FormNo.3416-266RevA

RearRemoteHydraulicKit

SandPro®/IneldPro®3040and5040TractionUnit

ModelNo.08781—SerialNo.315000001andUp

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia

tocausecancer,birthdefects,orreproductiveharm.

WARNING

Hydraulicuidescapingunderpressurecan

penetrateskinandcauseinjury.

•Makesurethatallhydraulicuidhoses

andlinesareingoodconditionandall

hydraulicconnectionsandttingsaretight

beforeapplyingpressuretothehydraulic

system.

•Keepyourbodyandhandsawayfrom

pin-holeleaksornozzlesthateject

high-pressurehydraulicuid.

•Usecardboardorpapertondhydraulic

leaks.

•Safelyrelieveallpressureinthehydraulic

systembeforeperforminganyworkonthe

hydraulicsystem.

•Seekimmediatemedicalattentionifuid

isinjectedintoskin.

Wheneveryouneedservice,genuineT oroparts,or

additionalinformation,contactanAuthorizedService

DealerorToroCustomerServiceandhavethemodel

andserialnumbersofyourproductready.Figure1

identiesthelocationofthemodelandserialnumbers

ontheproduct.Writethenumbersinthespace

provided.

g220043

Figure1

1.Locationofthemodelandserialnumbers

ModelNo.

SerialNo.

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3416-266*A

Safety

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea

ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

decal110-1303

110-1303

1.Pressure3.Highpressureuid,

injectionintobody

hazard—stoptheengine,

stoptheimplement,

anddisconnectthe

quick-connectports.

2.Tank4.Tank

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

2Nopartsrequired–Removetheaircleaner.

3Nopartsrequired–Removethehydraulicreservoirand

shrouds.

Small90-degreeteewithbarb1

Large90-degreeelbow(threadedboth

ends)1

4Strainer1

Installttingstothehydraulictank.

Retainerbracket1

Muferclamp2

Hose-retainerbracket1

5Couplerbracket1

Installthecouplerbrackettotherear

frame.

Valve1

Valveplate1

Bolt(1/4x1-3/4inches)2

Nut(1/4inch)2

Small90-degreeelbow1

Teetting1

Thread-formingscrew(9/32x3/4inch)2

Teeadapter1

Relay1

Cap1

Installthemanifoldandbracket.

Hydrauliccap1

Hydrauliclinenumber11

Hydrauliclinenumber21

7Hydraulicline(hose)number51

Installthehydrauliclines.

Hydraulicpump1

45-degreetting(maleends)1

Hubassembly1

Squarekey(1/4x1inch)1

Setscrew(5/16x3/4inch)4

Pumpbracket1

Bolt(withthread-lockingcompound)

(5/16x3/4inch)2

Washer(3/8inch)2

Large90-degreeelbow(withhose

barbedend)1

Installthehydraulicpump.

Hydrauliclinenumber31

9Hydrauliclinenumber41Installthehydrauliclines.

ProcedureDescriptionQty.Use

Largehydraulichose1

Hydraulichosewithttings1

Largehoseclamp2

Smallhoseclamp2

Smallmoldedhydraulichose1

R-clamp1

Bolt(5/16x7/8inch)1

Flangenut(5/16inch)1

Installthehydraulichoses.

11Nopartsrequired–Tightenallconnections.

Harness1

Switch1

12Fuse1

Installtheswitchandharness.

Dipstick1

13Hydraulicuid

25.5L

(6-3/4US

gallons)

Installthehydraulicuidandcheckfor

leaks.

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface.

2.Lowertheattachments.

3.Engagetheparkingbrake.

4.Shutofftheengineandremovethekey.

5.Thoroughlycleanthemachine.Removeall

debristoensurethatthemountingbracketswill

tproperlyandthatnodirtordebrisgetsinto

thehydraulicsystem.

RemovingtheAirCleaner

NoPartsRequired

Procedure

1.Thoroughlycleantheareaaroundtheair

cleaner.

2.Loosentheradiatorclamparoundthehoseand

lowertheclampontothehose.

3.Removetheinsideboltholdingtheaircleaner

inplace.

