FlexSym©OLT-mini Installation and Turnup Guide

Page 2 of 35

Tellabs®Information

The information in this publication is proprietary to Tellabs Enterprise, Inc.

No part of this publication may be used, disclosed, reproduced, adapted, translated, stored in a

retrieval system, or transmitted in any form or by any means, electronic or mechanical, for any

purpose, without the written permission of Tellabs Enterprise, Inc. Although every precaution

has been taken in the preparation of this publication, Tellabs Enterprise, Inc. assumes no (i)

responsibility for errors or omissions contained herein or (ii) liability for any damages resulting

from the use of information contained herein. Information in this publication is subject to change

without notice.

Trademarks

The following trademarks and service marks are owned by Tellabs Operations, Inc. or its

affiliates in the United States and/or other countries: TELLABS®, TELLABS and T symbol®,

T symbol®.

Any other company or product names may be trademarks of their respective companies.

Proprietary

This document is the property of Tellabs Enterprise, Inc. and contains confidential and

proprietary information owned by Tellabs Enterprise, Inc. Any copying, use, or disclosure of the

contents of this document, without the written permission of Tellabs Enterprise, Inc., is strictly

prohibited.

FlexSym©OLT-mini Installation and Turnup Guide
Page 3 of 35
Table of Contents

Tellabs®Information ......................................................................................................... 2
Copyright.....................................................................................................................................2
Trademarks.................................................................................................................................2
Proprietary..................................................................................................................................2
Tellabs®FlexSym OLT-mini Installation and Turnup Guide........................................ 4
Description..................................................................................................................................5
Site Preparation..........................................................................................................................7
Safety Precautions...................................................................................................................10
Installation ................................................................................................................................12
OLT Turnup...............................................................................................................................19
Add OLT to Panorama PON....................................................................................................26
Add ONT....................................................................................................................................31
Contact Us ................................................................................................................................35



FlexSym©OLT-mini Installation and Turnup Guide

Page 4 of 35

Tellabs®FlexSym OLT-mini Installation and Turnup

Guide

This document provides instructions to install and turnup the Tellabs® FlexSym OLT-

mini optical line terminal.

Document Revisions

Revision

Date

Notes

Revision A

Jul 2021

•Initial Release of Document

Related Documentation

N/A

FlexSym©OLT-mini Installation and Turnup Guide

Page 5 of 35

Description

The Tellabs FlexSym® OLT-mini is a small line size outdoor OLT with industrial temp

ratings. This OLT is designed to be utilized for small installations without temperature

control.

The OLT-mini supports the following features:

•2x PON Ports: The OLT-mini supports 2x PON ports. The ports can be either GPON or

XGS-PON. The PON modes cannot be mixed.

•4x 10/1 SFP+ Ports: The OLT-mini supports 4x OLT PON ports, typically intended to be

daisy chained to support the full bandwidth either East or West in an RSTP Switched

ring. The OLT uplinks are totally non blocking and can deliver the full bandwidth of the

10G PONs upstream or downstream.

•μUSB Interface: The OLT-mini provides a μUSB interface for turnup and debugging. The

OLT-mini supports turnup via a copper Ethernet interface as well.

•Industrial Temp Rating: The OLT-mini comes with a weathertight enclosure which

supports an operating range of -40C to +55C.

FlexSym©OLT-mini Installation and Turnup Guide

Page 6 of 35

•AC or DC Powering Options: The OLT-mini can be installed with AC power or DC

power input options. Additionally dual AC or DC power inputs are supported for high

availability solutions.

•Wall Mount:Supports standard mounting bracket for mounting of the OLT-mini on

walls or backboards.

•SSHv2 CLI Interface: The standard Tellabs CLI interface is supported for turn up and

debugging of the unit.

•Standard Panorama PON Interface: The Tellabs Panorama PON software will manage

the OLT-mini using the standard GUI and web interfaces.

FlexSym©OLT-mini Installation and Turnup Guide

Page 7 of 35

Site Preparation

•Tools Required

•OLT Part Numbers for Ordering

•OLT Laser Part Numbers

•OLT-mini Power Requirements

•OLT-mini Environmental Specifications

Tools Required

Installation of the OLT-mini will require the following tools:

•Laptop Computer: A laptop computer is required for turnup of the OLT-mini and

proper configuration of the uplink interfaces.

•μUSB Cable: If connecting to the OLT-mini using the μUSB interface, you will

need a standard USB3 to μUSB cable. The OLT-mini has a built in μUSB to serial

converter, so nothing other than the cable is needed for turnup via this interface.

