TRENDnet TV-IP212W - Wireless Internet Camera Server Bedienungsanleitung

• Compatible with wireless g and b devices.

• Advanced encryption modes include WEP, WPA-PSK and WPA2-PSK

• Built-in USB port allows you to store still image directly onto a USB flash or hard drive*

• Supports TCP/IP networking, SMTP Email, HTTP, Samba and other Internet protocols

• High quality MPEG-4 and MJPEG video recording with up to 30 frames per second

• Supports 3GPP live video viewing via 3G mobile phone **

• Hear and talk to people in your camera’s viewing area through your computer

• Record streaming video to your computer and Network Storage

• Supports still image snapshot to FTP, Email and Flash drive

• Motion detection with Email notification

• Supports two adjustable motion detection windows with just-in-time snapshot

• Supports time stamp overlay

• Quick Universal Plug and Play installation

• Free SecurView™ software: view and record up to 16 cameras simultaneously ***

• 3-Year Warranty

* USB port supports up to 500mA power device with FAT16/32 format

** The 3G service from a mobile phone provider is required

*** Monitoring multiple cameras may require a high performance CPU

FEATURES

The Wireless 2-Way Audio Internet Camera transmits real-time high

quality video and audio over the Internet. See, hear and talk to

people, in your camera’s from any Internet connection.

Complimentary SecurView camera management software allows

you to monitor what you value most at home or at work.

The camera provides crystal clear MPEG4 video streams over a

secure encrypted internet connection. A built-in microphone and

optional speakers accommodate 2-way audio communication.

Advanced intuitive software includes motion detection recording,

email alerts, scheduled recordings and progressive search options.

This cameras brilliant image quality, USB flash support and 2-way

audio make it ideal for home, small office and business use.

TV-IP212W (A1.0R)

Wireless 2-Way Audio Internet Camera Server

TV-IP212W

rev:09.06.2007

SPECIFICATIONS

Resolution

Compression Ration Setting

Lens

Microphone Input

Audio Output

Format

Resolution

Flip Images

LAN

Image Setting

Protocol

• ¼” Color CMOS Sensor

• 5 Levels

• 640 x 480 pixel

• 640 x 480, 320 x 240, 160 x 120

• Vertical / Horizontal

• HTTP, FTP, TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, PPPoE, UPnP, RTP, RTSP, RTCP

• f: 4.6mm, F: 2.8 (Board Lens)

• Internal Omni-Directional • Sensitivity: -48dB + 3dB • Response Frequency: 50 ~ 16000Hz

• 3.5mm Speaker Output Jack

• Adjustable brightness, contrast,saturation & sharpness

• PCM/AMR (Mono)

• 30fps @VGA, QVGA, QQVGA

• 10/100Mbps Auto MDIX

Image Frame Rate

Frame Rate Setting

Audio

Video/Image

Communication

Sensor

Image Sensor

• 1 ~ 30fps

RAM

CPU

Memory Size

Resolution

• ARM9 base

• 32Mbyte SDRM

• Linux

• Pentium III 350MHz or above

• 128MB or above

• 800 x 600 or above

System Requirement (Web Configuration)

CPU

System

Wireless 2-Way Audio Internet Camera Server

TV-IP212W (A1.0R)

TV-IP212W

rev:09.06.2007

Minimum Illumination • 0.5Lux @ F2.0

Viewing Angle • 60 Degree

Light Frequency • 50Hz, 60Hz or Outdoor

Exposure Control, White Balance,

Gain Control • Automatic

Video Format • MPEG4(Simple Profile), MJPEG, 3GPP

ROM • 8Mbyte Nor Flash

Browser • Internet Explorer 6.0 or above

Supported OS • Windows 2000/XP/Vista

CPU

Memory Size

Resolution

• Pentium 4 1GHz or above

• 512MB or above

• 1024 X 768 or above

System Requirement (SecurView™ Software)

Supported OS • Windows 2000/XP/Vista

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Wireless 2-Way Audio Internet Camera Server

TV-IP212W (A1.0R)

To Order Please Call:

1-888-326-6061

ORDERING INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

• Multi-Language Quick Installation Guide

• Power Adapter (5V DC 2.5A)

• TV-IP212W

• Utility CD-ROM

• Camera stand

TV-IP212

TV-IP312

TV-IP312W 2- Way Audio Wireless Day/Night Internet Camera Server

2- Way Audio Internet Camera Server

2- Way Audio Day/Night Internet Camera Server

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

Dimension

Weight

LED

Power Consumption

LEDs

USB Port

Power

Temperature

• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

• 70 x 100 x 57mm (2.67 x 3.94 x 2.95 in.)

• Camera: 170g (6 oz.); Stand: 135g (4.76oz.)

• Enable/Disable Support

• USB 1.1 (Type 1)

• 8 Watts (Max)

• Operating: 0ºC ~ 45ºC (32ºF ~ 113ºF); Storage : -10ºC ~ 60ºC (14ºF ~ 140ºF)

• 5V DC, 2.5A External Adapter

• Power (Orange), Link (Green)

Physical/Environmental

SPECIFICATIONS

NETWORKING SOLUTIONS

• 1.8m Cat. 5 Fast Ethernet Cable

Other

• Up to 500mA Power Device with FAT16/32 Format

Wireless 2-Way Audio

Internet Camera Server

(TV-IP212W)

Wireless Firewall Router

(TEW-432APB)

54Mbps

Modem

Internet

Notebook with

Wireless PC Card

(TEW-421PC)

Mobile Phone with

3G Support & Service

Standard

Security

Antenna

• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

• IEEE 802.11b/g

• 64/128-bit WEP, WPA-PSK, WPA2-PSK

• 2dBi Detachable Reverse SMA Connector

Wireless
