TRENDnet TE100S8P - Fast Ethernet Switch Bedienungsanleitung

TE100-S5P

TE100-S8P

5/8-port 10/100Mbps

Auto-MDI

Fast Ethernet Switch

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with this user’s guide,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be

required to correct the interference at his own expense.

CE Mark Warning

This is a Class B product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

VCCI Mark Warning

TABLE OF CONTENTS

ABOUT THIS GUIDE..................................................................3

PURPOSE...........................................................................................3

TERMS/USAGE.................................................................................3

OVERVIEW OFTHIS USER’S GUIDE..............................................3

INTRODUCTION..........................................................................4

FAST ETHERNET TECHNOLOGY....................................................4

SWITCHING TECHNOLOGY.............................................................5

FEATURES.........................................................................................6

UNPACKING AND SETUP........................................................8

UNPACKING.....................................................................................8

SETUP................................................................................................8

IDENTIFYING EXTERNAL COMPONENTS.....................9

FRONT PANEL..................................................................................9

REAR PANEL..................................................................................10

LED INDICATORS.........................................................................11

CONNECTING THE SWITCH...............................................13

PC TO SWITCH...............................................................................13

HUB TO SWITCH............................................................................13

SWITCH TO SWITCH (OTHER DEVICES).......................................13

PORT SPEED & DUPLEXMODE...................................................14

RJ-45 PIN SPECIFICATION...................................................15

TECHNICAL SPECIFICATIONS..........................................16

ABOUT THIS GUIDE

Congratulations on your purchase of the 5/8-port 10/100M Fast

Ethernet Switch. This device integrates 100Mbps Fast Ethernet and

10Mbps Ethernet network capabilities in a highly flexible desktop

package.

Purpose

This manual discusses how to install the 5/8-port 10/100M Fast

Ethernet Switch.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to the

5/8-port 10/100M auto-negotiation Fast Ethernet Switch, and ”switch”

(first letter lower case) refers to other Ethernet switches.

Overview of this User’s Guide

Introduction: Describes the Switch and its features.

Unpacking and Setup: Helps you get started with the basic

installation of the Switch.

Identifying External Components: Describes the front panel,

rear panel and LED indicators of the Switch.

Connecting the Switch: Explains how to connect the Switch to

your Ethernet network.

Technical Specifications: Lists the technical (general, physical

and environmental, and performance) specifications of the

Switch.

RJ-45 Pin Specification: Describes the RJ-45

receptacle/connector.

INTRODUCTION

This chapter describes the features of the Switch and some

background information about Ethernet/Fast Ethernet

switching technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing

complexity of desktop computing applications are fueling the

need for high performance networks. A number of high-speed

LAN technologies have been proposed to provide greater

bandwidth and improve client/server response times. Among

them, 100BASE-T (Fast Ethernet) provides a non-disruptive,

smooth evolution from the current 10BASE-T technology. The

non-disruptive and smooth evolution nature, and the

dominating potential market base, virtually guarantee cost

effective and high performance Fast Ethernet solutions in the

years to come.

100Mbps Fast Ethernet is a standard specified by the IEEE

802.3 LAN committee. It is an extension of the 10Mbps

Ethernet standard with the ability to transmit and receive data

at 100Mbps, while maintaining the CSMA/CD Ethernet

protocol. Some of the 100Mbps Fast Ethernet products

(10/100Mbps dual-speed) are compatible with 10Mbps

Ethernet environments; they provide a straightforward upgrade

and take advantage of the existing investment in hardware,

software, and personnel training.

Switching Technology

Another approach to pushing beyond the limits of Ethernet

technology is the development of switching technology. A

switch bridges Ethernet packets at the MAC address level of

the Ethernet protocol transmitting among connected Ethernet

or Fast Ethernet LAN segments.

Switching is a cost-effective way of increasing the total

network capacity available to users on a local area network. A

switch increases capacity and decreases network loading by

dividing a local area network into different segments, which

don’t compete with each other for network transmission

capacity.

The switch acts as a high-speed selective bridge between the

individual segments. The switch, without interfering with any

other segments, automatically forwards traffic that needs to go

from one segment to another. By doing this the total network

capacity is multiplied, while still maintaining the same network

cabling and adapter cards.

For Fast Ethernet networks, a switch is an effective way of

eliminating problems of chaining hubs beyond the “two-

repeater limit.” A switch can be used to split parts of the

network into different collision domains, making it possible to

expand your Fast Ethernet network beyond the 205-meter

network diameter limit for 100BASE-TX networks. Switches

supporting both traditional 10Mbps Ethernet and 100Mbps Fast

Ethernet are also ideal for bridging between the existing

10Mbps networks and the new 100Mbps networks.

Switching LAN technology is a marked improvement over the

previous generation of network bridges, which were

characterized by higher latencies. Routers have also been used

to segment local area networks, but the cost of a router, the

setup and maintenance required make routers relatively

impractical. Today, switches are an ideal solution to most

kinds of local area network congestion problems.

