Toro 145-3530 Bedienungsanleitung
Form No. 3463-130 Rev A
T rimmer Rack
GrandStand
®
Revolution
®
Mower
Model No. 145-3530
Installation Instructions
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
1
No parts required
–
Prepare the machine for installation.
Upper mount bracket 1
Screw (5/16 inch)
3
Slot bracket
1
Carriage bolt (1/4 x 3/4 inch)
2
Nut (1/4 inch)
4
Large st clamp
1
Large backer plate 1
2
Hex-head ange screw (1/4 x 1-1/2
inches)
2
Install the upper bracket assembly .
Lower mount bracket 1
Screw (5/16 inch)
2
Adjustment plate 1
Carriage bolt (1/4 x 3/4 inch)
2
Nut (1/4 inch)
4
Small st clamp
1
Small backer plate
1
3
Hex-head ange screw (1/4 x 1-1/2
inches)
2
Install the lower mount bracket.
4
No parts required
–
Complete the installation.
© 2023—The T oro® Company
81 1 1 L yndale A venue South
Bloomington, MN 55420
Register at www .T oro.com.
Original Instructions (EN)
Printed in the USA
All Rights Reserved
*3463-130*
1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Disengage the drives and the power take-of f.
3. Shut of f the machine and remove the key .
4. W ait for all moving parts to stop.
5. T urn the battery-disconnect switch to the O FF
position.
6. Lower the platform.
7. Loosen the twist knobs on each side of the
machine.
g375719
Figure 1
1. T wist knob
2. Cushion
8. Lower the cushion to the platform.
9. Remove the rear access cover .
g377627
Figure 2
2
2
Installing the Upper Bracket
Assembly
Parts needed for this procedure:
1 Upper mount bracket
3
Screw (5/16 inch)
1
Slot bracket
2
Carriage bolt (1/4 x 3/4 inch)
4
Nut (1/4 inch)
1
Large st clamp
1 Large backer plate
2
Hex-head ange screw (1/4 x 1-1/2 inches)
Procedure
1. On the left side of the machine, measure and
mark the 3 holes as shown below .
g443616
Figure 3
1. 17.6 cm (6.93 inches) 4. 6.4 cm (2.52 inches)
2. 4.6 cm (1.82 inches) 5. 1 1.4 cm (4.5 inches)
3. 4.1 cm (1.61 inches) 6. 14.5 cm (5.71 inches)
W ARNING
Using a drill without proper eye
protection may allow debris to enter the
eye, causing injury .
When drilling, always wear eye
protection.
2. Use a drill bit (9/32 inch) to drill through the 3
marked hole locations.
Note: When drilling, avoid pushing the drill bit
too far beyond the plate.
3. Use compressed air to remove the metal
shavings from drilling.
4. Use 3 screws (5/16 inch) to secure the upper
mount bracket to the machine.
g441540
Figure 4
1. Screw (5/16 inch)
2. Upper mount bracket
5. Use 2 carriage bolts (1/4 x 3/4 inch) and 2 nuts
(1/4 inch) to secure the slot bracket to the upper
mount bracket.
3
g441543
Figure 5
1. Slot bracket 3. Nut (1/4 inch)
2. Carriage bolt (1/4 x 3/4
inch)
4. Upper mount bracket
6. Use 2 hex-head ange screws (1/4 x 1-1/2
inches) and 2 nuts (1/4 inch) to secure the large
st clamp and large backer plate to the slot
bracket.
g441545
Figure 6
1. Large st clamp 3. Nut (1/4 inch)
2. Large backer plate
4. Hex-head ange screw
(1/4 x 1-1/2 inches)
3
Installing the Lower Mount
Bracket
Parts needed for this procedure:
1 Lower mount bracket
2
Screw (5/16 inch)
1 Adjustment plate
2
Carriage bolt (1/4 x 3/4 inch)
4
Nut (1/4 inch)
1
Small st clamp
1
Small backer plate
2
Hex-head ange screw (1/4 x 1-1/2 inches)
Procedure
1. Using the lower mount bracket as a template,
mark the 2 holes as shown below .
g443617
Figure 7
1. 2.54 cm (1 inch) 3. 17.6 cm (6.93 inches)
2. 2.54 cm (1 inch)
4
W ARNING
Using a drill without proper eye
protection may allow debris to enter the
eye, causing injury .
When drilling, always wear eye
protection.
2. Use a 9/32 inch drill bit to drill through the 2
marked hole locations.
Note: Do not push the drill bit too far past the
plate when drilling.
3. Use 2 screws (5/16 inch) to secure the lower
mount bracket to the machine.
g441547
Figure 8
1. Lower mount bracket
2. Screw (5/16 inch)
4. Use compressed air to remove the metal
shavings from drilling.
5. Use 2 carriage bolts (1/4 x 3/4 inch) and 2 nuts
(1/4 inch) to secure the adjustment plate to the
lower mount bracket.
g441563
Figure 9
1. Lower mount bracket 3. Adjustment plate
2. Carriage bolt (1/4 x 3/4
inch)
4. Nut (1/4 inch)
6. Use 2 hex-head ange screws (1/4 x 1-1/2
inches) and 2 nuts (1/4 inch) to secure the
small backer plate and small st clamp to the
adjustment plate.
g441614
Figure 10
1. Small st clamp 3. Nut (1/4 inch)
2. Small backer plate 4. Hex-head ange screw
(1/4 x 1-1/2 inches)
5
4
Completing the Installation
No Parts Required
Procedure
1. Install the rear access cover .
g377627
Figure 1 1
2. Raise the cushion to the platform.
3. T ighten the twist knobs on each side of the
machine.
g375719
Figure 12
1. T wist knob
2. Cushion
4. Adjust the upper and lower plates to t your
trimmer as needed.
5. T urn the battery-disconnect switch to the O N
position.
Figure 13 illustrates the correct position of the
trimmer on the rack.
Note: Position the upper trimmer handle so that
is held in place by the upper clamp.
g442743
Figure 13
6
Notes:
