Terratrip GeoTrip Bedienungsanleitung

User Manual

EN FR DE

for Terratrip GeoTrip IT ES PT

Version V1.1, 06/02/13

User Manuals available at www.terratrip.com/manuals.htm

Page 1 of 20

Index. Page :

Features ..........................................................................................................................3

1.0 Probe Selection: .......................................................................................................3

1.1 GPS receiver: .......................................................................................................3

1.2 Wheel Probe, Part Number T005:........................................................................3

1.3 Wheel Probe, Part Number T005A:.....................................................................3

1.4 Speedo Cable Probe, Probe No. T006: ................................................................3

1.5 Gear Box Probe, Probe No. T007: .......................................................................4

1.6 Electronic speedometer probe (DSI), Part No. T014:..........................................4

2.0 Optional Extras: .......................................................................................................4

2.1 Remote display. Part No. T016G:........................................................................4

2.2 Remote Zeroing unit. Part No. T008 (foot RZU), T011G (Hand operated):.......4

2.3 Bracket. Part No. T009G: ....................................................................................4

3.0 Fitting GeoTrip® to vehicle.....................................................................................4

3.1 Mounting GeoTrip®: ...........................................................................................4

3.2 Power lead:...........................................................................................................4

4.0 Probe & RZU Installation: .......................................................................................5

4.1 Wheel/ Drive Shaft Probe T005 & T005A: .........................................................5

4.2 Cable Drive Probe – T006: ..................................................................................5

4.3 Japanese Gearbox Probe – T007:.........................................................................5

4.4 Electronic Probe (DSI) - T014:............................................................................6

4.5 Remote zeroing unit – T008 & T011G:...............................................................6

5.0 Menu Layout on GeoTrip®: ....................................................................................6

6.0 Calibration: ..............................................................................................................6

6.1 Select Cal: ............................................................................................................7

6.2 Auto Cal:..............................................................................................................7

6.3 Manual Cal:..........................................................................................................7

6.4 GPS Cal:...............................................................................................................8

7.0 Display Menu:..........................................................................................................8

7.1 Screen Brightness: ...............................................................................................8

7.2 Remote Brightness:..............................................................................................9

7.3 Contrast:...............................................................................................................9

8.0 Settings menu:..........................................................................................................9

8.1 Set Units:..............................................................................................................9

8.2 Digit Font:............................................................................................................9

8.3 FRZ clears INT: ...................................................................................................9

8.4 Set AVS Times: .................................................................................................10

9.0 GPS Options: .........................................................................................................10

9.1 Start Threshold:..................................................................................................10

9.2 Standby Probe: ...................................................................................................11

Page 2 of 20

10.0 Time / Date: .........................................................................................................11

10.1 Time: ................................................................................................................11

10.2 Date:.................................................................................................................11

10.3 Time Zone:.......................................................................................................12

10.4 Set from GPS (UTC):.......................................................................................12

10.5 Time format: ....................................................................................................12

11.0 Performance: ........................................................................................................12

11.1 Maximum Speed:.............................................................................................12

11.2 0-60 times: .......................................................................................................13

11.3 0-100 times: .....................................................................................................13

11.4 0-(custom) times: .............................................................................................13

12.0 Key Functions: .....................................................................................................14

12.1 FRZ: .................................................................................................................14

12.2 DIS SET:..........................................................................................................14

12.3 SCREEN: .........................................................................................................14

12.4 DIS FLY: .........................................................................................................15

12.5 +/-:....................................................................................................................15

12.6 PWR.................................................................................................................15

12.7 /: .......................................................................................................................15

12.8 PROBE:............................................................................................................15

12.9 \/: ......................................................................................................................16

13.0 MENU / EXIT: ................................................................................................16

13.1 CLR:.................................................................................................................16

13.2 CLR / ENTER:.................................................................................................16

13.3 AVS SELECT:.................................................................................................16

13.4 AVS SET: ........................................................................................................17

14.1 Language:.........................................................................................................17

14.2 Factory Reset: ..................................................................................................18

14.3 Road Survey / high precision mode:................................................................18

15.0 Electrical Connections & probe mounting:..........................................................18

15.1 Fig 1. Probe connections T005 & T005A:.......................................................18

15.2 Fig 2. Mounting T005 & T005A: ....................................................................19

15.3 Fig 3. T006 & T007. Gearbox / Speedo cable connections:............................19

15.4 Fig 4. T014 Electronic Probe (DSI) Connections:...........................................20

15.5 Fig 5. T011G Hand held RZU & T008 Foot operated RZU:...........................20

Terratrip GeoTrip® User Manual

Page 3 of 20

Features

Feature 303 GeoTrip

GPS GPS

Probe inputs 2

5 Digit Calibration

Total Distance

Interval Distance

Speed

Average Speed

Max Speed

Time of Day

Stop Watch

Performance Timers x 3. With data logging.

Miles or km

Dis Fly speed adjust

Auto easy Calibration

Calibrate probe by GPS

1 or 2 CAL 2

Languages, EN, FR, DE, IT, ES, PT

Remote display

AVS. Regularity target speed indicator on remote

display

RZU Foot / Hand F + H

1.0 Probe Selection:

1.1 GPS receiver:

The Terratrip GeoTrip® has a removable cover on the rear case, this holds the GPS.

GPS can be fitted to the GeoTrip® after purchase.

1.2 Wheel Probe, Part Number T005:

Compatible with all cars. 1.5mm Gap sensor fits to either your wheel assembly or a

prop shaft on a 4x4 vehicle.

1.3 Wheel Probe, Part Number T005A:

Compatible with all cars. 3.5mm Gap sensor fits to either your wheel assembly or a

prop shaft on a 4x4 vehicle.

1.4 Speedo Cable Probe, Probe No. T006:

Fits most mechanical speedo cables.

Page 4 of 20

1.5 Gear Box Probe, Probe No. T007:

Fits M22 Gearbox speedometer cable drive. Japanese and some American car makers

gearbox.

1.6 Electronic speedometer probe (DSI), Part No. T014:

Compatible with all cars that have an electronic speed signal (Not CANBUS).

2.0 Optional Extras:

2.1 Remote display. Part No. T016G:

Remote graphical LCD display with LED backlight. This displays Speed, Average

Speed & Distance. There are 7 LEDs that are used on regularity rallies. These indicate

to the driver how far ahead or behind of the required target speed in seconds. This

item can be connected to the tripmeter after purchase.

2.2 Remote Zeroing unit. Part No. T008 (foot RZU), T011G (Hand

operated):

Remote zeroing unit comes in two models, foot remote for zeroing the Interval

distance. Or a hand operated remote to change the displayed screen or clear both

distance readouts. When fitting, follow figure 5

2.3 Bracket. Part No. T009G:

The bracket can be bolted to the cars dashboard or use the supplied suction cups for

window fixing. The included sun visor can be removed.

3.0 Fitting GeoTrip® to vehicle.

3.1 Mounting GeoTrip®:

Secure GeoTrip® to the car using optional accessory T009G bracket, use the screw

mount brackets or suction cups to the vehicles windscreen.

3.2 Power lead:

Connect the power lead to the vehicles 12 volt power using the supplied 2 Ampere

fuse. When connecting RZU (remote zeroing unit) or probes you will need to connect

the cables to the back of the GeoTrip® using the 12 way connector, follow the wiring

diagrams at the back of this manual.

Page 5 of 20

4.0 Probe & RZU Installation:

4.1 Wheel/ Drive Shaft Probe T005 & T005A:

Also see Figure 1 & 2 for wiring and fitting diagrams.

