Thrustmaster Ferrari GT Bedienungsanleitung

5075091

Thrustmaster is a division

of the Guillemot Corporation group

USER MANUAL

MANUEL DE L’UTILISATEUR

BENUTZERHANDBUCH

HANDLEIDING

MANUALE D’USO

MANUAL DEL USUARIO

MANUAL DO UTILIZADOR

Ferrari GT

Playstation

2 in 1 Force Feedback Racing Wheel

QI_FGT2in1FFBRW.indd 7/07/05, 18:041

English - CAUTION: On PCs equipped with certain motherboards, your wheel may

remain powered (LED on) and may stay turned to one side (full left or full

right) while the PC is off. In this case, you must disconnect the power adapter

connector and/or the USB connector in order to prevent overheat which might

damage the wheel’s motor.

Français - ATTENTION : sur des PC équipés de certaines cartes mères, il se peut que

votre volant reste alimenté (voyant allumé) et bloqué en position braquée à

gauche ou à droite une fois l’ordinateur éteint. Dans ce cas, il est impératif de

débrancher l’adaptateur secteur et/ou la prise USB afin d’éviter une

surchauffe du moteur du volant qui pourrait l’endommager.

Deutsch - ACHTUNG: Bei PCs mit bestimmten Mainboards kann das Wheel nach dem

Abschalten des PCs eingeschaltet bleiben (LED leuchtet) und das Lenkrad

dreht sich automatisch an den Rechts- oder Linksanschlag. In diesem Fall

müssen Sie entweder den Stecker des Netzadapters abziehen oder die USB-

Verbindung zum PC lösen, um Schäden am Motor des Lenkrads zu

vermeiden.

Nederlands - WAARSCHUWING: op PC's met moederborden van bepaalde merken kan,

terwijl de PC uit staat, de stroom op uw stuur aan blijven staan (de LED

brandt) en kan het stuur volledig naar links of rechts zijn gedraaid. In dat

geval moet u de kabel van de voedingsadapter en/of de USB-kabel

lostrekken om te voorkomen dat het stuur oververhit raakt en de motor van

het stuur beschadigd wordt.

Italiano - ATTENZIONE: Su PC equipaggiati con alcune schede madri, il vostro volante

potrebbe rimanere alimentato (LED acceso) e restare bloccato

completamente a sinistra o a destra quando il PC è spento. In questo caso, è

necessario scollegare l’adattatore di rete e/o il connettore USB per evitare il

surriscaldamento che potrebbe danneggiare il motorino del volante.

Español - PRECAUCIÓN: en PC equipados con ciertas placas base, el volante puede

quedarse funcionando (LED encendido) y puede bloquearse todo a la

izquierda o todo a la derecha mientras el PC está apagado. En tal caso,

debes desconectar el conector del adaptador de corriente y/o el conector

USB para evitar un sobrecalentamiento que podría dañar el motor del

volante.

Português - ATENÇÃO: Nos PC equipados com certas placas-mães, o volante poderá

manter-se ligado (LED aceso) e bloqueado completamente virado para a

esquerda ou direita enquanto o computador estiver desligado. Se isso

acontecer, deverá desligar o conector do transformador e/ou o conector USB

a fim de impedir que ocorra o sobreaquecimento, o qual poderá danificar o

motor do volante.

1/8

User Manual

TECHNICAL FEATURES

1 2 digital gearshift levers

2Mode led

3 Action buttons

4D-pad

5Select and Start buttons

6Force button

2/8

7 Analog pedal set

8 Pedal cable

9 Pedal connector

10 Table clamp

11 Clamp screw

12 GAMEPORT connector (for PlayStation2)

13 USB connector (for PC and PlayStation2)

14 Power adapter

15 Adapter connector

INSTALLING THE WHEEL

Fixing the wheel in place

1. Place the wheel on a table or other flat surface.

2. Place the clamp screw (11) in the table clamp (10) and then screw the clamping unit into the hole on

the underside of the wheel until firmly fixed in place. Do not turn the screw too tightly, as you risk

damaging the clamping unit and/or the table.

Connecting the pedal set

1. Connect the pedal connector (8) to the pedal receptor (9).

2. Connect the power adapter (14) to the adapter connector (15) and plug the adapter into an electrical

outlet.

3/8

INSTALLATION FOR PC

System requirements: PC (Windows 98 SE, Me, 2000, XP) equipped with USB port.

The CD-ROM included with this product allows you to install the Force Feedback drivers.

1. Insert the installation CD-ROM into your CD-ROM drive. Follow the on-screen instructions to install the

Force Feedback drivers. Once the installation is complete, click Finish and restart your computer.

2. Once your computer has restarted, connect the USB connector (10) to one of your computer’s USB

ports. Windows 98/Me/2000/XP will automatically detect the new device. (If you are connecting a USB

device for the first time, Windows may ask you to insert the Windows CD-ROM during the installation

procedure in order to install the required system files.)

