TRENDnet TU-S9 Bedienungsanleitung
TU-S9
Quick Installation Guide
Table of Contents
Table of Contents
Version 05.16.2007
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
2
5
1. Before You Start
2. .....................................................................................
................................................................................
How to Install
System Requirements
Application
Package Contents
1. Before You Start
English
1
?TU-S9
?Quick Installation Guide
?Driver CD-ROM
Serial Modem
USB Serial
Notebook
USB to Serial
Converter
(TU-S9)
?CD-ROM Drive
?Computer with An Available USB 1.1 or 2.0 Port
?CPU: 300MHz or above (Windows 2003 Server/XP/2000/ME/98SE) /
800MHz or above (Windows Vista)/ Power PC G3, G4, G5 (Mac OS X
10.1~10.4)
?Memory: 256MB RAM or above (Windows 2003 Server/XP/2000/ME/
98SE, Mac OS X 10.1~10.4) / 512MB RAM or above (Windows Vista)
?Windows Vista/2003 Server/XP/2000/ME/98SE, Mac OS X 10.1~10.4
?RS-232 device (e.g. modem)
?RS-232 Male to Female Serial Cable (Optional)
2. How to Install
English
2
1. Turn on your computer and wait
until the Windows desktop
appears.
2. Insert the Driver CD-ROM into
your CD-ROM drive.
Note: E:\represents the drive letter that is assigned to your CD-ROM drive.
4. Click Next.
5. Click Finish.
Note: Do not connect the TU-S9 until instructed to do so.
3. Go to Start > Run, type in
E:\Driver\Win98_2003\Setup.exe
and then click OK.
Windows 2003 Server/XP/2000/ME/98SE
English
3
Windows Vista
6. Connect the Adapter to an
available USB port of your
computer.
7. Connect the Serial device to the
TU-S9.
1. Turn on your computer and wait
until the Windows desktop
appears.
2. Connect the Adapter to an
available USB port on your
computer.
3. Click Locate and install driver
software (recommended).
4. Insert the Driver CD-ROM into
your CD-ROM drive and click Next.
5. Click Close.
For detailed information regarding the TU-S9, please refer to the User's Guide
included on the Driver CD-ROM or TRENDnet's website at www.trendnet.com
Your installation is now complete.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.TRENDnet.com/register
Thank you for choosing TRENDnet
English
4
6. Connect Serial device to the
TU-S9.
5
Q1:
A1:
Q2:
A2:
Q3:
A3:
Windows is unable to recognize my hardware. What should I do?
First, make sure your computer meets the minimum requirements as
specified in Section 1 of this Quick Installation Guide. Second, try
plugging the TU-S9 into a different USB port on your computer.
Can I use the TU-S9 with my serial keyboard, mouse, or joystick?
The TU-S9 does not support interrupt transfer mode devices. If your
serial keyboard, mouse, or joystick is an HID Device, it is not supported.
Can I connect or disconnect the USB cables while the computer is
on?
Yes, you can connect or disconnect the USB cable while the computer
is on, because the USB interface is Plug-and-Play and hot-pluggable.
If you still encounter problems or have any questions regarding the TU-S9 USB
to Serial Converter, please contact TRENDnet’s Technical Support Department.
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de alimentacón
necesario para su funcionamiento. El uso de un adaptador distinto al mencionado puede producir
daños fisicos y/o daños al equipo conectado. El adaptador de alimentación debe operar con voltaje y
frecuencia de la energia electrica domiciliaria existente en el pais o zona de instalación.
TRENDnet Technical Support
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
US Canada
24/7 Tech Support
Toll Free Telephone: 1(866) 845-3673
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: +00800 60 76 76 67
.
. . . .
Copyright ©2007. All Rights Reserved. TRENDnet.
20675 Manhattan Place
Torrance, CA 90501
USA
