ELECTRONIC SCALE

PC SERIES

OWNER’S MANUAL

REVISION: 1.5

IMPORTANT:

BEFORE OPERATING THIS SCALE, PLEASE READ THIS MANUAL THROUGHLY. COD. 13100174

INDEX

IMPORTANT WARNINGS

INTRODUCTION

INSTRUCTIONS FOR INSTALLATION

NAME AND LOCATION OF IMPORTANT PARTS

KEYBOARD

GENERAL VIEW FINDER (LCD DISPLAY)

OPERATIONS DESCRIPTION

HOW TO WEIGHT A PRODUCT

HOW TO ENTER PRICES

HOW TO CLEAR WRONG PRICES

USE OF THE “FIXED PRICE”

USE OF THE “TARE”

HOW TO USE THE “REFERENCE TO ZERO”

PRICE ADD-UP

PRICE MULTIPLING FUNCTION

HOW TO SAVE MEMORIES

HOW TO LOAD A MEMORY

HOW TO TURN ON THE BACKLIGHT

POWER OFF TIMER FUNCTION

USE OF THE BATTERY

BATTERY RECHARGE

LIFE TIME OF THE RECHARGEABLE BATTERY

LOW BATTERY INDICATOR

HOW TO ACCESS THE COUNTERS

OTHER IMPORTANT MESSAGES THAT APPEAR ON THE SCALE

MAINTENANCE AND CLEANING

TROUBLESHOOTING

TECHNICAL SPECIFICATIONS AND SCALE DIMENSIONS

WARNING

!!DO NOT OPEN ¡¡

RISK OF SHORT CIRCUIT

CAUTION: TO REDUCE THE RISK OF SHORT CIRCUIT IN YOUR

SCALE, DO NOT REMOVE THE COVER OR SUBSTITUTE

ANY OF THE PARTS FOR OTHERS THAT ARE NOT

ORIGINAL. ONLY AUTHORIZED DISTRIBUTOR

IMPORTANT NOTE

THIS SCALE MEETS THE REQUIERMENTS ESTABLISHED BY THE MEXICAN ( NOM-10-1993-SCFI ) AND

INTERNATIONAL ( NTEP ) REGULATION. MAKING ANY CHANGE OR MODIFICATION TO THE ORIGINAL

PARTS OR COMPONENTS WILL CAUSE THE NON-COMPLIANCE OF THE REGULATIONS MENTIONED BEFORE,

RESULTING THE INMEDIATLY ANNULMENT OF THE WARRANTY.

IMPORTANT WARNINGS

1.- IN CASE YOU HAVE A PROBLEM 2.- DO NOT OPEN THE SCALE ON 3.-”NEVER” PRESS THE KEYBOARD

WITH THE SCALE, FIRST READ THE YOUR OWN. YOUR WARRANTY WILL WITH OBJECTS SUCH AS PENCILS,

THE WARRANTY CONDITIONS. BE CANCELED. PENS,KNIVES,ETC.

4.- USE A 120 V AC OUTLET EXCLUSIVE FOR THE SCALE 5.- “NEVER” WASH THE SCALE USING A FLOW OF WATER .THIS

AVOIDING OVERLOAD OR VOLTAGE VARIATIONS. CAN DAMAGE THE ELECTRONIC COMPONENTS. FOR MORE

INFORMATION READ “MAINTENANCE AND CLEANING” SECTION.

6.- PROTECT THE SCALE FROM INSECTS 7.- DO NOT DROP OR HIT THE SCALE 8.- DO NOT USE SOLVENTS OR

(MAINLY FROM ROACHES) THEY CAN SERIOUSLY WITH THE PRODUCT TO BE WEIGHTED DETERGENTS FOR CLEANING

DAMAGE THE ELECTRONIC COMPONENTS. USE BECAUSE AS TIME GOES BY IT WILL ONLY USE A DAMP RAG.

SOLID PRODUCTS AGAINST ROACHES. DAMAGE THE WEIGHT SENSOR.

