Tecnoalarm TP8-96 Benutzerhandbuch

TP8-96 VIDEO

864 ZONES

CONTROL PANEL

8 TO 96 ZONES EXPANDIBLE

CONTROL PANEL

WITH INTEGRATED

ETHERNET SWITCH

EN60950

EN50130-4

EN50081-1

INSTALLER

MANUAL

Release: 1.0

Update: July2011

Language: English

FWversion: 0.7.05

II InstallerManual-TP8-96VIDEO

Theproductfeaturescanbesubjecttochangewithoutnotice.Unauthorizedreproductionordistributionofthis

manual, or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be

subject to change without notice

III

TP8-96VIDEO-InstallerManual

CONFORMITY

Hereby,Tecnoalarm srl declaresthat the presentequipment is incompliance with theessential requirements and

otherrelevantprovisionsoftheR&TTE1999/05/ECdirective.

Thedeclarationofconformityisavailableonthewebsite:www.tecnoalarm.com.

IV InstallerManual-TP8-96VIDEO

TP8-96VIDEO-InstallerManual Index 1

INDEX

1. INTRODUCTION TO THE TP8-96 VIDEO SYSTEM

1.1 PROGRAMMINGMENU 1-1

1.2 HARDWARECONFIGURATION-AVAILABLEMODULES 1-7

2. PROGRAMMING OF ZONES AND PROGRAMS

2.1 ZONECONFIGURATION 2-1

2.1.1 Creationoflistandparameters 2-1

2.1.2 Zone-functionassociation 2-11

2.1.3 Zone-programassociation 2-13

2.1.4 Consoles 2-14

2.1.5 Keypoints 2-16

2.1.6 Options 2-17

2.1.7 Outputs 2-20

2.1.8 Bus sirens 2-22

3. PROGRAMMING OF TELEPHONE SECTION

3.1 TELEPHONEPARAMETERCONFIGURATION 3-1

3.1.1 Telephonechannelsandstandardtelephoneparameters 3-1

3.1.2 GSMmodule 3-4

3.1.3 Tecnocell 3-6

3.1.4 Ethernet 3-8

3.1.5 Teportcodes 3-10

3.1.6 Openingmessage-vocabulary 3-11

3.1.7 Remotecontrols 3-13

3.2 EXPLANATORYNOTES 3-14

3.2.1 Telephonenumbers 3-14

3.2.2 Protocols 3-15

3.2.3 Communicatorblock 3-17

3.2.4 Airtimerequest 3-17

3.2.5 Call-back 3-18

3.2.6 Ethernet 3-20

3.2.7 Remotecontrolmanagement by SMS 3-21

4. PROGRAMMING OF TIME PARAMETERS

4.1 TIMESETTINGS 4-1

4.2 TIMERS 4-3

4.3 ACCESSPERIODS 4-5

4.4 CUSTOMIZATIONOFTHECALENDAR 4-7

4.5 EXPLANATORYNOTES 4-9

5. POGRAMMING OF ACCESS CODES AND KEYS

5.1 PROGRAMMINGOFTHECODES 5-1

5.2 PROGRAMMINGOFTHEKEYS 5-4

5.3 PROGRAMMINGOFTHEWIRELESSKEYS 5-6

5.4 EXPLANATORYNOTES 5-8

6. PROGRAMMINNG OF WIRELESS DEVICES

6.1 PROGRAMMINGOFTHEWIRELESSSIRENS 6-1

6.2 PROGRAMMINGOFTHEWIRELESSCONSOLES 6-3

Index InstallerManual-TP8-96VIDEO

7. HARDWARE CONFIGURATION

7.1 ADDITIONORDELETIONOFMODULES 7-1

8. RS485 SERIAL BUS ANALYSIS

8.1 SERIALBUSANALYSIS 8-1

A. APPENDIX A - APPENDIX SPECIAL PROCEDURES

A.1 RESETOFTHEDEFAULTCODES A-3

A.2 COMPLETEDELETIONOFSYSTEMCONFIGURATION(RESETOFDEFAULTSETTINGS) A-4

A.3 BACKUP/RESTOREOFTHECONFIGURATIONOFTHEWIRELESSSECTION A-5

A.4 FIRMWAREUPGRADE A-7

Electronicboard A-11

Terminals A-12

System A-13

Cameraconnection A-14

Supply by terminals A-15

Supply by cables + splitter A-16

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-1

1.1 PROGRAMMING MENU

Descriptionoftheprogrammingmenus.

zAdvanced:Enablingordisablingofadvancedprogramminglevel.

N.B.It is possible to enable the advanced programming level only if you are in

possession ofthe corresponding license.

zAutomatic wiring:Enabling or disabling of the automatic wiring function.

