TRENDnet TEW-624UB Bedienungsanleitung
TEW-624UB
H/W:B1.1R
Quick Installation Guide
Table of Contents
Table of Contents
Version 02.29.2008
English ..................................................................................................... 1
1
2
3
5
1. Before You Start
2. How to Install ....................................................................................
3. Wireless Configuration ......................................................................
................................................................................
Troubleshooting ........................................................................................
System Requirements
Application
Package Contents
1. Before You Start
English
1
?TEW-624UB
?Quick Installation Guide
?Utility & Driver CD-ROM
?USB Extension Cable
?
?CD-ROM Drive
?CPU: 300MHz or above (XP/2000)/ 800MHz or above (Windows Vista)
?Memory: 256MB RAM or above (XP/2000)/ 512MB RAM or above
(Windows Vista)
?Windows Vista/XP/2000
USB port: 1.1 or 2.0
HD
DATA
300Mbps Wireless N
USB Adapter
(TEW-624UB)
300Mbps, share multimedia throughout the house
2. How to Install
English
2
1. Insert the Utility & Driver CD-
ROM into your computer's CD-
ROM Drive . Click Install Utility
and then click on your operating
system.
2. Follow the InstallShield Wizard
instructions.
Important! DO NOT install the USB adapter in the computer until instructed to
do so.
3. Click Finish.
4. Connect the wireless adapter to an
available USB port on your
computer.
Your installation is now complete.
5. Drivers will install automatically.
English
3
1. On the bottom right-hand corner of
the screen, double-click on the
wireless client utility icon.
3. Wireless Configuration
2. Click Site Survey.Click the SSID
that matches your wireless access
point and then click Connect.
Windows XP/2000
Windows Vista
3. If Encryption is enabled on your
access point, select the
Authentication and Encryption
enter the encryption key and then
click Apply.
1. On the bottom right-hand corner of
the screen, double-click on the
wireless client utility icon.
English
4
Wireless configuration is now complete.
For detailed information regarding the TEW-624UB configuration and advanced
settings, please refer to the User's Guide included on the Utility & Driver CD-
ROM or TRENDnet's website at www.trendnet.com
2. Click Site Survey, select the SSID
and then click Connect.
3. If Encryption is enabled on your
access point, select the
Authentication and Encryption
enter the encryption key and then
click Apply.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
5
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
I inserted the Utility & Driver CD-ROM into my computer's CD-ROM Drive but
the installation menu does not appear automatically. What should I do?
If the window does not appear automatically, click Start, click Run, and type
D:\autorun.exe where "D" in "D:\autorun.exe" is the letter assigned to your
CD-ROM Drive, and then press the ENTER key on your keyboard.
I completed all the steps in the quick installation guide, but my Wireless USB
Adapter is not connecting to my access point. What should I do?
First, verify that the Network Name (SSID) matches your wireless router or
access point’s Network Name (SSID). Second, please check with your network
administrator for security key in order to access a secured wireless access point or
router. Please refer to the User’s Guide for more information regarding wireless
network security. Third, check your TCP/IPproperties to ensure that Obtain an IP
address automatically is selected. Fourth, double-click the Wireless Client Utility
icon, click Site Survey and then click Refresh to check and see if there are any
available wireless networks listed.
Windows is unable to recognize my hardware. What should I do?
Make sure your computer meets the minimum requirements as specified in
Section 1 of this quick installation guide. Also, you must complete the installation
of the wireless configuration utility (as described in Section 2) before connecting
the Wireless USBAdapter to your computer. Lastly, you may consider moving the
Wireless USBAdapter to a different USB port of your computer.
I cannot open the wireless configuration utility. What should I do?
Access your device manager to make sure the adapter is installed properly. If
you see a networking device with a yellow question mark or exclamation point, you
will need to reinstall the device and/or the drivers. To access your device manager,
right-click My Computer, click Properties, under the Hardware tab click Device
Manager.
If you still encounter problems or have any questions regarding the TEW-624UB, please
refer to the User's Guide included on the Utility & Driver CD-ROM or contact Trendnet's
Technical Support Department.
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause undesired
operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FORANY RADIO ORTV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TOTHIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’SAUTHORITYTO OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recyclewherefacilitiesexist. CheckwithyouLocal
AuthorityorRetailerforrecyclingadvice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
Copyright ©2008. All Rights Reserved. TRENDnet.
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com/register
20675 Manhattan Place
Torrance, CA 90501
USA