Make a bracket to mount the probe and position the probe so that it ‘looks’ at the steel

heads of the bolts which secure the brake disc to the wheel hub of a non-driven wheel

– see drawing. In some cases it might be more convenient to look at holes in a metal

surface. The probe must be co-axial with the centre line of the bolts and the front face

of the probe must be parallel with the heads of the bolts. Cup-head [Allen] head bolts

do not give the probe a good signal and should not be used. Screw the probe on so that

it touches the head of one of the bolts and then un-screw 1 to 1 1/2 turns(T005), 1 to 3

½ (T005A).

Connections: See wiring diagram

4.2 Cable Drive Probe – T006:

Also see Figure 3 for wiring diagram.

For fitting to a mechanical speedo cable.

Position the probe in a straight section of the speedometer cable. Remove the inner

speedometer cable and cut out 42 mm section from the outer cable. Put the metal

sleeves and ring nuts over each end of the outer cable. Push the inner cable through

one outer half and then through the sensor. Put the inner cable through the other outer

cable; tighten the two socket head screws in the rotor. Fasten the ring nuts.

The sensor is designed for 3.2mm [1/8 inch] inner cables. If your cable is larger

remove the two socket head screws from the rotor and fit a M2.5 mm screw in one of

the rotors screw holes. Carefully drill out the rotor with a sharp drill with your drill

rotating at low speed.

Some cars have an inner cable which cannot easily be removed. In this case cut

through both inner and outer cable. Remove 21 mm from each end of the outer cable.

Push the metal sleeve and ring nut on to each end of the outer cable. Push the inner

cable in to each end of the sensor and tighten the rotor screws and then the ring nuts.

4.3 Japanese Gearbox Probe – T007:

See Figure 3 for wiring diagram.

Unscrew the car speedometer cable from the gearbox. Push the forked peg into the

probe from the end of the probe with ring nut, push square peg into probe from other

end so that it engages into the forked peg. Screw the Japanese probe into the gearbox

(thread must be M22) tighten by hand only. Screw the car speedometer cable into the

opposite end of the probe.

Page 6 of 20

4.4 Electronic Probe (DSI) - T014:

Connect as per the instructions that come with the DSI. Also see figure 5 for wiring

diagram for connections to the GeoTrip®. Note the connections to the GeoTrip® are

not the same as the 202PLUS/ 303PLUS.

4.5 Remote zeroing unit – T008 & T011G:

When installing, follow figure 5.

Fit terminal pins to RZU cable and follow wiring diagram for terminal connections.

5.0 Menu Layout on GeoTrip®:

*Only available with GeoTrip® GPS module fitted.

**Only available on the 303 GeoTrip®.

6.0 Calibration:

The GeoTrip® offers two calibration methods, automatic and manual calibration with

the option to calibrate from GPS.

Before calibration select either CAL1 or CAL2 from the Calibration menu, and the

correct units (km or miles) are selected from the settings menu. This is most important

if you are calibrating from GPS, as the unit needs to know the correct distance

travelled in km or miles.

CALIBRATION

SELECT CAL

AUTO CAL

MANUAL CAL

GPS CAL*

DISPLAY

SCREEN BRIGHTNESS

REMOTE BRIGHTNESS

CONTRAST

SETTINGS

SET UNITS

DIGIT FONT

FRZ CLEAR INT

SET AVS TIMES**

GPS OPTIONS* START THRESHOLD

STANDBY PROBE

TIME / DATE**

TIME

DATE

TIME ZONE

SET FROM GPS (UTC)*

TIME FORMAT

PERFORMANCE**

MAXIMUM SPEED

0-60 TIMES

0-100 TIMES

0-xxx (CUSTOM) TIMES

Page 7 of 20

6.1 Select Cal:

The display shows the current calibration by placing a solid dot next to the selected

calibration figure.

Select Cal : ●-CAL 1

○-CAL 2

*(CAL 1 is selected)

Press ENTER to switch between calibration figures, and MENU to exit.

6.2 Auto Cal:

Auto cal can be used to calibrate the unit from a set distance, e.g. a measured mile or

kilometre or a calibration distance from a road-book.