3. Driver installation:

Windows 98: the Add New Hardware Wizard will search for the appropriate drivers. Click Next.

Follow the on-screen instructions to complete the installation.

Windows Me/2000/XP: the drivers are installed automatically.

4. Select Start/All Programs/Thrustmaster/Force Feedback driver/Control Panel. The Game

Controllers dialog box displays the gamepad’s name with OK status.

5. In the Control Panel, click Properties to configure your gamepad:

•Test device: to test and visualize the buttons, D-pad and 3 axes (wheel, brake and gas pedals).

•Test forces: to test 8 Force effects and configure the ForceFeedback settings (3 possible settings:

from 0 to 150 % : Forces Main, Static and Dynamic).

ADVANCED FUNCTIONS ON PC

Calibrating the wheel

The wheel is calibrated automatically once the USB is connected (this operation will move the wheel). The

pedals self calibrate after a few presses.

Selecting “Separate” (3-axis) OR “Combined” (2-axis) acceleration/braking mode

By default, the wheel’s acceleration/braking controls operate in “separate” 3-axis mode, i.e. with brake and

gas pedals operating on independent axes.

3-axis support considerably improves driving precision in races.

If the 3-axis mode is not supported by your game, the wheel’s gas pedals will not work properly. Please

exit the game and select the “combined” 2-axis mode.

To activate this mode, press simultaneously the acceleration/braking controls (7) and the Force button (6).

To revert to the “separate” 3-axis mode, repeat the same procedure.

Note:

- When you select the "combined" (2-axis) mode, the led flashes red for a few seconds

(Wheel = "X" axis, Accelerator and Brake = "RZ" axis).

- When you select the "separate" (3-axis) mode, the led flashes green for a few seconds

(Wheel = X" axis, Accelerator = "RZ" axis and Brake = "Y" axis).

4/8

Enabling/disabling the recentering function

Wheel recentering is enabled by default.

To disable or re-enable the recentering, press the Force button (6).

Most recent games now propose their own recentering mode.

You are strongly advised to disable wheel recentering (in most cases), to allow the game to handle it. The

ForceFeedback will then be of greater quality.

When enabled, the recentering mode is especially useful in games that do not feature ForceFeedback.

Note:

- When Recentering is enabled, the led is Red (default mode on PC).

- When Recentering is disabled, the led is Green (mode recommended for PC).

INSTALLATION FOR PLAYSTATION 2

CONNECTING THE WHEEL

1. Switch off your console before connecting the wheel.

2. Connect the console connector (12) to port 1 of your console and connect

the USB connector (13) to the upper USB port (connect in this order).

3. Switch your console back on. The wheel calibrates itself autonomously

(this operation will move the wheel.) and the led (2) is red to indicate that

the ForceFeedback mode is activated.

You are now ready to play!

ADVANCED FUNCTIONS ON PLAYSTATION 2

Configuring the wheel

By default, the wheel’s acceleration/braking controls operate in “separate” 3-axis mode, i.e. with brake and

gas pedals operating on independent axes.

3-axis support considerably improves driving precision in races.

However you can still select the “combined” 2-axis mode.

To activate this mode, press simultaneously the acceleration/braking controls (7) and the Force button (6).

To revert to the “separate” 3-axis mode, repeat the same procedure.

Note:

- When you select the "combined" (2-axis) mode, the led flashes green for a few seconds

(Wheel = "Left Horizontal Joystick" axis, Accelerator et Brake = "Right Vertical Joystick" axis).

- When you select the "separate" (3-axis) mode, the led flashes red for a few seconds (Wheel

= "Left Horizontal Joystick" axis, Accelerator = "Cross" and Brake "Square").

To change the configuration of the other buttons, go to the "gamepad control options" of your game.

5/8

Setting the ForceFeedback

On PlayStation 2, your wheel has 3 Force Feedback modes = Power, Medium or Off.

Just press the Force button (6) to switch from one mode to the other.

Note:

- When you select the Power ForceFeedback mode, the led is Red (default mode).

- When you select the Medium ForceFeedback mode,the led is Orange.

- When you select the ForceFeedback Off mode, the led is Green.

“Sequential gearbox inversion” function

In most games, gearshift functions (1) are assigned to the L2, R2 buttons by default.

The “Sequential gearbox inversion” function allows you to assign gear shifting directly to the 2 digital

gearshift levers (1) in 100% of games.

To switch from “Normal sequential gearbox” mode to “Inverted sequential gearbox” mode, press the L1 +

R1 and Force buttons (6) simultaneously.

Note: follow the same steps to return to "normal" mode.

Note:

- When you select the Inverted Sequential Gearbox Mode, the led flashes red for a few

seconds.

