Teltonika FMC640 Installationsanleitung

FMC640

Professional tracker with CAN data

reading feature

Quick Manual v1.4

Quick Manual v2.2 // FMC640 2

CONTENT

Know your device................................................................................................................................................................................................3

Pinout ...................................................................................................................................................................................................................4

Wiring scheme.....................................................................................................................................................................................................5

Set up your device ..............................................................................................................................................................................................6

PC Connection (Windows)..................................................................................................................................................................................7

How to install USB drivers (Windows) ..............................................................................................................................................................7

Conguration (Windows) ...................................................................................................................................................................................8

Quick SMS conguration................................................................................................................................................................................. 10

Mounting recommendations.......................................................................................................................................................................... 12

LED indications................................................................................................................................................................................................. 13

Basic characteristics ........................................................................................................................................................................................ 13

Electrical characteristics.................................................................................................................................................................................. 16

Safety information ........................................................................................................................................................................................... 18

Certication and Approvals ............................................................................................................................................................................ 19

Warranty ........................................................................................................................................................................................................... 21

Warranty disclaimer ....................................................................................................................................................................................... 21

Quick Manual v2.2 // FMC640 3

KNOW YOUR DEVICE

GNSSS ANTENNA

SOCKET

STATUS

LED

J1708 CELLULAR ANTENNA

SOCKET

NAVIGATE

LED

DUAL-SIM

SLOT

BATTERY

SOCKET

MICRO-USBRS232

RS232/RS485

MICRO SD

SLOT

2x10

SOCKET

TOP VIEW TOP VIEW (WITHOUT COVER)BOTTOM VIEW (WITHOUT COVER)

Quick Manual v2.2 // FMC640 4

PIN NUMBER PIN NAME DESCRIPTION

1 GND (-) Ground

2CAN 1L SAE J1939 CAN interface Low

channel 1

31WIRE

POWER

Power supply pin for Dallas

1-Wire® devices

4 DIN4 Digital input, channel 1

5 DIN2 Digital input, channel 2

6CAN 2L SAE J1939 CAN interface Low

channel 2

7AIN2 Analog input, channel 2. Input

range: 0-30V/0-10V DC

8 DOUT3 Digital output. Open collector

output

9 DOUT2 Digital output. Open collector

output

10 AIN3 Analog input, channel 3. Input

range: 0-30V/0-10V DC

11 VCC (+) Power supply (+10-30 V DC)

12 CAN 1H SAE J1939 CAN interface High

channel 1

13 1WIRE DATA Data channel for Dallas 1-Wire®

devices

14 DIN3 Digital input, channel 3

15 IGN (DIN1)

Digital input, channel 1.

DEDICATED FOR IGNITION

INPUT

PINOUT

DIN3

1WIRE DATA

+10...30 V DC

DOUT4/AIN4

CAN2H

CAN1H

DIN1

AIN1

DOUT1

K-LINEAIN3

1WIRE POWER

DIN4

GND

CAN2L

DOUT3

DIN2

CAN1L

AIN2

DOUT2

FMC640 2x10 socket pinout

16 CAN 2H SAE J1939 CAN interface High

channel 2

17 AIN1 Analog input, channel 1. Input

range: 0-30V/0-10V DC

18 DOUT4/

AIN4

Digital output. Open collector

output OR Analog input, channel

4. Input range: 0-30V/0-10V DC

19 DOUT1 Digital output. Open collector

output

20 K-Line

K-LINE interface for online

Tachograph Vehicle Data

transfer

Quick Manual v2.2 // FMC640 5

WIRING SCHEME

ALARM BUT TON

MULTIPLE

TEMPERATURE

SENSORS

BUZZER LED LIGHTS

RELAY

FUEL GAUGE

IBUTTON

POWER SUPPLY

8 - 32V DC

ANALOG

LLS SENSOR

8586

87a

IGNITION

DETECTION

STARTER

TACHOGRAPH

J1939 RFID

MULTIPLE

LLS SENSORS

BUFFERED

TRANSPARENT

MODE

RS485

RJ9 FUEL DATA

J1708 PROTOCOL

SUPPORT

CONTINENTAL

TPMS

DIN3

1WIRE DATA

+10...30 V DC

DO UT4/AIN4

CAN2H

CAN1H

DIN1

AIN1

DOUT1

K-LINEAIN3

1WIRE POWER

DIN4

GND

CAN2L

DOUT3

DIN2

CAN1L

AIN2

DOUT2

CONFIGURATION

VIA PC

RS232

CAN ADAPTERS

USB

GARMIN

BUFFERED

TRANSPARENT

MODE

RFID

LLS SENSOR

CARRIER

FREEZER

IRIDIUM EDGE

Quick Manual v2.2 // FMC640 6

SIM card insertion/

removal must be

performed when device

is powered o – external

voltage and internal

battery disconnected. Otherwise SIM

card might be damaged or device will

not detect it.

FMX6 devices use Standard

size SIM cards for SIM1

and SIM2. Currently most

of the SIM cards provided

by operators can be disassembled into 3

parts - Standard/Micro/Nano. Depending

on the SIM card construction - during

device usage in harsh conditions, SIM

assembly might come apart which

causes instability when connecting to

operator.

To avoid such risk:

1. If possible - ask operator for

Standard SIM card with solid

construction (not pre-cut to 3 parts)

2. Do not use SIM cards that were

previously disassembled (SIM was

taken apart previously)

3. If you plan to use only one SIM card

- insert it into SIM1 slot (lower slot)

- this ensures greater pressure on

SIM contacts as the contact bed is

pushed by PCB.

When 2 SIM cards are used

simultaneously risk is mitigated as

well - when SIM1 is inserted, a greater

pressure is applied for SIM2, so SIM

parts are harder to come lose.

SET UP YOUR DEVICE

HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY

1UNSCREW SCREWS

Unscrew 4 screws counterclockwise that are located on the

bottom of the device.

4BATTERY CONNECTION

Connect battery as shown to device.

2COVER REMOVAL

Remove the cover

5ATTACHING COVER BACK

After conguration, see “PC Connection (Windows)1”, attach

device cover back.

1 Page 7 "PC Connection (Windows)

3SIM CARD INSERT

Insert SIM card as shown with PIN request disabled or read

Security info1how to enter it later in Teltonika Congurator2.

Make sure that SIM card cut-o corner is pointing forward to

slot. SIM slot 1 is closer to PCB, SIM slot 2 is the upper one.

1 wiki.teltonika.lt/view/FMB641_Security_info

2 wiki.teltonika.lt/view/Teltonika_Congurator

6DEVICE IS READY

Screw in all screws. Device is ready to be mounted.

3 in 1

SIM

Quick Manual v2.2 // FMC640 7

PC CONNECTION (WINDOWS)

HOW TO INSTALL USB DRIVERS (WINDOWS)

1. Please download COM port drivers from here1.

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button.

5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the

setup.

1 teltonika-gps.com/downloads/en/FMC640/TeltonikaCOMDriver.zip

1. Power-up FMC640 with DC voltage (8 – 32 V) power supply using supplied power cable. LED’s should start blinking, see “LED

indications1”.

2. Connect device to computer using Micro-USB cable or Bluetooth connection:

• Using Mini-USB cable

• You will need to install USB drivers, see “How to install USB drivers (Windows)2”

3. You are now ready to use the device on your computer.

1 wiki.teltonika-gps.com/view/FMC640_LED_status

2 Page 7, "How to install USB drivers"

Quick Manual v2.2 // FMC640 8

MS .NET REQUIREMENTS

Operating system MS .NET Framework version Version Links

Windows Vista

Windows 7

Windows 8.1

Windows 10

MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1

1 dotnet.microsoft.com/en-us/download/dotnet-framework/net462

At rst FMC640 device will have default factory settings set. These settings should be changed according to the users needs. Main

conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator

operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.

1 wiki.teltonika-gps.com/view/Teltonika_Congurator

2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions

CONFIGURATION (WINDOWS)

Quick Manual v2.2 // FMC640 9

Downloaded Congurator will be in compressed archive.

