Toro 08865 Bedienungsanleitung
Form No. 3459-473 Rev B
Laser Level Installation Kit
Field Pro
®
6040 T raction Unit
Model No. 08865
Installation Instructions
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
1
No parts required
–
Prepare the machine.
2
No parts required
–
Remove the hood.
Bolt (3/8 x 1/2 inch)
2
Flat washer 4
Spacer
2
Locknut (3/8 inch)
3
Curved washer
2
Bushing 2
Receiver mast 1
Locknut (1/2 inch)
1
Thrust washer 1
Mast-support mount 1
Carriage bolt (1/2 x 2-1/2 inches)
1
3
Carriage bolt (3/8 x 1-1/4 inches)
2
Install the receiver mast.
Hydraulic hose (65 cm or 25-1/2 inches)
1
Hydraulic hose (48 cm or 19 inches)
1
Long hydraulic tube (mid-port)
1
Short hydraulic tube (mid-port)
1
Hydraulic tube (no port)
1
Hydraulic hose (90° elbow tting)
1
Long 90° elbow tting
1
Short 90° elbow tting
1
Straight tting
2
Carriage bolt (5/16 x 3/4 inch)
2
Control manifold
1
V alve bracket 1
Bolt (1/4 x 5/8 inch)
3
4
Nut (5/16 inch)
2
Install the hydraulics.
© 2023—The T oro® Company
81 1 1 L yndale A venue South
Bloomington, MN 55420 Register at www .T oro.com.
Original Instructions (EN)
Printed in the USA
All Rights Reserved
*3459-473*
Procedure Description
Qty .
Use
Bolt (1/4 x 5/8 inch)
2
Locknut (#6)
1
Carriage bolt (#10 x 5/8 inch)
2
Laser controller mount 1
Nut (#10)
2
Grommet
1
Screw (#6 x 1/2 inch)
1
5
Nut (1/4 inch)
2
Install the laser controller mount.
Switch bracket
1
Proximity switch 1
Switch plate
1
Carriage bolt (#10 x 5/8 inch)
1
Locknut (#10 inch)
1
Activator bracket 1
T orsion spring 1
Carriage bolt (1/4 x 3/4 inch)
2
6
Locknut (1/4 inch)
2
Install the operator presence switch.
1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface or move the
machine to a machine lift.
2. Engage the parking brake.
3. Raise the mid-mount attachment. Insert the
depth control pin into the T RANSPORT (T) position
to keep the mid-mount attachment up.
4. Shut of f the engine and remove the key .
5. W ait for all moving parts to stop and machine
components to cool.
6. Chock the wheels.
2
3
Installing the Receiver Mast
Parts needed for this procedure:
2
Bolt (3/8 x 1/2 inch)
4 Flat washer
2
Spacer
3
Locknut (3/8 inch)
2
Curved washer
2 Bushing
1 Receiver mast
1
Locknut (1/2 inch)
1 Thrust washer
1 Mast-support mount
1
Carriage bolt (1/2 x 2-1/2 inches)
2
Carriage bolt (3/8 x 1-1/4 inches)
Procedure
1. Install the mast-support mount to the machine
as shown in Figure 3 .
g389485
Figure 3
1. Locknut (3/8 inch) 3. Carriage bolt (3/8 x 1-1/4
inches)
2. Mast-support mount
4
2. Install the mast to the mast-support mount as
shown in Figure 4 .
3. Install the upper part of the mast to the machine
fork as shown in Figure 4 .
g439863
Figure 4
1. Bolt (3/8 x 3-1/2 inches)
7. Mast
2. Flat washer
8. Locknut (1/2 inch)
3. Spacer
9. Thrust washer
4. Locknut (3/8 inch)
10. Installed mast-support
mount
5. Curved washer 1 1. Carriage bolt (1/2 x 2-1/2
inches)
6. Bushing
4
Installing the Hydraulics
Parts needed for this procedure:
1
Hydraulic hose (65 cm or 25-1/2 inches)
1
Hydraulic hose (48 cm or 19 inches)
1
Long hydraulic tube (mid-port)
1
Short hydraulic tube (mid-port)
1
Hydraulic tube (no port)
1
Hydraulic hose (90° elbow tting)
1
Long 90° elbow tting
1
Short 90° elbow tting
2
Straight tting
2
Carriage bolt (5/16 x 3/4 inch)
1
Control manifold
1 V alve bracket
3
Bolt (1/4 x 5/8 inch)
2
Nut (5/16 inch)
Procedure
W ARNING
Hydraulic uid escaping under pressure can
penetrate skin and cause injury . Fluid injected
into the skin must be surgically removed
within a few hours by a doctor familiar with
this form of injury; otherwise, gangrene may
result.
• Ensure that all hydraulic-uid hoses
and lines are in good condition and all
hydraulic connections and ttings are tight
before applying pressure to the hydraulic
system.
• Keep your body and hands away from
pinhole leaks or nozzles that eject
high-pressure hydraulic uid.
• Use cardboard or paper to nd hydraulic
leaks; never use your hands.
1. Ensure the stop pin is in the transport and
maintenance position holding the tool up.
2. Move the valve control levers forward and
reverse to release internal pressure in the
hydraulic hoses and tubes.
5
6. Install the control manifold and bracket to the
machine as shown in Figure 9 .
g389329
Figure 9
1. Carriage bolt (5/16 x 3/4
inches)
3. Nut (5/16 inch)
2. Manifold with bracket
7. Use Figure 10 to identify the hydraulic tubes and
the hoses.
g389303
Figure 10
1. Hydraulic hose (90° elbow
tting)
4. Long hydraulic tube
(mid-port)
2. Hydraulic hose (48 cm or
19 inches)
5. Short hydraulic tube
(mid-port)
3. Hydraulic hose (65 cm or
25-1/2 inches)
6. Hydraulic tube (no port)
8
8. Install the hydraulic hose (90° elbow tting) to
the straight tting on the manifold, route it back
to the hydraulic uid cooler , and attach the 90°
elbow tting to the hydraulic uid cooler; refer to
Figure 10 ,Figure 1 1 , and Figure 12 .
Note: Ensure the hose is routed away from hot
surfaces, not rubbing on other parts, and not
being pinched.
g390663
Figure 1 1
1. Hydraulic hose (90° elbow tting)
g390674
Figure 12
1. 90° elbow tting connected to the hydraulic uid cooler
9
9. Install the short hydraulic tube (mid-port) to the
valve control and the 90° elbow tting (short) on
the manifold; refer to Figure 8 ,Figure 10 , and
Figure 13 .
g389241
Figure 13
1. Short hydraulic tube (mid-port)
10. Install the long hydraulic tube (mid-port) to the
valve control and the 90° elbow tting (long) on
the manifold; refer to Figure 8 ,Figure 10 , and
Figure 14 .
g389242
Figure 14
1. Long hydraulic tube (mid-port)
1 1. Install the hydraulic tube (no port) to the valve
control and the straight tting on the manifold;
refer to Figure 8 ,Figure 10 , and Figure 15 .
10