Note: If the GPS probe is selected, the unit will exit auto calibration automatically.

You do not need to calibrate the GPS!

How to use auto calibration:

1. Press MENU.

2. Select CALIBRATION then press ENTER.

3. Select Auto Cal.

4. The auto calibration screen displays ‘00000’.

5. Press ENTER and start to drive.

6. The display will show ‘Now drive to set distance’ briefly and shows an

animated arrow running across the screen. If there is no pulses being received

from the probe, or the incorrect probe is selected the figure will remain at

00000. If this is the case, you need to exit auto calibration and select a

different probe using KEY 8 (Probe).

7. Press ENTER at the end of the measured distance, and the unit will prompt

you to enter the distance driven. E.g. if you have driven 1.2km, enter 0120

using the number keys. Then press ENTER.

8. The display will now show the calibration figure that has been calculated from

the driven distance. Press ENTER to accept the calibration to the shown figure

or MENU to exit, and leave calibration as it was previously.

6.3 Manual Cal:

If you know the calibration figure (impulses per kilometre or mile) for your vehicle

then you can enter the figure manually.

The Manual Calibration screen will show the current calibration number, and

calibration value followed by 00000.Use the number keys to enter a value i.e. if the

calibration value is 1540, press 1, 5, 4, 0 then ENTER. If a mistake is made, the digits

will scroll, so entering 0, 1, 5, 4, 0 will reset all the digits shown to 01540.

To exit the menu without setting a calibration, figure press the upper CLR.

Page 8 of 20

6.4 GPS Cal:

GPS calibration lets you calibrate a wheel probe, gearbox probe, speedo cable or

electronics probe (DSI) via the GPS. It is important that the correct units for

calibration i.e. kilometres or miles are selected, as if they are not correct the

calibration will not be correct.

The GPS calibration menu will only be enabled once the GPS has a valid satellite fix,

and is receiving position data. We recommend that you turn the tripmeter on for one

or two minutes before calibration, this will enable a full satellite fix.

How to use GPS calibration:

1. Press MENU.

2. Select CALIBRATION, then press ENTER.

3. Select GPS cal then press ENTER.

4. The GPS calibration screen shows ‘00000’.

5. Press ENTER and start to drive.

6. The display will show ‘Now drive to set distance’ briefly and show an

animated arrow running across the screen. If there are no pulses being

received from the probe, or the incorrect probe is selected the figure will

remain at 00000. If this is the case, you need to exit auto calibration and

select a different probe using KEY 8 (Probe).

7. After driving approximately 1 km/mi press ENTER at the end of the

driven distance.

8. The display will now show the calibration figure that has been calculated

from the driven distance. Press ENTER to accept and set the calibration to

the shown figure or MENU to exit, and leave calibration at the previous

value.

7.0 Display Menu:

The display menu contains brightness and contrast settings for the internal screen and

the Remote Display, if fitted.

7.1 Screen Brightness:

Use the up and down keys (/\ and \/) to set the screen brightness, and ENTER to set.

MENU exits without setting the screen brightness and the previous set level will

restore.

Page 9 of 20

7.2 Remote Brightness:

Use the up and down keys (/\ and \/) to set the remote brightness, and ENTER to

accept the new level. MENU exits without changing the screen brightness and the

previous set level will restore.

The Remote Brightness also sets the intensity of the AVS indicator LED’s when

connected to a 303 GeoTrip®.

7.3 Contrast:

Use the up and down keys (/\ and \/) to set the screen contrast. Higher the contrast

value, the darker the screen and text are and it can make the screen easier to view

from above. Lower the contrast value, the lighter the screen and it can make the

screen easier to read from below.

Adjust the contrast to make the display as sharp and clear as possible depending on

the angle that the unit is mounted.

ENTER will set the contrast, MENU exits without changing the contrast.

8.0 Settings menu:

The settings menu contains options to set the display units, characters and various

options for timing.

