This manual explains the installa-

tion and use of the Trek Incite ACH

and ACH Digital bicycle computers.

Please read this manual carefully

and save it for future reference.

If you do not understand the

information in this manual, or you

have a question about your Incite

ACH computer that this manual

does not cover, consult your Trek

dealer. If you have a question or

problem that your Trek dealer can’t

handle, contact us at:



 







 © Copyright Trek Bicycle Corporation



06 Incite ACH 07_13.indd 1 7/14/06 7:25:51 AM





Safety and general guidelines ......................................................... 1

Functions ......................................................................................... 2

Installation....................................................................................... 5

Placing the computer on the handlebar...................................... 6

Placing the magnet and sensors ................................................. 8

Positioning of the heart rate strap ........................................... 11

Easy setup (ReSet)..................................................................... 12

ReStart- Getting ready to ride....................................................... 17

Additional information................................................................... 18

Troubleshooting............................................................................. 19

Replacing the battery .................................................................... 20

Advanced features.......................................................................... 22

Units .......................................................................................... 23

Clock .......................................................................................... 24

Stopwatch .................................................................................. 25

Wheel size and setting a second wheel ..................................... 26

Speed.......................................................................................... 30

Odometer ................................................................................... 31

Cadence...................................................................................... 32

Altitude ...................................................................................... 33

Grade ......................................................................................... 35

Heart rate .................................................................................. 36

Heart rate zone.......................................................................... 37

Limited Warranty........................................................................... 38

06 Incite ACH 07_13.indd 2 7/14/06 7:25:52 AM





While riding your bicycle, do not stare

at the computer for long periods of time

(Figure 1). If you do not watch the road,

you could hit an obstacle, which may

cause you to lose control and fall.

Make sure the computer wire cannot

contact the tire or wheel spokes (Figure

2). The wire could be damaged causing

the computer to malfunction. Also, the

wire could get caught, causing you to lose

control and fall. 









06 Incite ACH 07_13.indd 1 7/14/06 7:25:52 AM





 

 















 











 















06 Incite ACH 07_13.indd 2 7/14/06 7:25:53 AM



 











 













 









 











06 Incite ACH 07_13.indd 3 7/14/06 7:25:54 AM



 













 





















 















06 Incite ACH 07_13.indd 4 7/14/06 7:25:55 AM







Stem mount

Handlebar

mount Speed sensor Cadence sensor



Tools needed:

• Electrical tape

• Slot-type screwdriver

• Phillips-type screwdriver

• Scissors

06 Incite ACH 07_13.indd 5 7/14/06 7:25:56 AM











The Trek Incite ACH computer can be

mounted on the handlebar or on the stem

(Figure 3).



1. Select the bar clamp that fits your bike.

31.8mm bars: large clamp

25.4mm and 26.0mm: small clamp

22.2mm bar: small clamp with rubber shim

2. Insert the handlebar clamp into the back of

the computer base (Figure 4) and slide it

towards the front of the base.

3. Insert the rubber friction pad into the computer base, aligned

across the computer base.

4. With the wire pointing toward the front of the bike, wrap the bar

clamp around the handlebar.

5. Insert the screw through the washer and into the computer base.

6. Tighten the screw until the computer base cannot rotate on the

handlebar.

7. Slide the computer into the computer base until the front of the

computer and computer base line up.

06 Incite ACH 07_13.indd 6 7/14/06 7:25:57 AM



Check that the computer base cannot be

rotated around the handlebar, and that the

computer cannot slide backwards on the

computer base (Figure 5).



1. Insert the rubber friction pad into

the computer base, aligned along the

computer base.

2. Insert two nylon ties through the

computer base (Figure 6).

3. Place the base on the stem and tighten

the nylon tie.

4. Slide the computer into the computer

base until the front of the computer and

computer base line up.

5. Check that the computer base cannot

be rotated around the stem and the

computer cannot slide backwards on the

computer base.

6. Tighten the nylon ties and trim the

excess length.











06 Incite ACH 07_13.indd 7 7/14/06 7:25:57 AM





The wheel magnet must be aligned so that

it passes across the sensor. As the magnet

passes the sensor, it must be no further from

the sensor than 1 to 3mm (1/32 to 1/8 inch).

The wheel magnet has a ‘T’ shaped slot with

two configurations: round spokes and flat or

bladed spokes (Figure 7).

The cadence sensor, with the wire, mounts

near the crankset. It must be aligned so that

the magnet passes within 1-3mm, and in line

with the small line on the sensor (Figure 8).











 

1. Remove the screw from the magnet.

2. Slide the slot in the back of the magnet

over the spoke.

For a flat or bladed spoke, start the spoke near

the end where the spoke is round, and align the

top of the ‘T’ with the spoke as you slide the

magnet up the blade (Figure 7).

3. Thread the screw into the magnet until it

is snug against the spoke.

06 Incite ACH 07_13.indd 8 7/14/06 7:25:58 AM
