TRENDnet TV-IP400 Bedienungsanleitung
Q: How can I configure my TV-IP400 (w) through the web-based configuration?
A:
Q: What is the default IP address of my TV-IP400 (w)?
A:
Q: How can I view the TV-IP400 (w) remotely if it’s behind a router or firewall?
A:
Open your web browser and type the IP address of the TV-IP400 (w) in the address bar. The
default IP address is 192.168.0.20.
The default IP address is 192.168.0.20
Each camera behind a firewall or router will need to forward the port that the camera is using. The
default port is 80.
If you are installing multiple cameras you must change the port on the additional cameras.
Step 1. Open your web browser and type the IP address of the TV-IP400 (w) in the address bar.
The default IP address is 192.168.0.20.
Step 2. Click Configuration at the top of the page then click Network on the left hand side.
TV-IP400/TV-IP400W F.A.Q.
Step 3. Enable the Second HTTP Port and enter in the desired port for the camera in the Port
Number field.
Note: If you are still unable to access the camera remotely please check the following.
a) Please make sure the proper gateway address is entered. This will be your router's LAN IP
Address.
b) Please make sure the proper DNS servers are entered. You can find this information on your
router's status page. If that information is not available on your router's status page please
contact your ISP for your DNS server addresses and enter them.
Router's LAN IP address
TV-IP400/TV-IP400W F.A.Q.
Q: How do I configure the camera to record motion?
A:Motion Configuration-1
Step 1. Start the IPView Pro Program by going to Start>Programs>IPView Pro>IPView Pro.
Step 2. Click on “System Configuration”.
SYSTEM CONFIGURATION
Step 3. Motion Configuration-1
This setting provides the commands for motion detection control. Before configuring,
you should select one camera from the pull-down menu.
Step 4. Detect Region field:
• Full picture – When you select this option, the camera will monitor the whole area.
• Custom region – Click Add Region and then use your mouse to draw an area in the
view screen. When motion is detected within the area, the camera starts recording
automatically. You can set multiple areas in the view screen. Click Delete Region to r
remove the area selected. Click Clear All Regions to remove all areas in the view
screen.
Step 5. Sensitivity Level: Move the slide bar to adjust the sensitivity level for detecting motion to
record video.
Note: The Sensitivity rating determines the amount of motion in the created window(s) to activate
motion. Setting it too high or too low may produce unexpected results. .
TV-IP400/TV-IP400W F.A.Q.
Step 5. Click "Save".
Motion Configuration-2
The Motion Configuration-2 setting allows you to configure the alarm and e-mail settings.
- Invoke Alarm: Select this option to enable an alarm when motion is detected by the system.
Note: Invoke Alarm requires that you have a trigger installed on the camera.
TV-IP400/TV-IP400W F.A.Q.
Q: How do I upgrade the firmware of my camera?
A:Step 1. Open your web browser and type the IP address of the TV-IP400 (w) in the address bar.
The default IP address is 192.168.0.20.
Step 2. Click on “Configuration” on the top bar, then click the Firmware Upgrade on the left
hand side of the screen.
Step 3. Click Browse and locate the firmware file then click Upgrade.
Q: Can my TV-IP400 (w) series camera use Power over Ethernet?
A:No. However, with the use of a TRENDnet TPE-102S you could power the unit via PoE.
Note: You must have a PoE injector for the TPE-102S. You could use either an existing PoE
switch or a TPE-101I.
TV-IP400/TV-IP400W F.A.Q.
Step 1. Start the IPView Pro Program by going to Start>Programs>IPView Pro>IPView Pro.
Step 2. Click on the “System Configuration” button.
Step 3. Click on “Mailing Configuration” and input your mail settings.
Q: How can I email snapshots based on motion from my camera?
A:
Step 4. Enter your mail settings and click “Save”.
Mail Server: Mail Server IP or Name.
Mail From: E-Mail Address of sender.
Mail To: E-Mail Address of receiver.
Subject: Can be any information to high light the message.
User Name: Enter the user name in this field.
Password: Enter the user password in this field to login receiver's mail server.
Interval Time: The time interval to send the next E-Mail.
SYSTEM CONFIGURATION
TV-IP400/TV-IP400W F.A.Q.
Q: How do I configure my TV-IP400 (w) series cameras to upload snapshots to an
FTP server?
A:Step 1. Open your web browser and type the IP address of the TV-IP400 (w) in the address
bar. The default IP address is 192.168.0.20.
Step 2. Click on Configuration at the top of the page then click on Upload on the left hand side.
Enter your FTP server information and click “Save”.
TV-IP400/TV-IP400W F.A.Q.
Note: For manual uploading view the image of the camera and click ON next to Upload Video.
Q: How do I view the TV-IP400 (w) image using IPView Pro?
A:Step 1. Start the IPView Pro Program by going to Start>Programs>IPView Pro>IPView Pro
Step 2. Click the “System Configuration” button to enter the System Configuration.
SYSTEM CONFIGURATION
TV-IP400/TV-IP400W F.A.Q.
If you are not sure of the camera's IP address, you can click “Search” to search the available
camera(s) within the network.
Step 3. Select the camera you want by highlighting it, and then click “Add Camera”.
Internet Explorer (5.0 or above) or Netscape Navigator (6.0 or above)
Q: Which web browsers will allow me to view the video from a TV-IP400 (w)?
A:
Q: How do I add user accounts to my TV-IP400 (w)?
A:Step 1. Open your web browser and type the IP address of the TV-IP400 (w) in the address
bar. The default IP address is 192.168.0.20.
Step 2. Click on Configuration at the top of the page then click on User on the left hand side.
Enable the Access Control and enter in the desired usernames and passwords. Click
Add to add the user.
TV-IP400/TV-IP400W F.A.Q.
Q: How do I reset my TV-IP400 (w) back to factory defaults?
A:Step 1. Locate the reset button on the back of the unit.
Step 2. Disconnect the power supply.
Step 3. Press and hold in the reset button.
Step 4. While holding in the reset button; reconnect the power supply.
Step 5. Continue to hold in the reset button for approximately 10 seconds to restore the default
settings.
RESET BUTTON
Note: You can enable pan and tilt controls as well for individual users.
TV-IP400/TV-IP400W F.A.Q.