9.- DO NOT PLACE FANS OR HEATERS 10.- DO NOT PLACE THE SCALE WHERE 11.- ONLY AUTHORIZED AND QUALIFIED

DIRECTED TOWARDS THE SCALE. THERE IS A LOT OF MOISTURE AND/OR PERSONNEL SHOULD CHECK AND

DUST.REPAIRYOURSCALE.

INTRODUCTION

DEAR CUSTOMER:

We appreciate that you have chosen this product and we assure you that you will get the maximum satisfaction of the new

acquisition for your bussines the scale has been designed to give you a great deal saving time and money, avoiding losses

by human mistakes of interpretation and calculation, offering you more fluency and security in your commercial tasks.

To make your equipment a long lasting investment, we suggest to read carefully this manual and make sure to keep it at

hand for later consultations. In this manual we indicate the necessary steps to benefit and prolong your appliances

availability.

INSTRUCTIONS FOR INSTALLATION

1.- Unpack the scale and check the conditions of the product.

If it is damaged report it inmediately to your authorized distributor.

2.- Place the scale where there is not any movement

or vibration, make sure it is leveled adequately

checking that the four leveling bases are supporting the scale

over the surface were it has been placed and if the level bubble

(under the plate) is centered, to adjust, tighten or loosen the leveling

bases until the bubble is in the center of the circle.

3.- Connect the AC/DC power supply (if you use it)

to a 120 V A.C. outlet.

4.- Turn the scale on after the countdown sequence your

scale will display zeroes and will be ready to use.

IMPORTANT NOTE: If your scale displays "HELP" after you followed the previous steps and after the initial countdown, it

means that it was handled roughly and/or got hit during the shipment, wich cause irreversible damage in its operation. Call

your authorized distributor. It is possible that the scale displays “HELP“ when you turn it on with weight on the plate, when

this happens, remove the weight and turn the scale off and then turn it on

NOTE:ALL THE EXAMPLES IN THIS MANUAL WERE PERFORMED IN A PC-40L SCALE MODEL

NAME AND LOCATION OF IMPORTANT PARTS

1. CABINET: Manufactured in stainless steel and resistant to corrosion and strokes.

2. PLATE: Also manufactured in stainless steel with the border bent and rounded.

3. PLATE HOLDER: Manufactured in aluminum that provides resistance to corrosion.

4. LEVEL BUBBLE: Inserted in the cabinet. It is used to level the scale.

5. MEMBRANE KEYBOARD: It has multifunctions, with big and readable keys.

6. GENERAL VIEW FINDER: It shows the necessary information it has individual indicators upper left indicator,

alphanumeric ("MODE") indicator, "PRICE" indicator, "TOTAL" indicator.

7. LEVELING BASES: They level the scale tightening or loosening them.

8. JACK: Connects the AC/DC power supply to the scale.

9.- CUSTOMER VIEW FINDER: Customer display.

KEYBOARD

M1 M2 M3 M4

M5 M6 M7 M8

M9 M10 M11 M12

M13 M14 M15

P-PACK

SERIES

PRICE /lb

TOTAL $

OFF

0 T

000

¼½

P-PACK

RCL

STO

M+

1234

910

1213

capacity 40 x 0.005 lb

1) Keyusedtoturnonthescale.

2) When this key is pressed the appliance turns off.

3) This key is used to start with zero on the weight.

4) This key is used to eliminate any containers weight that you do not wish to consider during a transaction (for

example: boxes, bags, bottles, etc).

5) It is used to store prices in a memory location of the scale.

6) It is used to load a PLU price from memory.

7) Key used to add prices up.

8) ,..., Numerical section: it is useful to enter data into the scale such as price per pound or kilogram.

9) Enter two zeroes.

10) Key used to clear wrong data that has been entered with the keyboard. It is also used to eliminate the "FIXED

PRICE" function.

11) It enables the function "FIXED PRICE".

12) ,Keys used to multiply the unit price under 1/2 o 1/4 lb or kg mode.

13) , ..., PLU's direct access keys.

14) Key used to turn on/off the backlight.