You will need a terminal program to access the serial interface of the OLT-mini if you

use the μUSB interface. Teraterm and putty are good open source options. Teraterm is

used for the examples in this document.

•Copper SFP Module: If connecting to the OLT-mini using SSHv2, you will need a

copper SFP module to install into one of the OLT uplink ports.

You will need an SSHv2 terminal program if using SSHv2 to access the CLI and

configure the OLT-mini Turnup parameters. Teraterm and putty are good open source

options.

•Power Wiring: If using DC wiring, 20 AWG wiring or better is recommended.

•Uplink Lasers: Ensure you have purchased the appropriate Tellabs supported

Modules shown in the "OLT Laser Part Numbers" table shown below.

•M6 or 7/32" Allen Wrench: The enclosure is opened using either an M6 or

7/32" Allen wrench.

FlexSym©OLT-mini Installation and Turnup Guide

Page 8 of 35

OLT Part Numbers for Ordering

OLT Mini Part

Numbers

OLT Description

Comments

81.11S-OLTM-AC

FlexSym® OLT-mini, 2 PON, 4 Uplink, 120V AC

powered, optional DC power

Redundant power supply. DC

input option.

OLT Laser Part Numbers

Laser modules for the PONs and Uplinks must be purchased seperately. The OLT-mini

comes equipped with no laser modules.

Both PON lasers in the OLT-mini must be of the same type, i.e. both GPON, or both

XGS-PON.

OLT Laser Part

Number

Laser Description

Distance

Connector

Comments

0410-0471

850nm 10G SR SFP+

400m MMF

2xLC

Short Range MMF 10G Laser

0410-0470

1310nm 10G LR SFP+

10km SMF

2xLC

Long Range 10km 10G Laser

128211

850nm 1G SX SFP

550m MMF

2xLC

Short Range 1G Laser

81.11T-S1GB40KM-R6

1310 1G LR SFP

40km SMF

2xLC

Long Range 1G Laser

C.11T-S1GBELX1131S

1310 1G LR SFP

10km SMF

2xLC

Long Range 1G Wideband Laser

C11T-S1GBER450030

Copper1G SFP

100m

RJ45

Copper 1G SFP

81.11T-XFPGPON-IT

Tellabs GPON Laser

20km

1xSC UPC(blue)

2.5/1.25G Bidi GPON Laser

81.11T-XFPXGSPON

Tellabs XGS-PON Laser

20km

1xSC UPC(blue)

10G/10G Bidi XGS-PON Laser

FlexSym©OLT-mini Installation and Turnup Guide

Page 9 of 35

OLT-mini Power Requirements

The OLT-mini has the following AC power requirements when powered by AC:

AC Power Specifications

Value

Comments

AC Input Voltage

100-240VAC

AC Input Line Frequency

50-60Hz (nominal)

AC Current Rating

.7 A @ 100VAC, .3 A @ 240VAC

Max AC Input Power

72 W

The OLT-mini has the following DC power requirements when powered by DC:

DC Power Specifications

Value

Comment

DC Input Voltage

43-57DC

DC Current Rating

1.2 A @ 54VDC

DC Power

65 W

OLT-mini Environmental Specifications

Environmental Specifications

Value

Comments

Dimensions

13.5 x 6.25 x 14 in (343 x 159 x 356 mm)

Certifications

Operating Temperature Range

-40C to +55C (-40F to 131F)

Operating Humidity

5 to 95% non condensing

FlexSym©OLT-mini Installation and Turnup Guide

Page 10 of 35

Safety Precautions

Product Disposal Symbol

The Waste Electrical and Electronic Equipment (WEEE) symbol will accompany specific

products that must be collected and disposed of separately from household waste. The

black bar under the symbol signifies the product was placed on the market after August

13, 2005.

Items such as integrated batteries can be disposed of along with the product; they will

be separated at recycling centers. By participating in the separate collection of identified

products, you will help with the correct disposal of these items and contribute to the

ongoing protection of our environment and human health.

Safety Precautions

•Read this manual, in its entirety, prior to installing the device.

•Observe all warnings and cautions mentioned in this manual.

•Keep the device dry, ventilated, and clean.

•During severe weather conditions, unplug all electrical connections to the device

to protect against lightning surges.

•Keep the ventilation openings clean to ensure proper airflow and prolong the life

of the device.

•Do not open the device. There are no user-serviceable parts in the device.
