TRENDnet TBW-103UB Bedienungsanleitung

The 54Mbps 802.11g Wireless USB 2.0 & Bluetooth Combo Adapter

simultaneously provides Bluetooth and Wi-Fi connections, allowing

you to concurrently link to Wi-Fi Internet hotspots and Bluetooth

devices. Experience the power of downloading ring tones, iTunes,

or digital pictures from a wireless Internet connection and transfer

the same files seamlessly into your Bluetooth enabled phone. The

external antenna can be adjusted easily to improve signal strength

gain and transmission.

TBW-103UB

802.11g Wireless & Bluetooth Combo

USB Adapter

TBW-103UB

rev:12.06.2005

Wireless

• Wi-Fi Compliant with IEEE 802.11g and IEEE 802.11b Standards

• Supports Ad-Hoc (Peer-to-Peer) Mode or Infrastructure (AP-Client) Mode

• Dynamic Data Rate Scaling at 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11g

• Dynamic Data Rate Scaling at 11, 5.5, 2 and 1Mbps for 802.11b

• Supports 64/128/256-bit WEP and WPA Encryptions

• Range of 100 meters indoor, 400 meters outdoor (depends on the environment)

Bluetooth

• Compliant with Bluetooth v1.2 and Class 2 Operation

• Fully Bluetooth v1.2 BQB Qualified

• Compatible with Microsoft HID Devices

• Support up to 7 active and 8 parked slaves

• Bluetooth Range of up to 10 meters

General

• Uses 2.4 GHz Frequency Band, which Complies with Worldwide Requirements

• Compatible with Windows 2000/XP (SP1/SP2)

• Simple User Setup & Diagnostics Utilities

• 3-Year Warranty

FEATURESFEATURES

Dimensions (LxWxH)

Transmit Power

Weight

Temperature

Humidity

Safety Emissions

Module Technique

Receiving Sensitivity

Encryption

Frequency

Data Rate

Range

Encryption

Channels

Module Technique

• USB 2.0, 1.1 Compliant, Bluetooth 1.2 Class 2

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

• 100 x 30 x 15 mm (3.9 x 1.2 x 0.6 inches)

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 802.11b: 16dBm ± 2dBm; 802.11g: 13dBm ± 2dBm

• 1~11 (US), 1~13 (EU)

• Gaussian Frequency Shift Keying (GFSK)

• 32g (1 oz.)

• Operating: 0° ~ 60° C (32° ~ 140° F) • Storage: -20° ~ 70° C (-4° ~ 158° F)

• 5% ~ 95%max (Non-condensing)

• FCC, CE

• 802.11b: < -70dBm @PER < 10%, All Rate • 802.11g: < -70dBm @PER < 8%, All Rate

• 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) • 802.11g: OFDM

• 2.412 ~ 2.484 GHz

• 64/128/256-bit WEP, AES-CCM, and TKIP

• 2.400 ~ 2.483.5 GHz

• Up to 723Kbps

• Up to 10 meters

• 128-bit Encryption

Frequency

Data Rate (auto fallback)

Wireless

Bluetooth

Interface

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

802.11g Wireless & Bluetooth Combo USB Adapter

TBW-103UB

RELATED PRODUCTSRELATED PRODUCTS

PACKAGE CONTENTSPACKAGE CONTENTS

• Multi-Language Quick Installation Guide

• TBW-103UB

• Utility & Driver CD-ROM

ORDERING INFORMATIONORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-888-777-1550

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONSNETWORKING SOLUTIONS

SPECIFICATIONSSPECIFICATIONS

802.11g Wireless & Bluetooth

Combo USB 2.0 Adapter

(TBW-103UB)

54Mbps 802.11g

Wireless Firewall Router

(TEW-432BRP)

Bluetooth Headset

High-Power Bluetooth

USB Adapter

(TEW-102UB)

USB Printer

54Mbps 802.11g Wireless

USB 2.0 Print Server

(TEW-P1UG)

Internet

wirelessbluetooth

TEW-423PI

TEW-430APB

TEW-421PC 54Mbps 802.11g Wireless PC Card

54Mbps 802.11g Wireless PCI Adapter

54Mbps 802.11g Wireless Access Point