N.B. All the other items of the option window are disabled.

zZones: Association of the logical zones to the physical zones, alphanumerical

description, enabling of voice message, zone type, alarm cycles, alarm counter,

contact type, configuration of the connected detector, enter filter and sensitivity

zZones-functions:Association of the followingfunctions to the zones:siren, PGM, by-

pass, coinciding zone, chime, non excludable zone, common zone

zZones-programs:Associationofthezonestotheprograms,alphanumerical

descriptionof theprograms, enabling of the voicemessage

zConsoles:Consoleconfiguration,association of the program statusLEDtothe

programs, quick arming/disarming, panic alarm, quick menu, chime, audio settings,

messagescheduling

zKeypoints:Associationoftheprograms

zOptions: Buzzer section, wireless section, voice report, key zone properties, single

armingmode,enabling/disablingtamper,antimasking control, association of the

siren and PGM outputs to the programs

zOutputs:Outputconfiguration,polarityprogramming

zBus sirens:Associationofthesirenstotheprograms,aftersoundblinking,volume

setting,siren mode, soundtype,functioningmode,enabling/disabling of theantifoam

andantidrillingprotection

PROGRAMMINGOPTIONS

ZONECONFIGURATION

1. INTRODUCTION

PROGRAMMINGOPTIONS

IntroductiontotheTP8-96 VIDEO system Installermanual-TP8-96VIDEO

1-2

TELEPHONE SECTIONCONFIGURATION

zTelephone interface:Programming of the channels from A to H, call back function,

commmunicatorblock,generalsettings

zGSM: Enabling of the GSM interface, answering mode, rings, airtime request, SMS

heading, GPRS settings, commands by SMS, password, white list

zTecnocell:Enablingofthe external GSM communicator, answering mode,emergency

phonenumber,associationofthe messages, emergency SMS, enabling oftheguided

menuandof the data channel

zEthernet:Configurationoftheintegrated 8 ports Ethernet switch,IPaddress, subnet

mask,gateway,programmingofthecommunicationportfortheLocalServer

Tecnoalarm,RemoteServerTecnoalarm,TecnoserverTecnoalarm,Tecno_Out

zReport codes:Programming ofthereportcodesofall8channelsfortheevent

transmission

zOpening message - Vocabulary:Test/recording/loading of the opening message,

loadingandupdateofthevocabulary

zRemotecontrol: Remotecontrolmessage, alphanumericaldescription,

programmingoftheactivationtime

zTime settings: Entry time 1 and 2, exit time, disarming confirmation time, delay of

channelandsirenactivation,antimaskingandpower failure,alarmtime,tamper,

technicalandhold-upalarmtime; duration of end of by-passandautomaticarming

warning,maximumdurationofby-pass,supervisioninterval

zTimers:Frequency and moment of activation, association of the function

zAccessperiods:Frequencyand moment ofactivation,associationoftheaccess

periodstothecodes,transponders/RFIDandremotecontrols

zCustomization 1st year:Programmingofthe working days, holidays andholiday

eves,winterandsummertime,viewingofthescheduledmessageontheconsole

zCustomization 2nd year: Same as for the first year

TIMEPARAMETERCONFIGURATION

TP8-96VIDEO-Installermanual IntroductiontotheTP8-96VIDEOsystem 1-3

ACCESSCONFIGURATION

zCodes:Programming ofthecodes,nameand lengthofthecode, arming/disarming

function and by-pass, association to the programs, attributes

zTransponders: Programmingofthetransponders,name, arming/disarmingfunction

and by-pass, association to the programs, attributes

zWireless keys: Programming of the wireless keys, name, association of the keys to

theprogramsor the functions, attributes

zWireless sirens:Alarmtime, siren delay, flashing time, volume setting,functioning

mode

zWireless consoles: Association of the program status LED to the programs, attributes

zEvents ->Operations:Whenaspecific event happens, the controlpanelexecutes a

specific operation associated to the event, e.g.:

• What kind of event? Arming

•Whicharming?Remotearming

• By whom? User 1

•Whichprogram?Program2

•How? By telephone

zOperations:Creationofanewoperation,operationmodification,operationdeleted

zTelephone directory: Association of specific telephone numbers to the operations

WIRELESSDEVICECONFIGURATION

ADVANCEDPROGRAMMING

IntroductiontotheTP8-96 VIDEO system Installermanual-TP8-96VIDEO

1-4

EVENTLOG

Viewing,printingandsavingasatextfile(TXT)ofthecontrolpaneleventlog.Thestoredeventsareviewedwith

indication of date and time. You can list the event log by date or type.

zN.:Event number. Click to list in chronological order (recordingsequence)

zDate and time: Click to view the events of a determined period of time

zDescription: Event description. Click to list the events by type and view the events of a

specific type

Hardwareconfigurationofthesystem.

Thismenu permits addition or deletion of thehardware modules ofthe system.

zAdd: Click on "add" to add the device selected in the list.

zDelete: Click on "delete" to delete the device selected in the list.

zModules available: List of the modules available for the system.

HARDWARECONFIGURATION

FLOORPLANCONFIGURATION

This menu allows to create and to manage the floor plans associated to the system.

Thismenuisonly enabled if you have thecorrespondingTecnoalarmlicenseand the automatic wiring option is

disabled.

zMenu which permits the selection of the useful elements to create the floor plan.

Forviewingspecificcommandsareavailable.

zSymbols available:For floor plan configuration
