Telit Wireless Solutions WE310F5-I Bedienungsanleitung

WE310F5-I/P Evaluation Board

Quick Start Guide

1VV0301671 Rev. 9 – 2022 -04 -18

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 2of 19 2022-04-18

Not Subject to NDA

APPLICABILITY TABLE

PRODUCTS

WE310F5-I

WE310F5-P

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 3of 19 2022-04-18

Not Subject to NDA

CONTENTS

APPLICABILITY TABLE 2

CONTENTS 3

1. INTRODUCTION 4

Scope 4

Audience 4

Contact Information, Support 4

Symbol Convention 4

Related Documents 5

2. INITIATING THE MODULE 6

2.1. Program the Module 6

2.2. Configure the Module 6

3. MODES 7

3.1. Wireless Station Mode 7

3.2. Wireless AP Mode 7

3.3. Bluetooth Station Mode 7

4. WE310F5 MODULE 9

WE310F5 Module 3D View 9

WE310F5 Module Description 10

5. RESOURCE LINKS 12

6. PRODUCT AND SAFETY INFORMATION 13

6.1. Copyrights and Other Notices 13

6.1.1. Copyrights 13

6.1.2. Computer Software Copyrights 13

6.2. Usage and Disclosure Restrictions 14

6.2.1. License Agreements 14

6.2.2. Copyrighted Materials 14

6.2.3. High-Risk Materials 14

6.2.4. Trademarks 14

6.2.5. Third-Party Rights 14

6.2.6. Waiver of Liability 15

6.3. Safety Recommendations 15

7. GLOSSARY 17

8. RELATED DOCUMENTS 18

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 4of 19 2022-04-18

Not Subject to NDA

1. INTRODUCTION

Scope

This document describes electrical specifications, mechanical information, interfaces

application, and manufacturing information about the Telit WE310F5-I/P Wi-Fi/BLE

module. With the help of this document and other application notes or user guides, users

can understand the Telit WE310F5-I/P Wi-Fi/BLE module well and develop various products

quickly.

Audience

This document is intended for Telit customers, especially system integrators, about to

implement their applications using the Telit module.

Contact Information, Support

For technical support and general questions please e-mail:

•

TS[email protected]

•

TS-AMERICAS@telit.com

•

TS-APAC@telit.com

•

TS[email protected]

•

TS[email protected]

Alternatively, use

https://www.telit.com/contact-us

For detailed information about where you can buy the Telit modules or for

recommendations on accessories and components, visit

https://www.telit.com

We aim to make this guide as helpful as possible. Keep us informed of your comments and

suggestions for improvements.

Telit appreciates feedback from the users of our information.

Symbol Convention

Danger:

This information MUST be followed, or catastrophic equipment failure

or personal injury may occur.

Warning:

Alerts the user on important steps about the module integration.

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 5of 19 2022-04-18

Not Subject to NDA

Note/Tip:

Provides advice and suggestions that may be useful when

integrating the module.

Electrostatic Discharge:

Notifies the user to take proper grounding

precautions before handling the product.

All dates are in ISO 8601 format, that is. YYYY-MM-DD.

Related Documents

•WE310F5-I/P AT Command Reference Guide, 80664ST11034A

•WE310F5-I/P WE310F5-IP Module Hardware User Guide, 1VV0301662

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 6of 19 2022-04-18

Not Subject to NDA

2. INITIATING THE MODULE

Program the Module

1. Connect the micro-USB UART1 port to your system.

2. Change the toggle switch position to Program.

3. Download and unzip the Telit_Wifi_Image_Tool. For download information, see

Resource Links.

4. Open the Telit_Wifi_Image_Tool folder.

5. Open the Telit_Wifi_Image_Tool application.

6. Select the appropriate COM Port and Click Browse.

7. Navigate to the Telit_Wifi_Image_Tool and select the s2w.bin file.

8. To initiate the flash, click Program.

9. After the flash process is complete, click OK.

10. Close the Telit_Wifi_Image_Tool.

The WE310F5 EVB is ready to configure.

Configure the Module

1. Connect the micro-USB cable to the UART0 port.

2. Change the toggle switch position to Run.

3. Open Tera Term > Setup > Serial Port.

4. Set the BAUD rate to 115200.

The WE310F5 EVB is ready to use.

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 7of 19 2022-04-18

Not Subject to NDA

3. MODES

Wireless Station Mode

1. To set the module in Station Mode:

AT+WNI=0

2. To connect the network to L3:

AT+WNCN=1,"Telit_WiFi",“Password123",11

Wireless AP Mode

1. To set the module in AP Mode:

AT+WNI=1

2. To configure the IP:

AT+WNIPC=0,1,192.168.5.1,255.255.255.0,192.168.5.1

3. To configure the node in AP Mode:

AT+WNAPIPC=0,192.168.5.3,192.168.5.20,86400000

4. To create a network:

AT+WNCR=0,”roam3”,6,”WPA2”,”AES”,”1234567890”

Bluetooth Station Mode

1. To initialize BLE on the module:

AT+BI=1

2. To scan and connect to a peripheral device:

AT+BSCAN

3. For DUT peripheral connection:

AT&W0

AT+YSR

AT+BI=1

AT+BIOCAP=0

AT+BADVINTMIN=60

AT+BADVINTMAX=60

AT+BADVE=1

AT+BATTRIB="pserv","uuid=1234"

AT+BATTRIB="char","prop=0x0c","uuid=5678"

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 8of 19 2022-04-18

Not Subject to NDA

AT+BATTRIB="charval","perm=0011","len=1","val=0x30"

AT+BATTRIB="complete"

AT+BOAD

AT+BI=1

AT+BCONINTMAX=1000

AT+BCONINTMIN=1000

AT+BCONNECT="00217E36822","t2","gatt"

Note:

When the module behaves as a peripheral, the AT+BCONNECT and

AT+BSCAN must be initiated from the Central module (Primary WE310F5

module).

Note:

When a Mobile device (External Application) is designated as a Central

module, it scans and connects automatically to the peripheral WE310F5

module.

WE310F5-I/P Evaluation Board Quick Start Guide

1VV0301671 Rev. 9 Page 10 of 19 2022-04-18

Not Subject to NDA

WE310F5 Module Description

Figure 2: WE310F5-P Components

W-P

WE310F5-P Antenna Connector

ARDUINO Enable (PL705)

UART (PL608)

UART1

I2S-I2C (PL601)

GPIO- LED (PL606)

GPIO – Alternate Function (PL302 – PL305)

UART0

General Purpose Button (PB1-PB2)

Power Switch- EVB

Reset Button

Power connector USB 2.0

RUN/ PROGRAM Toggle Switch

Power Config (PL201-P204)

Audio Jack

SWD

Power Switch- Module

SPI-SDIO (PL604)

PB1-PB2 (PL605)

LED