Extract it and launch Congurator.exe. After launch software

language can be changed by clicking 🌐in the right bottom

corner.

Conguration process begins by pressing on connected device.

FMC640

Various Status window1 tabs display information about GNSS2,

GSM3, I/O4, Maintenance5 and etc. FMC640 has one user

editable prole, which can be loaded and saved to the device.

After any modication of conguration the changes need to

be saved to device using Save to device button. Main buttons

oer following functionality:

 Load from device – loads conguration from device.

 Save to device – saves conguration to device.

 Load from le – loads conguration from le.

 Save to le – saves conguration to le.

 Update rmware – updates rmware on device.

 Read records – reads records from the device.

 Reboot device – restarts device.

 Reset conguration – sets device conguration to

default.

Most important congurator section is GPRS – where all

your server and GPRS settings6 can be congured and Data

Acquisition7 – where data acquiring parameters can be

congured. More details about FMC640 conguration using

Congurator can be found in our Wiki8.

After connection to Congurator Status window will be

displayed.

FMC640

1 wiki.teltonika-gps.com/view/FMC640_Status_info

2 wiki.teltonika-gps.com/view/FMC640_Status_info#GNSS_Info

3 wiki.teltonika-gps.com/view/FMC6401_Status_info#GSM_Info

4 wiki.teltonika-gps.com/view/FMC640_Status_info#I.2FO_Info

5 wiki.teltonika-gps.com/view/FMC640_Status_info#Maintenance

6 wiki.teltonika-gps.com/index.php?title=FMC640_GPRS_settings

7 wiki.teltonika-gps.com/index.php?title=FMC640_Data_acquisition_

settings

8 wiki.teltonika-gps.com/index.php?title=FMC640_Conguration

Quick Manual v2.2 // FMC640 10

QUICK SMS CONFIGURATION

Default conguration has optimal parameters present to ensure best performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

Note: Before SMS text, two space symbols should be inserted.

GPRS SETTINGS:

 2001 – APN

 2002 – APN username (if there are no APN username,

empty eld should be left)

 2003 – APN password (if there are no APN password,

empty eld should be left)

SERVER SETTINGS:

 2004 – Domain

 2005 – Port

 2006 – Data sending protocol (0 – TCP, 1 – UDP)

« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»

1 2 3 4 5 6

Andere Handbücher für FMC640

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Teltonika GPS Handbücher

Teltonika

Teltonika FMB202 Installationsanleitung

Teltonika

Teltonika Telematics FMC880 Bedienungsanleitung

Teltonika

Teltonika GH120 Series Bedienungsanleitung

Teltonika

Teltonika FM6300 Bedienungsanleitung

Teltonika

Teltonika FMB920 Installationsanleitung

Teltonika

Teltonika Telematics FMM150 Bedienungsanleitung

Teltonika

Teltonika Telematics FMB150 Bedienungsanleitung

Teltonika

Teltonika FMC230 Installationsanleitung

Teltonika

Teltonika FMB225 Bedienungsanleitung

Teltonika

Teltonika FMB965 Bedienungsanleitung

Teltonika

Teltonika FMT100 Bedienungsanleitung

Teltonika

Teltonika FM4200 Bedienungsanleitung

Teltonika

Teltonika FMM130 Bedienungsanleitung

Teltonika

Teltonika FMT100 Bedienungsanleitung

Teltonika

Teltonika FM5300 Bedienungsanleitung

Teltonika

Teltonika Telematics FMM650 Installationsanleitung

Teltonika

Teltonika FMC130 Installationsanleitung

Teltonika

Teltonika FMB225 Installationsanleitung

Teltonika

Teltonika FM1110 Bedienungsanleitung

Teltonika

Teltonika FMB650 Bedienungsanleitung

Teltonika

Teltonika Telematics FMC150 Installationsanleitung

Teltonika

Teltonika MSP500+ETC Bedienungsanleitung

Teltonika

Teltonika WORKER BADGE PLUS Bedienungsanleitung

Teltonika

Teltonika GH1201 Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
