TRENDnet TW100-W2plus Bedienungsanleitung

TRENDnet's TW100-W2plus Internet Station allows a group

of users to share Internet connections using common external

modems/ISDN terminal adapters. This device eliminates the

need for a separate modem, phone line, and Internet account

for each individual user. Equipped with two COM ports, users

can connect two external modems/ISDN terminal adapters at

the same time to double the Internet bandwidth. Easy local

network connection is achieved through a 10/100Mbps NWay

port that supports both Ethernet and Fast Ethernet networks.

With TRENDnet's TW100-W2plus Internet Station, significant

savings on router costs, phone line charges, and on-line

charges will be made!!

TW100-W2plus

10/100Mbps Fast Ethernet Internet Station

BENEFITSFEATURES

Easy Integration:

Cost-Effectiveness:

Flexibility:

Security:

Performance:

Designed to easily integrate into

10/100Mbps Ethernet network

Saves router costs, on-line charges -

less cost than a class C IP address

Can be used in either LAN or WAN

Built-in firewall and secure gateway

for LAN users

Asynchronous WAN ports support up

to 460Kbps data transfer

Two RS-232 460Kbps baud rate COM ports

56Kbps modems/128Kbps BRI ISDN TA support

Bandwidth doubling through simultaneous use of two COM

ports

One auto-sensing 10/100Mbps LAN port

One or two ISP account sharing for Internet users

Modem/ISDN TA sharing

PPP, PAP/CHAP, NAT, TCP/IP, DHCP support

Dial-on-demand, idle-time auto-disconnection

Firewall protection and PPP security

Virtual server lets Internet users access designated local

sites

Administer through Telnet, Web browser, and Windows-

based program

Flash memory for firmware upgrade

5 Year warranty

TW100-W2plus (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TW100-W2plus:

2-port 10/100Mbps Fast Ethernet

Internet Station

NETWORKING SOLUTIONS

SPECIFICATIONS

LAN Standard:

• IEEE 802.3 10Base-T Ethernet, IEEE

802.3µ 100Base-TX Fast Ethernet, and

ANSI/IEEE 802.3 N-way auto-negotiation

LAN Ports:

• 1 x 10/100Mbps Ethernet/Fast Ethernet

NWay port

Network Cables:

• CAT 3, 4, 5 UTP/STP for 10Base-T

(max. 100M)

• CAT5 UTP/STP 100Base-TX (max. 100M)

Protocol:

• CSMA/CD

LEDs:

• Pw/Tx (Power/Transmit), Link/Rx

(Link/Reception), COM1, COM2

WAN Ports:

• 2 x male DB-9 RS-232 COM ports

COM Port Baud Rates:

• Up to 460Kbps, analog modem supports

up to 56Kbps, ISDN TA supports BRI

128Kbps

Internet Protocol:

• PPP, PAP/CHAP, NAT, TCP/IP, DHCP,

ARP, ICMP, FTP, Telnet, HTTP

Power Supply:

• External AC power adapter, 5VDC / 2.4A

Power Consumption:

• 12 Watts max.

Dimensions:

• 223.3 x 131.7 x 35 mm

(8.79 x 5.19 x 1.38 inches)

Weight:

• 430 g. (15.2 Oz.)

Temperature:

• Operating: 0° to 50° C (32° to 122°F)

• Storage: -25° to 55° C (-13° to 131°F)

Humidity:

• Operating: 10 % to 90 %

• Storage: 5 % to 95 % (non-condensing)

Certifications:

• FCC, CE, VCCI

TW100-W2plus

10/100Mbps Fast Ethernet Internet Station

TW100-W2plus

10/100Mbps Fast Ethernet Internet Station

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
