW Key Two-Position

Concentric or

Ergo Switch

Blank (O)

Low Power (∅)Blank (O)

Low Power (∅)

TSW Key Three-Position

Toggle Switch Blank (A)

Scan (B)

Blank (C)

Blank (A)

Scan (B)

Blank (C)

Blank (A)

Scan (B)

Blank (C)

Note: It is possible to use Motorola’s Radio Service Software (RSS™ or CPS™) to alter the default keypad

settings of the TDFM-600/6000 series radios. However if custom key settings are chosen it will not

be possible for Technisonic to help the Pilot or other Radio User through operational difficulties. These

questions will have to be referred to the Radio System Administrator responsible for customising the

settings. Technisonic recommends that the default key settings stay in place until all airframe installation

and operational issues have been overcome.

The TDFM-600/6000 series Transceivers are programmable by Motorola Radio Service Software. The following

settings may be programmed for each Channel in a Conventional Radio:

Tx Frequency Zone

Tx PL/DPL Code Channel

Rx Frequency Name

Rx PL/DPL Code RX Signal Voice Type

Time-Out Timer TX Signal Voice Type

Scan List Network Access Code

Phone Tx Power

Smart PTT

2-4

The following settings must be programmed for each mode in a Trunked (SmartNet or SMARTZONE) Radio:

System Type TG Strapping

System ID Zone

Individual ID Scan List

Coverage Type Scan Type

Affiliation Type Interconnect

Control Channel 1 Phone Display Format

Control Channel 2 Private Call

Talkgroup 1 Private Call Type

Talkgroup 2 Private Call Operation

The function keys along with the rest of the key pad, revert to normal number keys during transmit and when

NUM LOCK is selected by pressing the rotary knob.

2.7 MUP AND MDN KEYS

These keys provide the same function as the rotary knob does when it is set to CHAN. This equates to the 16

position rotary knob on the portable. When one of these keys is pressed, the function of the rotary knob is

automatically set to CHAN.

2.8 UP AND DN KEYS

The keys provide the same function as the left and right arrow keys on the portable. The UP key equates to the

right arrow key. These keys are used for a variety of functions but in the normal mode they are used to scroll

through the soft key menus.

2.9 BRT AND DIM KEYS

Use these keys to dim or brighten the display. The radio powers up at full brightness for normal use but can

be dimmed for night operations.

2.10 ESW KEY

The ESW key provides the function of the concentric or ‘ergo’switch on the portable. The switch has two

conditions which are represented by ‘O’ and ‘∅’. Pressing the ESW key toggles the condition back and forth.

The condition is displayed at the bottom of the display, second character from the right. The ergo switch

condition is saved when the unit is turned off. There are separate conditions for each band installed. The ESW

key can be programmed with the RSS™ to a variety of functions such as low power, scan, channel, and secure

mode.

2.11 TSW KEY

The TSW key provides the function of the toggle switch on the portable. The switch has three conditions

which are represented by ‘A’, ‘B’and ‘C’. Pressing the TSW key toggles the condition A,B,C,A,B, etc. The

condition is displayed at the bottom of the display, last character on the right. The toggle switch condition is

saved when the unit is turned off. There are separate conditions for each band installed. The TSW key can be

programmed with the RSS™ to a variety of functions such as low power, scan, channel, and secure mode.

2-5

2.12 DISPLAY

The transceiver has a two line, 48 character LED display which gives information about the selected band. On

the top line is shown the zone number, channel name and rotary knob function. The bottom line displays the

soft key menu, the band selected, and the ESW/TSW condition. Also displayed are letters and symbols

indicating scan, direct/repeater talk around, monitor, secure, priority and call. In addition to the character

display, there are two LED indicators on the left. The top LED on the indicates a signal is being received on the

selected band while the bottom LED indicates that any one or more of the installed bands are transmitting.

2.13 GENERAL OPERATION

Switch on the transceiver as described in 2.3. Select the desired band by pressing the appropriate knob. Select

the same band on the audio panel. Press the knob again so that CHAN shows up on the top right of the display.

Rotate the knob until the desired mode, channel or talk group is selected. Press the knob until VOL is again

shown on the display. You can adjust the volume by waiting until a signal is received or by pressing F1 (factory

programmed for monitor function) and adjusting the rotary knob. The radio is ready to use. Remember that the

band selected by pressing the rotary knobs is what is displayed on the screen but the band selected by the

audio panel is band that you are actually transmitting and receiving on. If another band is displayed, the rotary

knob for the band you are using is still operating the volume level. To use the DTMF key pad while transmitting,

the band you are using must be displayed on the screen.