- When you select the Normal Sequential Gearbox Mode, the led flashes green for a few

seconds.

Precision Drive mode

Precision Drive mode has been specially developed with a view to enhancing performance.

Depending on the game, it may help you to beat your best times (and those of your opponents) or make it

easier to successfully complete the different driving events.

This new exclusive mode calculates and redistributes your wheel’s various analogy points without

generating any dead zones (as may be the case with other wheels which allow you to adjust their

sensitivity).

Normal Sequential Gearbox Inverted Sequential Gearbox

6/8

How appropriate and effective this mode will be depends on the game you are playing and the course you

are racing on. In this mode, the wheel is more sensitive and will allow you to powerslide more easily and

thus avoid an excessive loss of speed, in courses with hairpin turns for example.

In games where the wheel’s reactions are very sensitive (such as F1 racing, for example), you will

therefore probably want to avoid using this mode.

We recommend that you use this mode with an interior view for maximum effectiveness.

To go into Precision Drive mode, simultaneously press the D-pad (4) and the Force button (6). Proceed

in the same way to return to normal driving mode.

Note:

- When the Precision Drive mode is enabled, the led flashes continuously.

- When the Precision Drive mode is disabled, the led does not flash.

TROUBLESHOOTING

- My wheel doesn’t work correctly or appears to be incorrectly calibrated. Switch off your PC or your

console, then disconnect your wheel, reconnect all the cables (with power adapter and pedals), switch

back on and restart the game.

- My wheel moves by itself during the game. This is normal and is the recentering function featuring in

some games. To stop these movements, just place your hands on the wheel or reduce the

ForceFeedback intensity.

- My wheel stays turned to one side (left or right) after auto-calibration. This is normal in some

games. The wheel will recenter itself once you have identified it as a wheel in the game’s setup options.

- On PC, my wheel is detected by my computer but doesn’t work in the game. Access your game’s

options to configure your wheel. Please refer to your game’s manual for further information.

- On PC, my pedal set does not work correctly. Display your game's option management interface to

reconfigure the wheel. If the problem persists, exit the game and switch the pedal set to the "combined"

(2-axis) mode. Then return to the game to reconfigure the wheel with the new axes.

SAFETY RECOMMENDATIONS AND INFORMATION

- When connecting the wheel and during auto-calibration: to prevent any incorrect calibration,

never turn the wheel, press the pedals or buttons.

- When not in use for extended periods and to avoid any unwanted power consumption or

deterioration, disconnect the mains adaptor of the wheel. Reconnect it before going back to the

game.

- Your wheel features ForceFeedback: NEVER leave the wheel within the reach of young

children, especially during the auto-calibration phases.

7/8

TECHNICAL SUPPORT

If you encounter a problem with your product, please go to http://ts.thrustmaster.com and click Technical Support. From

there you will be able to access various utilities (Frequently Asked Questions (FAQ), the latest versions of drivers and

software) that may help to resolve your problem. If the problem persists, you can contact the Thrustmaster products

technical support service (“Technical Support”):

By email:

In order to take advantage of technical support by email, you must first register online. The information you provide will help

the agents to resolve your problem more quickly. Click Registration on the left-hand side of the Technical Support page and

follow the on-screen instructions. If you have already registered, fill in the Username and Password fields and then click

By telephone:

WARRANTY INFORMATION

Worldwide, Guillemot Corporation S.A. (“Guillemot”) warrants to the consumer that this Thrustmaster product will be free from material defects and

manufacturing flaws for a period of two (2) years from the original date of purchase. Should the product appear to be defective during the warranty

period, immediately contact Technical Support, who will indicate the procedure to follow. If the defect is confirmed, the product must be returned to its

place of purchase (or any other location indicated by Technical Support).

Within the context of this warranty, the consumer’s defective product will, at Technical Support’s option, be either repaired or replaced. Where

authorized by applicable law, the full liability of Guillemot and its subsidiaries (including for indirect damages) is limited to the repair or replacement of

the Thrustmaster product. The consumer’s legal rights with respect to legislation applicable to the sale of consumer goods are not affected by this

warranty.

This warranty shall not apply: (1) if the product has been modified, opened, altered, or has suffered damage as a result of inappropriate or abusive

use, negligence, an accident, normal wear, or any other cause not related to a material defect or manufacturing flaw; (2) in the event of failure to

comply with the instructions provided by Technical Support; (3) to software not published by Guillemot, said software being subject to a specific

warranty provided by its publisher.

Additional warranty provisions

In the United States of America and in Canada, this warranty is limited to the product’s internal mechanism and external housing. Any applicable

implied warranties, including warranties of merchantability and fitness for a particular purpose, are hereby limited to two (2) years from the date of

purchase and are subject to the conditions set forth in this limited warranty. In no event shall Guillemot Corporation S.A. or its affiliates be liable for

consequential or incidental damage resulting from the breach of any express or implied warranties. Some States/Provinces do not allow limitation on

how long an implied warranty lasts or exclusion or limitation of incidental/consequential damages, so the above limitation may not apply to you. This

warranty gives you specific legal rights, and you may also have other legal rights which vary from State to State or Province to Province.