1lb

GENERAL VIEW FINDER ( LCD DISPLAY )

1.- UPPER-LEFT indicator: shows the products weight in POUNDS or KILOGRAMS when this happens, the symbol lb or

kg appears in the alphanumeric ("MODE") indicator e.

2.- PRICE indicator: shows the price per POUND or KILOGRAM of the product. This price can have up to 5 digits.

3.- Total amount to pay indicator (" TOTAL "): shows the partial or total sale during a commercial transaction

4.- ZERO indicator: this reference to ZERO indicates that the scale is ready to start weighing products. The indicators

disappear when a weight is placed on the scale.

5.- .- NET indicator: indicates that the TARE function has been activated. This indicator disappears when you press the

key.

6.- FIXED PRICE indicator: when it is activated, it indicates that the price per POUND or KILOGRAM thatisshowninthe

indicator will not be cleared automatically when the product is removed from the scale (it is fixed).

7.- AC/DC POWER SUPPLY indicator: it means that the scale was connected to the AC/DC power supply.

8.- KG INIDICATOR - Is showed when the scale is configured in kilograms.

LB INDICATOR - Is showed when the scales is configured in pounds.

OPERATIONS DESCRIPTION.

HOW TO WEIGHT A PRODUCT

At the end of scale initialization, zeroes will appear in the view finder, indicating that the scale is ready to use.

If not, see section reference to zero. Then place the product to be weighed on the plate and you will see the weight in the

corresponding indicator.

9.-

HOW TO ENTER PRICES

The product price per pound or kilogram is entered pressing the numbers of the keyboard to indicate the desired value.

This value will appear in the "PRICE" indicator and the total amount to pay will be calculated automatically being shown in the

"TOTAL" indicator. For example, if the product price per pound in the previous examples is $8.20, just press

and the following display will appear:

HOW TO CLEAR WRONG PRICES

When a mistaken price is entered, you can clear it in two ways:

a) Manually: Simply press the clear key and enter the correct price.

b) Automatically: The price is automatically cleared removing the product from the plate, except if it's not enabled the fixed

price function.

FIXED PRICE FUNCTION

When it is necessary to constantly be weighing the same kind of product, one does not change its price, you can use the

"FIXED PRICE" function. It is used to keep the price "FIXED" in the "PRICE" indicator avoiding it to be automatically cleared

when the weight is removed from the scale.

To fix a price, follow these steps:

1.- Place the product on the plate.

2.- Enter the product price per pound or kilogram.

3.- Press .

After these steps, a small arrow will light up in the upper rig ht corner of the "TOTAL" indicator, pointing to the label "P-

PACK" (fixed price). As an example, suppose that the product is ham, the weight is 4 pounds, and the price is $2.70 per

pound after entering the fixed price, the view finder will look like this:

To clear the fixed price function, just press the key.

USE OF THE "TARE"

When you wish to weight a product in a container but you do not want to consider the containers weight during the

operation, you can use the TARE function. To use this function follow this steps:

Suppose you are going to weight 15 pounds of sugar in a plastic container that weights 3.5 pounds and that the price per lb

is $1.80.

1.- Place the empty container on the scale.

2.- Press the key. After some seconds the view finder will display:

3.- Remove the container and put the sugar inside it. When you remove the container, a negative number (weight of the

container) appears in the UPPER-LEFT indicator.

4.- Place the container on the scale and put in the container sugar until you have 15 lb. Then enter the price per pound press

It is important to mention that this function is substractive from the scale maximum capacity. For example if you have a

container that weights 7 lb, The scale will only be able to weight up to 33 lb of product to complete the maximum capacity.

HOW TO USE THE REFERENCE TO ZERO

This function has two uses:

a) Permanent tare: when you wish to weigh some products over a same container several times, you should use this

function , and to eliminate it, just remove the container from the plate and press key again. As in the tare function

this function is also substractive from the scale capacity, for example: if you reference to 10 lb, the scale will only be able

to weight up to 30 lb.

b) Due to voltage variance or some other factor, it is posibble that without having any weight over the plate, the view finder

shows some weight, or that the zero flag it's not on, then press the key and the scale will be referenced to zero

turning the zero flag on.
