TP-Link TL-R460 Bedienungsanleitung

Turn off all of your network devices, including your computer, Modem and the

Router.

Connect the WAN port on your

Router to the Modem’s LAN

port with an Ethernet cable.

Connect your computer to the

Port labeled 1~4 on the Router

with an Ethernet cable.

Plug the provided Power

Adapter into the Power jack on

the back of the Router and the

other end to a standard

electrical wall socket.

Note The product model shown in this part is TL-R460, as an example.

LAN: Flashing or solid light if the

corres

ondin

ort is connected

LAN: Flashing or solid light if the

corresponding port is connected

Turn on all of your network devices, including your computer, Modem and the Router

then check to see if the LEDs of the Router display normally as the digram below

describes.

Note If the LEDs display abnormally, please check to see if all the cable connectors

(power adapter and Ethernet cable) are well connected to your device.

WAN: Flashing or solid light if the

corresponding port is connected

Power: Solid light

WAN: Flashing or solid light if the

corres

ondin

ort is connected

System: Flashing

PWR: Solid light

SYS: Flashing

LAN: Flashing or solid light if the

corresponding port is connected

WAN: Flashing or solid light if the

corresponding port is connected

Insert the provided Resource

CD into your CD-ROM drive.

The Setup Wizard will

automatically pop up on

your computer’s screen.

Please select your

product model and click

Easy Setup Assistant

Note To configure the device, you can either run the Resource CD (Method One),

or run the Web based Quick Setup Wizard (Method Two). TP-LINK strongly

recommends that you run the Resource CD (Method One).

TL-R402M only supports Web based Quick Setup Wizard (Method Two).

Here takes TL-R460 as an example.

Note

The configuration has now been completed. Please skip to step 4 Testing the

Internet Connection on page 7.

Login

dialog box will prompt you for the

User name and Password. Enter

the default values and click OK.

User name: admin

Password: admin

Click OK

Open your web browser, type

http://192.168.0.1/ in the

address field and press Enter

Click START, and then follow

the step-by-step instructions

until you complete the

configuration

Note If your product is TL-R402M or TL-R860, plesase type http://192.168.1.1/ in

the address field.

Click Quick Setu

Click Next

Internet Parameters Configuration

Configuration for PPPoE

Note If the dialog box does not pop up, please refer to T3 in the Troubleshooting

guide on page 8. T2 will help you if you forget the password.

Note 1. If you did not get the Connection Type information, please contact your

ISP for this information.

2. If your ISP provides other connection types such as PPTP, L2TP or

BigPond (or Heart Beat Signal), please go to “Network > WAN” to

configure the connection type referring to the User Guide on the Resource

CD provided.

This page will then display.

The web management page will

display after a successful login.

If you select PPPoE, this page

will then display.

Click Next

Choose the Connection Type given by

your ISP.

If PPPoE is selected, please proceed to A;

If Dynamic IP is selected, please skip to B;

If Static IP is selectedǈplease skip to C.

Enter the Username and

Password provided by

our ISP

Click Finish

Configuration for Dynamic IP

If you select Dynamic IP, you will be prompted to the Quick Setup - Finish page.

Configuration for Static IP

Quick Setup - Finish

If you select Static IP, this page

will then display.

Enter the IP Address,

Subnet Mask, Gateway,

DNS provided by your ISP

manuall

Click Next

The basic settings for your Router are completed. Please open the web browser and

log on to the following websites:

http://www.tp-link.com

http://www.google.com

If the above websites can be accessed, it indicates that your Router has been

configured successfully and you can begin to enjoy the Internet. If the website

cannot be accessed, please refer to “T4. What can I do if I cannot access the

Internet?” in the Troubleshooting guide on page 16.

Note The above configurations only need to be set once. If you want other

computers in your network to access the Internet, please connect the desired

computer to the Router directly. If the additional computer can not access the

Internet, please set that computer referring to “T3. What can I do if I cannot

access the web-based configuration page?” in the Troubleshooting

guide on page 8.

Note For advanced configurations, please refer to the User Guide on the Resource

CD provided.

T1. How do I restore my Router’s configuration to its factory default settings?

TL-R402M:

TL-R460:

TL-R860:

T2. What can I do if I don’t know or forgot my password?

1) Restore the Router’s configuration to its factory default settings. If you don’t

know how to do that, please refer to section T1.

2) Use the default user name and password: admin, admin.

3) Try to configure your Router once again by following the instructions in the

previous steps of the QIG.

T3. What can I do if I cannot access the web-based configuration page?

1) Configure your computer’s IP Address.

With the Router powered on, press and hold the Reset/RESET button on the panel

for 8 to 10 seconds before releasing it.

Note Once the Router is reset, the current configuration settings will be lost and

you will need to re-configure the Router.

For Windows XP OS

Go to Start > Control Panel,

you will then see the

following page.

Click Network and Internet

Connections

Click Network

Connections

Click Properties

Right-click Local

Area Connection

Select Obtain an IP

address automaticall

Select Obtain DNS

server address

automaticall

Click OK

Double-click Internet

Protocol

(

TCP/IP

)
