Tektronix 8 Series Handbuch

8 Series

Sampling Oscilloscope

Installation and Safety Instructions

*P071366302*

071-3663-02

8 Series

Sampling Oscilloscope

Installation and Safety Instructions

www.tek.com

071-3663-02

protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued

and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges

reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14150 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

■In North America, call 1-800-833-9200.

■Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents

Important safety information ................................................................................................................................ iii

General safety summary ................................................................................................................................ iii

Service safety summary ................................................................................................................................ iv

Terms in the manual ....................................................................................................................................... v

Terms on the product ..................................................................................................................................... v

Symbols on the product .................................................................................................................................. v

Compliance Information ...................................................................................................................................... vii

EMC compliance ........................................................................................................................................... vii

Safety compliance ........................................................................................................................................ viii

Environmental compliance ............................................................................................................................. x

Preface

TSO8 Series ................................................................................................................................................... 1

Key features include ....................................................................................................................................... 1

Available product documentation ................................................................................................................... 2

Introduction to the instrument

What ships with your product ......................................................................................................................... 3

Environmental requirements .......................................................................................................................... 3

Power requirements ....................................................................................................................................... 4

Electrostatic discharge information ................................................................................................................ 4

Front panel ..................................................................................................................................................... 5

Rear panel ...................................................................................................................................................... 6

Initial setup and connection

Module installation and removal ..................................................................................................................... 7

Software installation and requirements .......................................................................................................... 9

Software licenses and options ..................................................................................................................... 11

Firmware installation and requirements ....................................................................................................... 13

Connect the mainframe to the network and TSOVu .................................................................................... 13

Cleaning

Cleaning the instrument ............................................................................................................................... 17

8 Series Installation and Safety Instructions i

Table of Contents

ii 8 Series Installation and Safety Instructions

Important safety information

This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a

safe condition.

To safely perform service on this product, see the Service safety summary that follows the General safety summary.

General safety summary

Use the product only as specified. Review the following safety precautions to avoid injury and prevent damage to this product or

any products connected to it. Carefully read all instructions. Retain these instructions for future reference.

This product shall be used in accordance with local and national codes.

For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to

the safety precautions specified in this manual.

The product is designed to be used by trained personnel only.

Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.

Before use, always check the product with a known source to be sure it is operating correctly.

This product is not intended for detection of hazardous voltages.

Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.

While using this product, you may need to access other parts of a larger system. Read the safety sections of the other

component manuals for warnings and cautions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.

To avoid fire or personal injury

Use proper power cord. Use only the power cord specified for this product and certified for the country of use. Do not use the

provided power cord for other products.

Ground the product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the

grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the

product, ensure that the product is properly grounded. Do not disable the power cord grounding connection.

Power disconnect. The power cord disconnects the product from the power source. See instructions for the location. Do not

position the equipment so that it is difficult to operate the power cord; it must remain accessible to the user at all times to allow for

quick disconnection if needed.

Observe all terminal ratings. To avoid fire or shock hazard, observe all rating and markings on the product. Consult the product

manual for further ratings information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

Do not float the common terminal above the rated voltage for that terminal.

The measurement terminals on this product are not rated for connection to mains or Category II, III, or IV circuits.

Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous

voltage exposure is possible.

Avoid exposed circuitry. Do not touch exposed connections and components when power is present.

Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualified

service personnel.

8 Series Installation and Safety Instructions iii

Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the

product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.

Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use

probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.

Examine the exterior of the product before you use it. Look for cracks or missing pieces.

Use only specified replacement parts.

Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm

environment.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry. Remove the input signals before you clean the product.

Provide proper ventilation. Refer to the installation instructions in the manual for details on installing the product so it has

proper ventilation.

Slots and openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push objects into

any of the openings.

Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may

result in serious injury.

Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.

Use care when lifting and carrying the product. This product is provided with a handle or handles for lifting and carrying.

Use only the Tektronix rackmount hardware specified for this product.

Service safety summary

The Service safety summary section contains additional information required to safely perform service on the product. Only

qualified personnel should perform service procedures. Read this Service safety summary and the General safety summary

before performing any service procedures.

To avoid electric shock. Do not touch exposed connections.

Do not service alone. Do not perform internal service or adjustments of this product unless another person capable of rendering

first aid and resuscitation is present.

Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power

before removing any covers or panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist in this product. Disconnect power, remove

battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric strength after performing a repair.

Important safety information

iv 8 Series Installation and Safety Instructions

Terms in the manual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.

Terms on the product

These terms may appear on the product:

■DANGER indicates an injury hazard immediately accessible as you read the marking.

■WARNING indicates an injury hazard not immediately accessible as you read the marking.

■CAUTION indicates a hazard to property including the product.

Symbols on the product

When this symbol is marked on the product, be sure to consult the manual to find out the nature of the potential

hazards and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to

ratings in the manual.)

The following symbols may appear on the product:

Important safety information

8 Series Installation and Safety Instructions v

Important safety information

vi 8 Series Installation and Safety Instructions