8.1 Set Units:

Changes the current units (km or mi) set in the trip meter. Current selection has a solid

dot next to the units. Press ENTER to change the selection, MENU exits the settings

menu. This setting does not just change the displayed text, but makes the GPS probe

calculate distance and speed as required in kilometres, or miles.

8.2 Digit Font:

Changes the display font used on the main screens. Current selection has a solid dot

next to it. Normal is a rounded bold font (default setting) and digital shows a 7

segment type display. Press ENTER to change the selection, MENU exits the settings

menu.

8.3 FRZ clears INT:

This option selects what happens when FRZ is pressed. The default setting when FRZ

is pressed, the interval distance counter clears, and starts counting in the background

from zero whilst the displays are frozen. When FRZ is pressed again, the distance

counters resume, showing distance in real time (Split Freeze).

Page 10 of 20

If the option is set to ‘Off’ the interval distance will not zero when FRZ is pressed.

Selection is shown by a solid dot next to the option (on/off). Press ENTER to change

the selection, MENU exits the settings menu.

8.4 Set AVS Times:

Note: This option is only for 303 models with the remote display fitted. This option

allows you to change the average speed indicator times on the optional remote

display (Part No. T016G), so that it can be adjusted to your preferences.

When AVS is turned on, the LEDs on the remote display show target timing in

seconds. The LEDs displayed relate to your target average speed error in seconds as

set below.

Example: If target speed/time is within +/-1s of the calculated time then just the Green

LED will be lit. If then the driver slows down, and the target time goes greater than 3

seconds, the first yellow LED to the left of the Green LED will also light. If the driver

is still driving slower than the calculated target, and the target time goes greater than 6

seconds, the 2nd yellow LED’s to the left of the green LED will be lit. This continues

until the target time goes over 15seconds where all the LED’s to the left of the Green

LED will be lit.

If the driver is driving faster than the target speed then the exact same will happen

except that the LED’s will illuminate to the right of the Green LED to indicate that the

speed is greater than calculated.

The display shows:

Green : +/-01s

Yellow : +/-03s

Yellow : +/-06s

Red : +/-15s

Press ENTER on the relevant line to set the time in seconds after which the relevant

LED will light up. Use the number keys to enter the time, and press ENTER once

more to set, or the upper CLR to cancel editing.

9.0 GPS Options:

The GPS menu will not be accessible unless the GPS module is fitted. Please refer to

‘Fitting GPS module’ if you are fitting a module to an existing GeoTrip®.

9.1 Start Threshold:

Start threshold is the speed at which the GPS probe will start recording distance.

Andere Handbücher für GeoTrip

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Terratrip Autozubehör Handbücher

Terratrip

Terratrip GeoTrip Bedienungsanleitung

Beliebte Autozubehör Handbücher anderer Marken

James Baroud

James Baroud Odyssey Bedienungsanleitung

Motorola

Motorola i50sx Bedienungsanleitung

Yakima

Yakima 9MM STANDARD BIKE MOUNT Bedienungsanleitung

Feniex

Feniex T3 Bedienungsanleitung

Renault

Renault 77 11 423 180 Bedienungsanleitung

Kia

Kia E8300-4D000 Bedienungsanleitung

Brink

Brink 756843 Bedienungsanleitung

Whispbar

Whispbar K085W Bedienungsanleitung

v.link

v.link CI-VL2-PC-HSD Bedienungsanleitung

Viking

Viking Stack-Rack Kurzanleitung zur Einrichtung

Aries

Aries 203015 Bedienungsanleitung

Choetech

Choetech AT0005 Bedienungsanleitung

ZZ2

ZZ2 ZZAIR-PRO Bedienungsanleitung

Holman

Holman 4A80L Bedienungsanleitung

Thule

Thule 2075 Bedienungsanleitung

Motorola

Motorola T325 Bedienungsanleitung

TAUBENREUTHER

TAUBENREUTHER 16-3950 Installationsanleitung

DV8

DV8 FBJL-02 Bedienungsanleitung