Features

The Switch was designed for easy installation and high performance

in an environment where traffic on the network and the number of

user increase continuously.

The Switch with its small, compact size was specifically designed for

small to mid size workgroups. This Switch can be installed where

space is limited; moreover, they provide immediate access to a rapidly

growing network through a wide range of user-reliable functions.

The Switch is ideal for deployment with multiple high-speed servers

for shared bandwidth 10Mbps or 100Mbps workgroups. With the

highest bandwidth 200Mbps (100Mbps full-duplex mode), any port

can provide workstations with a congestion-free data pipe for

simultaneous access to the server.

The Switch is expandable by cascading two or more switches

together. As all ports support 200Mbps, the Switch can be cascaded

from any port and to any number of switches.

The Switch is a perfect choice for site planning to upgrade to Fast

Ethernet in the future. Ethernet workgroups can connect to the Switch

now, and change adapters and hubs anytime later without needing to

change the Switches or reconfigure the network.

The Switch combine dynamic memory allocation with store-and-

forward switching to ensure that the buffer is effectively allocated for

each port, while controlling the data flow between the transmit and

receive nodes to guarantee against all possible packet loss.

The Switch is an unmanaged 10/100 Fast Ethernet Switch that offers

solutions in increasing small Ethernet/Fast Ethernet workgroup

bandwidth. Other key features are:

?? Store and forward switching scheme capability. As the result

of complete frame checking and error frame filtering, this

scheme prevents error packages from transmitting among

segments.

?? Auto-MDI function supports automatic MDI/MDIX crossover

detection function gives true ‘plug and play’ capability without

the need of confusing crossover cables or crossover ports.

?? Auto-negotiation for any port. This allows for auto-sensing of

speed (10/100Mbps) thereby providing you with automatic and

flexible solutions in your network connections.

?? Flow control for any port. This minimizes dropped packets by

sending out collision signals when the port’s receiving buffer is

full. Note that flow control is only available in half duplex

mode.

?? Data filtering rate eliminates all error packets, runts, etc., per

port at wire-speed for 100Mbps speed.

?? Data filtering rate eliminates all error packets, runts, etc., per

port at wire-speed for 10Mbps speed.

UNPACKING AND SETUP

This chapter provides unpacking and setup information for the

Switch.

Unpacking

Open the box of the Switch and carefully unpack it. The box

should contain the following items:

One 5 or 8-port 10/100M Fast Ethernet Switch

One External AC Power Adapter

This User’s Guide

If any item is found missing or damaged, please contact your

local reseller for replacement.

Setup

The setup of the Switch can be performed using the following

steps:

?? The surface must support at least 1.5 Kg for the Switch.

?? The power outlet should be within 1.82 meters (6 feet) of

the Switch.

?? Visually inspect the DC power jack and make sure that it

is securely connected to the power adapter.

?? Make sure that there is proper heat dissipation from and

adequate ventilation around the Switch. Do not place

heavy objects on the Switch.

Andere Handbücher für TE100S8P - Fast Ethernet Switch

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere TRENDnet Netzwerk-Router Handbücher

TRENDnet

TRENDnet TEW-721BRM Bedienungsanleitung

TRENDnet

TRENDnet TEW-WLC100P Bedienungsanleitung

TRENDnet

TRENDnet TEW-752DRU Bedienungsanleitung

TRENDnet

TRENDnet DSLR-2000G Bedienungsanleitung

TRENDnet

TRENDnet TEW-733GR Bedienungsanleitung

TRENDnet

TRENDnet TEW-671BR Bedienungsanleitung

TRENDnet

TRENDnet TEW-751DR Bedienungsanleitung

TRENDnet

TRENDnet TEW-638APB Bedienungsanleitung

TRENDnet

TRENDnet TEG-S160TX - Gigabit Switch With 31 Gbps Switching... Bedienungsanleitung

TRENDnet

TRENDnet TW100-BRF114U Bedienungsanleitung

TRENDnet

TRENDnet TW100-BRV204 SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TW100-BRV204 SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TW100-BRV304 SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TEG-S80g - Switch Bedienungsanleitung

TRENDnet

TRENDnet TEW-231BRP Bedienungsanleitung

TRENDnet

TRENDnet TEW-637AP - 300Mbps Wireless Easy-N-Upgrader Bedienungsanleitung

TRENDnet

TRENDnet TEW-637AP - 300Mbps Wireless Easy-N-Upgrader Bedienungsanleitung

TRENDnet

TRENDnet TWG-BRF114 Bedienungsanleitung

TRENDnet

TRENDnet WRT-390L Bedienungsanleitung

TRENDnet

TRENDnet TDM-C500 Bedienungsanleitung

TRENDnet

TRENDnet TW-H6W1IR Bedienungsanleitung

TRENDnet

TRENDnet TW100-BRV324 Bedienungsanleitung

TRENDnet

TRENDnet TEW-691GR Bedienungsanleitung

TRENDnet

TRENDnet TEW-816DRM Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