United Kingdom 020 7216 0047 price of a national phone call, Monday to Friday, from 12PM to 10PM

United States /

Canada 514-279-9911 price of a long distance phone call, Monday to Friday,

from 7AM to 5PM (Eastern time)

Australia 1902 262 514 $1.98/min, Monday to Friday from 9AM to 6PM

Denmark 82 33 28 58 price of a national phone call, Monday to Friday from 1PM to 10PM

Finland 09 81 71 01 54 price of a national phone call, Monday to Friday from 2PM to 11PM

Norway 23 50 01 16 price of a national phone call, Monday to Friday from 1PM to 10PM

Sweden 08-51992032 price of a national phone call, Monday to Friday from 1PM to 11PM

Andere Handbücher für Ferrari GT

Inhaltsverzeichnis

Sprachen:

Andere Thrustmaster Videospiel-Controller Handbücher

Thrustmaster

Thrustmaster TOP GUN AfterBurner Force Feedback Bedienungsanleitung

Thrustmaster

Thrustmaster T-WIRELESS 3-IN-1 RUMBLE FORCE Bedienungsanleitung

Thrustmaster

Thrustmaster TH8 RS Bedienungsanleitung

Thrustmaster

Thrustmaster T150 Bedienungsanleitung

Thrustmaster

Thrustmaster TS-XW RACER Sparco P310 Competition Mod Bedienungsanleitung

Thrustmaster

Thrustmaster Afterburner Bedienungsanleitung

Thrustmaster

Thrustmaster T.Flight Hotas One Bedienungsanleitung

Thrustmaster

Thrustmaster Enzo Ferrari wireless Bedienungsanleitung

Thrustmaster

Thrustmaster RUN'N'DRIVE WIRELESS 3-IN-1 Bedienungsanleitung

Thrustmaster

Thrustmaster T500RS Bedienungsanleitung

Thrustmaster

Thrustmaster T300 Bedienungsanleitung

Thrustmaster

Thrustmaster SIMTASK FARMSTICK Bedienungsanleitung

Thrustmaster

Thrustmaster TH8A Bedienungsanleitung

Thrustmaster

Thrustmaster T-Wireless Black Bedienungsanleitung

Thrustmaster

Thrustmaster Ferrari F1 Wheel Add-on Bedienungsanleitung

Thrustmaster

Thrustmaster universal challenge Gebrauchsanweisung

Thrustmaster

Thrustmaster T248 Bedienungsanleitung

Thrustmaster

Thrustmaster Ferrari GT Experience Bedienungsanleitung

Thrustmaster

Thrustmaster TCA Quadrant Add-On Airbus Edition Bedienungsanleitung

Thrustmaster

Thrustmaster T500RS Bedienungsanleitung

Thrustmaster

Thrustmaster Thrustmaster Force Feedback Racing Wheel Bedienungsanleitung

Thrustmaster

Thrustmaster RUN'N'DRIVE 3-IN-1 RUMBLE FORCE Bedienungsanleitung

Thrustmaster

Thrustmaster Rechargeable Wireless Dual Trigger 2-in-1 Bedienungsanleitung

Thrustmaster

Thrustmaster GT Cockpit 458 Bedienungsanleitung

Beliebte Videospiel-Controller Handbücher anderer Marken

Wasp

Wasp SL-6610 Bedienungsanleitung

JKG

JKG JKG2022A Bedienungsanleitung

Marvo

Marvo MG08 Bedienungsanleitung

Belkin

Belkin F8GBPC001 Bedienungsanleitung

GameSir

GameSir Z2 Bedienungsanleitung

Laser

Laser PCO-AGAMEC-BK Bedienungsanleitung

Cortex

Cortex VEXnet Bedienungsanleitung

Gioteck

Gioteck HF-1 Bedienungsanleitung

Nacon

Nacon DAIJA ARCADE STICK Bedienungsanleitung

SHAKS

SHAKS S1+ Bedienungsanleitung

YCCTEAM

YCCTEAM Joy Con Bedienungsanleitung

Hyperkin

Hyperkin Smartboy Bedienungsanleitung

Nerf

Nerf DuraGrip Bedienungsanleitung

MoveMaster

MoveMaster MoveMaster Bedienungsanleitung

WinWing

WinWing Super Libra J1 Bedienungsanleitung

ECCI

ECCI Trackstar 6000 Series Bedienungsanleitung

Logitech

Logitech 963291-0403 - Attack 3 Joystick Bedienungsanleitung

Pelican

Pelican Afterglow PL-678 Bedienungsanleitung