4.Removetheair-cleanercoverandlter(Figure

2).

g003574

Figure2

1.Air-cleanercanister3.Canistercover

2.Airlter

5.Removethehosefromtheair-cleanercanister.

6.Spreadtheair-cleanerstrapopenandpullit

overtheendofthecanisterwherethelterwas

takenout(Figure3).

g003580

Figure3

1.Bolt4.Cap

2.Air-cleanerstrap5.Air-cleanercanister

3.Machineframe

7.Coverthehoseorinsertaragintoitsothatno

dirtordebrisgetsintoitwhileinstallingthiskit.

8.Removetheoppositeboltholdingtheair-cleaner

straptothemachineframe.

RemovingtheHydraulic

ReservoirandShrouds

NoPartsRequired

Procedure

1.Drainthehydraulictank.Refertothemachine

Operator'sManual.

2.Raisetherearofthemachineofftheground

andblockuptherearofthemachine.Referto

themachineOperator'sManualunderRaising

theMachine.

WARNING

Mechanicalorhydraulicjacksmayfailto

supportthemachineandcauseserious

injury.

Usejackstandswhensupportingthe

machine.

3.Removetheleftreartire.

4.Removethe4ange-headscrewssecuring

theleftwheelshroudtotheframe(Figure4).

Removeandretaintheshroud.

g003581

Figure4

1.Leftwheelshroud3.Tire

2.Flange-headscrews4.Nut

5.Removethe2ange-headscrewssecuring

theleftfrontscreentotheframe.Removeand

retainthescreen.

g003836

Figure5

1.Flange-headscrews3.Leftfrontscreen

2.Frame

6.Removethe3boltssecuringtherearhitch

shieldtotheframe.

g003838

Figure6

1.Bolt2.Rearhitchshield

7.Removethe2screwssecuringthecenter

shroudtotheframe(Figure7).Removeand

retaintheshroud.

g003617

Figure7

1.Centershroud3.Seat

2.Screws

8.Disconnectthehydrauliclinesgoingtothetank.

9.Removethetophydraulictankbracketfromthe

machineframeandloosenthe2bracketsonthe

sideoftheframe(Figure8).Removethetank

andretainthehardware.

g003575

Figure8

1.Hydraulictank4.Nut

2.Bolt5.Sidebracket

3.Topbracket6.Washer

InstallingFittingstothe

HydraulicTank

Partsneededforthisprocedure:

1Small90-degreeteewithbarb

1Large90-degreeelbow(threadedbothends)

1Strainer

Procedure

Note:MakesurethatallO-ringsarelubricatedand

properlypositionedonallttingsbeforeinstallation.

Note:Installallttingsandhydrauliclineslooselyrst

andthentightenthemwheneverythingisinstalled.

Installthettingsattheanglesshowninthegures.

1.Removethe2hydraulictankplugsfromtheside

ofthetank.

2.Installthestrainerintothehydraulictankwhere

thelargeplugwasremoved.

3.Installthelarge90-degreeelbowintothe

strainer.

4.Installthesmall90-degreeteewithbarbwhere

thesmallplugwasremoved(Figure9).

g015917

Figure9

1.Large90-degreeelbow

(installatangleshown)

5.Small90-degreetee

(installatangleshown)

2.Strainer6.Removethesmallplug.

3.Removethelargeplug.7.45degrees

4.Hydraulictank

InstallingtheCoupler

BrackettotheRearFrame

Partsneededforthisprocedure:

1Retainerbracket

2Muferclamp

1Hose-retainerbracket

1Couplerbracket

Procedure

Note:Installallhydrauliclineslooselyrstandthen

tightenthemwheneverythingisinstalled.

1.Positiontheclampsaroundtheroundtubeof

therearframe.

2.Installthehose-retainerbracketandthecoupler

brackettothemuferclamps.

Note:Donottightenthenutsatthistime.The

couplerbracketneedstobeloosetoinstallthe

hydrauliclines(Figure10).

g003578

Figure10

1.Mufeclamp4.Retainerbracket

2.Muferbracket5.Nut

3.Couplerbracket6.Rearframeroundtube

3.Temporarilypositionthecouplerbracketonthe

roundframetube;refertoFigure11.