2.14 RADIO SERVICE SOFTWARE (RSS™ for DOS or CPS™ or Windows)

To make any changes to the programming in the radio, RSS™ software must be used. There is no provision in

the radio to allow the user to change frequencies, zones, talk groups, etc. RSS™ software can be purchased

from your local Motorola dealer. Along with the RSS™, a Motorola Radio Interface Box (RIB) is required to

connect the computer to the TDFM-600/6000. Each band in the TDFM-600/6000 is considered an XTS-3000

portable by the RSS™ software. To program a band in the transceiver, it must be selected by pressing the

appropriate knob before running the RSS™. Follow the instructions supplied with the RSS™ and RIB. The radio

cable supplied with the RIB will not connect to the TDFM-600/6000, therefore you will need to fabricate or

purchase the cable shown below.

FIGURE 2-2 Programming Cable

3-1

SECTION 3

INSTALLATION INSTRUCTIONS

3.1 GENERAL

This section contains information and instructions for the correct installation of the TDFM-600/6000

Transceiver.

3.2 EQUIPMENT PACKING LOG

Unpack the equipment and check for any damage that may have occurred during transit. Save the original

shipping container for returns due to damage or warranty claims. Check that each item on the packing slip

has been shipped in the container.

3.3 INSTALLATION

The TDFM-600/6000 Transceiver is designed to be dzus mounted and should be installed in conjunction with

an IN-600 installation kit. See figure 3-1 for an outline drawing of the unit with dimensions to facilitate the

installation.

3.4 INSTALLATION KIT - CONTENTS

The IN-600 installation kit (P/N 019301-1) consists of:

1. One 25 pin Cannon D mating connector (female) complete with crimp pins and hood.

2. 3 BNC connectors.

3.5 ANTENNA INSTALLATION

The type and number of antennas depends on the model of transceiver being installed. The following is a list

of recommended antennas for the various RF modules:

VHF 136 to 176 MHz Comant part # CI-292

UHFLO 403 to 470 MHz Comant part # CI-275

UHFHI 450 to 512 MHz Comant part # CI-275

800 806 to 870 MHz Comant part # CI-306

The antenna should be mounted on the bottom of the aircraft whenever possible. Consult with instructions

provided with the antenna. Connect the RF cables to the back of the transceiver using the BNC connectors

provided in the installation kit.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Technisonic Industries Limited Transceiver Handbücher

Technisonic Industries Limited

Technisonic Industries Limited TFM-30 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDAM-1000 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-403 Handbuch

Technisonic Industries Limited

Technisonic Industries Limited T3018 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-138A Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-138 Handbuch

Technisonic Industries Limited

Technisonic Industries Limited TFM-138 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-566 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-9300 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-556 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-9200 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TiL-91-DE Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-530 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-530 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TiL-91-DE/8.33 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-550 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TFM-550 Handbuch

Technisonic Industries Limited

Technisonic Industries Limited TDFM-600 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-136 Handbuch

Technisonic Industries Limited

Technisonic Industries Limited TMS-110 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TSC-4400 Bedienungsanleitung

Technisonic Industries Limited

Technisonic Industries Limited TDFM-600 Bedienungsanleitung

Beliebte Transceiver Handbücher anderer Marken

Yaesu

Yaesu FT-7B Bedienungsanleitung

Kenwood

Kenwood ProTalk TK-3201 Bedienungsanleitung

Texas Instruments

Texas Instruments TLK10232 Bedienungsanleitung

Mizuho

Mizuho MX-2 Produkthandbuch

Kenwood

Kenwood TK-3180 Bedienungs- und Wartungshandbuch

Blitz

Blitz MJ-398U Bedienungsanleitung

Utilicom

Utilicom LongRanger 2050 Bedienungsanleitung

Standart

Standart HX290UKA Bedienungsanleitung

Altronix

Altronix Pace1PTM Bedienungsanleitung

Kirisun

Kirisun PT2208 Bedienungsanleitung

ELECRAFT

ELECRAFT KX2 Bedienungsanleitung

Zodiac

Zodiac K3 Bedienungsanleitung

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Bedienungsanleitung

Kenwood

Kenwood TK-2217 Bedienungsanleitung

Siemens

Siemens PSO 4000 Bedienungsanleitung

Kenwood

Kenwood TS-590SG Bedienungsanleitung

Midland

Midland G8E-BT Handbuch

ComNav

ComNav Mariner X2 Bedienungsanleitung