Note:Placethecouplerbracketwherethetube

beginstobend.

g003837

Figure11

1.Roundframetube3.Couplerbracket

2.Temporarypositionforthe

couplerbracket

InstallingtheValve

Partsneededforthisprocedure:

1Valve

1Valveplate

2Bolt(1/4x1-3/4inches)

2Nut(1/4inch)

1Small90-degreeelbow

1Teetting

2Thread-formingscrew(9/32x3/4inch)

1Teeadapter

1Relay

1Cap

Procedure

Note:MakesurethatallO-ringsarelubricatedand

properlypositionedonallttingsbeforeinstallation.

Note:Installallttingsandhydrauliclineslooselyrst

andthentightenthemwheneverythingisinstalled.

Installthettingsattheanglesshowninthegures.

1.Installthettingsattheanglesshowninthe

gures.Installtheteettingtothesideofthe

valve.RefertoFigure12forthecorrecttee

tting.

2.Installasmall90-degreeelbowtothetopofthe

valve(Figure12).

3.Installtheteeadaptertothe90-degreeelbow.

RefertoFigure12forthecorrectteetting.

4.Installthecapontotheteeadapter(Figure12).

5.Installtherelaytothevalvebracketatthesame

timethevalveisinstalledtothevalvebracket.

6.Installthevalvetothevalvebracketwith2bolts

(1/4x1-3/4inches)and2nuts(1/4inch);refer

toFigure12.

g003576

Figure12

1.Teeadapter6.Valvebracket

2.Small90-degreeelbow7.Relay

3.Nut8.Bolt(1/4x1-3/4inches)

4.Valve9.Cap

5.Teetting

7.Installthevalvebrackettothemachineframe

with2thread-formingscrews(9/32x3/4inch);

refertoFigure13.

g003577

Figure13

1.Thread-formingscrew

(9/32x3/4inch)

2.Valveassembly

InstallingHydraulicLines

1,2,and5

Partsneededforthisprocedure:

1Hydrauliccap

1Hydrauliclinenumber1

1Hydrauliclinenumber2

1Hydraulicline(hose)number5

Procedure

UseFigure14foridentifyingthecorrecthydraulic

lines.

g015920

Figure14

1.Hydrauliclinenumber14.Hydrauliclinenumber4

2.Hydrauliclinenumber25.Hydraulicline(hose)

number5

3.Hydrauliclinenumber3

Note:Installallhydrauliclineslooselyrstandthen

tightenthemwheneverythingisinstalled.

1.Installthehydrauliccapontohydraulicline

number1,port1b.

2.Positionhydrauliclinenumber1intothe

machineasshowninFigure15.

3.Installhydrauliclinenumber1totheteetting

assembledtothesideofthevalve(Figure15).

4.Installthehydrauliclinenumber1totheupper

malecoupler(Figure15).

g003608

Figure15

1.Teettingonthesideof

thevalve

4.Uppermalecoupler

2.Valve5.Couplerbracket

3.Hydrauliclinenumber1

5.Positionhydrauliclinenumber2intothe

machineasshowninFigure16.

6.Installhydrauliclinenumber2totheteetting

assembledtothe90-degreeelbowandthetop

ofthevalve(Figure16).

7.Installhydrauliclinenumber2totheupper

femalecoupler(Figure16).

g003607

Figure16

1.Valve4.Upperfemalecoupler

2.Teettingassembledto

the90-degreeelbow

5.Couplerbracket

3.Hydrauliclinenumber2

8.Looselyinstallhydraulicline(hose)number5to

thelowermalecoupler(Figure17).

Note:Theotherendofthishosewillbe

installedinProcedure10.

g015919

Figure17

1.Hydrauliclinenumber14.Hydraulicline(hose)

number5

2.Couplerbracket5.Hydrauliccap

3.Lowermalecoupler

InstallingtheHydraulic

Pump

Partsneededforthisprocedure:

1Hydraulicpump

145-degreetting(maleends)

1Hubassembly

1Squarekey(1/4x1inch)

4Setscrew(5/16x3/4inch)

1Pumpbracket

2Bolt(withthread-lockingcompound)(5/16x3/4inch)

2Washer(3/8inch)

1Large90-degreeelbow(withhosebarbedend)

Procedure

1.Installthelargesquare90-degreeelbowtothe

sideofthehydraulicpump.

2.Installthe45-degreeelbowtothesideofthe

hydraulicpump(Figure18).

g003611

Figure18

1.45-degreeelbow4.Maleend

2.Hydraulicpump5.Femaleend

3.Large90-degreeelbow

(withhosebarbedend)

3.RemovetheexistingcoverovertheenginePTO

(powertakeoff).

4.Installthepumpbrackettotheenginewith2

bolts(5/16x3/4inch)and2washers(3/8inch).

RefertoFigure19forthecorrectpositionto

installthepumpbracket.

g003818

Figure19

1.Engine4.Washer(3/8inch)

2.EnginePTOshaft5.Bolt(5/16x3/4inch)

3.Pumpbracket

5.Applyanti-seizecompoundtotheenginePTO

(powertakeoff)shaftandthehydraulicmotor

shaft.

6.Installthesquarekey(1/4x1inch)intotheslot

intheenginePTOshaft(Figure20).

Andere Handbücher für 08781

Inhaltsverzeichnis

Andere Toro Rasenmäherzubehör Handbücher

Toro

Toro 106-2245 Bedienungsanleitung

Toro

Toro 13-32G Wheel Horse Bedienungsanleitung

Toro

Toro 07320 Bedienungsanleitung

Toro

Toro SUPER RECYCLER 59193 Bedienungsanleitung

Toro

Toro Workman GTX Series Bedienungsanleitung

Toro

Toro 03614 Bedienungsanleitung

Toro

Toro 79348 Bedienungsanleitung

Toro

Toro 30107 Bedienungsanleitung

Toro

Toro 145-3495 Bedienungsanleitung

Toro

Toro 30653 Bedienungsanleitung

Toro

Toro 108-3160 Bedienungsanleitung

Toro

Toro 79390 Bedienungsanleitung

Toro

Toro 04259 Bedienungsanleitung

Toro

Toro 117-0354 Bedienungsanleitung

Toro

Toro 110-6506 Bedienungsanleitung

Toro

Toro 03626 Bedienungsanleitung

Toro

Toro 121-2984 Bedienungsanleitung

Toro

Toro 30365 Bedienungsanleitung

Toro

Toro 30856 Handbuch

Toro

Toro 125-5180 Bedienungsanleitung

Toro

Toro 02710 Bedienungsanleitung

Toro

Toro 31984 Bedienungsanleitung

Toro

Toro Groundsmaster 4500-D Bedienungsanleitung

Toro

Toro 137-5470 Bedienungsanleitung

Beliebte Rasenmäherzubehör Handbücher anderer Marken

Ariens

Ariens 891008 Bedienungsanleitung

Rover

Rover 108 - 109 Bedienungsanleitung

Snapper

Snapper 1690047 Bedienungsanleitung

Scag Power Equipment

Scag Power Equipment GC-F4 Bedienungsanleitung

RHINO

RHINO 800 Bedienungsanleitung

Exmark

Exmark Quest 126-7506 Bedienungsanleitung

Snapper

Snapper 1685167 Bedienungsanleitung

Cub Cadet

Cub Cadet 19B70029100 Bedienungsanleitung

Stihl

Stihl AMK 043.1 Bedienungsanleitung

MTD

MTD 753-0873 Handbuch

Bush Hog

Bush Hog RG60 Bedienungsanleitung

Land Pride

Land Pride RCF2760 Bedienungsanleitung

Simplicity

Simplicity 211 Bedienungsanleitung

Exmark

Exmark ULTRAVAC QUICK DUMP SYSTEM Bedienungsanleitung

Excel

Excel Two Bag Catcher Bedienungsanleitung

Textron

Textron Jacobsen Pro12 DFS Bedienungsanleitung

Ryobi

Ryobi AC018130 Bedienungsanleitung

Snapper

Snapper 4544 Einrichtungshandbuch
